Michael Bahr

Siemens AG Chairman of WG 1

5G ACIA Workshop, Coventry, Jan 2020

WG1 General Scope

22 Jan 2020 5G Alliance for Connected Industries and Automation 74

Use Cases

• Industrial automation use cases from real life utilizing (5G)

communication

• Current and future use cases
• Translate from real world to using 5G network

Requirements - from ha (KPIs) o ho (neork

• peration)
• Application requirements from industrial automation use cases
• Network requirements for industrial communication
• Translate from application to network, from industrial

communication to (mobile) communication network

• Requirements on configuration and operation

Cu Current Fu Future Re Real Life Ho How Wh What

5G ACIA Workshop, Coventry, Jan 2020

Working Group 1 | Overview

22 Jan 2020 5G Alliance for Connected Industries and Automation 75

WG 1 Scope

• Use case and requirements analysis
• Streamline terminology
• Consolidation of input to 3GPP SA1
• Support for other 3GPP and 5G-ACIA working groups
• Identification of other relevant SDOs

Current & Past Work Items

• Use case collection
• Discussion and consolidation of contributions to 3GPP SA1
• Explanation of ongoing 5G requirements specification and explanation of terminology
• Gap analysis between requirements of industrial automation and agreed 3GPP 5G requirements
• Review of other work, e.g. network slicing templates, from requirements point of view
• Requirements on Commmunication Service Interface / Service API

WG 1 Chairs

Michael Bahr (Siemens) Xueli An (Huawei)

5G ACIA Workshop, Coventry, Jan 2020

Overall Requirements

22 Jan 2020 5G Alliance for Connected Industries and Automation 76

Operation Functional Requirements Performance Differentiation

KPIs

• high dependability
• high communication service availability

(99.9999%)

• periodic deterministic traffic (transfer interval

1 .. 250 ms)

• ultra-low latency (< 1..10 ms)
• typical service area (~m² km²)

Functional Requirements

• non-public operation (NPN)
• security (e.g. non-3GPP credentials)
• time synchronization (±1 µs)
• support of time-sensitive networking (TSN)
• integration of IEEE 802-based networks and 5G

mobile networks (e.g. 5G LAN services)

• communication service interface / API for operations

and management by vertical

• QoS Monitoring

Requirements / Challenges

• high flexibility and versatility
• increasing number of mobile assets
• service guarantees and 24/7 operation
• ease of use
• integration of installed network infrastructure

2019 Nov Oct Mar Apr May Jun Jul Aug Sep Oct Nov Dec 2020 Jan Feb Mar Apr May Jun Jul Aug Sep WI 029: Discussion of 3GPP SA1 contributions relevant for 5G-ACIA (Rel.17) WI 028: Cooperation with GSMA Network Slicing Taskforce on Generic Slice Template (GST) WI 005: Whitepaper on 3GPP TR 22.804, 22.821, 22.830 WI 030: Gap Analysis between prioritized requirements and 3GPP documents WI 039: Interface for 5G Network Exposure for Enterprises WI 044: From 5G ACIA Requirements to 3GPP RAN/SA mapping WI 045: 3GPP SA(1) support in 2020 related to 5G- ACIA use cases, requirements, and KPIs WI 046: Guaranteed Service Level Specification (SLS) for 5G technology enabled connected Industries WI 006: Clarification of TR 22.804 concepts and discussion of normative requirements (Rel.16) WI 016: Use Case Wiki Pilot WI 024: In-Advance (Predicted) QoS Notification for 5G (ADAPT)

5G ACIA Workshop, Coventry, Jan 2020

WG1 Work Item Timelines

22 Jan 2020 5G Alliance for Connected Industries and Automation 77

2019 Nov Oct Mar Apr May Jun Jul Aug Sep Oct Nov Dec 2020 Jan Feb Mar Apr May Jun Jul Aug Sep WI 029: Discussion of 3GPP SA1 contributions relevant for 5G-ACIA (Rel.17) WI 028: Cooperation with GSMA Network Slicing Taskforce on Generic Slice Template (GST) WI 005: Whitepaper on 3GPP TR 22.804, 22.821, 22.830 WI 030: Gap Analysis between prioritized requirements and 3GPP documents WI 039: Interface for 5G Network Exposure for Enterprises WI 044: From 5G ACIA Requirements to 3GPP RAN/SA mapping WI 045: 3GPP SA(1) support in 2020 related to 5G- ACIA use cases, requirements, and KPIs WI 046: Guaranteed Service Level Specification (SLS) for 5G technology enabled connected Industries WI 006: Clarification of TR 22.804 concepts and discussion of normative requirements (Rel.16) WI 016: Use Case Wiki Pilot WI 024: In-Advance (Predicted) QoS Notification for 5G (ADAPT)

5G ACIA Workshop, Coventry, Jan 2020

WG1 Work Item Timelines

22 Jan 2020 5G Alliance for Connected Industries and Automation 78

Industrial 5G Use Cases and Requirements Interface Requirements

for Configuration and Operation

• f Industrial 5G networks

Feedback to other Organizations This work liveson the dialogue between OT and IT 5G ACIA WG1 provides a forum for this

5G ACIA Workshop, Coventry, Jan 2020

5G-ACIA WG1 Input to 3GPP SA1

22 Jan 2020 5G Alliance for Connected Industries and Automation 79

TS 22.261

R15

Release 15 Release 16 Release 17

TS 22.261

R16

TS 22.261

R17

TR22.830

FS_BMNS

TR22.804

FS_CAV

TR22.821

FS_5G_LAN

TS 22.104

cyberCAV

TS 22.104

cyberCAV

TR22.832

FS_eCAV

TR22.827

FS_AVPROD

TS 22.261 (SMARTER): Service requirements for the 5G system TR 22.804 (FS_CAV): Study on Communication for Automation in Vertical Domains TR 22.821 (FS_5G_LAN): Feasibility Study on LAN Support in 5G TR 22.830 (FS_BMNS): Feasibility Study on Business Role Models for Netw ork Slicing TR 22.832 (FS_eCAV): Study on enhancements for cyber-physical control applications in vertical domains TS 22.104 (cyberCAV, eCAV): Service requirements for cyber-physical control applications in vertical domains

WG1 Input to 3GPP SA1

3GPP SA1 collects use cases and normative requirements for the 5G network

IT OT academic,

• ther

ICT

5G ACIA Workshop, Coventry, Jan 2020

5G-ACIA WG1 Input to 3GPP SA1

22 Jan 2020 5G Alliance for Connected Industries and Automation 80

3GPP

members

5G-ACIA is not an individual member of 3GPP no direct contributions by 5G-ACIA possible

5G Alliance for Connected Industries and Automation 80

But: several members of 5G-ACIA are 3GPP members 3GPP contributions by 5G-ACIA members Discussion on 3GPP SA1 topics in 5G-ACIA WG1 Non-3GPP-members can contribute to 3GPP contributions Pre-consensus between 3GPP members of 5G ACIA

White Paper: 5G for Automation in Industry Primary use cases, functions and service requirements First version at Hannover Messe 2019 Available at 5G-ACIA website www.5g-acia.org

5G-ACIA Workshop, Paris, Nov 2019

Helping with Terminology

22 Jan 2020 5G Alliance for Connected Industries and Automation 81

Different worlds with their own assumptions, terminology, and solutions

Definition Explanation Description

22 Jan 2020 5G Alliance for Connected Industries and Automation 82

Contact: Michael Bahr, bahr@siemens.com
