SLIDE 1
Metaphor Detection
through
Term Relevance
1
Metaphor Detection
2
Metaphor Detection through Term Relevance Marc Schulder Eduard - - PowerPoint PPT Presentation
Metaphor Detection through Term Relevance Marc Schulder Eduard - - PowerPoint PPT Presentation
Metaphor Detection through Term Relevance Marc Schulder Eduard Hovy Saarland University Carnegie Mellon University 1 Metaphor Detection And yet we stand together as we did two centuries ago. 2 Metaphor Detection And yet we
SLIDE 2
SLIDE 3
Metaphor Detection
2
“And yet we stand together as we did two centuries ago.”
SLIDE 4
Metaphor Detection
Challenges
3
Required Knowledge
SLIDE 5
Metaphor Detection
Challenges
3
Required Knowledge
Conceptual Mappings Target Domain ⨉ Mappings ⨉ Source Domains
SLIDE 6
Metaphor Detection
Challenges
3
Required Knowledge
Conceptual Mappings Target Domain ⨉ Mappings ⨉ Source Domains Selectional Preference Violation Preferences ⨉ Argument Domains
SLIDE 7
Metaphor Detection
Challenges
3
Required Knowledge
Conceptual Mappings Target Domain ⨉ Mappings ⨉ Source Domains Selectional Preference Violation Preferences ⨉ Argument Domains
Typical Restrictions
Low Coverage POS Limitations
SLIDE 8
Metaphor Detection
Challenges
3
Required Knowledge
Conceptual Mappings Target Domain ⨉ Mappings ⨉ Source Domains Selectional Preference Violation Preferences ⨉ Argument Domains
Typical Restrictions
Low Coverage POS Limitations
SLIDE 9
Metaphor Detection
Term Relevance
4
SLIDE 10
Metaphor Detection
Term Relevance
4
Simple
SLIDE 11
Metaphor Detection
Term Relevance
4
Simple Robust
SLIDE 12
Metaphor Detection
Term Relevance
4
Simple Robust POS independent
SLIDE 13
Metaphor Detection
Term Relevance
4
Simple Robust POS independent Target Domain only
SLIDE 14
Term Relevance
Hypothesis
5
If a word does not fit in the context, then it is probably not meant literally.
See also Sporleder & Li (2009)/Li & Sporleder(2010)
SLIDE 15
Term Relevance
Overview
6
Relevance Metric Domain Data
(Web Corpus)
Evaluation
(Metaphor Corpus)
Basic Classifier Multi-Feature Classifier
SLIDE 16
Term Relevance
Metric
7
Is word common in all domains? Is word typical for this domain? literal metaphor literal
yes yes no no
SLIDE 17
Term Relevance
TF-IDF
8
Term Frequency
How often does term appear in a document
Document Frequency
In how many documents does term appear
TF-IDF
Impact of term on document term frequency ⨉ inverse document frequency
SLIDE 18
Term Relevance
TF-IDF
8
Term Frequency
How often does term appear in a document
Document Frequency
In how many documents does term appear
TF-IDF
Impact of term on document term frequency ⨉ inverse document frequency
D
- m
a i n
domain domai d
- m
a i n s d
- m
a i n
SLIDE 19
Term Relevance
TF-IDF
8
Term Frequency
How often does term appear in a document
Document Frequency
In how many documents does term appear
TF-IDF
Impact of term on document term frequency ⨉ inverse document frequency
D
- m
a i n
domain domai d
- m
a i n s
Domain Relevance
d
- m
a i n
SLIDE 20
Term Relevance
Metric
9
Is word common in all domains? Is word typical for this domain? literal metaphor literal
yes yes no no
SLIDE 21
Term Relevance
Metric
10
document frequency > δ Is word typical for this domain? literal metaphor literal
yes yes no no
SLIDE 22
Term Relevance
Metric
11
document frequency > δ domain relevance > 𝜹 literal metaphor literal
yes yes no no
SLIDE 23
Overview
12
Relevance Metric Domain Data Evaluation Basic Classifier Multi-Feature Classifier
SLIDE 24
Domain Data
Web Corpus
ClueWeb-09
13
1 Billion Web Documents 500 Million English Web Documents Segment en0000 3 Million Documents 1.8 Million Documents without Spam
SLIDE 25
Domain Data
Domain Clustering
14
Lucene Database Domain Seeds Domain Data Pseudo-Domain Data
ClueWeb-09
SLIDE 26
Domain Data
Domain Clustering
14
Lucene Database Domain Seeds Domain Data Pseudo-Domain Data Legislative
pass law regulate debate parliament
ClueWeb-09
SLIDE 27
Domain Data
Domain Clustering
14
Lucene Database Domain Seeds Domain Data Pseudo-Domain Data Legislative 10,000 docs
ClueWeb-09
SLIDE 28
Domain Data
Domain Clustering
14
Lucene Database Domain Seeds Domain Data Pseudo-Domain Data Legislative 10,000 docs Economy
budget tax spend plan finances
ClueWeb-09
SLIDE 29
Domain Data
Domain Clustering
14
Lucene Database Domain Seeds Domain Data Pseudo-Domain Data Legislative 10,000 docs Economy 10,000 docs
ClueWeb-09
SLIDE 30
Domain Data
Domain Clustering
14
Lucene Database Domain Seeds Domain Data Pseudo-Domain Data Legislative 10,000 docs Economy 10,000 docs Pseudo 1 10,000 docs Pseudo 2 10,000 docs Pseudo 3 10,000 docs
ClueWeb-09
SLIDE 31
Overview
15
Relevance Metric Domain Data Evaluation Basic Classifier Multi-Feature Classifier
SLIDE 32
Evaluation
Experimental Setup
16
“And yet we stand together as we did two centuries ago.”
SLIDE 33
Evaluation
Experimental Setup
16
“And yet we stand together as we did two centuries ago.” X X X M M X X X X X X
SLIDE 34
Evaluation
Experimental Setup
16
Metrics
- F-Measure
- Precision
- Recall
- Accuracy
“And yet we stand together as we did two centuries ago.” X X X M M X X X X X X
SLIDE 35
Evaluation
Experimental Setup
16
Metrics
- F-Measure
- Precision
- Recall
- Accuracy
“And yet we stand together as we did two centuries ago.” X X X M M X X X X X X
SLIDE 36
Evaluation
Experimental Setup
16
Metrics
- F-Measure
- Precision
- Recall
- Accuracy
Baseline: “And yet we stand together as we did two centuries ago.” X X X M M X X X X X X M M M M M M M M M M M
SLIDE 37
Evaluation
Gold Corpus
17
MICS Governance Corpus 2510 Sentences
SLIDE 38
Evaluation
Gold Corpus
17
MICS Governance Corpus 2510 Sentences
23 % 60 % 17 %
0 metaphors 1 metaphor 2+ metaphors
SLIDE 39
Evaluation
Gold Corpus
17
MICS Governance Corpus 2510 Sentences “And yet we stand together as we did two centuries ago.” “Many Jewish voters will find themselves at a crossroads.” Examples
23 % 60 % 17 %
0 metaphors 1 metaphor 2+ metaphors
SLIDE 40
Overview
18
Relevance Metric Domain Data Evaluation Basic Classifier Multi-Feature Classifier
SLIDE 41
Basic Classifier
Seeds & Thresholds
19
SLIDE 42
Basic Classifier
Seeds & Thresholds
19
Economy
budget tax spend plan finances
SLIDE 43
Basic Classifier
Seeds & Thresholds
19
Economy
budget tax spend plan finances
Economy 10,000 docs
SLIDE 44
Basic Classifier
Seeds & Thresholds
19
document frequency > δ domain relevance > 𝜹
Economy
budget tax spend plan finances
Economy 10,000 docs
SLIDE 45
Basic Classifier
Seeds & Thresholds
20
document frequency > δ domain relevance > 𝜹 literal metaphor literal
yes yes no no
SLIDE 46
Basic Classifier
Seeds & Thresholds
20
document frequency > δ domain relevance > 𝜹 literal metaphor literal
yes yes no no
8 Subdomains 4-14 manual seeds 8 ⨉ 10.000 Docs each
𝜹=0.02 ; δ=0.1
Seed Set 1: Manual
SLIDE 47
Basic Classifier
Seeds & Thresholds
21
document frequency > δ literal literal
yes yes no no
8 Subdomains 4-14 manual seeds 8 ⨉ 10.000 Docs each
𝜹=0.02 ; δ=0.1
Seed Set 1: Manual
legislative relevance > 𝜹 economy relevance > 𝜹 ... literal
yes no
metaphor
SLIDE 48
Basic Classifier
Seeds & Thresholds
22
document frequency > δ domain relevance > 𝜹 literal metaphor literal
yes yes no no
8 Subdomains 4-14 manual seeds 8 ⨉ 10.000 Docs each
𝜹=0.02 ; δ=0.1
Seed Set 1: Manual
SLIDE 49
Basic Classifier
Seeds & Thresholds
22
document frequency > δ domain relevance > 𝜹 literal metaphor literal
yes yes no no
8 Subdomains 4-14 manual seeds 8 ⨉ 10.000 Docs each
𝜹=0.02 ; δ=0.1
Seed Set 1: Manual 1 Domain 50 best gold metaphors 80.000 Docs
𝜹=0.01 ; δ=0.1
Seed Set 2: Gold
SLIDE 50
Basic Classifier
Evaluation
23
0.25 0.5 0.75 1 F1 Precision Recall
.591 .245 .346 .478 .276 .350 1.000 .142 .249
All Metaphor Manual Seeds Gold Seeds
SLIDE 51
Overview
Almost Done
24
Relevance Metric Domain Data Evaluation Basic Classifier Multi-Feature Classifier
SLIDE 52
Multi-Feature Classifier
Conditional Random Fields
25
Bigram model 10-fold cross validation Setup
SLIDE 53
Multi-Feature Classifier
Conditional Random Fields
25
Bigram model 10-fold cross validation Setup Part of Speech Lexicographer Sense Features Relevance Weights (𝜹=0.02 ; δ=0.79)
SLIDE 54
Multi-Feature Classifier
Evaluation
26
0.25 0.5 0.75 1 F1 Precision Recall
.263 .640 .373 .230 .654 .340 .130 .683 .219 .108 .706 .187
CRF: Basic CRF: Relev CRF: PosLex CRF: PosLex + Relev All Metaphor Manual Seeds
SLIDE 55
Multi-Feature Classifier
Training Size
27
0.05 0.1 0.15 0.2 0.25 0.3 0.35 0.4 200 400 600 800 1000 1200 1400 1600 1800 0.05 0.1 0.15 0.2 0.25 0.3 0.35 0.4 F1 Number of Training Sentences Models CRF Basic CRF PosLex Threshold + Relevance + Relevance Baseline
SLIDE 56
Multi-Feature Classifier
Relative Gain
28
0 % 25 % 50 % 75 % 100 % 125 % 150 % 200 400 600 800 1000 1200 1400 1600 1800 0 % 25 % 50 % 75 % 100 % 125 % 150 % Relative Gain Number of Training Sentences Models CRF Basic CRF PosLex
SLIDE 57
Conclusion
29
