SLIDE 1
Overview
¨ Notes
¤ Homework 9 (deadline Apr. 9th)
n Verify your submitted file before midnight ¨ This lecture
¤ Pipeline hazards
n Control
¤ Memory system
n Cache
MEMORY SYSTEM Mahdi Nazm Bojnordi Assistant Professor School of - - PowerPoint PPT Presentation
MEMORY SYSTEM Mahdi Nazm Bojnordi Assistant Professor School of - - PowerPoint PPT Presentation
MEMORY SYSTEM Mahdi Nazm Bojnordi Assistant Professor School of Computing University of Utah CS/ECE 3810: Computer Organization Overview Notes Homework 9 (deadline Apr. 9 th ) n Verify your submitted file before midnight This lecture
SLIDE 2
SLIDE 3
Recall: Pipeline Hazards
¨ Structural hazards: multiple instructions compete for
the same resource
¨ Data hazards: a dependent instruction cannot
proceed because it needs a value that hasn’t been produced
¨ Control hazards: the next instruction cannot be
fetched because the outcome of an earlier branch is unknown
SLIDE 4
Control Hazards
¨ Sample C++ code
for (i=100; i != 0; i--) { sum = sum + i; } total = total + sum;
How many branches in this code?
SLIDE 5
Control Hazards
¨ Sample C++ code
add $2, $2, $1 J for add $3, $3, $2 addi $1, $1, -1 next: beq $0, $1, next for: addi $1, $0, 100
for (i=100; i != 0; i--) { sum = sum + i; } total = total + sum;
What are possible target instructions?
SLIDE 6
Control Hazards
¨ Sample C++ code
add $2, $2, $1 J for add $3, $3, $2 addi $1, $1, -1 next:
IM ALU DM Reg Reg IM ALU DM Reg Reg IM ALU DM Reg Reg IM ALU DM Reg IM ALU Reg
beq $0, $1, next for: addi $1, $0, 100
for (i=100; i != 0; i--) { sum = sum + i; } total = total + sum;
IM Reg
What happens inside the pipeline?
SLIDE 7
Control Hazards
¨ The outcome of the branch
SLIDE 8
Handling Control Hazards
¨ 1. introducing stall cycles and delay slots
¤ How many cycles/slots? ¤ One branch per every six instructions on average!! nothing add $2, $2, $1 addi $1, $1, -1 nothing
IM ALU DM Reg Reg IM ALU DM Reg Reg IM ALU DM Reg Reg IM ALU DM Reg IM ALU Reg
beq $0, $1, next for: addi $1, $0, 100
IM Reg
2 additional delay slots per 6 cycles!
J for
SLIDE 9
Handling Control Hazards
¨ 1. introducing stall cycles and delay slots
¤ How many cycles/slots? ¤ One branch per every six instructions on average!! nothing addi $1, $1, -1 J for add $2, $2, $1
IM ALU DM Reg Reg IM ALU DM Reg Reg IM ALU DM Reg Reg IM ALU DM Reg IM ALU Reg
beq $0, $1, next for: addi $1, $0, 100
IM Reg
1 additional delay slot, but longer path
nothing
SLIDE 10
Handling Control Hazards
¨ 1. introducing stall cycles and delay slots
¤ How many cycles/slots? ¤ One branch per every six instructions on average!! nothing J for addi $1, $1, -1 add $2, $2, $1
IM ALU DM Reg Reg IM ALU DM Reg Reg IM ALU DM Reg Reg IM ALU DM Reg IM ALU Reg
beq $0, $1, next for: addi $1, $0, 100
IM Reg
Reordering instructions may help
add r3, r3, r2 next:
SLIDE 11
Handling Control Hazards
¨ Strategies for filling up the branch delay slot
¤ (a) is the best choice; what about (b) and (c)?
SLIDE 12
Handling Control Hazards
¨ 1. introducing stall cycles and delay slots
¤ How many cycles/slots? ¤ One branch per every six instructions on average!! nothing J for addi $1, $1, -1 add $2, $2, $1
IM ALU DM Reg Reg IM ALU DM Reg Reg IM ALU DM Reg Reg IM ALU DM Reg IM ALU Reg
beq $0, $1, next for: addi $1, $0, 100
IM Reg
Jump and function calls can be resolved in the decode stage.
add r3, r3, r2 next:
SLIDE 13
Handling Control Hazards
¨ 1. introducing stall cycles and delay slots ¨ 2. predict the branch outcome n simply assume the branch is taken or not taken n predict the next PC
add $2, $2, $1 J for add r3, r3, r2 addi $1, $1, -1
IM ALU DM Reg Reg IM ALU DM Reg Reg IM ALU DM Reg Reg IM ALU DM Reg IM ALU Reg
beq $0, $1, next for: addi $1, $0, 100
IM Reg
May need to cancel the wrong path
next:
SLIDE 14
Handling Control Hazards
¨ Pipeline without branch predictor
IF (br) PC Reg Read Compare Br-target PC + 4
SLIDE 15
Handling Control Hazards
¨ Pipeline with branch predictor
IF (br) PC Reg Read Compare Br-target PC + 4 Branch Predictor
SLIDE 16
Handling Control Hazards
¨ The 2-bit branch predictor
SLIDE 17
Summary of the Pipeline
SLIDE 18
Memory System
¨ Data and instructions are stored on DRAM chips
¤ DRAM has high bit density and low speed ¤ An access DRAM may take about 300 processor cycles
¨ How to bridge the speed gap?
~300X Memory Processor
SLIDE 19
Memory Hierarchy
¨ The basic structure of a memory hierarchy.
Registers 1KB 1 cycle L1 data or instruction Cache 32KB 2 cycles L2 cache 2MB 15 cycles Memory 1GB 300 cycles Disk 80 GB 10M cycles
SLIDE 20
Memory Hierarchy
¨ The basic structure of a memory hierarchy. ¨ Multiple levels of the memory
Upper Level Lower Level Idea: keep important data closer to processor.
SLIDE 21
Cache Architecture
¨ Design principles
¤ Temporal locality: if you used some data recently, you
will likely use it again
¤ Spatial locality: if you used some data recently, you
will likely access its neighbors
¨ Cache terminology
¤ Access time ¤ Hit vs. miss ¤ Miss penalty Processor Cache Memory
SLIDE 22
Direct-Mapped Cache
¨ Cache address
SLIDE 23
Direct-Mapped Cache
¨ Cache lookup
