Memory Management

Chester Rebeiro IIT Madras

slide-2
SLIDE 2

Sharing RAM

2

Process 1 Process 2 Process 3 Process 4

Memory map of process 1 Memory map of process 2 Memory map of process 3 Memory map of process 4

slide-3
SLIDE 3

3

x86 address translation

CPU Logical Address

(segment +

  • ffset)

Segmentation Unit Linear Address Paging Unit Physical Memory Physical Address

slide-4
SLIDE 4

4

x86 Memory Management

slide-5
SLIDE 5

5

Segmentation

slide-6
SLIDE 6

6

Executing Programs (Process)

  • Process

– A program in execution – Present in the RAM – Comprises of

  • Executable instructions
  • Stack
  • Heap
  • State in the OS (in kernel)

– State contains : registers, list

  • f open files, related

processes, etc.

Executable (a.out) $gcc hello.c Process $./a.out Stored on hard disk Executes from RAM

slide-7
SLIDE 7

7

Segments (an example)

Heap Stack stack segment heap segment data segment text segment Text Data

slide-8
SLIDE 8

8

Segmentation (logical to linear address)

Logical address Heap Stack Text Data

slide-9
SLIDE 9

(linear address) (logical address)

9

Example

Segment Base Limit

  • 1

1000 1000 2 4000 500 3 8000 1000 4 9000 1000

1 segment register (eg %CS) 0x3000 pointer to descriptor table 0x3000 (descriptor table) 100

  • ffset register (eg %eip)

+ 1100

slide-10
SLIDE 10

10

Pointer to Descriptor Table

  • Global Descriptor Table (GDT)

– Stored in memory

  • Pointed to by GDTR (GDT Register)

– lgdt (instruction used to load the GDT register)

47 16 size base GDTR

Segment Descriptor Segment Descriptor Segment Descriptor Segment Descriptor Segment Descriptor

GDT Size : size of GDT Base : pointer to GDT

slide-11
SLIDE 11

11

Segment Descriptor

0 to 3 : privilege level (DPL_USER : 3, Kernel : 0) Segment type : STA_X : executable segment STA_R : readable segment STA_W : writeable segment Segment base (32 bit) Segment limit (20 bit)

slide-12
SLIDE 12

12

Segment Descriptor in xv6

ref : mmu.h ([7], 0752, 0769) SEG(STA_W, 0, 0xFFFFFFFF, DPL_USER)

slide-13
SLIDE 13

Segments in xv6

Segment Base Limit Type DPL Kernel Code 4 GB X, R Kernel Data 4 GB W User Code 4 GB X, R 3 User Data 4 GB W 3

13

slide-14
SLIDE 14

14

Loading the GDT

struct segdesc gdt[NSEGS]; 2308

0512

1724

slide-15
SLIDE 15

15

Virtual Memory

slide-16
SLIDE 16

Paging Unit

16

Linear address

Linear Address Space

  • f a process

Paging Unit Physical address Segmentation Unit RAM

slide-17
SLIDE 17

Virtual Memory

17

RAM

1 2 3 4 5 6 7 8 9 10 11 12 13 14 1 2 3 4 5 6

Linear address space of process1

block page frame 1 14 2 2 3 13 4 4 5 1 6 8

process page table

1 2 3 4 5 6 block page frame 1 1 2 2 3 3 4 4 5 5 6 6

Because of the page table, blocks need not be in contiguous page frames Every time a memory location is accessed, the processor looks into the page table to identify the corresponding page frame number.

slide-18
SLIDE 18

Virtual Memory

18

RAM

1 2 3 4 5 6 7 8 9 10 11 12 13 14 1 2 3 4 5 6

process1

block page frame 1 14 2 2 3 13 4 4 5 1 6 8

process page table

1 2 3 4 5 6 1 2 3 4

process2

block page frame 1 10 2 7 3 12 4 9

process page table

1 2 3 4

process3

block page frame 1 11 2 6 3 3 4 5

process page table

1 2 3 1 2 3 4 4

Blocks from Several processes can share pages in RAM simultaneously

slide-19
SLIDE 19

Virtual Memory

19

RAM

1 2 3 4 5 6 7 8 9 10 11 12 13 14 1 2 3 4 5 6

process1

block page frame 1 14 2 2 3 13 4 4 5 1 6 8

process page table

1 2 3 4 5 6 1 2 3 4 1 2 3 4

Do we really need to load all blocks into memory before the process starts executing? No. Not all parts of the program are accessed simultaneously. Infact, some code may not even be executed. Virtual memory takes advantage of this by using a concept called demand paging.

slide-20
SLIDE 20

Demand Paging

20

RAM

1 2 3 4 5 6 7 8 9 10 11 12 13 14 block page frame 1 14 2 3 4 5 6 8

process page table in RAM

1 2 3 4 1 2 3 4

1 2 3 4 5 6

Swap space (on disk)

P 1 1 1

present bit

Pages are loaded from disk to RAM, only when needed. A ‘present bit’ in the page table indicates if the block is in RAM or not. If (present bit = 1){ block in RAM} else {block not in RAM}

1 6

If a page is accessed that is not present in RAM, the processor issues a page fault interrupt, triggering the OS to load the page into RAM and mark the present bit to 1

5 6 1

slide-21
SLIDE 21

Demand Paging

21

RAM

1 2 3 4 5 6 7 8 9 10 11 12 13 14 block page frame 1 14 2 2 3 4 4 5 1 6 8

process page table in RAM

1 2 3 4 1 2 3 4

1 2 3 4 5 6

Swap space (on disk)

P 1 1 1 1 1 1 6 5 1 6 2 4

If there are no pages free for a new block to be loaded, the OS makes a decision to remove another block from RAM. This is based on a replacement policy, implemented in the OS. Some replacement policies are * First in first out * Least recently used * Least frequently used The replaced block may need to be written back to the swap (swap out)

3 1 14

slide-22
SLIDE 22

Demand Paging

22

RAM

1 2 3 4 5 6 7 8 9 10 11 12 13 14 1 2 3 4 1 2 3 4

1 2 3 4 5 6

Swap space (on disk)

6 5 6 2 4

The dirty bit, in the page table indicates if a page needs to be written back to disk If the dirty bit is 1, indicates the page needs to be written back to disk.

3 block page frame 1 14 2 2 3 14 4 4 5 1 6 8

process page table in RAM

P 1 1 1 1 1 1 D 1 1 1 1 1

slide-23
SLIDE 23

Demand Paging

23

RAM

1 2 3 4 5 6 7 8 9 10 11 12 13 14 block page frame 1 14 2 2 3 14 4 4 5 1 6 8

process page table in RAM

1 2 3 4 1 2 3 4

1 2 3 4 5 6

Swap space (on disk)

P 1 1 1 1 1 6 5 1 6 2 4

Protection bits, in the page table determine if the page is executable, readonly, and accessible by a user process.

3 1 D 1 1 1 1 1 1 10 11 01 1 10 11 00

protection bits

slide-24
SLIDE 24

2 Level Page Translation

24

linear address

Table Offset Physical Address (p) (CR3) Dir

Dir : 10 bits Table : 10 bits Offset : 12 bits

Number of Page tables is 210 = 1024. Total size of page tables is 4MB. But not contiguous!

slide-25
SLIDE 25

25

Linear to Physical Address

  • 2 level page translation
  • How many page

tables are present?

  • What is the

maximum size of the process’ address space?

– 4G

ref : mmu.h (PGADDR, NPDENTRIES, NPTENTRIES, PGSIZE)

slide-26
SLIDE 26

26

back to booting…

slide-27
SLIDE 27

27

so far…

BIOS bootloader

  • executes on reset.
  • does POST, initializes devices
  • loads boot loader to 0x07c00 and jump to it

(all in real mode) Power on Reset

  • disable interrupts
  • Setup GDT (8941)
  • switch real mode to protected mode
  • setup an initial stack (8967)
  • load kernel from second sector of disk to

0x100000

  • executes kernel (_start)
slide-28
SLIDE 28

28

Memory when kernel is invoked

(just after the bootloader)

  • Segmentation enabled but no paging
  • Memory map

CPU

Segmentation Unit physical memory

logical address physical address code data bootloader

stack

logical memory physical memory

kernel 0x100000

Slide taken from Anton Burtsev, Univ. of Utah

slide-29
SLIDE 29

Memory Management Analysis

  • Advantages

– Got the kernel into protected mode (32 bit code) with minimum trouble

  • Disadvantages

– Protection of kernel memory from user writes – Protection between user processes – User space restricted by physical memory

  • The plan ahead

– Need to get paging up and running 29

CPU

Segmentation Unit physical memory

logical address physical address

slide-30
SLIDE 30

30

entry

The kernel executes from here

slide-31
SLIDE 31

OS code Linker address

  • kernel.asm (xv6)
  • The linker sets the

executable so that the kernel starts from 0x80100000

  • 0x80100000 is a virtual

address and not a physical address

31

slide-32
SLIDE 32

32

Virtual Address Space

0xffffffff KERNBASE

0x80000000

Virtual Physical

Device memory

+0x100000 0x100000 PHYSTOP

  • Kernel memory mapped into every process
  • easy to switch between kernel and user modes
  • VA(KERNBASE:+PHYSTOP) à PA(0:PHYSTOP)
  • convert from VA to PA just by +/- KERNBASE
  • easily write to physical page
  • limits size of physical memory to 2GB

Kernel Memory

ref : memlayout.h (0200)

slide-33
SLIDE 33

33

Virtual Address Space

0xffffffff KERNBASE

0x80000000

Virtual Physical

Device memory

+0x100000 0x100000 PHYSTOP

  • Linking address not the same as the loading

address

  • Linking address 0x80100000
  • Loading address 0x100000

Kernel Memory

ref : memlayout.h (0200)

slide-34
SLIDE 34

Converting virtual to physical in kernel space

34

slide-35
SLIDE 35

35

Enable Paging

  • 1. Start of with a quick solution

Aim is get the kernel running with paging enabled

  • - create a minimal paging environment
  • --- two pages of 4MB size (just sufficient to hold the OS)
  • 2. Have an elaborate paging mechanism

Create pages for each 4KB RAM block Allocate and manage free memory

slide-36
SLIDE 36

36

Enable Paging

Turn on Page size extension Aim is to create two 4MB pages 1

slide-37
SLIDE 37

37

4MB Pages

slide-38
SLIDE 38

38

Enable Paging

Set Page Directory 2

slide-39
SLIDE 39

39

Kernel memory setup

  • First setup two 4MB pages

– Entry 0: Virtual addresses 0 to 0x04000000 àPhysical addresses 0 to 4MB – Entry 512:

Virtual addresses 0x80000000 to 0x84000000 à Physical addresses 0 to 4MB

What would be the address generated before and immediately after paging is enabled? before : 0x001000xx Immediately after : 0x8001000xx So the OS needs to be present at two memory ranges

slide-40
SLIDE 40

40

Enable Paging

Turn on Paging 1 2 3

slide-41
SLIDE 41

41

First Page Table

courtesy Anton Burtsev, Univ. of Utah

logical memory

physical memory virtual memory

slide-42
SLIDE 42

42

Execute main

Set up stack Jump to main

slide-43
SLIDE 43

43

Stack

courtesy Anton Burtsev, Univ. of Utah

slide-44
SLIDE 44

44

(Re)Initializing Paging

  • Configure another page table

– Map kernel only once making space for other user level processes – Map more physical memory, not just the first 4MB – Use 4KB pages instead of 4MB pages

  • 4MB pages very wasteful if processes are small
  • Xv6 programs are a few dozen kilobytes

main à kvmalloc à setupkvm

slide-45
SLIDE 45

45

Setup kernel vm

1823 KERNBASE = 0x80000000 KERNLINK = KERNBASE + 0x100000 PHYSTOP = 0xE000000 EXTMEM = 0x100000

Setting Up kernel pages (vm.c)

  • 1. stuct kmap

data obtained from linker script, which determines size of code+readonly data

  • 2. Kernel page tables set up in kvmalloc() (1857)

(invoked from main)

slide-46
SLIDE 46

Creating the Page Table Mapping for the kernel

  • Enable paging
  • Create/Fill page directory
  • Create/Fill page tables
  • Load CR3 register

46

slide-47
SLIDE 47

Creating the Page Table Mapping for the kernel

  • Enable paging
  • Create/Fill page directory
  • Create/Fill page tables
  • Load CR3 register

47

Setting paging enable bit in CR0 register (1049)

slide-48
SLIDE 48

Creating the Page Table Mapping for the kernel

  • Enable paging
  • Create/Fill page directory
  • Create/Fill page tables
  • Load CR3 register

48

done in function walkpgdir (1754)

slide-49
SLIDE 49

walkpgdir (1754)

  • Create a page directory entry

corresponding to a virtual address.

  • If page table is not present, then

allocate it.

  • PDX(va) : page directory index
  • PTE_ADDR(*pde) : page

directory entry

  • PTX(va) : page table entry

49

slide-50
SLIDE 50

Creating the Page Table Mapping for the kernel

  • Enable paging
  • Create/Fill page directory
  • Create/Fill page tables
  • Load CR3 register

50

done in function mappages (1779)

slide-51
SLIDE 51

mappages (1779)

  • Fill page table entries

mapping virtual addresses to physical addresses

  • What are the contents?

– Physical address – Permissions – Present bit

51

slide-52
SLIDE 52

Creating the Page Table Mapping for the kernel

  • Enable paging
  • Create/Fill page directory
  • Create/Fill page tables
  • Load CR3 register

52

Load the CR3 register to point to the page directory.

slide-53
SLIDE 53

53

User Pages mapped twice

0xffffffff KERNBASE Virtual Physical

Device memory

+0x10000

Device memory

0x10000 PHYSTOP

Kernel Memory

  • Kernel has easy access to user pages (useful for

system calls)

slide-54
SLIDE 54

Allocating Memory

54

slide-55
SLIDE 55

55

Allocating Pages (kalloc)

RAM

end of kernel PHYSTOP

used for allocation

Used page Free page

freelist

  • Physical memory allocation done in page

granularity (i.e. 4KB)

  • Free physical pages in a list
  • Page Allocation removes from list head (see

function kalloc)

  • Page free adds to list head (see kfree)

ref : kalloc.c [30]

slide-56
SLIDE 56

56

Freelist Implementation

  • How is the freelist implemented?

– No exclusive memory to store links (3014)

ptr to next free page ptr to next free page ptr to next free page ptr to next free page

freelist

slide-57
SLIDE 57

57

Initializing the list (chicken & egg problem)

create free list marking all pages as free

at boot

access memory via Page tables

this needs

Page tables are in memory and need to be allocated

Create a page table

this needs ref : kalloc.c (kinit1 and kinit2) Resolved by a separate page allocator during boot up, which allocates 4MB memory just after the kernel’s data segment (see kinit1 and kinit2).

slide-58
SLIDE 58

Per CPU Data

58

slide-59
SLIDE 59

Recall

Memory is Symmetric Across Processors

Processor 1 Processor 2 Processor 3 Processor 4

front side bus

North Bridge DRAM

Memory bus

  • Memory Symmetry
  • All processors in the system share the same memory space
  • Advantage : Common operating system code
  • However there are certain data which have to be unique to each

processor

  • This is the per-cpu data
  • example, cpu id, scheduler context, taskstate, gdt, etc.
slide-60
SLIDE 60

Naïve implementation of per-cpu data

  • An array of structures, each element in array corresponding to a processor
  • Access to a per-cpu data, example : cpu[cpunum()].ncli
  • This requires locking every time the cpu structure is accessed

– eg. Consider process migrating from one processor to another while updating a per-cpu data – slow (because locking can be tedious)!!!

60

ref : proc.h [23]

slide-61
SLIDE 61

Alternate Solution (using CPU registers)

  • CPU has several general purpose registers

– The registers are unique to each processor (not shared)

  • Use CPU registers to store per-cpu data

– Must ensure the gcc does not use these registers for other purposes

  • Fastest solution to our problem, but we do not have so

many registers L

61 Content borrowed from Carmi Merimovich (http://www2.mta.ac.il/~carmi/)

slide-62
SLIDE 62

Next best solution (xv6 implementation)

  • In seginit(), which is run on each CPU initialization, the

following is done.

– GDTR will point upon cpu initialization to cpus[cpunum()].gdt. – (Thus, each processor will have its own private GDT in struct cpu).

  • Have an entry which is unique for each processor

– The base address field of SEG_KCPU entry in GDT is &cpus[cpunum()].cpu (1731) – %gs register loaded with SEG KCPU << 3.

  • Lock free access to per-cpu data

– %gs indexes into the SEG_KCPU offset in GDT – This is unique for each processor

62

CPU0 CPU1

GDT For CPU0 GDT For CPU1

per-cpu for CPU0 per-cpu for CPU1 %gs %gs

Content borrowed from Carmi Merimovich (http://www2.mta.ac.il/~carmi/)

slide-63
SLIDE 63

Using %gs

  • Without locking or cpunum() overhead we have:

– %gs:0 is cpus[cpunum()].cpu. – %gs:4 is cpus[cpunum()].proc.

  • If we are interrupting user mode code then %gs

might contain irrelevant value. Hence

– In alltraps %gs is loaded with SEG_KCPU << 3.

– (The interrupted code %gs is already on the trapframe.)

  • gcc not aware of the existence of %gs, so it will no generate code messing

up gs.

63 Content borrowed from Carmi Merimovich (http://www2.mta.ac.il/~carmi/)
