Memory Hierarchy

Heechul Yun

1

Topics

• Introduction to Real-Time Systems, CPS
• CPS Applications
• Real-time architecture/OS
• Fault tolerance, safety, security

2

Amazon prime air

Topics

• Introduction to Real-Time Systems, CPS
• CPS Applications
• Real-time architecture/OS

– Real-time cache, DRAM controller designs – Real-time microarchitecture/OS Support – Real-time support for GPU/FPGA

• Fault tolerance, safety, security

3

Real-Time Computing

• Performance vs. Determinism

– Performance: average timing – Determinism: variance and worst-case timing

• Traditional real-time systems

– Focused on determinism – So that we can analyze the system at design time – Many challenges exist in computer architecture – In general, performance demand was not high.

• High performance real-time systems

– Such as self-driving cars and UAVs (intelligent robots) – Demand both performance and determinism – More difficult to satisfy both

4

Architecture for Intelligent Robots

• Time predictability
• High performance

5

Performance Predictability

Performance Architecture Real-Time Architecture High Performance Real-Time Architecture

Challenge: Memory Hierarchy

6

• Many important hardware resources are shared
• Each is locally optimized for average performance
• Software has limited ability to reason and control
• Unpredictable software execution timing

Core1 Core2 GPU Accel. Memory Controller (MC) Shared Cache DRAM

Automotive Industry Challenges

• “Automotive industry is transitioning from µC

toward μP based platforms”

• “Interference effects (on μPs) are more severe by
• rders of magnitude compared to µC platforms”
• “Goal for automotive systems engineering:

predictable real-time behavior on high- performance platforms”

7

(*) Arne Hamann (Bosch), “Industrial Challenges: moving from classical to high-performance real-time systems." In Waters 2019

Certification Challenges in Aviation

8

https://www.faa.gov/aircraft/air_cert/design_approvals/air_software/cast/cast_papers/media/cast-32A.pdf

CAST-32A: Multicore-Processors

• A position paper by FAA and other

certification agencies on multicore

• Discuss interference channels of multi-core

that affect software timing

• Suggestion 1: disable all but one core
• Suggestion 2: provide evidence that all

interference channels are taken care of (“robust partitioning”)  nobody can (yet)

9

Timing Matters for Security

• Measurable timing differences in accessing

shared hardware resources can leak secret

10

https://meltdownattack.com/

Challenge: Memory Hierarchy

11

• Many important hardware resources are shared
• Each is locally optimized for average performance
• Software has limited ability to reason and control
• Unpredictable software execution timing

Core1 Core2 GPU Accel. Memory Controller (MC) Shared Cache DRAM

Cache

• Small but fast memory (SRAM)
• Hardware (cache controller) managed storage

– Mapping: phy addr  mapping function  set index – Replacement: select victim line among the ways

• Improve average performance
• Transparent to software

– It just works!

12

Direct-Map Cache

• Cache-line size = 2L
• # of cache-sets = 2S
• Cache size = 2L+S

13

tags index

• ffset

Cache cache-line (L) Cache Physical address Cache sets S L

Cache Cache Cache

Set-Associative Cache

• Cache-line size = 2L
• # of cache-sets = 2S
• # of ways = W
• Cache size = W x 2L+S

14

tags index

• ffset

Cache Physical address Cache sets Cache cache-line (L) S L 2 3 4 1

Cache Replacement Policy

• Least Recently Used (LRU)

– Evict least recently used cache-line – “Good” (analyzable) policy. Tight analysis exists. – Expensive to maintain order. Not used for large caches

15

Cache Replacement Policy

• (Tree) Pseudo-LRU

– Use a binary tree – Each node records which half is older – On a miss, follow the older path and flip the bits along the way – Approximate LRU, No need to sort, practical – But analysis is more pessimistic

16

1 1 1 1

L0 L1 L2 L3 L4 L5 L6 L7

Older

Image credit: Prof. Mikko H. Lipasti

Cache Replacement Policy

• (Tree) Pseudo-LRU

17

Image credit: https://en.wikipedia.org/wiki/Pseudo-LRU

Cache Replacement Policy

• (Bit) PLRU or NRU (Not Recently Used)

– One MRU bit per cache-line – Set 1 on access; when the last remaining 0 bit is set to 1, all other bits are reset to 0. – At cache misses, the line with lowest index whose MRU-bit is 0 is replaced.

18

Udacity Lecture: https://www.youtube.com/watch?v=8CjifA2yw7s

Cache Replacement Policies

• How to know which policy is used?

– Manual (if you are lucky) – Reverse engineering

19

Image source: [Abel and Reineke, RTAS 2013]

WCET and Caches

• How to determine the WCET of a task?
• The longest execution path of the task?

– Problem: the longest path can take less time to finish than shorter paths if your system has a cache(s)!

• Example

– Path1: 1000 instructions, 0 cache misses – Path2: 500 instructions, 100 cache misses – Cache hit: 1 cycle, Cache miss: 100 cycles – Path 2 takes much longer

20

WCET and Caches

• Treat all memory accesses as cache-misses?

– Problem: extremely pessimistic

• Example

– 1000 instructions, 100 mem accesses, 10 misses

• Cache hit: 1 cycle, cache miss: 100 cycles

– Actual = 900 + 90*1 + 10*100 = 1990 = ~2000cycles – WCETallmiss = 900 + 100 * 100 = 10900 = ~11000 cycles

• >5X higher

21

WCET and Caches

• Take cache hits/misses into account?

– To reduce pessimism in WCET estimation

• How to know cache hits/misses of a given job?

– If we assume

• the path (instruction stream) is given
• the job is not interrupted.
• A known “good” cache replacement policy is used

– Then we can statically determine hits/misses

• But less so when “bad” replacement policies are used

22

Shared Cache

23

• Cache space is shared between cores
• How to improve isolation?

Core1 Core2 GPU Accel. Memory Controller (MC) Shared Cache DRAM

Cache Partitioning

• Way-partitioning

– Requires h/w support

• Set-partitioning

– Can be done in s/w as long as there’s MMU.

• MMU: virtual -> physical address translation h/w
• Page table: translation table managed by the OS
• Most (but not all) processors support MMU

– Page-coloring

24

Way Partitioning

• H/W support is needed

– E.g., Freescale P4080, Intel

25

Cache Cache Cache Cache Cache sets Cache cache-line (L) 2 3 4 1 Core1 Core2 Core3 Core4

Intel CAT

• Cache Allocation Technology (CAT)

– Intel’s way partitioning mechanism – Thread/VM  logical id  resource (cache) partition

• Part of intel’s platform QoS techniques

– CAT: cache allocation technology – CMT: cache monitoring technology – MBM: memory bandwidth monitoring – CDP: code/data prioritization

• Some slides are from

– C. Peng, “Achieving QoS in Server Virtualization,” 2016

26

27

28

29

30

Set Partitioning

31

Cache Cache Cache Cache Cache sets Cache cache-line (L) 2 3 4 1 Core1 Core2 Core3 Core4

• Can be done in S/W

– Page coloring: control physical address (cache index) of pages

Page Coloring

• Cache can be divided into page colors
• Assign certain colors to

certain CPU cores

32

Cache Cache Cache Cache Cache sets Cache cache-line (L) 2 3 4 1 Core1 Core2 Core3 Core4

Page Coloring

• OS’s memory allocator controls the color of each

allocated page

33

Color index: OS-controlled address bits

OS controlled bits for L2 partitioning 31 6 Set index 17 12 31 6 Set index 14 12 Tag Page offset Cache-line

• ffset

12 Physical page frame number Cache-line

• ffset

Cache-line

• ffset

Set index Set index Tag Tag 6 14 16 L2 Cache (shared) L1 Cache (private) Physical Address 31

ARM Cortex-A15

• Why not using bit 12,13?

34

12 14 banks L3 cache-sets 31 6 19 21 banks (private) L1: 32K-I/D (4/8 way)  4KB/way (12 bits) (private) L2: 256KB (8way)  32KB/way (12 + 3bits) (shared) L3: 8MB (16way)  512KB/way (12 + 7bits) L2 cache-sets 15 L1-D cache-sets

Intel Nehalem

• Co-partitioning problem

– Partitioning L3 using bit 12,13 also partitions the L2 cache and DRAM banks due to address overlap

35

Intel Sandy Bridge

• Modern Intel processors use more complex mapping

– Slice id + Set index  unique cache location

USENIX, SP’15 “Last-Level Cache Side-Channel Attacks are Practical”

36

How to Partition?

• Decision: Core (Thread)  Page colors
• Static partitioning

– Assign the mapping statically at once – Pros: simple – Cons: what if the assignment is not ideal?

• Dynamic

– Assignment may change over time – Pros: can adapt changes in behavior – Cons: page recoloring is costly

37

Summary

• Cache way partitioning

– Pros

• Low re-partition overhead

– Cons

• Hardware support is needed.
• Cache set partitioning (Page coloring)

– Pros

• SW (OS) approach. No HW support is needed

– Cons

• Co-partitioning problem
• Re-partitioning (coloring) overhead is high

38

Main Memory

39

• Cache space
• Cache internal hardware structures

– MSHRs, WBBuffer, …

Core1 Core2 GPU Accel. Memory Controller (MC) Shared Cache DRAM

Why is DRAM Important?

• Why do we need bigger and faster memory?
• Data intensive computing

– Bigger, more complex application – Large and high-bandwidth data processing – DRAM is often a performance bottleneck

40

Why is DRAM Important?

• Parallelism

– Out-of-order core

• A single core can generate many memory requests

– Multicore

• Multiple cores share DRAM

– Accelerator

• GPU

41

Memory Performance Isolation

• Q. How to guarantee predictable memory

performance?

Part 1 Part 2 Part 3 Part 4

42

Core1 Core2 Core3 Core4 DRAM Memory Controller LLC LLC LLC LLC

Memory System Architecture

43

CORE 1

L2 CACHE 0

SHARED L3 CACHE DRAM INTERFACE

CORE 0 CORE 2 CORE 3

L2 CACHE 1 L2 CACHE 2 L2 CACHE 3

DRAM BANKS

DRAM MEMORY CONTROLLER

This slide is from Prof. Onur Mutlu

DRAM Organization

• Channel
• Rank
• Chip
• Bank
• Row
• Row/Column

44

The DRAM subsystem

Memory channel Memory channel DIMM (Dual in-line memory module) Processor “Channel”

This slide is from Prof. Onur Mutlu

Breaking down a DIMM

DIMM (Dual in-line memory module) Side view Front of DIMM Back of DIMM

This slide is from Prof. Onur Mutlu

Breaking down a DIMM

DIMM (Dual in-line memory module) Side view Front of DIMM Back of DIMM Rank 0: collection of 8 chips Rank 1

This slide is from Prof. Onur Mutlu

Rank

Rank 0 (Front) Rank 1 (Back) Data <0:63> CS <0:1> Addr/Cmd <0:63> <0:63> Memory channel

This slide is from Prof. Onur Mutlu

Breaking down a Rank

Rank 0 <0:63> Chip 0 Chip 1 Chip 7

. . .

<0:7> <8:15> <56:63> Data <0:63>

This slide is from Prof. Onur Mutlu

Breaking down a Chip

Chip 0 <0:7> Bank 0

<0:7> <0:7> <0:7>

...

<0:7>

This slide is from Prof. Onur Mutlu

Breaking down a Bank

Bank 0 <0:7>

row 0 row 16k-1

...

2kB

1B

1B (column)

1B

Row-buffer

1B

...

<0:7>

This slide is from Prof. Onur Mutlu

Example: Transferring a cache block

0xFFFF…F 0x00 0x40

...

64B cache block Physical memory space

Channel 0 DIMM 0 Rank 0

This slide is from Prof. Onur Mutlu

Example: Transferring a cache block

0xFFFF…F 0x00 0x40

...

64B cache block Physical memory space

Rank 0

Chip 0 Chip 1 Chip 7

<0:7> <8:15> <56:63> Data <0:63>

. . .

This slide is from Prof. Onur Mutlu

Example: Transferring a cache block

0xFFFF…F 0x00 0x40

...

64B cache block Physical memory space

Rank 0

Chip 0 Chip 1 Chip 7

<0:7> <8:15> <56:63> Data <0:63>

Row 0 Col 0

. . .

This slide is from Prof. Onur Mutlu

Example: Transferring a cache block

0xFFFF…F 0x00 0x40

...

64B cache block Physical memory space

Rank 0

Chip 0 Chip 1 Chip 7

<0:7> <8:15> <56:63> Data <0:63>

8B Row 0 Col 0

. . .

8B

This slide is from Prof. Onur Mutlu

Example: Transferring a cache block

0xFFFF…F 0x00 0x40

...

64B cache block Physical memory space

Rank 0

Chip 0 Chip 1 Chip 7

<0:7> <8:15> <56:63> Data <0:63>

8B Row 0 Col 1

. . .

This slide is from Prof. Onur Mutlu

Example: Transferring a cache block

0xFFFF…F 0x00 0x40

...

64B cache block Physical memory space

Rank 0

Chip 0 Chip 1 Chip 7

<0:7> <8:15> <56:63> Data <0:63>

8B 8B Row 0 Col 1

. . .

8B

This slide is from Prof. Onur Mutlu

Example: Transferring a cache block

0xFFFF…F 0x00 0x40

...

64B cache block Physical memory space

Rank 0

Chip 0 Chip 1 Chip 7

<0:7> <8:15> <56:63> Data <0:63>

8B 8B Row 0 Col 1

A 64B cache block takes 8 I/O cycles to transfer. During the process, 8 columns are read sequentially.

. . .

This slide is from Prof. Onur Mutlu

DRAM Organization

L3 DRAM DIMM Memory Controller (MC) Bank 4 Bank 3 Bank 2 Bank 1

Core1 Core2 Core3 Core4

• Have multiple banks
• Different banks can be

accessed in parallel

Best-case

L3 DRAM DIMM Memory Controller (MC) Bank 4 Bank 3 Bank 2 Bank 1

Core1 Core2 Core3 Core4

Fast

• Peak = 10.6 GB/s

– DDR3 1333Mhz

Best-case

L3 DRAM DIMM Memory Controller (MC) Bank 4 Bank 3 Bank 2 Bank 1

Core1 Core2 Core3 Core4

• Peak = 10.6 GB/s

– DDR3 1333Mhz

• Out-of-order processors

Fast

Most-cases

L3 DRAM DIMM Memory Controller (MC) Bank 4 Bank 3 Bank 2 Bank 1

Core1 Core2 Core3 Core4

Mess

• Performance = ??

Worst-case

• 1bank b/w

– Less than peak b/w – How much?

Slow

L3 DRAM DIMM Memory Controller (MC) Bank 4 Bank 3 Bank 2 Bank 1

Core1 Core2 Core3 Core4

Bank 4

DRAM Chip

Row 1 Row 2 Row 3 Row 4 Row 5 Bank 1 Row Buffer Bank 2 Bank 3 activate precharge Read/write

• State dependent access latency

– Row miss: 19 cycles, Row hit: 9 cycles

(*) PC6400-DDR2 with 5-5-5 (RAS-CAS-CL latency setting)

READ (Bank 1, Row 3, Col 7)

Col7

DDR3 Timing Parameters

65

Kim et al., “Bounding Memory Interference Delay in COTS-based Multi-Core Systems,” RTAS’14

DRAM Controller

• Service DRAM requests (from CPU) while obeying

timing/resource constraints

– Translate requests to DRAM command sequences – Timing constraints: e.g., minimum write-to-read delay, activation time, … – Resource conflicts: bank, bus, channel

• Maximize performance

– Buffering, reordering, pipelining in scheduling requests

66

DRAM Controller

• Request queue

– Buffer read/write requests from CPU cores – Unpredictable queuing delay due to reordering

67

Bruce Jacob et al, “Memory Systems: Cache, DRAM, Disk” Fig 13.1.

Request Reordering

• Improve row hit ratio and throughput
• Unpredictable queuing delay

68

Core1: READ Row 1, Col 1 Core2: READ Row 2, Col 1 Core1: READ Row 1, Col 2 Core1: READ Row 1, Col 1 Core1: READ Row 1, Col 2 Core2: READ Row 2, Col 1

DRAM DRAM Initial Queue Reordered Queue 2 Row Switch 1 Row Switch

Row Management Policy

• Open row

– Keep the row open after an access

• If next access targets the same row: CAS
• If next access targets a different row: PRE + ACT + CAS
• Close row

– Close the row after an access

• always pay the same (longer) cost: ACT + CAS
• Adaptive policies

69

COTS DRAM Controller

• FR-FCFS scheduling (out-of-order)
• Separate read/write buffers

– High/low watermark based switching

• Read prioritized over writes

70

PALLOC: DRAM Bank-Aware Memory Allocator for Performance Isolation on Multicore Platforms

Heechul Yun*, Renato Mancuso+, Zheng-Pei Wu#, Rodolfo Pellizzoni# *University of Kansas, +University of Illinois , #University of Waterloo

71

Background: DRAM Organization

L3 DRAM DIMM Memory Controller (MC) Bank 4 Bank 3 Bank 2 Bank 1

Core1 Core2 Core3 Core4

• Have multiple banks
• Different banks can be

accessed in parallel

72

Best-case

L3 DRAM DIMM Memory Controller (MC) Bank 4 Bank 3 Bank 2 Bank 1

Core1 Core2 Core3 Core4

Fast

• Peak = 10.6 GB/s

– DDR3 1333Mhz

73

Best-case

L3 DRAM DIMM Memory Controller (MC) Bank 4 Bank 3 Bank 2 Bank 1

Core1 Core2 Core3 Core4

• Peak = 10.6 GB/s

– DDR3 1333Mhz

• Out-of-order processors

Fast

74

Most-cases

L3 DRAM DIMM Memory Controller (MC) Bank 4 Bank 3 Bank 2 Bank 1

Core1 Core2 Core3 Core4

Mess

• Performance = ??

75

Worst-case

• 1bank b/w

– Less than peak b/w – How much?

Slow

L3 DRAM DIMM Memory Controller (MC) Bank 4 Bank 3 Bank 2 Bank 1

Core1 Core2 Core3 Core4

76

Timing Diagram

77

Row misses are slow but can overlap when target different banks Row hits are fast but can still suffer interference at bus

Heechul Yun, Rodolfo Pellizzoni, Prathap Kumar Valsan. Parallelism-Aware Memory Interference Delay Analysis for COTS Multicore Systems. Euromicro Conference on Real-Time Systems (ECRTS), 2015. [pdf] [ppt]

Problem

L3 DRAM DIMM Memory Controller (MC) Bank 4 Bank 3 Bank 2 Bank 1

Core1 Core2 Core3 Core4

• OS does NOT know

DRAM banks

• OS memory pages are

spread all over multiple banks

????

Unpredictable memory performance

SMP OS

78

DRAM DIMM

PALLOC

CPC Memory Controller (MC) Bank 4 Bank 3 Bank 2 Bank 1

Core1 Core2 Core3 Core4

• OS is aware of

DRAM mapping

• Each page can be

allocated to a desired DRAM bank

Flexible allocation policy

SMP OS

79

PALLOC

L3 DRAM DIMM Memory Controller (MC) Bank 4 Bank 3 Bank 2 Bank 1

Core1 Core2 Core3 Core4

• Private banking

– Allocate pages

• n certain

exclusively assigned banks

Eliminate Inter-core bank conflicts

80

Challenges

• Finding DRAM address mapping
• Modifying Linux’s memory allocation

mechanism

81

Identifying Memory Mapping

• Memory mappings are platform specific
• We developed a detection tool software

82

12 14 19 21 banks banks cache-sets 31 6 14 18 banks 31 6 7 channel cache-sets 16

Intel Xeon 3530 + 4GiB DDR3 DIMM (16 banks) Freescale P4080 + 2x2 GiB DDR3 DIMM (32 banks)

DRAM Address Map Detector

83

https://github.com/heechul/palloc/blob/master/README-map-detector.md Slow Fast

More Recent Solution

84

https://github.com/IAIK/drama

Complex Addressing

85

Implementation

• Modified Linux kernel’s buddy allocator

– DRAM bank-aware page frame allocation at each page fault

86

Background

• On how Linux allocates memory

87

User-level Memory Allocation

• When does a process actually

allocate a memory from the kernel?

– On a page fault – Allocate a page (e.g., 4KB)

• What does malloc() do?

– Doesn’t physically allocate pages – Manage a process’s heap – Variable size objects in heap

88

Kernel-level Memory Allocation

• Page-level allocator (low-level)

– Page granularity (4K) – Buddy allocator

• Other kernel-memory allocators

– Support fine-grained allocations – Slab, kmalloc, vmalloc allocators

89

Kernel-Level Memory Allocators

90

Kernel code

kmalloc

Arbitrary size objects

SLAB allocator

Multiple fixed-sized object caches

Page allocator (buddy)

Allocate power of two pages: 4K, 8K, 16K, …

vmalloc

(large) non-physically contiguous memory

Buddy Allocator

• Linux’s page-level allocator
• Allocate power of two number of pages: 1, 2, 4, 8, … pages.
• Request rounded up to next highest power of 2
• When smaller allocation needed than is available, current

chunk split into two buddies of next-lower power of 2

• Quickly expand/shrink across the lists

91

4KB 8KB 16KB 32KB

Buddy Allocator

• Example

– Assume 256KB chunk available, kernel requests 21KB

92

32 A 32 Free 64 Free 128 Free 32 Free 64 Free 128 Free 32 Free 64 Free 128 Free 64 Free 128 Free 128 Free 256 Free

Buddy Allocator

• Example

– Free A

93

32 A 32 Free 64 Free 128 Free 32 Free 64 Free 128 Free 32 Free 64 Free 128 Free 64 Free 128 Free 128 Free 256 Free

PALLOC in Linux

94

Kernel code

kmalloc

Arbitrary size objects

SLAB allocator

Multiple fixed-sized object caches

PALLOC

vmalloc

(large) non-physically contiguous memory

Simplified Pseudocode

95

PALLOC Interface

• Example: per-core private banking (PB)

96

# cd /sys/fs/cgroup # mkdir core0 core1 core2 core3  create 4 cgroup partitions # echo 0-3 > core0/palloc.dram_bank  assign bank 0 ~ 3 for the core0 partition. # echo 4-7 > core1/palloc.dram_bank # echo 8-11 > core2/palloc.dram_bank # echo 12-15 > core3/palloc.dram_bank

Evaluation Platforms

• Platform #1: Intel Xeon 3530

– X86-64, 4 cores, 8MB shared L3 cache – 1 x 4GB DDR3 DRAM module (16 banks) – Modified Linux 3.6.0

• Platform #2: Freescale P4080

– PowerPC, 8 cores, 2MB shared LLC – 2 x 2GB DDR3 DRAM module (32 banks) – Modified Linux 3.0.6

97

Samebank vs. Diffbank

• Samebank: All cores  Bank0
• Diffbank: Core0  Bank0, Core1-3  Bank 1-3

– Zero interference !!!

98

Real-Time Performance

• Setup: HRT  Core0, X-server  Core1
• Buddy: no bank control (use all Bank 0-15)
• Diffbank: Core0  Bank0-7, Core1  Bank8-15

99

Buddy(solo) PALLOC(diffbank) Buddy

SPEC2006

• Use 15 high-medium memory intensive benchmarks

100

Performance Impact on Unicore

• #of bank vs. performance on a single core
• Finding: bank partitioning negatively affect performance due to reduced

MLP, but not significant for most benchmarks

101

Normalized IPC

0.00 0.20 0.40 0.60 0.80 1.00 1.20 4banks 8banks 16banks Buddy

Performance Isolation on 4 Cores

• Setup: Core0: X-axis, Core1-3: 470.lbm x 3 (interference)
• PB: DRAM bank partitioning only;
• PB+PC: DRAM bank and Cache partitioning
• Finding: bank (and cache) partitioning improves isolation, but far from ideal

102

Slowdown ratio

0.00 1.00 2.00 3.00 4.00 5.00 6.00 7.00

buddy PB PB+PC

Taming Non-blocking Caches to Improve Isolation in Multicore Real-Time Systems

Prathap Kumar Valsan, Heechul Yun, Farzad Farshchi University of Kansas

103

Cache Interference Experiments

• Measure the performance of the ‘subject’

– (1) alone, (2) with co-runners – LLC is partitioned (equal partition) using PALLOC (*)

• Q: Does cache partitioning provide isolation?

104

DRAM LLC Core1 Core2 Core3 Core4

subject co-runner(s)

(*) Heechul Yun, Renato Mancuso, Zheng-Pei Wu, Rodolfo Pellizzoni. “PALLOC: DRAM Bank-Aware Memory Allocator for Performance Isolation on Multicore Platforms.” RTAS’14

IsolBench: Synthetic Workloads

• Latency

– A linked-list traversal, data dependency, one outstanding miss

• Bandwidth

– An array reads or writes, no data dependency, multiple misses

• Subject benchmarks: LLC partition fitting

105

Working-set size: (LLC) < ¼ LLC  cache-hits, (DRAM) > 2X LLC  cache misses

Latency(LLC) vs. BwRead(DRAM)

• No interference on Cortex-A7 and Nehalem
• On Cortex-A15, Latency(LLC) suffers 3.8X slowdown

– despite partitioned LLC

106

BwRead(LLC) vs. BwRead(DRAM)

• Up to 10.6X slowdown on Cortex-A15
• Cache partitioning != performance isolation

– On all tested out-of-order cores (A9, A15, Nehalem)

107

BwRead(LLC) vs. BwWrite(DRAM)

• Up to 21X slowdown on Cortex-A15
• Writes generally cause more slowdowns

– Due to write-backs

108

EEMBC and SD-VBS

• X-axis: EEMBC, SD-VBS (cache partition fitting)

– Co-runners: BwWrite(DRAM)

• Cache partitioning != performance isolation

109

Cortex-A7 (in-order) Cortex-A15 (out-of-order)

Summary

• PALLOC

– Page-coloring based kernel level memory allocator – Can partition cache and DRAM banks

• Findings

– Space partitioning (dedicated DRAM banks, cache partition) improves performance isolation – But not perfect: memory bus contention, MSHR, …

• Things to consider

– Multichannel, NUMA systems. – Complex addressing schemes in modern DRAM controllers

110

https://github.com/heechul/palloc

PALLOC in Linux

111

Kernel code

kmalloc

Arbitrary size objects

SLAB allocator

Multiple fixed-sized object caches

PALLOC

vmalloc

(large) non-physically contiguous memory

Page Fault

• When a virtual address can not be translated

to a physical address, MMU generates a trap to the OS

• Page fault handling procedure

– Step 1: allocate a free page frame – Step 2: bring the stored page on disk (if necessary) – Step 3: update the PTE (mapping and valid bit) – Step 4: restart the instruction

112

Page Fault Handling

113

Demand Paging

114

Starting Up a Process

115

Unmapped pages

Code Data Heap Stack

Starting Up a Process

116

Access next instruction

Code Data Heap Stack

Starting Up a Process

117

Page fault

Code Data Heap Stack

Starting Up a Process

118

OS 1) allocates free page frame 2) loads the missed page from the disk (exec file) 3) updates the page table entry

Code Data Heap Stack

Starting Up a Process

119

Code Data Heap Stack

Over time, more pages are mapped as needed

Page Fault Handling in Linux

• __handle_mm_fault (mm/memory.c)

– handle_pte_fault

• do_anonymous_page

– pte_alloc(vma->mm, .., fe->address) – page = alloc_zeroed_user_highpage_movable » alloc_pages_nodemask

• alloc_pages_nodemask (mm/page_alloc.c)

– buffered_rmqueue

__rmqueue_smallest

120

Simplified Pseudocode

121

rmqueue_smallest

ph = ph_from_subsys(current->cgroups->subsys[palloc_cgrp_id]); cmap = ph->cmap; if (order == 0) { page = palloc_find_cmap(zone, cmap, 0, c_stat); if (page) return page; /* Search the entire list. Make color cache in the process */ for (current_order = 0; current_order < MAX_ORDER; ++current_order) { area = &(zone->free_area[current_order]); list_for_each(curr, tmp, &area->free_list[migratetype]) { palloc_insert(zone, page, current_order); page = palloc_find_cmap(zone, cmap, 0, c_stat)

122

Node, Zone

123

Node, Zone

• x86 PC

$ cat /proc/buddyinfo Node 0, zone DMA 1 1 1 1 1 1 1 0 1 1 3 Node 0, zone DMA32 4 5 6 8 7 7 8 7 9 6 696 Node 0, zone Normal 3390 17134 4920 1413 537 239 79 46 11 4 5659

• x86 server (NUMA)

$ cat /proc/buddyinfo Node 0, zone DMA 0 0 1 0 2 1 1 0 1 1 3 Node 0, zone DMA32 18761 13471 10910 7731 5786 2960 756 57 1 0 0 Node 0, zone Normal 129885 67082 9032 1217 68 10 8 1 0 0 0 Node 1, zone Normal 294117 197469 109366 84395 10394 818 7 4 3 0 0

• Pi3

$ cat /proc/buddyinfo Node 0, zone Normal 2975 263 3898 1816 66 30 16 11 4 2 71

124

Pagemap

• /proc/<pid>/pagemap

– 64bit value for each virtual page

• Bits 0-54 page frame number (PFN) if present
• …
• Bit 62 page swapped
• Bit 63 page present
• /proc/<pid>/maps

– Process’s mapped virtual memory regions

125

Pagetype

# pagetype -L -p `pidof bandwidth` voffset offset flags 10 2a6f6 color=1 __RU_lA____M______________________ 11 2a6f7 color=1 __RU_lA____M______________________ 21 1bf67 color=1 ___U_lA____Ma_b___________________ 22 26f73 color=0 ___UDlA____Ma_b___________________ d3e 251c7 color=1 ___U_lA____Ma_b___________________ 769de 32d13 color=0 ___UDlA____Ma_b___________________ 769df 31ebe color=3 ___UDlA____Ma_b___________________ 769e0 31a4d color=3 ___UDlA____Ma_b___________________ 769e1 20c74 color=1 ___U_lA____Ma_b___________________ 769e2 285ae color=3 ___UDlA____Ma_b___________________ 769e3 313f5 color=1 ___U_lA____Ma_b___________________ 769e4 154b7 color=1 ___U_lA____Ma_b___________________ 769e5 1fa36 color=1 ___U_lA____Ma_b___________________ 769e6 7945 color=1 ___U_lA____Ma_b___________________

126

Virtual page number (<<12) Physical page frame number (<<12) Page color page table entry flag
