SLIDE 1
Melanie Palmer, Rob Sullivan, John Bilberry
LA-UR-13-25961
Overview
Introduction Test Method and Materials Results Conclusion Future Work Questions
LA-UR-13-25961
Melanie Palmer, Rob Sullivan, John Bilberry LA-UR-13-25961 Overview - - PowerPoint PPT Presentation
Melanie Palmer, Rob Sullivan, John Bilberry LA-UR-13-25961 Overview - - PowerPoint PPT Presentation
Melanie Palmer, Rob Sullivan, John Bilberry LA-UR-13-25961 Overview Introduction Test Method and Materials Results Conclusion Future Work Questions LA-UR-13-25961 Software Defined Networking Separate the
SLIDE 2
SLIDE 3
Software Defined Networking
Separate the data plane and the
control plane
Software layer between hardware
and admin
Virtual networks within a physical
network
LA-UR-13-25961
SLIDE 4
OpenFlow
Open source SDN Hardware management on a single
platform
Exploits a common set of functions
found on most switches
OpenFlow Protocol
Flow table Actions
LA-UR-13-25961
SLIDE 5
Controller
Management software for network Communicates via a secure channel Push and remove flows Determine actions for undefined flows
LA-UR-13-25961
SLIDE 6
Networks for Security
User Switch Network 2 Network 1
- User job in Node 1
- If User accesses Node 2
- Redirect to Security
Node
Security Node Controller
Rule 1 Allow access to Network 1 Rule 2 Redirect to Security Node if access to Network 2 is attempted LA-UR-13-25961
SLIDE 7
Networks for Security
User Network 2 Network 1
Rule 1 Allow access to Network 1 Rule 2 Redirect to Security Node if access to Network 2 is attempted
Security Node Controller Switch
LA-UR-13-25961
SLIDE 8
Melanie Palmer
LA-UR-13-25961
SLIDE 9
Objective
Performance Reliability Scalability
LA-UR-13-25961
SLIDE 10
Materials
Our Cluster
Seven node CentOS 6.4
Arista 7050S
OpenFlow 1.0 EOS 4.10.4
Floodlight 0.9
Open source Widely used in
industry
Java based
LA-UR-13-25961
SLIDE 11
Test Suite
Load Test
Performance Reliability
LA-UR-13-25961
SLIDE 12
Test Suite
Load Test
Start T Test
TCPDu Dump Start 1 10 Sections ns Inc Increme ment nt Ping ngs/Sec Fini nish h
Start Tr Traffic Cha hang nge Flo lows
Inc Increme ment nt Flo lows/Sec
Fini nish h
St Start
Tests
Sections
Timing Limit Traffic Limit
LA-UR-13-25961
SLIDE 13
Load Test
Controller Node C Node B Node A Rule 1: Connect A and B Rule 2: Drop Anything to C Switch LA-UR-13-25961
SLIDE 14
Load Test
Controller Node C Node B Node A Rule 1: Connect A and C Rule 2: Drop Anything to B Switch LA-UR-13-25961
SLIDE 15
Test Suite
Load Test Speed Test
Scalability Performance
LA-UR-13-25961
SLIDE 16
Test Suite
Load Test Speed Test
Start Test TCPDump to File Send Traffic to Node C Change Flow
LA-UR-13-25961
SLIDE 17
Speed Test
Controller Node C Node A Rule 1: Connect A and C Switch LA-UR-13-25961
SLIDE 18
Speed Test
Controller Node C Node A Rule 1: Drop Node C Switch LA-UR-13-25961
SLIDE 19
Test Suite
Load Test Speed Test Analysis Program
Failure! Expected Behavior
LA-UR-13-25961
SLIDE 20
Test Suite
Load Test Speed Test Analysis Program
Stage 1 - Extracts
○ Error rate ○ Flow change speed
Stage 2 - Analyzes
○ Averages data ○ Standard deviations
Failure!
LA-UR-13-25961
SLIDE 21
Rob Sullivan
LA-UR-13-25961
SLIDE 22
Load Test Results
2 4 6 8 10 12 14 16 0.1 0.2 0.3 0.6 1.2 2.3 4.3 7.9 13.9 21.9 31.4 40.0 45.8 51.2 53.5 Error (%) Flows per Second
Flow Push Error Rate
250 500 750
Pings/Second
LA-UR-13-25961
SLIDE 23
Speed Test Results
2 4 6 8 10 12 14 16
100 pings/s
Milliseconds
200 pings/s 300 pings/s 400 pings/s 600 pings/s 700 pings/s 800 pings/s 900 pings/s 1000 pings/s 500 pings/s
LA-UR-13-25961
SLIDE 24
Problems
OpenFlow 1.0 Volume and nature of
data
Human error Imprecision of some test
methods
Meaningful packet
redirection
LA-UR-13-25961
SLIDE 25
LA-UR-13-25961
SLIDE 26
Will OpenFlow Work?
Allows software
reconfiguration of networks
Easy administration Flows can be reliably
pushed up to a measurable rate
Flow push failure is
low even at high push rates
OpenFlow v. 1.0
inadequacies
Hardware specific
limits
Potential security
issues
Controller can get
- verwhelmed
LA-UR-13-25961
SLIDE 27
Future Work
OpenFlow 1.1 Security Controllers and hardware Scale
LA-UR-13-25961
SLIDE 28
Acknowledgements
Instructors – Dane Gardner and Matthew Broomfield (T.A.) Mentors – Kyle Lamb (HPC-3) and Ben McClelland (HPC-5) Special Thanks: Los Alamos National Laboratory – Gary Grider, Josephine Olivas, Carolyn Connor, Scott Robbins and Carol Hogsett New Mexico Consortium – Ann Kuiper PRObE – Andree Jacobson Our Schools: University of Texas at El Paso New Mexico Institute of Mining and Technology Michigan Technological University
LA-UR-13-25961
SLIDE 29
Your turn!
LA-UR-13-25961
