Meeting 20/01/2010 - Outcome

  • PVSS servers (PVSS project + Linux System)
  • + create a fwSystemOverview project on TN
  • + configure several UNICOS production machines to be monitored
  • Central PLC agent
  • + update code to be Network independent
  • + integrate a DIM publication
  • study a CMW publication
  • study message publication via [YAMI, JAPC, JMS - DIAMON]
  • Direct PLC agent
  • + study a direct PVSS link with SNMP - no central agent technology
  • + ask SIEMENS - Diagnostic driver (openLab)
  • develop a SCHNEIDER Diagnostic driver
  • FEC agent
  • + deploy an "ICE agent" (FMC or CLIC or other…) in the FEC – use the CMW publication
  • study message publication via [YAMI, JAPC, JMS - DIAMON]
slide-3
SLIDE 3

PVSS servers (PVSS project + Linux System) + create a fwSystemOverview project on TN + configure several UNICOS production machines to be monitored

Advances:

New fwSystemOverview component released FMC PVSS component updated Trending script developed (=> dashboard) New Linux server installed on TN (cs-ccr-moni) Account in dbabco DB and schema created (=> configuration)

Pending:

TN DB Oracle account for archived data FMC agent installed in a TN Linux server (cs-ccr-wic01) Creation and Configuration of the fwSystemOverview project

slide-4
SLIDE 4

Central PLC agent + update code to be Network independent + integrate a DIM publication

  • study a CMW publication
  • study message publication via [YAMI, JAPC, JMS - DIAMON]

Advances (Fernando):

Compilation on GPN without DIAMON libs succeeded DIM server integration done Prototype of PVSS interface (dpN and panel) to read the PLC info

done

Pending:

Complete the integration of DIM PLC S7 agent Development of the PVSS interface (linked to System Integrity ?)

slide-5
SLIDE 5

PLC info into fwSystemOverview

Schneider PLC agent DIM DNS PVSS - fwSystemOverview

Archives Configuration

PLC PLC PLC PLC Siemens PLC agent PLC PLC PLC PLC

DIM

PLC PLC PLC UI

CMW

DIAMON PLC PLC PLC UI

slide-6
SLIDE 6

Direct PLC agent () + study a direct PVSS link with SNMP - no central agent technology + ask SIEMENS - Diagnostic driver (openLab)

  • develop a SCHNEIDER Diagnostic driver

Advances:

SNMP doesn’t provide CPU info for S7 PLCs (Brice) SNMP very limited for Schneider PLCs (Jean Michel) Schneider supplied to the CERN the syntax for the

diagnostic requests (Jean Michel)

Siemens not closed to provide lib for the diagnostic

(Renaud)

slide-7
SLIDE 7

FEC agent + deploy an "ICE agent" (FMC or CLIC or other…) in the FEC – use a CMW publication

  • study message publication via [YAMI, JAPC, JMS - DIAMON]

Not yet explored
