Mediterranean Sea Italy The Mediterranean Sea has an average depth of 1,500 metres and is home to some of the worlds busiest shipping routes. These ships often carry hazardous cargo, which could result in serious harm to the environment if
SLIDE 2
SLIDE 3
To help mitigate this threat of environmental damage, the Italian government created a Ocean Data Acquisition System (ODAS) buoy network in 1989. With the requirement of updating the buoys in 2001, the Italian government became aware of considerable technological advances that had been made with new buoys to reduce the cost of gathering data and to make the data more useful to a broader audience.
SLIDE 4
Requirements
» Provide significant value for the coastal engineer and marine scientist » Be cost-effective » Transmit data every half hour from each station via VHF telemetry
SLIDE 5
Requirements
Collect data on the following parameters:
Meteorological
» wind speed » wind direction » wind gust » air temperature » barometric pressure » relative humidity
Water
» sea surface temperature » significant and maximum wave height » wave period and direction
Position (GPS)
» Latitude, longitude
SLIDE 6
AXYS Technical Solution
TRIAXYSTM Directional Wave Buoy TRIAXYS-WatchKeeperTM Buoy
Chosen for:
» Excellent solid-state sensors » Photovoltaic solar power & rechargeable batteries » Ease of handling » Data logging capacity » WatchCircle Alarm » Relative lightweight » Cost-effective » Low maintenance costs » Superior customer support
SLIDE 7
AXYS Technical Solution
TRIAXYSTM Directional Wave Buoy
» 0.9m diameter rugged, lightweight data collection buoy » Uses solar power technology to collect, process, and store wave data » Accurately measures directional waves »Transmits wave information to a shore base receiving station using VHF radio telemetry
SLIDE 8
AXYS Technical Solution
TRIAXYS-WatchKeeperTM Buoy
» 1.7m diameter polyethylene data collection buoy » Low operational costs » Designed for deployments in coastal areas, lakes, reservoirs and rivers » Expandable to allow new sensors
SLIDE 9
In 2001, 25 TRIAXYSTM Directional Wave buoys were selected by the Italian government and subsequently delivered and deployed by the AXYS Field Service Team.
AXYS Technical Solution
TRIAXYS buoy deployed off the coast of CapoCaccia Sardinia, Italy
SLIDE 10
In 2009, the Italian government awarded AXYS a contract to design, build, deliver and deploy 17 TRIAXYS- WatchKeeperTM buoys
- ver five months (July-
November).
AXYS Technical Solution
SLIDE 11
These new buoys are programmed for future expansion; modules to accept sensors such as CT (conductivity and temperature) and current profiling are built-in and will allow the Italian Government to scale up as their program needs change.
AXYS Technical Solution
SLIDE 12
Deployment
» Deployment of the first 3 buoys was carried out in September 2009. » The remaining buoys were deployed in November 2009 and January 2010.
SLIDE 13
Data Management & Display
AXYS Data Management System (DMS)
» Two-way command and control
- f data, station management and
remote diagnostics » SQL database archival
WebViewTM Data Display
» Internet access to all transmitted data, graphing and data export
AXYS WebViewTM Display Software
View live data at: http://www.envirtech.org/ron.htm
SLIDE 14
Benefits
Increased knowledge of local marine conditions
Port authorities, fishing fleets, marine weather forecasters, and coastal zone managers can now retrieve current weather information from the network of TRIAXYSTM and TRIAXYS-WatchKeeperTM buoys.
SLIDE 15
Benefits
Better Decision-Making
Port operators now have information on wave and wind conditions which improves vessel traffic management in busy local waterways.
SLIDE 16
Benefits
Vessel Captains and other mariners in the Mediterranean Sea around the coasts of Italy can now make better decisions, such as deciding the best and safest route to travel.
Better Decision-Making
SLIDE 17
Benefits
Coastal engineers now have access to accurate data that can be analyzed for scientific marine applications.
Better Decision-Making
