MCPET Microcellular Polyethylene Terephthalate MCPET IS A HIGHLY REFLECTIVE FOAM MATERIAL FOR LIGHTING APPLICATIONS MCPET offers several advantages over other reflective material and is widely recognised as the number one material for

slide-1
SLIDE 1

MCPET

Microcellular Polyethylene Terephthalate

slide-2
SLIDE 2

MCPET IS A HIGHLY REFLECTIVE FOAM MATERIAL FOR LIGHTING APPLICATIONS

MCPET offers several advantages over

  • ther reflective material and is widely

recognised as the number one material for reflectivity and versatility. The key to the material is its microcellular structure which ensures high reflectivity ratios, both overall and diffuse.

Compared to BaSo4 Barium Sulphate

slide-3
SLIDE 3

Unlike aluminium reflectors MCPET reflects light at different levels

  • Irregular cell structure reflects the light at different angles
  • The light reflects from the surface of the material and from within

Resulting in a far greater level of diffuse reflectivity

REFLECTIVITY

slide-4
SLIDE 4

ADVANTAGES

slide-5
SLIDE 5

ADVANTAGES OF USING MCPET

High Overall reflectivity - better performance High diffuse reflectivity - shallow/homogeneous Isolation - no requirement to earth reflector. Easy installation Lightweight Reliability and durability Securing – cables

slide-6
SLIDE 6

ADVANTAGES OF USING MCPET

Overall cost reduction Non harmful material Recyclable Thermal deformation = 170°C Melting temperature = 240°C Easier application than aluminium reflectors Equal or higher reflectivity can be achieved with simpler shapes

slide-7
SLIDE 7

ADVANTAGES OF USING MCPET

Holds curved shape under pressure due to rigidity of material Wires can be secured using MCPET

slide-8
SLIDE 8

PROCESSING

slide-9
SLIDE 9

PROCESSING OPTIONS

Furukawa work with a number of different converters who hold their own stock and can adapt the material to meet the customer's requirements Die cut Adhesive backing and die cut Fold (crease, laser or perforate) Origami Thermoforming

slide-10
SLIDE 10

EXAMPLES OF MCPET APPLICATIONS

High bay Downlight Base Light

slide-11
SLIDE 11
slide-12
SLIDE 12
slide-13
SLIDE 13

THERMOFORMING

slide-14
SLIDE 14

TYPICAL FORMING AND CUTTING TECHNIQUE

slide-15
SLIDE 15

MCPET OR MCPOLYCA?

  • Lower cost
  • Higher reflectivity
  • Available with or without

UV protection

  • High temperature resistant
  • Greater rigidity
  • Greater base to peak ratio
  • Fast forming time
slide-16
SLIDE 16

ABILITY TO MAINTAIN SHAPE UNDER HIGH TEMPERATURES REFLECTIVE FILMS HAVE A GREATER RATE OF SHRINKAGE

slide-17
SLIDE 17
slide-18
SLIDE 18
slide-19
SLIDE 19
slide-20
SLIDE 20

GRADES

slide-21
SLIDE 21

PRODUCT LINEUP

GRADE

RB 1mm M4 0.5 M4 1mm M2 0.5mm M2 1mm MCPOLYCA 1mm

Structure Std sizes (mm) 600 x 1200 600 x 1500 600 x 1200 615 x 1510 600 x 1200 615 x 1510 600 x 1200 600 x 1500 600 x 1200 600 x 1500 700 x 1500 UV protection Built-in None None Built-in Built-in Built-in Reflectivity 99% overall 96% diffuse 101.1% overall 100.8% diffuse 101.1% overall 100.8% diffuse 99.8% overall 99.7% diffuse 100.1% overall 99.9% diffuse 98% overall 98% diffuse Characteristics

  • Versatile
  • Good rigidity
  • Older grade
  • Trusted in the

industry

  • Highest

reflectivity

  • Highly diffusive
  • Lowest cost
  • Matt finish
  • Good rigidity
  • Highest

reflectivity

  • Highly diffusive
  • Lowest cost
  • Matt finish
  • Highly diffusive
  • Lowest cost UV
  • ption
  • Matt finish
  • Versatile
  • Good rigidity
  • Highly diffusive
  • Matt finish
  • Most versatile
  • Best results from

thermoforming

  • Highest cost

Thermoformable

✔ X ✔ X ✔ ✔

UL94 File No. E99693 HBF HBF HBF HBF HBF HBF
