Learning Probabilistic Graphical Parameter Estimation Models Max Likelihood for Log-Linear Models Daphne Koller Log-Likelihood for Markov Nets A B C Partition function couples the parameters No decomposition of likelihood No

SLIDE 1

Daphne Koller

Max Likelihood for Log-Linear Models

Probabilistic Graphical Models

Parameter Estimation Learning

SLIDE 2

Daphne Koller

Log-Likelihood for Markov Nets

Partition function couples the parameters

– No decomposition of likelihood – No closed form solution

B A C

SLIDE 3

Daphne Koller

20 40 60 80 100 120 140 160 180 200

20 40 60

B A C

Example: Log-Likelihood Function

SLIDE 4

Daphne Koller

Log-Likelihood for Log-Linear Model

SLIDE 5

Daphne Koller

The Log-Partition Function

Theorem: Proof:

SLIDE 6

Daphne Koller

The Log-Partition Function

Log likelihood function

– No local optima – Easy to optimize

Theorem:

SLIDE 7

Daphne Koller

Maximum Likelihood Estimation

Theorem: is the MLE if and only if

SLIDE 8

Daphne Koller

Computation: Gradient Ascent

Use gradient ascent:

– typically L-BFGS – a quasi-Newton method

For gradient, need expected feature counts:

– in data – relative to current model

Requires inference at each gradient step

SLIDE 9

Daphne Koller

Example: Ising Model

SLIDE 10

Daphne Koller

Summary

Partition function couples parameters in likelihood
No closed form solution, but convex optimization

– Solved using gradient ascent (usually L-BFGS)

Gradient computation requires inference at each

gradient step to compute expected feature counts

Features are always within clusters in cluster-

graph or clique tree due to family preservation

– One calibration suffices for all feature expectations

SLIDE 11

Daphne Koller

Max Likelihood for CRFs

Probabilistic Graphical Models

Parameter Estimation Learning

SLIDE 12

Daphne Koller

Estimation for CRFs

SLIDE 13

Daphne Koller

Example

f2(Ys, Yt) = 1(Ys = Yt) f1(Ys, Xs) = 1(Ys = g) Gs Yi Yj

average intensity of green channel for pixels in superpixel s

SLIDE 14

Daphne Koller

Computation

Requires inference at each gradient step
Requires inference for each x[m] at each

gradient step

MRF CRF

SLIDE 15

Daphne Koller

However…

For inference of P(Y | x), we need to

compute distribution only over Y

If we learn an MRF, need to compute

P(Y,X), which may be much more complex

f2(Ys, Yt) = 1(Ys = Yt) f1(Ys, Xs) = 1(Ys = g) Gs

average intensity of green channel for pixels in superpixel i

SLIDE 16

Daphne Koller

Summary

CRF learning very similar to MRF learning

– Likelihood function is concave – Optimized using gradient ascent (usually L-BFGS)

Gradient computation requires inference: one per

gradient step, data instance

– c.f., once per gradient step for MRFs

But conditional model is often much simpler, so

inference cost for CRF, MRF is not the same

SLIDE 17

Daphne Koller

MAP Estimation for MRFs, CRFs

Probabilistic Graphical Models

Parameter Estimation Learning

SLIDE 18

Daphne Koller

0.1 0.2 0.3 0.4 0.5

5 10

Gaussian Parameter Prior

SLIDE 19

Daphne Koller

0.1 0.2 0.3 0.4 0.5

5 10

Laplacian Parameter Prior

SLIDE 20

Daphne Koller

MAP Estimation & Regularization

L2 L1

log P( )

SLIDE 21

Daphne Koller

Summary

In undirected models, parameter coupling

prevents efficient Bayesian estimation

However, can still use parameter priors to

avoid overfitting of MLE

Typical priors are L1, L2

– Drive parameters toward zero

L1 provably induces sparse solutions

– Performs feature selection / structure learning
