1

BUSINESS MATHEMATICS

Linear programming

2

CONTENTS Mathematical programming Linear programming The LP-problem Old exam question Further study

3

MATHEMATICAL PROGRAMMING Mathematical programming ▪ refers to deciding on levels of decision variables in order to make an optimal decision Linear programming (LP) ▪ refers to a programming problem with a linear objective function Constraint (recall the Lagrangian) ▪ usually not all values of the decision variables are admissible

4

LINEAR PROGRAMMING Example: the army’s diet ▪ you must feed your soldiers ▪ you have a choice of food types

▪ potatoes, corn, meat, carrots, etc.

▪ each food type has nutritional characteristics

▪ calories, vitamins, proteins, etc.

▪ there is a minimum level of nutritional input (calories, vitamins, etc.) required to stay healthy and strong ▪ you want to select the cheapest diet (=composition of food types) that meets all constraints

5

LINEAR PROGRAMMING Example (continued) Decision variables: ▪ amount of potatoes, amount of corn, amount of meat, etc. Objective function: ▪ cost Constraints: ▪ minimum amount of calories, minimum amount of vitamins, etc. ▪ no negative amounts of potatoes, corn, etc.

6

LINEAR PROGRAMMING Example (continued) Symbols and variables: ▪ there are 𝑛 food types and 𝑜 nutritional elements ▪ food type 𝑗 contains nutritional element 𝑘 in an amount 𝑏𝑗𝑘 ▪ the minimum amount of nutritional element 𝑘 is 𝑑

𝑘 ′

▪ the amount of food type 𝑗 in the diet 𝑦𝑗 ▪ the price of food type 𝑗 is 𝑞𝑗

7

LINEAR PROGRAMMING Example (continued) Relationships ▪ cost: 𝐷 = σ𝑗=1

𝑛 𝑞𝑗𝑦𝑗

▪ nutritional value: 𝑑

𝑘 = σ𝑗=1 𝑛 𝑏𝑗𝑘𝑦𝑗

𝑘 = 1, … , 𝑜 Objective ▪ minimize cost 𝐷 Constraints ▪ staying healthy: 𝑑

𝑘 ≥ 𝑑 𝑘 ′

𝑘 = 1, … , 𝑜 ▪ “no nonsense”: 𝑦𝑗 ≥ 0 𝑗 = 1, … , 𝑛

8

THE LP-PROBLEM Formulation of the problem minimize 𝐷 = ෍

𝑗=1 𝑛

𝑞𝑗𝑦𝑗 subject to 𝑑

𝑘 = ෍ 𝑗=1 𝑛

𝑏𝑘𝑗𝑦𝑗 ≥ 𝑑

𝑘 ′

𝑘 = 1, … , 𝑜 and 𝑦𝑗 ≥ 0 𝑗 = 1, … , 𝑛

9

THE LP-PROBLEM In matrix notation ቐ minimize 𝐷 = 𝐪 ⋅ 𝐲 subject to 𝐝 = 𝐁𝐲 ≥ 𝐝′ and 𝐲 ≥ 𝟏

10

THE LP-PROBLEM Similar to previous constrained maximization/minimization problem But with: ▪ linear objective function ▪ many constraints ▪ inequality constraints ▪ non-negativity constraints Constraints define a feasible/admissable solution space Optimal solution is always on a vertex

11

GRAPHICAL SOLUTION Take: ▪ 𝑛 = 2:

▪ food 1 (meat); food 2 (potatoes) ▪ decision variables 𝑦1 (amount of meat); 𝑦2 (amount of potatoes)

▪ non-negativity constraints ▪ 𝑜 = 3:

▪ constraint 1 (calories); constraint 2 (vitamins); constraint 3 (proteins)

▪ iso-budget lines

12

GRAPHICAL SOLUTION

𝑦1 𝑦2 constraint 1 constraint 2 constraint 3 𝐷1 𝐷2 𝐷3 𝐷𝑛𝑗𝑜

13

NON-GRAPHICAL SOLUTION When 𝑛 > 2 Dedicated algorithm ▪ Simplex method ▪ in Excel Solver

Use “Simplex LP” for linear programming problems Use “GRG Nonlinear” or “Evolutionary” for other problems

14

OLD EXAM QUESTION 10 December 2014, Q1e

15

OLD EXAM QUESTION 24 March 2016, Q2c

16

FURTHER STUDY Sydsæter et al. 5/E 17.1 Tutorial exercises week 6 Linear programming1 Linear programming2
