Mask R-CNN OBJECT INSTANCE SEGMENTATION AND HUMAN POSE ESTIMATION Kaiming He Georgia Gkioxari Piotr Dollr Ross Girshick RESEARCH SCIENTIST POSTDOC RESEARCH SCIENTIST RESEARCH SCIENTIST FACEBOOK AI RESEARCH (FAIR) Classic Computer Vision

SLIDE 1

OBJECT INSTANCE SEGMENTATION AND HUMAN POSE ESTIMATION

RESEARCH SCIENTIST POSTDOC RESEARCH SCIENTIST

Kaiming He Georgia Gkioxari Piotr Dollár

Mask R-CNN

RESEARCH SCIENTIST

Ross Girshick

FACEBOOK AI RESEARCH (FAIR)

SLIDE 2

Classic Computer Vision Problems

Image classification

✓boat ✓person

Source: PASCAL Dataset

SLIDE 3

Classic Computer Vision Problems

Image classification

✓boat ✓person

Object detection

Source: PASCAL Dataset

SLIDE 4

Semantic Segmentation

person

Semantic segmentation

(pixel-level classification)

Source: PASCAL Dataset

SLIDE 5

The Instance Segmentation Task

person

Person 1 Person 2 Person 3 Person 4 Person 5

Semantic segmentation

(pixel-level classification)

Instance segmentation

(pixel-level detection)

Our task

Source: PASCAL Dataset

SLIDE 6

Source: COCO Dataset

SLIDE 7

Source: DAVIS Dataset

SLIDE 8

Mask R-CNN

Mask R-CNN
Object instance segmentation
Human pose estimation
Role of Caffe2 in our research
Conclusions

TALK OUTLINE

SLIDE 9

SOURCE: GIRSHICK, DONAHUE, DARRELL, MALIK. RICH FEATURE HIERARCHIES FOR ACCURATE OBJECT DETECTION AND SEMANTIC SEGMENTATION. CVPR 2014

REGION-BASED CONVOLUTION NEURAL NETWORK

Object Detection: R-CNN

Image Per-region classification by a CNN Region proposals (External algorithm)

SLIDE 10

SOURCE: GIRSHICK, DONAHUE, DARRELL, MALIK. RICH FEATURE HIERARCHIES FOR ACCURATE OBJECT DETECTION AND SEMANTIC SEGMENTATION. CVPR 2014

REGION-BASED CONVOLUTION NEURAL NETWORK

Object Detection: R-CNN

CNN

Class/box

CNN

Class/box

CNN

Class/box

CNN

Class/box

Per-region classification by a CNN Region proposals (External algorithm) Image

SLIDE 11

SOURCE: GIRSHICK. FAST R-CNN. ICCV 2015

A SHARED CNN BODY

Fast R-CNN

Class/box

CNN applied to entire image RoIPool op

Class/box Class/box

Shared region-wise subnetwork External region proposal algorithm (same as R-CNN)

SLIDE 12

SOURCE: REN, HE, GIRSHICK,SUN. FASTER R-CNN: TOWARDS REAL-TIME OBJECT DETECTION WITH REGION PROPOSAL NETWORKS. NIPS 2015

REGION PROPOSAL NETWORK

Faster R-CNN

Class/box

RoIPool op

Class/box Class/box

Shared region-wise subnetwork In-network region proposals from RPN CNN applied to entire image

SLIDE 13

Mask R-CNN for Instance Segmentation

An extension of Faster R-CNN
Surprisingly simple
Fast: 200 ms / im
Accurate: state of the art on COCO

OVERVIEW

SLIDE 14

Mask R-CNN for Instance Segmentation

Faster R-CNN Region-wise segmentation subnetwork CNN applied to entire image Mask “head” RoIAlign

SLIDE 15

Mask R-CNN results on COCO

SLIDE 16

Mask R-CNN results on COCO

SLIDE 17

Mask R-CNN results on COCO

SLIDE 18

Quantitative Results

backbone mask AP MNC ResNet-101-C4 24.6 FCIS w/ OHEM ResNet-101-C5-dilated 29.2 FCIS+++ w/ OHEM ResNet-101-C5-dilated 33.6 Mask R-CNN ResNet-101-C4 33.1 Mask R-CNN ResNet-101-FPN 35.7 Mask R-CNN ResNeXt-101-FPN 37.1

2015 COCO winner 2016 COCO winner

[seconds per image]

Our 200ms version

SLIDE 19

Mask R-CNN for Human Pose Estimation

Keypoint = 1-hot mask
Human pose = 17 keypoints
Represent pose as 17 masks

OVERVIEW

SLIDE 20

Mask R-CNN results on COCO

SLIDE 21

Mask R-CNN results on COCO

SLIDE 22

Mask R-CNN results on COCO

SLIDE 23

Mask R-CNN results on COCO

SLIDE 24

Quantitative Results

keypoint AP CMU-Pose+++ 61.8 G-RMI [w/ extra data] 62.4 Mask R-CNN [keypoint-only] 62.7 Mask R-CNN [keypoint & mask] 63.1

2016 COCO winner

[seconds per image]

Our 200ms version

SLIDE 25

Caffe2 Accelerated Research

SLIDE 26

Caffe2 Object Detection Platform

Early alpha users starting in May 2016
Ported py-faster-rcnn from Caffe to Caffe2
Key design choices
Flexible framework for implementing object detection models
Parallelize data loading with forward/backward computation

RAPID IDEA ITERATION IS A KEY ENABLING FACTOR IN RESEARCH

SLIDE 27

Caffe2 Object Detection Platform

Sync SGD with 8 GPUs [Tesla M40] in a BigSur server
Rapid prototyping of Mask R-CNN models in 8-12 hours
SOTA Mask R-CNN models train in 44 hours
Previous systems: ~ 4 days training time [experience from

MSRA]

RAPID IDEA ITERATION IS A KEY ENABLING FACTOR IN RESEARCH

SLIDE 28

From Research to Mobile with Caffe2

SLIDE 29

Conclusions

Simple and effective
Fast inference
Box, mask, and pose all-in-one network and method
Caffe2 enables extremely fast prototyping, critical to our

success

SLIDE 30
