` M. Isachenkov, I.K., V. Schomerus, arXiv: 1308.XXXX Coset approach to the Luttinger Liquid Ingo Kirsch DESY Hamburg, Germany Gauge/Gravity Duality 2013 Max Planck Institute for Physics, 29 July to 2 Aug 2013

Coset approach to the Luttinger Liquid Luttinger Liquid • Electron transport in conductors is usually well-described by Fermi-liquid theory (d>1) • BUT d=1: Electrons in a one-dimensional system form a quantum liquid which can be described as a Luttinger liquid rather than by Landau's Fermi-liquid theory • Fermi surface but no weakly-coupled quasi-particles above FS Luttinger relation • Experimentally realized e.g. in quantum wires/carbon nanotubes carbon nanotube (source: wiki) Vertically aligned Carbon Nanotubes by using a photolithography method (source: Dept. of Electronics U. York) 2 Gauge/Gravity Duality, MPI Munich 2013 -- Ingo Kirsch

Coset approach to the Luttinger Liquid Luttinger Liquid and matrix cosets Gopakumar-Hashimoto-Klebanov-Sachdev-Schoutens (2012): • UV: 2d SU(N) gauge theory coupled to Dirac fermions 3 Gauge/Gravity Duality, MPI Munich 2013 -- Ingo Kirsch

Coset approach to the Luttinger Liquid Luttinger Liquid and matrix cosets Gopakumar-Hashimoto-Klebanov-Sachdev-Schoutens (2012): • UV: 2d SU(N) gauge theory coupled to Dirac fermions • IR: effective low-energy theory flows to 2d coset CFT: emergent SUSY in the IR - not present in the UV theory! 3 Gauge/Gravity Duality, MPI Munich 2013 -- Ingo Kirsch

Coset approach to the Luttinger Liquid Luttinger Liquid and matrix cosets Gopakumar-Hashimoto-Klebanov-Sachdev-Schoutens (2012): • UV: 2d SU(N) gauge theory coupled to Dirac fermions • IR: effective low-energy theory flows to 2d coset CFT: emergent SUSY in the IR - not present in the UV theory! • coset studied only for N=2, 3: equivalence to minimal models: • What can we do (no relation to minimal models)? 3 Gauge/Gravity Duality, MPI Munich 2013 -- Ingo Kirsch

Coset approach to the Luttinger Liquid Overview Outline: I. Motivation: Luttinger Liquid II. Matrix coset theories III. Partition function Z N (for higher N ) IV. Spectrum of primary fields V. Chiral ring of chiral primaries Conclusions 4 ETH Zurich, 30 June 2010 Gauge/Gravity Duality, MPI Munich 2013 -- Ingo Kirsch

Coset approach to the Luttinger Liquid Example: The partition function Z 3 ( N=3 ) Numerator partition function: 5 Gauge/Gravity Duality, MPI Munich 2013 -- Ingo Kirsch

Coset approach to the Luttinger Liquid Example: The partition function Z 3 ( N=3 ) Numerator partition function: Denominator partition function: D-type modular invariant of the type 5 Gauge/Gravity Duality, MPI Munich 2013 -- Ingo Kirsch

Coset approach to the Luttinger Liquid Example: The partition function Z 3 ( N=3 ) Numerator partition function: Denominator partition function: D-type modular invariant of the type Coset partition function: 5 Gauge/Gravity Duality, MPI Munich 2013 -- Ingo Kirsch

Coset approach to the Luttinger Liquid Example: The partition function Z 3 ( N=3 ) Numerator partition function: Denominator partition function: D-type modular invariant of the type Coset partition function: 5 Gauge/Gravity Duality, MPI Munich 2013 -- Ingo Kirsch

Coset approach to the Luttinger Liquid Example: The partition function Z 3 ( N=3 ) It is possible to write Two successive decompositions: i) decomposition of SO(16) 1 characters into characters of SO(8) 1 x SO(8) 1 : ii) decomposition of SO(8) 1 characters into characters of SU(3) 3 branching the characters of SO(16) 1 into those of SU(3) 6 : 6 Gauge/Gravity Duality, MPI Munich 2013 -- Ingo Kirsch

Coset approach to the Luttinger Liquid Example: The partition function Z 3 ( N=3 ) Result for partition function Z 3 : where and 7 Gauge/Gravity Duality, MPI Munich 2013 -- Ingo Kirsch

Coset approach to the Luttinger Liquid Partition function Z N (general N ) We constructed an expression for the coset partition function Z N : are branching functions: 8 Gauge/Gravity Duality, MPI Munich 2013 -- Ingo Kirsch

Coset approach to the Luttinger Liquid Bouwknegt-McCarthy-Pilch formula Bouwknegt-McCarthy-Pilch (1991) The branching functions are computed using a formula for diagonal cosets. This gives the q -expansion of . Spectrum: 9 Gauge/Gravity Duality, MPI Munich 2013 -- Ingo Kirsch

Coset approach to the Luttinger Liquid N=2,3 : Partition function Z N and supersymmetry Goal: Compute the coset partition function Z N in terms of the branching functions and then rewrite it in terms of characters. Example: N=2 10 Gauge/Gravity Duality, MPI Munich 2013 -- Ingo Kirsch

Coset approach to the Luttinger Liquid N=2,3 : Partition function Z N and supersymmetry Goal: Compute the coset partition function Z N in terms of the branching functions and then rewrite it in terms of characters. Example: N=2 10 Gauge/Gravity Duality, MPI Munich 2013 -- Ingo Kirsch

Coset approach to the Luttinger Liquid N=2,3 : Partition function Z N and supersymmetry Goal: Compute the coset partition function Z N in terms of the branching functions and then rewrite it in terms of characters. Example: N=2 cf. w/ characters 10 Gauge/Gravity Duality, MPI Munich 2013 -- Ingo Kirsch

Coset approach to the Luttinger Liquid N=4, 5 : The partition function Z N (q) For N>3 it is difficult to rewrite Z N in terms of characters. BUT: Still possible to write Z N = Z N (q) using BMP formula 11 Gauge/Gravity Duality, MPI Munich 2013 -- Ingo Kirsch

Coset approach to the Luttinger Liquid N=4, 5 : The partition function Z N (q) For N>3 it is difficult to rewrite Z N in terms of characters. BUT: Still possible to write Z N = Z N (q) using BMP formula Example : N=3 similarly Likewise, we found the q-expansions of Z 4 = Z 4 (q), Z 5 = Z 5 (q) by computing 700 (N=4) and 10292 (N=5) branching functions… 11 Gauge/Gravity Duality, MPI Munich 2013 -- Ingo Kirsch

Coset approach to the Luttinger Liquid Spectrum: coset elements and their conformal weights Parallel computing on DESY’s theory and HPC clusters N=2 N=3 12 Gauge/Gravity Duality, MPI Munich 2013 -- Ingo Kirsch

Coset approach to the Luttinger Liquid Spectrum: coset elements and their conformal weights Parallel computing on DESY’s theory and HPC clusters we also have N=5 ... N=4 12 Gauge/Gravity Duality, MPI Munich 2013 -- Ingo Kirsch

Coset approach to the Luttinger Liquid Chiral Ring A particular feature of superconformal field theories is the chiral ring of NS sector chiral primary fields. These fields form a closed algebra under fusion. Let’s identify the chiral primary fields ( h=Q ) by introducing charge into the branching functions (i.e. make them z -dependent) Example: N=3 13 Gauge/Gravity Duality, MPI Munich 2013 -- Ingo Kirsch

Coset approach to the Luttinger Liquid Chiral Ring Do the chiral primaries form a closed algebra under fusion? - Yes. For instance, for N=3 : Generator of the chiral ring (h=Q=1/6): Claim: Repeatedly act with x on the identity. This generates the chiral ring of NS chiral primary fields. 14 Gauge/Gravity Duality, MPI Munich 2013 -- Ingo Kirsch

Coset approach to the Luttinger Liquid Chiral Ring Visualization of the chiral ring by tree diagrams: An arrow represents the action of x on a field, e.g. OPE ( N=3 ) 15 Gauge/Gravity Duality, MPI Munich 2013 -- Ingo Kirsch

Coset approach to the Luttinger Liquid Chiral Ring Visualization of the chiral ring by tree diagrams: An arrow represents the action of x on a field, e.g. OPE ( N=3 ) 15 Gauge/Gravity Duality, MPI Munich 2013 -- Ingo Kirsch

Coset approach to the Luttinger Liquid Chiral Ring N=4, 5 : 16 Gauge/Gravity Duality, MPI Munich 2013 -- Ingo Kirsch

Coset approach to the Luttinger Liquid Chiral Ring N=4, 5 : In the large N limit, the number of chiral primaries is governed by the partition function p(6h) . 16 Gauge/Gravity Duality, MPI Munich 2013 -- Ingo Kirsch

Coset approach to the Luttinger Liquid Conclusions I discussed diagonal coset theories of the type Gopakumar et al. studied this space for N=2, 3 (by relating it to minimal models) Our method works in principle for general N : • general N: we derived the partition function Z N =Z N (b(q)), the branching functions b(q) can be computed using the BPM formula (needs a lot of computer power for higher N though) • N=2, 3 : we rewrote Z N in terms of characters • N=4, 5 : - we explicitly derived the q -expansion of Z N (up to some order) - we identified the chiral primary fields and - showed that they form a chiral ring under fusion Outlook (work in progress): • Large N limit + AdS dual description 17 Gauge/Gravity Duality, MPI Munich 2013 -- Ingo Kirsch
