M ETHANE E MISSIONS E STIMATES FROM O IL AND N ATURAL G AS P RODUCTION U SING A TMOSPHERIC M EASUREMENTS Anna Karion, Colm Sweeney, Eric Kort, Paul Shepson, Mackenzie Smith, M. Obie Cambaliza, Tegan Lavoie, Sonja Wolter, Stephen Conley, Gabrielle

slide-1
SLIDE 1

METHANE EMISSIONS ESTIMATES FROM OIL

AND NATURAL GAS PRODUCTION USING

ATMOSPHERIC MEASUREMENTS

Anna Karion, Colm Sweeney, Eric Kort, Paul Shepson, Mackenzie Smith,

  • M. Obie Cambaliza, Tegan Lavoie, Sonja Wolter, Stephen Conley,

Gabrielle Pétron, Tim Newberger, Scott Herndon, Tara Yacovitch, Chris Rella, Mike Hardesty, Alan Brewer, Jon Kofler

Photo: sunset over the Denton airport, by Sonja Wolter

slide-2
SLIDE 2

Why (continue to) study US oil and gas CH4 emissions?

 Methane (CH4) is the principal component of natural gas

and a powerful greenhouse gas (GWP 100 yrs = 28)

 Methane is released in fugitive emissions from oil and

natural gas production, processing, etc.

 Emissions of methane from natural and anthropogenic

sources are not well quantified (globally or regionally).

 Recent studies and overviews (Brandt et al., Science,

2014) show high emissions but they generally cover only a small fraction of US production.

NOAA Global Monitoring Division Annual Conference, May 21 2014

2

slide-3
SLIDE 3

So what are the CH4 emissions from natural gas?

1 2 3

1 2 3

% CH4 Leakage

Report

Distribution Transmission Processing Production

2013 2011 2010

2 4 6 8 10 12

2004 2009 Tg CH4/yr

Year

2010 Report 2011 Report 2013 Report

5 10 15

1 2 3

Tg CH4/yr

Report

Distribution Transmission Processing Production

2013 2011 2010 EPA Inventory of GHG Sources and Sinks

NOAA Global Monitoring Division Annual Conference, May 21 2014

3

slide-4
SLIDE 4

Mass Balance Approach for Emissions Estimation

∫ ∫

+ −

        ∆ =

b b z z air CH CH

dx dz n X V n

PBL gnd 4 4

cosθ 

Perpendicular wind speed Wind emissions Wind

Background CH4 Downwind CH4

CH4 flux Molar CH4 enhancement in PBL mixing height (PBL)

NOAA Global Monitoring Division Annual Conference, May 21 2014

4

slide-5
SLIDE 5

TEXas Methane EXperiment

NOAA Global Monitoring Division Annual Conference, May 21 2014

6

Barnett Shale: 7% of US gas production; one of top 3 shale plays in US

slide-6
SLIDE 6

Texas Methane Experiment

Phase I: March 2013

University of Colorado

NOAA/ESRL (GMD, CSD)

Picarro

Shell / Sanders Geophysics

Aerodyne

Penn State (Davis group) 

Phase II: October 2013

Purdue (Shepson group)

University of Michigan (Kort)

University of Cincinnati (Townsend-Small)

UC Irvine (Blake group)

University of Houston

West Virginia University

Duke

Princeton & UT Dallas

LI-COR

NOAA Global Monitoring Division Annual Conference, May 21 2014

7

slide-7
SLIDE 7

Texas Methane Experiment: Aircraft

Purdue Duchess Scientific Aviation Mooney

NOAA Global Monitoring Division Annual Conference, May 21 2014

8

slide-8
SLIDE 8

19 Oct 2013

Upwind (Duchess) Downwind (Mooney)

NOAA Global Monitoring Division Annual Conference, May 21 2014

10

wind

slide-9
SLIDE 9

19 Oct 2013

CH4 C2H6

Methane (left) and ethane (right) in five separate downwind transects show consistency of plume. They also indicate that a portion of the methane enhancement does not correspond with an ethane enhancement.

5 downwind transects

NOAA Global Monitoring Division Annual Conference, May 21 2014

12

slide-10
SLIDE 10

NOAA Global Monitoring Division Annual Conference, May 21 2014

13

slide-11
SLIDE 11

Total CH4 Emission

NOAA Global Monitoring Division Annual Conference, May 21 2014

14

Mean of nine flights

slide-12
SLIDE 12

Attribution to oil and gas

NOAA Global Monitoring Division Annual Conference, May 21 2014

17

10172014 Oil producing wells Dry gas producing wells

slide-13
SLIDE 13

Ethane to Methane Ratio: 19 Oct 2013

NOAA Global Monitoring Division Annual Conference, May 21 2014

18

slide-14
SLIDE 14

Ethane to Methane Ratio: 19 Oct 2013

~10% ~2-3%

NOAA Global Monitoring Division Annual Conference, May 21 2014

19

slide-15
SLIDE 15

NOAA Global Monitoring Division Annual Conference, May 21 2014

20

Wells with Gas Production Gray dots = wells with gas production

slide-16
SLIDE 16

NOAA Global Monitoring Division Annual Conference, May 21 2014

21

Gray dots = wells with oil (liquids) production

slide-17
SLIDE 17

NOAA Global Monitoring Division Annual Conference, May 21 2014

22

Gray dots = wells with oil (liquids) production

slide-18
SLIDE 18

Correlations of C2H6 with CH4

NOAA Global Monitoring Division Annual Conference, May 21 2014

23

Survey Flight 10172013 Significant correlation No correlation

Use the sum of CH4 that does NOT correlate with C2H6 (blue) to establish contribution from biogenic sources: ~25%.

slide-19
SLIDE 19

Conclusions & Future Work

NOAA Global Monitoring Division Annual Conference, May 21 2014

24

 Methane emissions for several other basins are

going to be published in the next year

Barnett

Fayetteville, Haynesville, Marcellus (Peischl, in prep.)

Bakken, San Juan, Marcellus – upcoming measurements planned  Work is still needed to reconcile inventories with

estimates based on atmospheric measurements.

 More work is going to focus on attribution using

ethane (U Mich, Aerodyne) and 13CH4 (Picarro).

slide-20
SLIDE 20

NOAA Global Monitoring Division Annual Conference, May 21 2014

25

slide-21
SLIDE 21

Utah, 2012

Distance perpendicular to wind (km)

CH4 (ppb)

downwind upwind

Karion, A., C. Sweeney, et al. (2013). Methane emissions estimate from airborne measurements over a western United States natural gas field. Geophysical Research Letters.

NOAA Global Monitoring Division Annual Conference, May 21 2014

26

High emissions, but this field only represents ~1% of US production.

slide-22
SLIDE 22

Denver-Julesburg, May 2012

Pétron et al., 2014.

NOAA Global Monitoring Division Annual Conference, May 21 2014

27

slide-23
SLIDE 23

Summary of Results for O&G Emissions in the D-J Basin

28

  • 1. Top-down oil and gas emission estimates based on flight data in May

2012 are ~2 times larger than state inventory estimates for NMHCs and 7 times larger for the carcinogen benzene (C6H6).

  • 2. CH4 emissions are close to 3 times larger than an estimate based on

EPA GHGRP data. C6H6 CH4 NMHC cars Pétron et al., 2014

slide-24
SLIDE 24

Average Daily NG Production

5/22/2014

29

Barnett Shale natural gas comprises 7% of US total production.

slide-25
SLIDE 25

19 Oct 2013

NOAA Global Monitoring Division Annual Conference, May 21 2014

30

slide-26
SLIDE 26

27 March 2013

Methane (CH4) Ethane (C2H6)

NOAA Global Monitoring Division Annual Conference, May 21 2014

31

slide-27
SLIDE 27

27 March 2013

Methane (CH4) Ethane (C2H6)

CH4 but no C2H6 in this plume

NOAA Global Monitoring Division Annual Conference, May 21 2014

32

slide-28
SLIDE 28

27 March 2013

CH4 C2H6 CO

CH4 and C2H6 are both components of natural gas; CO is not.

Downwind Transect 1 Downwind Transect 2

NOAA Global Monitoring Division Annual Conference, May 21 2014

33

slide-29
SLIDE 29

27 March 2013

Downwind Transect 1

CH4 but no C2H6 in this plume

Downwind Transect 2 CH4 C2H6 CO

NOAA Global Monitoring Division Annual Conference, May 21 2014

34

slide-30
SLIDE 30

Average Daily NG Production

NOAA Global Monitoring Division Annual Conference, May 21 2014

35

slide-31
SLIDE 31

Well Count

NOAA Global Monitoring Division Annual Conference, May 21 2014

36
