Lunar Site Preparation and Outpost Setup Workshop October 20 & - - PowerPoint PPT Presentation

ASCE

Lunar Site Preparation and Outpost Setup Workshop

LUNAR SITE PLANNING WORKSHOP ASCE/NASA

October 20 & 21, 2009 Huntsville, AL

Implications of Geology for Construction

Doug Rickman

IMAGE IMAGE

American Society of Civil Engineers Aerospace Division, Space Engineering & Construction Committee p p g g NASA, Constellation Program Lunar Surface Systems, Habitation Team, MSFC Advanced Concepts Office

https://ntrs.nasa.gov/search.jsp?R=20090043187 2018-03-12T07:14:27+00:00Z

ASCE

Menu

LUNAR SITE PLANNING WORKSHOP ASCE/NASA

Basic Geology and Conclusions (Dessert First) Apollo Vistas and Interpretation (Cheese and Fruit) Minerals of the Moon with C i ith E i i M t i l (M i ) Comparisons with Engineering Materials (Main) P ti l C iti i l di C t (S ) Particle Composition, including Caveats (Soup)

2

Thin Sections of the Regolith (Appetizers)

ASCE

Simplified Summary of Lunar Geology

LUNAR SITE PLANNING WORKSHOP ASCE/NASA

Initial lunar rock (highlands) ~ norite.

Data

Subsequent basaltic volcanic (& other )flows. Hypervelocity impacts in a vacuum largely destroyed original rock d d d l t f l and produced a lot of glass. Resulting broken material covering surface = Regolith.

Conclusions

Regolith is NOT soil! Composition is relatively restricted compared to Earth materials Composition is relatively restricted compared to Earth materials. It is roughly equivalent to broken igneous rock plus glass.

ASCE

Particle Size

LUNAR SITE PLANNING WORKSHOP ASCE/NASA

Net result of continuing meteor bombardment.

Data

g Impacts both reduce particle size, shock weld existing particles and melt material. Surface of Moon is a mixture of fragments - Size range: nanoscopic to large blocks of rock. Mixture believed to be meters (kilometers?) deep everywhere Mixture believed to be meters (kilometers?) deep everywhere. For Apollo mission samples - typical average particle sizes from ~ 30 to 100 μm. typical average particle sizes from 30 to 100 μm.

Conclusions

The regolith commonly has very fine particle sizes.

4

Depth to bedrock is an almost meaningless concept.

ASCE

Sorting

LUNAR SITE PLANNING WORKSHOP ASCE/NASA

All natural Terrestrial materials made of particles show more or less

Data

All natural Terrestrial materials made of particles show more or less sorting based on size, shape and composition. This is due to interactions of fluid flow and gravity. There are no natural fluids on the Moon except for temporary There are no natural fluids on the Moon except for temporary

• ccurrences of molten glass.

Energy added to the lunar surface sufficient to cause particle motion will mix but not sort motion will mix but not sort.

Conclusions

For any reasonable sized sample of the regolith from the top few meters it is possible, and even probable to have particles of all size ranges and with any lunar component in the sample. g y p p Layering which affect mechanical properties does not exist.

ASCE

Particle Shape and Texture

LUNAR SITE PLANNING WORKSHOP ASCE/NASA

Particle shapes can be anything from perfect spheres to wildly

Data

p y g p p y formed pieces of splatter-welded material. The average aspect ratio of particles is estimated to be less than 0 5 0.5. Internally, the particles are commonly shattered. The affect on mechanical properties is totally unquantified.

Conclusions

Mechanical modeling of the regolith at the particle level is extremely problematic. Angular edges of the particles have not been mechanically

6

Angular edges of the particles have not been mechanically abraded or smoothed.

ASCE

General Conclusions

LUNAR SITE PLANNING WORKSHOP ASCE/NASA

The surface of the Moon is covered in regolith, which is NOT soil! The regolith is shattered igneous rock plus glass. The particles are unsorted, unweathered and not abraided. Modeling of the regolith at the level of individual particles will be very problematic. Modeling of the regolith, if successful for one area, will be g g , , successful for most other areas if variation in particle size is addressed.

7

ASCE

Apollo Vista 1

LUNAR SITE PLANNING WORKSHOP ASCE/NASA

A hill means? Lots of Lots of fine stuff

8

ASCE

Apollo Vista 2

LUNAR SITE PLANNING WORKSHOP ASCE/NASA

Note the lack of sorting

9

ASCE

Major Minerals

LUNAR SITE PLANNING WORKSHOP ASCE/NASA

Mineral Mohs

Spec G it

Chemical Composition Abundance Mineral Mohs

Gravity

Chemical Composition Abundance

Plagioclase 6.0-6.5 2.73 (Ca,Na)(Si,Al)4O8 A Olivine 6.5-7.0 4.39 (Mg,Fe)2SiO4 M Orthopyroxene 5.0-6.0 3.4 (Mg,Fe,Ca)2[Si2O6] M Clinopyroxene 5.0-6.0 3.4 (Mg, Fe)2[Si2O6] M Spinel 7.5-8.0 3.56 MgAl2O4 m - t Hercynite 7.5-8 3.93 Fe+2Al2O4 m - t Ulvospinel 5.5-6.0 4.7 TiFe+2

2O4

m - t p

2 4

Chromite 5.5 4.7 Fe+2Cr2O4 m - t Troilite 4 4.75 FeS t? Whitlockite 5 3.12 Ca9(Mg,Fe+2)(PO4)6(PO3OH) t? Apatite 5 3 19 Ca (PO ) (F Cl) t? Apatite 5 3.19 Ca5(PO4)3(F,Cl) t? Ilmenite 5.5 4.72 Fe+2TiO3 m Native Iron 4.5 7.87 Fe t

ASCE

LUNAR SITE PLANNING WORKSHOP ASCE/NASA

Spinel

From Rickman and Street, 2008

ASCE

Particle Composition

LUNAR SITE PLANNING WORKSHOP ASCE/NASA

Caveats: L d t f ti ( t i l 20 ) tl t ll Lunar dust fraction (material < 20μm) currently not well characterized. Some aspects may or may not be important, for example the presence of nanoscopic Fe or vapor deposited rims. R lith ( i ll ) i i l d ili t l Regolith (macroscopically) is minerals and silicate glass. A mineral is: a naturally occurring substance with a a naturally occurring substance, with a characteristic, limited chemical composition and a highly ordered atomic structure. Th f th f h i l’ ti i li it d AND Therefore the range of each mineral’s properties is limited AND a mineral’s properties are independent of source (lunar or terrestrial).

ASCE

Optical Scans of Thin Sections

LUNAR SITE PLANNING WORKSHOP ASCE/NASA

64002,6019 64001,6031

13

Data from Joint NASA/USGS/Intellection Study, 2008

ASCE

Particle Shapes and Textures 1

LUNAR SITE PLANNING WORKSHOP ASCE/NASA

6019 4002,6 64

14

Data from Joint NASA/USGS/Intellection Study, 2008

ASCE

Particle Shapes and Textures 2

LUNAR SITE PLANNING WORKSHOP ASCE/NASA

31 01,603 6400

15

Data from Joint NASA/USGS/Intellection Study, 2008

ASCE

Ditto

LUNAR SITE PLANNING WORKSHOP ASCE/NASA

31 01,603 6400

16

Data from Joint NASA/USGS/Intellection Study, 2008

ASCE

Agglutinates

LUNAR SITE PLANNING WORKSHOP ASCE/NASA

31 4001,603 64 20

17

Data from Joint NASA/USGS/Intellection Study, 2008

20µm

ASCE

Scale Invariance

LUNAR SITE PLANNING WORKSHOP ASCE/NASA

031 64001,6 6 10

18

10µm

Data from Joint NASA/USGS/Intellection Study, 2008
