Linux Performance Analysis and Tools Brendan Gregg Lead Performance Engineer brendan@joyent.com SCaLE11x @brendangregg February, 2013 Sunday, February 24, 13 Find the Bottleneck Operating System Hardware Applications DBs, all server

slide-1
SLIDE 1

Linux Performance Analysis and Tools

Lead Performance Engineer brendan@joyent.com

Brendan Gregg

@brendangregg

SCaLE11x

February, 2013

Sunday, February 24, 13

slide-2
SLIDE 2

Find the Bottleneck

Applications DBs, all server types, ... Block Device Interface Ethernet LVM IP ext3/... TCP/UDP VFS Sockets ZFS Disk Disk Port Port

Expander Interconnect I/O Bus Interface Transports

I/O Controller Network Controller I/O Bridge System Libraries Device Drivers Scheduler Virtual Memory System Call Interface

CPU Inter- connect Memory Bus

CPU 1 DRAM

Operating System Hardware Linux Kernel

Sunday, February 24, 13

slide-3
SLIDE 3

whoami

  • Lead Performance Engineer
  • Work/Research: tools, visualizations, methodologies
  • Was Brendan@Sun Microsystems, Oracle, now Joyent

Sunday, February 24, 13

slide-4
SLIDE 4

Joyent

  • High-Performance Cloud Infrastructure
  • Compete on cloud instance/OS performance
  • Public/private cloud provider
  • OS-Virtualization for bare metal performance (Zones)
  • Core developers of SmartOS and node.js
  • KVM for Linux guests

Sunday, February 24, 13

slide-5
SLIDE 5

SCaLE10x: Cloud Performance Analysis

  • Example perf issues, including new tools and visualizations:

http://dtrace.org/blogs/brendan/2012/01/30/performance-analysis-talk-at-scale10x/

Sunday, February 24, 13

slide-6
SLIDE 6

SCaLE11x: Linux Performance Analysis

Systems Performance

ENTERPRISE AND THE CLOUD Brendan Gregg Prentice Hall, 2013

  • The primary operating system for my next book:

(secondary is the OpenSolaris-illumos-based SmartOS)

Sunday, February 24, 13

slide-7
SLIDE 7

Agenda

  • Background
  • Linux Analysis and Tools
  • Basic
  • Intermediate
  • Advanced
  • Methodologies
  • Challenges

Sunday, February 24, 13

slide-8
SLIDE 8

Performance

  • Why do performance analysis?
  • Reduce IT spend – find and eliminate waste, find areas to

tune, and do more with less

  • Build scalable architectures – understand system limits

and develop around them

  • Solve issues – locate bottlenecks and latency outliers

Sunday, February 24, 13

slide-9
SLIDE 9

Systems Performance

  • Why study the operating system?
  • Find and fix kernel-based perf issues
  • 2-20% wins: I/O or buffer size tuning, NUMA config, etc
  • 2-200x wins: bugs, disabled features, perturbations causing

latency outliers

  • Kernels change, new devices are added, workloads scale, and

new perf issues are encountered.

  • Analyze application perf from kernel/system context
  • 2-2000x wins: identifying and eliminating unnecessary work

Sunday, February 24, 13

slide-10
SLIDE 10
  • System analysis can be top-down, or bottom-up:

Perspectives

Workload Application System Calls System Libraries Kernel Devices Workload Analysis Resource Analysis Operating System Software Stack

Developers Sysadmins

Sunday, February 24, 13

slide-11
SLIDE 11

Kernel Internals

  • Eventually you’ll need to know some kernel internals

Applications DBs, all server types, ... Block Device Int. Ethernet LVM IP ext3/... TCP/UDP VFS Sockets ZFS System Libraries Device Drivers Scheduler Virtual Memory System Call Interface Linux Kernel user-level kernel-level Operating System

Sunday, February 24, 13

slide-12
SLIDE 12

Common System Metrics

  • It’s also worth studying common system metrics (iostat, ...),

even if you intend to use a monitoring product. Monitoring products often use the same metrics, read from /proc.

$ iostat Linux 3.2.6-3.fc16.x86_64 (node104) 02/20/2013 _x86_64_ (1 CPU) avg-cpu: %user %nice %system %iowait %steal %idle 0.02 0.00 0.10 0.04 0.00 99.84 Device: tps kB_read/s kB_wrtn/s kB_read kB_wrtn vda 0.24 7.37 2.15 80735422 23571828 vdb 0.06 5.51 7.79 60333940 85320072

Sunday, February 24, 13

slide-13
SLIDE 13

Analysis and Tools

Sunday, February 24, 13

slide-14
SLIDE 14

Analysis and Tools

  • A quick tour of tools, to show what can be done
  • Then, some methodologies for applying them

Sunday, February 24, 13

slide-15
SLIDE 15

Analysis and Tools

Applications DBs, all server types, ... Block Device Interface Ethernet LVM IP ext3/... TCP/UDP VFS Sockets ZFS Disk Disk Port Port I/O Controller Network Controller I/O Bridge System Libraries Device Drivers Scheduler Virtual Memory System Call Interface CPU 1 DRAM

Operating System Hardware

Sunday, February 24, 13

slide-16
SLIDE 16

Analysis and Tools

Applications DBs, all server types, ... Block Device Interface Ethernet LVM IP ext3/... TCP/UDP VFS Sockets ZFS Disk Disk Port Port I/O Controller Network Controller I/O Bridge System Libraries Device Drivers Scheduler Virtual Memory System Call Interface CPU 1 DRAM

Operating System Hardware

perf dtrace stap perf iostat iotop blktrace dtrace perf top pidstat mpstat dstat slabtop dstat free top netstat strace tcpdump ip nicstat dtrace perf dstat sar /proc

Various:

vmstat ping

Sunday, February 24, 13

slide-17
SLIDE 17

Tools: Basic

  • uptime
  • top or htop
  • mpstat
  • iostat
  • vmstat
  • free
  • ping
  • nicstat
  • dstat

Sunday, February 24, 13

slide-18
SLIDE 18

uptime

  • Shows load averages, which are also shown by other tools:
  • This counts runnable threads (tasks), on-CPU, or, runnable

and waiting. Linux includes tasks blocked on disk I/O.

  • These are exponentially-damped moving averages, with time

constants of 1, 5 and 15 minutes. With three values you can see if load is increasing, steady, or decreasing.

  • If the load is greater than the CPU count, it might mean the

CPUs are saturated (100% utilized), and threads are suffering scheduler latency. Might. There’s that disk I/O factor too.

  • This is only useful as a clue. Use other tools to investigate!

$ uptime 16:23:34 up 126 days, 1:03, 1 user, load average: 5.09, 2.12, 1.82

Sunday, February 24, 13

slide-19
SLIDE 19
  • System-wide and per-process summaries:
  • %CPU = interval sum for all CPUs (varies on other OSes)
  • top can consume CPU (syscalls to read /proc)
  • Straight-forward. Or is it?

top

$ top top - 01:38:11 up 63 days, 1:17, 2 users, load average: 1.57, 1.81, 1.77 Tasks: 256 total, 2 running, 254 sleeping, 0 stopped, 0 zombie Cpu(s): 2.0%us, 3.6%sy, 0.0%ni, 94.2%id, 0.0%wa, 0.0%hi, 0.2%si, 0.0%st Mem: 49548744k total, 16746572k used, 32802172k free, 182900k buffers Swap: 100663292k total, 0k used, 100663292k free, 14925240k cached PID USER PR NI VIRT RES SHR S %CPU %MEM TIME+ COMMAND 11721 web 20 0 623m 50m 4984 R 93 0.1 0:59.50 node 11715 web 20 0 619m 20m 4916 S 25 0.0 0:07.52 node 10 root 20 0 0 0 0 S 1 0.0 248:52.56 ksoftirqd/2 51 root 20 0 0 0 0 S 0 0.0 0:35.66 events/0 11724 admin 20 0 19412 1444 960 R 0 0.0 0:00.07 top 1 root 20 0 23772 1948 1296 S 0 0.0 0:04.35 init [...]

Sunday, February 24, 13

slide-20
SLIDE 20

top, cont.

  • Interview questions:
  • 1. Does it show all CPU consumers?
  • 2. A process has high %CPU – next steps for analysis?

Sunday, February 24, 13

slide-21
SLIDE 21

top, cont.

  • 1. top can miss:
  • short-lived processes
  • kernel threads (tasks), unless included (see top options)
  • 2. analyzing high CPU processes:
  • identify why – profile code path
  • identify what – execution or stall cycles
  • High %CPU time may be stall cycles on memory I/O –

upgrading to faster CPUs doesn’t help!

Sunday, February 24, 13

slide-22
SLIDE 22

htop

  • Super top. Super configurable. Eg, basic CPU visualization:

Sunday, February 24, 13

slide-23
SLIDE 23

mpstat

  • Check for hot threads, unbalanced workloads:
  • Columns are summarized system-wide in top(1)’s header

$ mpstat -P ALL 1 02:47:49 CPU %usr %nice %sys %iowait %irq %soft %steal %guest %idle 02:47:50 all 54.37 0.00 33.12 0.00 0.00 0.00 0.00 0.00 12.50 02:47:50 0 22.00 0.00 57.00 0.00 0.00 0.00 0.00 0.00 21.00 02:47:50 1 19.00 0.00 65.00 0.00 0.00 0.00 0.00 0.00 16.00 02:47:50 2 24.00 0.00 52.00 0.00 0.00 0.00 0.00 0.00 24.00 02:47:50 3 100.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 02:47:50 4 100.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 02:47:50 5 100.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 02:47:50 6 100.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 02:47:50 7 16.00 0.00 63.00 0.00 0.00 0.00 0.00 0.00 21.00 02:47:50 8 100.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 [...]

Sunday, February 24, 13

slide-24
SLIDE 24
  • Disk I/O statistics. 1st output is summary since boot.

iostat

$ iostat -xkdz 1 Linux 2.6.35-32-server (prod21) 02/20/13 _x86_64_ (16 CPU) Device: rrqm/s wrqm/s r/s w/s rkB/s wkB/s \ ... sda 0.00 0.00 0.00 0.00 0.00 0.00 / ... sdb 0.00 0.35 0.00 0.05 0.10 1.58 \ ... / ... Device: rrqm/s wrqm/s r/s w/s rkB/s wkB/s \ ... sdb 0.00 0.00 591.00 0.00 2364.00 0.00 / ... ... \ avgqu-sz await r_await w_await svctm %util ... / 0.00 0.84 0.84 0.00 0.84 0.00 ... \ 0.00 3.82 3.47 3.86 0.30 0.00 ... / 0.00 2.31 2.31 0.00 2.31 0.00 ... \ ... / avgqu-sz await r_await w_await svctm %util ... \ 0.95 1.61 1.61 0.00 1.61 95.00

workload input resulting performance

Sunday, February 24, 13

slide-25
SLIDE 25

iostat, cont.

  • %util: usefulness depends on target – virtual devices backed

by multiple disks may accept more work a 100% utilization

  • Also calculate I/O controller stats by summing their devices
  • One nit: would like to see disk errors too. Add a “-e”?

Sunday, February 24, 13

slide-26
SLIDE 26

vmstat

  • Virtual-Memory statistics, and other high-level summaries:
  • First line of output includes some summary-since-boot values
  • “r” = total number of runnable threads, including those running
  • Swapping (aka paging) allows over-subscription of main

memory by swapping pages to disk, but costs performance

$ vmstat 1 procs -----------memory---------- ---swap-- -----io---- -system-- ----cpu---- r b swpd free buff cache si so bi bo in cs us sy id wa 15 0 2852 46686812 279456 1401196 0 0 0 0 0 0 0 0 100 0 16 0 2852 46685192 279456 1401196 0 0 0 0 2136 36607 56 33 11 0 15 0 2852 46685952 279456 1401196 0 0 0 56 2150 36905 54 35 11 0 15 0 2852 46685960 279456 1401196 0 0 0 0 2173 36645 54 33 13 0 [...]

Sunday, February 24, 13

slide-27
SLIDE 27

free

  • Memory usage summary (Kbytes default):
  • buffers: block device I/O cache
  • cached: virtual page cache

$ free total used free shared buffers cached Mem: 49548744 32787912 16760832 0 61588 342696

  • /+ buffers/cache: 32383628 17165116

Swap: 100663292 0 100663292

Sunday, February 24, 13

slide-28
SLIDE 28

ping

  • Simple network test (ICMP):
  • Used to measure network latency. Actually kernel <-> kernel

IP stack latency, including how the network handles ICMP.

  • Tells us some, but not a lot (above is an exception).

Lots of other/better tools for this (eg, hping). Try using TCP.

$ ping www.hilton.com PING a831.b.akamai.net (63.234.226.9): 56 data bytes 64 bytes from 63.234.226.9: icmp_seq=0 ttl=56 time=737.737 ms Request timeout for icmp_seq 1 64 bytes from 63.234.226.9: icmp_seq=2 ttl=56 time=819.457 ms 64 bytes from 63.234.226.9: icmp_seq=3 ttl=56 time=897.835 ms 64 bytes from 63.234.226.9: icmp_seq=4 ttl=56 time=669.052 ms 64 bytes from 63.234.226.9: icmp_seq=5 ttl=56 time=799.932 ms ^C

  • -- a831.b.akamai.net ping statistics ---

6 packets transmitted, 5 packets received, 16.7% packet loss round-trip min/avg/max/stddev = 669.052/784.803/897.835/77.226 ms

Sunday, February 24, 13

slide-29
SLIDE 29

nicstat

  • Network statistics tool, ver 1.92 on Linux:
  • This was the tool I wanted, and finally wrote it out of frustration

(Tim Cook ported and enhanced it on Linux)

  • Calculate network controller stats by summing interfaces

# nicstat -z 1 Time Int rKB/s wKB/s rPk/s wPk/s rAvs wAvs %Util Sat 01:20:58 eth0 0.07 0.00 0.95 0.02 79.43 64.81 0.00 0.00 01:20:58 eth4 0.28 0.01 0.20 0.10 1451.3 80.11 0.00 0.00 01:20:58 vlan123 0.00 0.00 0.00 0.02 42.00 64.81 0.00 0.00 01:20:58 br0 0.00 0.00 0.00 0.00 42.00 42.07 0.00 0.00 Time Int rKB/s wKB/s rPk/s wPk/s rAvs wAvs %Util Sat 01:20:59 eth4 42376.0 974.5 28589.4 14002.1 1517.8 71.27 35.5 0.00 Time Int rKB/s wKB/s rPk/s wPk/s rAvs wAvs %Util Sat 01:21:00 eth0 0.05 0.00 1.00 0.00 56.00 0.00 0.00 0.00 01:21:00 eth4 41834.7 977.9 28221.5 14058.3 1517.9 71.23 35.1 0.00 Time Int rKB/s wKB/s rPk/s wPk/s rAvs wAvs %Util Sat 01:21:01 eth4 42017.9 979.0 28345.0 14073.0 1517.9 71.24 35.2 0.00 [...]

Sunday, February 24, 13

slide-30
SLIDE 30

dstat

  • A better vmstat-like tool. Does coloring (FWIW).

Sunday, February 24, 13

slide-31
SLIDE 31

Tools: Basic, recap

  • uptime
  • top or htop
  • mpstat
  • iostat
  • vmstat
  • free
  • ping
  • nicstat
  • dstat

Sunday, February 24, 13

slide-32
SLIDE 32

Tools: Basic, recap

Applications DBs, all server types, ... Block Device Interface Ethernet LVM IP ext3/... TCP/UDP VFS Sockets ZFS Disk Disk Port Port System Libraries Device Drivers Scheduler Virtual Memory System Call Interface CPU 1 DRAM

Operating System Hardware

iostat top mpstat dstat dstat free top dstat vmstat ping

I/O Bridge

nicstat

I/O Controller Network Controller

infer infer

Sunday, February 24, 13

slide-33
SLIDE 33

Tools: Intermediate

  • sar
  • netstat
  • pidstat
  • strace
  • tcpdump
  • blktrace
  • iotop
  • slabtop
  • sysctl
  • /proc

Sunday, February 24, 13

slide-34
SLIDE 34

sar

  • System Activity Reporter. Eg, paging statistics -B:
  • Configure to archive statistics from cron
  • Many, many statistics available:
  • -d: block device statistics, -q: run queue statistics, ...
  • Same statistics as shown by other tools (vmstat, iostat, ...)

$ sar -B 1 Linux 3.2.6-3.fc16.x86_64 (node104) 02/20/2013 _x86_64_ (1 CPU) 05:24:34 PM pgpgin/s pgpgout/s fault/s majflt/s pgfree/s pgscank/s pgscand/s pgsteal/s %vmeff 05:24:35 PM 0.00 0.00 267.68 0.00 29.29 0.00 0.00 0.00 0.00 05:24:36 PM 19.80 0.00 265.35 0.99 28.71 0.00 0.00 0.00 0.00 05:24:37 PM 12.12 0.00 1339.39 1.01 2763.64 0.00 1035.35 1035.35 100.00 05:24:38 PM 0.00 0.00 534.00 0.00 28.00 0.00 0.00 0.00 0.00 05:24:39 PM 220.00 0.00 644.00 3.00 74.00 0.00 0.00 0.00 0.00 05:24:40 PM 2206.06 0.00 6188.89 17.17 5222.22 2919.19 0.00 2919.19 100.00 [...]

Sunday, February 24, 13

slide-35
SLIDE 35

netstat

  • Various network protocol statistics using -s:

$ netstat -s [...] Tcp: 127116 active connections openings 165223 passive connection openings 12904 failed connection attempts 19873 connection resets received 20 connections established 662889209 segments received 354923419 segments send out 405146 segments retransmited 6 bad segments received. 26379 resets sent [...] TcpExt: 2142 invalid SYN cookies received 3350 resets received for embryonic SYN_RECV sockets 7460 packets pruned from receive queue because of socket buffer overrun 2932 ICMP packets dropped because they were out-of-window 96670 TCP sockets finished time wait in fast timer 86 time wait sockets recycled by time stamp 1007 packets rejects in established connections because of timestamp [...many...]

Sunday, February 24, 13

slide-36
SLIDE 36

pidstat

  • Very useful process breakdowns:

# pidstat 1 Linux 3.2.6-3.fc16.x86_64 (node107) 02/20/2013 _x86_64_ (1 CPU) 05:55:18 PM PID %usr %system %guest %CPU CPU Command 05:55:19 PM 12642 0.00 1.01 0.00 1.01 0 pidstat 05:55:19 PM 12643 5.05 11.11 0.00 16.16 0 cksum 05:55:19 PM PID %usr %system %guest %CPU CPU Command 05:55:20 PM 12643 6.93 6.93 0.00 13.86 0 cksum [...] # pidstat -d 1 Linux 3.2.6-3.fc16.x86_64 (node107) 02/20/2013 _x86_64_ (1 CPU) 05:55:22 PM PID kB_rd/s kB_wr/s kB_ccwr/s Command 05:55:23 PM 279 0.00 61.90 0.00 jbd2/vda2-8 05:55:23 PM 12643 151985.71 0.00 0.00 cksum 05:55:23 PM PID kB_rd/s kB_wr/s kB_ccwr/s Command 05:55:24 PM 12643 96616.67 0.00 0.00 cksum [...]

disk I/O (yay!)

Sunday, February 24, 13

slide-37
SLIDE 37

strace

  • System call tracer:
  • -ttt: microsecond timestamp since epoch (left column)
  • -T: time spent in syscall (<seconds>)
  • -p: PID to trace (or provide a command)
  • Useful – high application latency often caused by resource I/O,

and most resource I/O is performed by syscalls

$ strace -tttT -p 12670 1361424797.229550 read(3, "REQUEST 1888 CID 2"..., 65536) = 959 <0.009214> 1361424797.239053 read(3, "", 61440) = 0 <0.000017> 1361424797.239406 close(3) = 0 <0.000016> 1361424797.239738 munmap(0x7f8b22684000, 4096) = 0 <0.000023> 1361424797.240145 fstat(1, {st_mode=S_IFCHR|0620, st_rdev=makedev(136, 0), ...}) = 0 <0.000017> [...]

Sunday, February 24, 13

slide-38
SLIDE 38

strace, cont.

  • -c: print summary:
  • This is also a (worst case) demo of the strace overhead:

# time dd if=/dev/zero of=/dev/null bs=512 count=1024k [...] 536870912 bytes (537 MB) copied, 0.35226 s, 1.5 GB/s real 0m0.355s user 0m0.021s sys 0m0.022s # time strace -c dd if=/dev/zero of=/dev/null bs=512 count=1024k [...] 536870912 bytes (537 MB) copied, 71.9565 s, 7.5 MB/s real 1m11.969s user 0m3.179s sys 1m6.346s

200x slower

# strace -c dd if=/dev/zero of=/dev/null bs=512 count=1024k [...] % time seconds usecs/call calls errors syscall

  • ----- ----------- ----------- --------- --------- ----------------

51.32 0.028376 0 1048581 read 48.68 0.026911 0 1048579 write 0.00 0.000000 0 7 open [...]

Sunday, February 24, 13

slide-39
SLIDE 39

tcpdump

  • Sniff network packets, dump to output files for post analysis:
  • Output has timestamps with microsecond resolution
  • Study odd network latency packet-by-packet
  • Import file into other tools (wireshark)

# tcpdump -i eth4 -w /tmp/out.tcpdump tcpdump: listening on eth4, link-type EN10MB (Ethernet), capture size 65535 bytes ^C33651 packets captured 34160 packets received by filter 508 packets dropped by kernel # tcpdump -nr /tmp/out.tcpdump reading from file /tmp/out.tcpdump, link-type EN10MB (Ethernet) 06:24:43.908732 IP 10.2.0.2.55502 > 10.2.203.2.22: Flags [.], ack ... 06:24:43.908922 IP 10.2.0.2.55502 > 10.2.203.2.22: Flags [.], ack ... 06:24:43.908943 IP 10.2.203.2.22 > 10.2.0.2.55502: Flags [.], seq ... 06:24:43.909061 IP 10.2.0.2.55502 > 10.2.203.2.22: Flags [.], ack ...

Sunday, February 24, 13

slide-40
SLIDE 40

tcpdump, cont.

  • Does have overhead in terms of CPU and storage; previous

example dropped packets

  • Should be using socket ring buffers to reduce overhead
  • Can use filter expressions to also reduce overhead
  • Could still be problematic for busy interfaces

Sunday, February 24, 13

slide-41
SLIDE 41

blktrace

  • Block device I/O event tracing. Launch using btrace, eg:
  • Above output shows a single disk I/O event. Action time is

highlighted (seconds).

  • Use for investigating I/O latency outliers

# btrace /dev/sdb 8,16 3 1 0.429604145 20442 A R 184773879 + 8 <- (8,17) 184773816 8,16 3 2 0.429604569 20442 Q R 184773879 + 8 [cksum] 8,16 3 3 0.429606014 20442 G R 184773879 + 8 [cksum] 8,16 3 4 0.429607624 20442 P N [cksum] 8,16 3 5 0.429608804 20442 I R 184773879 + 8 [cksum] 8,16 3 6 0.429610501 20442 U N [cksum] 1 8,16 3 7 0.429611912 20442 D R 184773879 + 8 [cksum] 8,16 1 1 0.440227144 0 C R 184773879 + 8 [0] [...]

Sunday, February 24, 13

slide-42
SLIDE 42

iotop

  • Disk I/O by process:
  • IO: time thread was waiting on I/O (this is even more useful

than pidstat’s Kbytes)

  • Needs CONFIG_TASK_IO_ACCOUNTING or something

similar enabled to work.

# iotop -bod5 Total DISK READ: 35.38 M/s | Total DISK WRITE: 39.50 K/s TID PRIO USER DISK READ DISK WRITE SWAPIN IO COMMAND 12824 be/4 root 35.35 M/s 0.00 B/s 0.00 % 80.59 % cksum ... 279 be/3 root 0.00 B/s 27.65 K/s 0.00 % 2.21 % [jbd2/vda2-8] 12716 be/4 root 28.44 K/s 0.00 B/s 2.35 % 0.00 % sshd: root@pts/0 12816 be/4 root 6.32 K/s 0.00 B/s 0.89 % 0.00 % python /usr/bin/ iotop -bod5 [...]

Sunday, February 24, 13

slide-43
SLIDE 43

slabtop

  • Kernel slab allocator usage top:
  • Shows where kernel memory is consumed

# slabtop -sc Active / Total Objects (% used) : 900356 / 1072416 (84.0%) Active / Total Slabs (% used) : 29085 / 29085 (100.0%) Active / Total Caches (% used) : 68 / 91 (74.7%) Active / Total Size (% used) : 237067.98K / 260697.24K (90.9%) Minimum / Average / Maximum Object : 0.01K / 0.24K / 10.09K OBJS ACTIVE USE OBJ SIZE SLABS OBJ/SLAB CACHE SIZE NAME 112035 110974 99% 0.91K 3201 35 102432K ext4_inode_cache 726660 579946 79% 0.11K 20185 36 80740K buffer_head 4608 4463 96% 4.00K 576 8 18432K kmalloc-4096 83496 76878 92% 0.19K 1988 42 15904K dentry 23809 23693 99% 0.55K 821 29 13136K radix_tree_node 11016 9559 86% 0.62K 216 51 6912K proc_inode_cache 3488 2702 77% 1.00K 109 32 3488K kmalloc-1024 510 431 84% 5.73K 102 5 3264K task_struct 10948 9054 82% 0.17K 238 46 1904K vm_area_struct 2585 1930 74% 0.58K 47 55 1504K inode_cache [...]

Sunday, February 24, 13

slide-44
SLIDE 44

sysctl

  • System settings:
  • Static performance tuning: check the config of the sysetm

# sysctl -a [...] net.ipv4.tcp_fack = 1 net.ipv4.tcp_reordering = 3 net.ipv4.tcp_ecn = 2 net.ipv4.tcp_dsack = 1 net.ipv4.tcp_mem = 24180 32240 48360 net.ipv4.tcp_wmem = 4096 16384 1031680 net.ipv4.tcp_rmem = 4096 87380 1031680 [...]

Sunday, February 24, 13

slide-45
SLIDE 45

/proc

  • Read statistic sources directly:
  • Also see /proc/vmstat

$ cat /proc/meminfo MemTotal: 8181740 kB MemFree: 71632 kB Buffers: 163288 kB Cached: 4518600 kB SwapCached: 7036 kB Active: 4765476 kB Inactive: 2866016 kB Active(anon): 2480336 kB Inactive(anon): 478580 kB Active(file): 2285140 kB Inactive(file): 2387436 kB Unevictable: 0 kB Mlocked: 0 kB SwapTotal: 2932728 kB SwapFree: 2799568 kB Dirty: 76 kB Writeback: 0 kB [...]

Sunday, February 24, 13

slide-46
SLIDE 46

Tools: Intermediate, recap.

  • sar
  • netstat
  • pidstat
  • strace
  • tcpdump
  • blktrace
  • iotop
  • slabtop
  • sysctl
  • /proc

Sunday, February 24, 13

slide-47
SLIDE 47

Tools: Advanced

  • perf
  • DTrace
  • SystemTap
  • and more ...

Sunday, February 24, 13

slide-48
SLIDE 48

perf

  • Originally Performance Counters for Linux (PCL), focusing on

CPU performance counters (programmable registers)

  • Now a collection of profiling and tracing tools, with numerous

subcommands, including:

kmem Trace/measure kernel memory (slab) properties kvm Trace/measure KVM guest OS list List available events (targets of instrumentation) lock Analyze lock events probe Create dynamic probe points (dynamic tracing!) record Run a command and record profile data (as perf.data) report Read perf.data and summarize, has an interactive mode sched Trace/measure kernel scheduler statistics stat Run a command, gather, and report perf counter stats

Sunday, February 24, 13

slide-49
SLIDE 49
  • Key performance counter summary:
  • Low IPC (<0.2) means stall cycles (likely memory); look for

ways to reduce memory I/O, and improve locality (NUMA)

perf: Performance Counters

$ perf stat gzip file1 Performance counter stats for 'gzip file1': 2294.924314 task-clock-msecs # 0.901 CPUs 62 context-switches # 0.000 M/sec 0 CPU-migrations # 0.000 M/sec 265 page-faults # 0.000 M/sec 5496871381 cycles # 2395.230 M/sec 12210601948 instructions # 2.221 IPC 1263678628 branches # 550.641 M/sec 13037608 branch-misses # 1.032 % 4725467 cache-references # 2.059 M/sec 2779597 cache-misses # 1.211 M/sec 2.546444859 seconds time elapsed

yay

Sunday, February 24, 13

slide-50
SLIDE 50
  • Can choose different counters:
  • Supports additional custom counters (in hex or a desc) for

whatever the processor supports. Examine bus events.

perf: Performance Counters, cont.

$ perf list | grep Hardware cpu-cycles OR cycles [Hardware event] stalled-cycles-frontend OR idle-cycles-frontend [Hardware event] stalled-cycles-backend OR idle-cycles-backend [Hardware event] instructions [Hardware event] cache-references [Hardware event] [...] $ perf stat -e instructions,cycles,L1-dcache-load-misses,LLC-load- misses,dTLB-load-misses gzip file1 Performance counter stats for 'gzip file1': 12278136571 instructions # 2.199 IPC 5582247352 cycles 90367344 L1-dcache-load-misses 1227085 LLC-load-misses 685149 dTLB-load-misses 2.332492555 seconds time elapsed

Sunday, February 24, 13

slide-51
SLIDE 51

perf: Performance Counters, cont.

Applications DBs, all server types, ... Block Device Interface Ethernet LVM IP ext3/... TCP/UDP VFS Sockets ZFS Disk Disk Port Port I/O Controller Network Controller I/O Bridge System Libraries Device Drivers Scheduler Virtual Memory System Call Interface CPU 1 DRAM

Operating System Hardware

perf stat

Expander Interconnect I/O Bus CPU Inter- connect Memory Bus

advanced activity: refer to the processor manuals

Sunday, February 24, 13

slide-52
SLIDE 52
  • Profiling (sampling) CPU activity:
  • -a: all CPUs
  • -g: call stacks
  • -F: Hertz
  • sleep 10: duration to sample (dummy command)
  • Generates a perf.data file
  • Can profile other hardware events too, with call stacks

perf: Profiling

# perf record -a -g -F 997 sleep 10 [ perf record: Woken up 44 times to write data ]

Sunday, February 24, 13

slide-53
SLIDE 53

perf: Profiling, cont.

  • Reading perf.data, forcing non-interactive mode (--stdio):

# perf report --stdio [...] # Overhead Command Shared Object Symbol # ........ ........... ................. .............................. # 72.98% swapper [kernel.kallsyms] [k] native_safe_halt |

  • -- native_safe_halt

default_idle cpu_idle rest_init start_kernel x86_64_start_reservations x86_64_start_kernel 9.43% dd [kernel.kallsyms] [k] acpi_pm_read |

  • -- acpi_pm_read

ktime_get_ts | |--87.75%-- __delayacct_blkio_start | io_schedule_timeout | balance_dirty_pages_ratelimited_nr | generic_file_buffered_write [...]

Sunday, February 24, 13

slide-54
SLIDE 54

perf: Profiling, cont.

  • Flame Graphs support perf profiling data:
  • Interactive SVG. Navigate to quantify and compare code paths

Sunday, February 24, 13

slide-55
SLIDE 55
  • Listing static tracepoints for block I/O:
  • Many useful probes already provided for kernel tracing:

perf: Static Tracing

$ perf list | grep block: block:block_rq_abort [Tracepoint event] block:block_rq_requeue [Tracepoint event] block:block_rq_complete [Tracepoint event] block:block_rq_insert [Tracepoint event] block:block_rq_issue [Tracepoint event] block:block_bio_bounce [Tracepoint event] block:block_bio_complete [Tracepoint event] block:block_bio_backmerge [Tracepoint event] block:block_bio_frontmerge [Tracepoint event] block:block_bio_queue [Tracepoint event] block:block_getrq [Tracepoint event] block:block_sleeprq [Tracepoint event] block:block_plug [Tracepoint event] block:block_unplug [Tracepoint event] block:block_split [Tracepoint event] block:block_bio_remap [Tracepoint event] block:block_rq_remap [Tracepoint event] $ perf list | grep Tracepoint | wc -l 840

Sunday, February 24, 13

slide-56
SLIDE 56

perf: Static Tracepoints

Disk Disk Port Port I/O Controller Network Controller I/O Bridge CPU 1 DRAM

Operating System Hardware

Applications DBs, all server types, ... Block Device Interface Ethernet LVM IP ext3/... TCP/UDP VFS Sockets ZFS System Libraries Device Drivers Scheduler Virtual Memory System Call Interface

sock: net: skb: scsi: irq: block: ext4: vmscan: kmem: sched: syscalls:

... more can be added as needed device stats can be inferred

Sunday, February 24, 13

slide-57
SLIDE 57
  • Define custom probes from kernel code; eg, tcp_sendmsg():

perf: Dynamic Tracing

# perf probe --add='tcp_sendmsg' Add new event: probe:tcp_sendmsg (on tcp_sendmsg) [...] # perf record -e probe:tcp_sendmsg -aR -g sleep 5 [ perf record: Woken up 1 times to write data ] [ perf record: Captured and wrote 0.091 MB perf.data (~3972 samples) ] # perf report --stdio [...] # Overhead Command Shared Object Symbol # ........ ....... ................. ........... # 100.00% sshd [kernel.kallsyms] [k] tcp_sendmsg |

  • -- tcp_sendmsg

sock_aio_write do_sync_write vfs_write sys_write system_call __GI___libc_write

active traced call stacks from arbitrary kernel locations!

Sunday, February 24, 13

slide-58
SLIDE 58

perf: Dynamic Tracing, cont.

Applications DBs, all server types, ... Block Device Interface Ethernet LVM IP ext3/... TCP/UDP VFS Sockets ZFS Disk Disk Port Port I/O Controller Network Controller I/O Bridge System Libraries Device Drivers Scheduler Virtual Memory System Call Interface CPU 1 DRAM

Operating System Hardware

perf probe --add

advanced activity: refer to the kernel source code device stats can be inferred

Sunday, February 24, 13

slide-59
SLIDE 59

perf: Dynamic Tracing, cont.

  • Fills in kernel observability gaps
  • Awesome capability
  • Takes some effort to use (waiting for the trace-dump-

analyze cycle, and using post-processors to rework the

  • utput, or the post-scripting capability)
  • Would be the awesomest tool ever, if it wasn’t for ...

Sunday, February 24, 13

slide-60
SLIDE 60

DTrace

Sunday, February 24, 13

slide-61
SLIDE 61

DTrace

  • Programmable, real-time, dynamic and static tracing
  • Perf analysis and troubleshooting, without restarting anything
  • Used on Solaris, illumos/SmartOS, Mac OS X, FreeBSD, ...
  • Two ports in development for Linux (that we know of):
  • 1. dtrace4linux
  • Mostly by Paul Fox
  • 2. Oracle Enterprise Linux DTrace
  • Steady progress

There are a couple of awesome books about DTrace too

Sunday, February 24, 13

slide-62
SLIDE 62

DTrace: Installation

  • dtrace4linux version:
  • WARNING: still a prototype, can panic/freeze kernels.

I’m using it the lab to solve replicated production perf issues

  • 1. https://github.com/dtrace4linux/dtrace
  • 2. README:

tools/get-deps.pl # if using Ubuntu tools/get-deps-fedora.sh # RedHat/Fedora make all make install make load (need to be root or have sudo access) # make load tools/load.pl 13:40:14 Syncing... 13:40:14 Loading: build-3.2.6-3.fc16.x86_64/driver/dtracedrv.ko 13:40:15 Preparing symbols... 13:40:15 Probes available: 281887 13:40:18 Time: 4s

Sunday, February 24, 13

slide-63
SLIDE 63

DTrace: Programming

  • Programming capabilities allow for powerful, efficient, one-

liners and scripts. In-kernel custom filtering and aggregation.

  • Example shows tcp_sendmsg() size dist for “sshd” PIDs

# dtrace -n 'fbt::tcp_sendmsg:entry /execname == "sshd"/ { @["bytes"] = quantize(arg3); }' dtrace: description 'fbt::tcp_sendmsg:entry ' matched 1 probe ^C bytes value ------------- Distribution ------------- count 16 | 0 32 |@@@@@@@@@@@@@@@@ 1869 64 |@@@@@@@@@@@@@ 1490 128 |@@@ 355 256 |@@@@ 461 512 |@@@ 373 1024 |@ 95 2048 | 4 4096 | 1 8192 | 0

Sunday, February 24, 13

slide-64
SLIDE 64

DTrace: Programming

  • Programming capabilities allow for powerful, efficient, one-

liners and scripts. In-kernel custom filtering and aggregation.

  • Example shows tcp_sendmsg() size dist for “sshd” PIDs

# dtrace -n 'fbt::tcp_sendmsg:entry /execname == "sshd"/ { @["bytes"] = quantize(arg3); }' dtrace: description 'fbt::tcp_sendmsg:entry ' matched 1 probe ^C bytes value ------------- Distribution ------------- count 16 | 0 32 |@@@@@@@@@@@@@@@@ 1869 64 |@@@@@@@@@@@@@ 1490 128 |@@@ 355 256 |@@@@ 461 512 |@@@ 373 1024 |@ 95 2048 | 4 4096 | 1 8192 | 0

these examples use dtrace4linux

filter aggregation (summarizes) kernel -> user transfers these these numbers

  • nly (pre-summarized)

Sunday, February 24, 13

slide-65
SLIDE 65

DTrace: Real-Time

  • Multiple GUIs use DTrace for real-time statistics. Eg, Joyent

Cloud Analytics, showing real-time cloud-wide syscall latency:

Sunday, February 24, 13

slide-66
SLIDE 66

DTrace, cont.

  • Has advanced capabilities, but not necessarily difficult;

You may just:

  • use one-liners (google “DTrace one-liners”)
  • use scripts (DTraceToolkit; DTrace book; google)
  • tweak one-liners or scripts a little
  • ask someone else to write the scripts you need
  • Ideally, you learn DTrace and write your own

Sunday, February 24, 13

slide-67
SLIDE 67

DTrace: Scripts

#!/usr/sbin/dtrace -s fbt::vfs_read:entry { self->start = timestamp; } fbt::vfs_read:return /self->start/ { @[execname, "ns"] = quantize(timestamp - self->start); self->start = 0; } # ./vfsread.d dtrace: script './vfsread.d' matched 2 probes cksum ns value ------------- Distribution ------------- count [...] 262144 | 0 524288 |@@@@@@@@@@ 834 1048576 | 8 2097152 | 30 4194304 | 40 8388608 |@ 66 16777216 | 28 33554432 | 1

13 line script to time VFS reads by process name read latency distribution, 0.5ms -> 33ms (disks)

Sunday, February 24, 13

slide-68
SLIDE 68

DTrace: Basics

  • CLI syntax:
  • provider – library of related probes
  • module:function – shows where probe is located (for debug)
  • name – name of probe
  • Online reference and tutorial: http://dtrace.org/guide

probe description

  • ptional

filter do this when probe “fires”

dtrace -n ‘provider:module:function:name /predicate/ { action }’

Sunday, February 24, 13

slide-69
SLIDE 69

DTrace: Providers

Applications DBs, all server types, ... Block Device Interface Ethernet LVM IP ext3/... TCP/UDP VFS Sockets ZFS Disk Disk Port Port I/O Controller Network Controller I/O Bridge System Libraries Device Drivers Scheduler Virtual Memory System Call Interface CPU 1 DRAM

Sunday, February 24, 13

slide-70
SLIDE 70

DTrace: Providers

Applications DBs, all server types, ... Block Device Interface Ethernet LVM IP ext3/... TCP/UDP VFS Sockets ZFS Disk Disk Port Port I/O Controller Network Controller I/O Bridge System Libraries Device Drivers Scheduler Virtual Memory System Call Interface CPU 1 DRAM

fbt pid syscall sched proc vminfo io profile tcp udp ip cpc

infer

ip fbt

infer

cpc profile java javascript node perl python php ruby erlang

  • bjc tcl ...

mysql postgres ...

fbt and pid are dynamic

plockstat

Sunday, February 24, 13

slide-71
SLIDE 71

DTrace: Linux Examples

  • Following examples use fbt – kernel dynamic tracing

Sunday, February 24, 13

slide-72
SLIDE 72

DTrace: ext4slower.d

  • Show me:
  • ext4 reads and writes
  • slower than a specified latency (milliseconds)
  • with time, process, direction, size, latency, and file name
  • I wrote this to answer: is ext4 to blame for latency outliers?
  • Argument is latency you are looking for: here, 10+ ms

# ./ext4slower.d 10 Tracing ext4 read/write slower than 10 ms TIME PROCESS D KB ms FILE 2013 Feb 22 17:17:02 cksum R 64 35 100m 2013 Feb 22 17:17:02 cksum R 64 16 1m 2013 Feb 22 17:17:03 cksum R 64 18 data1 2013 Feb 22 17:17:03 cksum R 64 23 data1

Sunday, February 24, 13

slide-73
SLIDE 73

DTrace: ext4slower.d, cont.

  • Extending vfs_read() example:
  • ... continued:

#!/usr/sbin/dtrace -s #pragma D option quiet #pragma D option defaultargs #pragma D option switchrate=5 dtrace:::BEGIN { min_ns = $1 * 1000000; printf("Tracing ext4 read/write slower than %d ms\n", $1); printf("%-20s %-16s %1s %4s %6s %s\n", "TIME", "PROCESS", "D", "KB", "ms", "FILE"); } fbt::vfs_read:entry, fbt::vfs_write:entry { this->file = (struct file *)arg0; this->fs = this->file->f_path.dentry->d_inode->i_sb->s_type->name; }

Sunday, February 24, 13

slide-74
SLIDE 74
  • Immediately exonerate or blame ext4.

DTrace: ext4slower.d, cont.

fbt::vfs_read:entry, fbt::vfs_write:entry /stringof(this->fs) == "ext4"/ { self->start = timestamp; self->name = this->file->f_path.dentry->d_name.name; } fbt::vfs_read:return, fbt::vfs_write:return /self->start && (this->delta = timestamp - self->start) > min_ns/ { this->dir = probefunc == "vfs_read" ? "R" : "W"; printf("%-20Y %-16s %1s %4d %6d %s\n", walltimestamp, execname, this->dir, arg1 / 1024, this->delta / 1000000, stringof(self->name)); } fbt::vfs_read:return, fbt::vfs_write:return { self->start = 0; self->name = 0; }

... should add more vfs_*() calls; or trace ext4 funcs directly

Sunday, February 24, 13

slide-75
SLIDE 75

DTrace: tcpretransmit.d

  • Show me:
  • TCP retransmits
  • destination IP address
  • kernel stack (shows why)
  • in real-time
  • Don’t sniff all packets – only trace retransmits, to minimize
  • verhead

Sunday, February 24, 13

slide-76
SLIDE 76

DTrace: tcpretransmit.d, cont.

# ./tcpretransmit.d Tracing TCP retransmits... Ctrl-C to end. 2013 Feb 23 18:24:11: retransmit to 10.2.124.2, by: kernel`tcp_retransmit_timer+0x1bd kernel`tcp_write_timer+0x188 kernel`run_timer_softirq+0x12b kernel`tcp_write_timer kernel`__do_softirq+0xb8 kernel`read_tsc+0x9 kernel`sched_clock+0x9 kernel`sched_clock_local+0x25 kernel`call_softirq+0x1c kernel`do_softirq+0x65 kernel`irq_exit+0x9e kernel`smp_apic_timer_interrupt+0x6e kernel`apic_timer_interrupt+0x6e [...]

... can trace those stack functions directly for more detail

Sunday, February 24, 13

slide-77
SLIDE 77
  • Source:

DTrace: tcpretransmit.d, cont.

#!/usr/sbin/dtrace -s #pragma D option quiet dtrace:::BEGIN { trace("Tracing TCP retransmits... Ctrl-C to end.\n"); } fbt::tcp_retransmit_skb:entry { this->so = (struct sock *)arg0; this->d = (unsigned char *)&this->so->__sk_common.skc_daddr; printf("%Y: retransmit to %d.%d.%d.%d, by:", walltimestamp, this->d[0], this->d[1], this->d[2], this->d[3]); stack(99); }

Sunday, February 24, 13

slide-78
SLIDE 78

DTrace: Current State

  • This was demoed on a prototype DTrace for Linux
  • Right now (Feb 2013) not stable – will panic/freeze
  • Needs other handholding to work around nits/bugs
  • AFAIK, both DTrace ports welcome help (that means you!)
  • Those examples were also fbt-based:
  • Will probably need tweaks to match different kernels, since

the API is dynamically built from the kernel code

  • DTrace stable providers solve that problem – but many

aren’t there on Linux yet

Sunday, February 24, 13

slide-79
SLIDE 79

DTrace: Trying it out

  • All providers are available to try on illumos/SmartOS
  • illumos is the on-going fork of the OpenSolaris kernel
  • SmartOS is Joyent’s illumos-based cloud OS (distro)
  • Rough translation guide:
  • DTrace implementation mature
  • Joyent uses SmartOS as a hypervisor for running KVM Linux
  • n ZFS

kernel: linux == illumos distros: {ubuntu|CentOS|Fedora} == {SmartOS|OmniOS|OpenIndiana}

Sunday, February 24, 13

slide-80
SLIDE 80

DTrace: Other Capabilities

  • Trace short lived processes
  • Profile CPU usage
  • Time any thread blocking event
  • Investigate disk I/O latency
  • Investigate network I/O latency
  • Examine cache activity
  • Investigate memory allocation: growth or leaks
  • Investigate swapping (paging) in detail
  • Follow network packets through the stack
  • Examine lock contention
  • ...

Sunday, February 24, 13

slide-81
SLIDE 81

SystemTap

Sunday, February 24, 13

slide-82
SLIDE 82

SystemTap

  • Created when there

wasn’t DTrace for Linux ports

  • Static and dynamic

tracing, probes, tapsets, scripts, ...

  • I’ve used it a lot:
  • panics/freezes
  • slow startups
  • for Linux only
  • incompatible with D

Sunday, February 24, 13

slide-83
SLIDE 83

Tools: Advanced, recap.

Applications DBs, all server types, ... Block Device Interface Ethernet LVM IP ext3/... TCP/UDP VFS Sockets ZFS Disk Disk Port Port I/O Controller Network Controller I/O Bridge System Libraries Device Drivers Scheduler Virtual Memory System Call Interface CPU 1 DRAM

Operating System Hardware

Given the tools to see everything, how do you use them?

Sunday, February 24, 13

slide-84
SLIDE 84

And More ...

  • Other observability tools at all levels include:
  • ps, pmap, traceroute, ntop, ss, lsof, oprofile, gprof,

kcachegrind, valgrind, google profiler, nfsiostat, cifsiostat, latencytop, powertop, LLTng, ktap, ...

  • And many experimental tools: micro-benchmarks
  • So many tools it gets confusing – where do you start?

Sunday, February 24, 13

slide-85
SLIDE 85

Methodologies

  • Selected four:
  • Streetlight Anti-Method
  • Workload Characterization Method
  • Drill-Down Analysis Method
  • USE Method
  • Methodologies give beginners a starting point, casual users a

checklist, and experts a reminder

Sunday, February 24, 13

slide-86
SLIDE 86

Streetlight Anti-Method

Sunday, February 24, 13

slide-87
SLIDE 87

Streetlight Anti-Method

  • 1. Pick observability tools that are
  • familiar
  • found on the Internet
  • found at random
  • 2. Run tools
  • 3. Look for obvious issues
  • Included for comparison (don’t use this methodology)

Sunday, February 24, 13

slide-88
SLIDE 88

Streetlight Anti-Method, cont.

  • Named after an observational bias called the streetlight effect

A policeman sees a drunk looking under a streetlight, and asks what he is looking for. The drunk says he has lost his keys. The policeman can't find them either, and asks if he lost them under the streetlight. The drunk replies: “No, but this is where the light is best.”

Sunday, February 24, 13

slide-89
SLIDE 89

Streetlight Anti-Method, cont.

  • Why are you still running top?

top - 15:09:38 up 255 days, 16:54, 10 users, load average: 0.00, 0.03, 0.00 Tasks: 274 total, 1 running, 273 sleeping, 0 stopped, 0 zombie Cpu(s): 0.7%us, 0.0%sy, 0.0%ni, 99.1%id, 0.1%wa, 0.0%hi, 0.0%si, 0.0%st Mem: 8181740k total, 7654228k used, 527512k free, 405616k buffers Swap: 2932728k total, 125064k used, 2807664k free, 3826244k cached PID USER PR NI VIRT RES SHR S %CPU %MEM TIME+ COMMAND 16876 root 20 0 57596 17m 1972 S 4 0.2 3:00.60 python 3947 brendan 20 0 19352 1552 1060 R 0 0.0 0:00.06 top 15841 joshw 20 0 67144 23m 908 S 0 0.3 218:21.70 mosh-server 16922 joshw 20 0 54924 11m 920 S 0 0.1 121:34.20 mosh-server 1 root 20 0 23788 1432 736 S 0 0.0 0:18.15 init 2 root 20 0 0 0 0 S 0 0.0 0:00.61 kthreadd 3 root RT 0 0 0 0 S 0 0.0 0:00.11 migration/0 4 root 20 0 0 0 0 S 0 0.0 18:43.09 ksoftirqd/0 5 root RT 0 0 0 0 S 0 0.0 0:00.00 watchdog/0 [...]

Sunday, February 24, 13

slide-90
SLIDE 90

Streetlight Anti-Method, cont.

  • Tools-based approach
  • Inefficient:
  • can take time before the right tool is found
  • can be wasteful when investigating false positives
  • Incomplete:
  • don’t find the right tool, or,
  • the right tool doesn’t exist

Sunday, February 24, 13

slide-91
SLIDE 91

Workload Characterization Method

Sunday, February 24, 13

slide-92
SLIDE 92

Workload Characterization Method

  • 1. Who
  • 2. Why
  • 3. What
  • 4. How

Sunday, February 24, 13

slide-93
SLIDE 93

Workload Characterization Method

  • 1. Who is causing the load? PID, UID, IP addr, ...
  • 2. Why is the load called? code path
  • 3. What is the load? IOPS, tput, direction, type
  • 4. How is the load changing over time?

Sunday, February 24, 13

slide-94
SLIDE 94

Workload Characterization Method, cont.

  • Identifies issues of load
  • Best performance wins are from eliminating unnecessary work
  • Don’t assume you know what the workload is – characterize
  • Many of the previous analysis tools included workload statistics

Sunday, February 24, 13

slide-95
SLIDE 95

Workload Characterization Method, cont.

  • Pros:
  • Potentially largest wins
  • Cons:
  • Only solves a class of issues – load
  • Time consuming, and can be discouraging – most

attributes examined will not be a problem

Sunday, February 24, 13

slide-96
SLIDE 96

Drill-Down Analysis Method

Sunday, February 24, 13

slide-97
SLIDE 97

Drill-Down Analysis Method

  • 1. Start at highest level
  • 2. Examine next-level details
  • 3. Pick most interesting breakdown
  • 4. If problem unsolved, go to 2

Sunday, February 24, 13

slide-98
SLIDE 98

Drill-Down Analysis Method, cont.: Example

  • For example, ext4 – identify latency origin top-down:

Drill-Down Analysis

Applications Block Device Interface ext4 VFS Device Drivers System Call Interface System Libraries

User Kernel

Dynamic Tracing / DTrace is well suited for this, as it can dig through all layers with custom detail

Sunday, February 24, 13

slide-99
SLIDE 99

Drill-Down Analysis: ext4

  • eg, ext4_readpages() latency distribution (microseconds):

# dtrace -n 'fbt::ext4_readpages:entry { self->ts = timestamp; } fbt::ext4_readpages:return /self->ts/ { @["us"] = lquantize((timestamp - self->ts) / 1000, 0, 10000, 250); self->ts = 0; }' dtrace: description 'fbt::ext4_readpages:entry ' matched 2 probes ^C us value ------------- Distribution ------------- count < 0 | 0 0 |@@@@@@@@@@@@ 303 250 | 0 500 | 0 750 |@@@@ 88 1000 |@@@@@@@@@@@@@@ 335 1250 | 0 1500 | 0 1750 |@@@@ 107 2000 |@@@@@@ 144 2250 | 0 2500 | 0 [...]

cache hits disk I/O

Sunday, February 24, 13

slide-100
SLIDE 100

Drill-Down Analysis: ext4

  • ... can dig out more details as needed: file name, code path:

# dtrace -n 'fbt::ext4_readpages:entry { this->file = (struct file *)arg0; this->name = this->file->f_path.dentry->d_name.name; @[stringof(this->name), stack()] = count(); }' dtrace: description 'fbt::ext4_readpages:entry ' matched 1 probe ^C[...] foo8 kernel`__do_page_cache_readahead+0x1c7 kernel`ra_submit+0x21 kernel`ondemand_readahead+0x115 kernel`page_cache_async_readahead+0x80 kernel`radix_tree_lookup_slot+0xe kernel`find_get_page+0x1e kernel`generic_file_aio_read+0x48b kernel`vma_merge+0x121 kernel`do_sync_read+0xd2 kernel`__switch_to+0x132 kernel`security_file_permission+0x93 kernel`rw_verify_area+0x61 kernel`vfs_read+0xb0 kernel`sys_read+0x4a kernel`system_call_fastpath+0x16 122

# of

  • ccurrences

Sunday, February 24, 13

slide-101
SLIDE 101

Drill-Down Analysis Method, cont.

  • Moves from higher- to lower-level details based on findings:

environment-wide down to metal

  • Pros:
  • Will identify root cause(s)
  • Cons:
  • Time consuming – especially when drilling in the wrong

direction

Sunday, February 24, 13

slide-102
SLIDE 102

USE Method

Sunday, February 24, 13

slide-103
SLIDE 103

USE Method

  • For every resource, check:
  • 1. Utilization
  • 2. Saturation
  • 3. Errors

Sunday, February 24, 13

slide-104
SLIDE 104

USE Method, cont.

  • For every resource, check:
  • 1. Utilization: time resource was busy, or degree used
  • 2. Saturation: degree of queued extra work
  • 3. Errors: any errors

Saturation Utilization Errors

X

Sunday, February 24, 13

slide-105
SLIDE 105

USE Method, cont.

  • Hardware Resources:
  • CPUs
  • Main Memory
  • Network Interfaces
  • Storage Devices
  • Controllers
  • Interconnects
  • Find the functional diagram and examine every item in the

data path...

Sunday, February 24, 13

slide-106
SLIDE 106

USE Method, cont.: Functional Diagram

For each check:

Disk Disk Port Port

Expander Interconnect I/O Bus Interface Transports

I/O Controller Network Controller I/O Bridge

CPU Interconnect

CPU 1 DRAM

Hardware

Memory Bus

CPU 1 DRAM

Memory Bus

  • 1. Utilization
  • 2. Saturation
  • 3. Errors

Sunday, February 24, 13

slide-107
SLIDE 107

USE Method, cont.: Example Linux Checklist

Resource Type Metric CPU Utilization

per-cpu: mpstat -P ALL 1, “%idle”; sar -P ALL, “%idle”; system-wide: vmstat 1, “id”; sar -u, “%idle”; dstat -c, “idl”; per-process:top, “%CPU”; htop, “CPU %”; ps -o pcpu; pidstat 1, “%CPU”; per-kernel- thread: top/htop (“K” to toggle), where VIRT == 0 (heuristic). [1]

CPU Saturation

system-wide: vmstat 1, “r” > CPU count [2]; sar -q, “runq-sz” > CPU count; dstat -p, “run” > CPU count; per-process: /proc/PID/schedstat 2nd field (sched_info.run_delay); perf sched latency (shows “Average” and “Maximum” delay per-schedule); dynamic tracing, eg, SystemTap schedtimes.stp “queued(us)” [3]

CPU Errors

perf (LPE) if processor specific error events (CPC) are available; eg, AMD64′s “04Ah Single-bit ECC Errors Recorded by Scrubber” [4]

http://dtrace.org/blogs/brendan/2012/03/07/the-use-method-linux-performance-checklist ... etc for all combinations (would fill a dozen slides)

Sunday, February 24, 13

slide-108
SLIDE 108

USE Method, cont.

  • Some software resources can also be studied:
  • Mutex Locks
  • Thread Pools
  • Process/Thread Capacity
  • File Descriptor Capacity
  • Consider possible USE metrics for each

Sunday, February 24, 13

slide-109
SLIDE 109

USE Method, cont.

  • This process may reveal missing metrics – those not provided

by your current toolset

  • They are your known unknowns
  • Much better than unknown unknowns
  • More tools can be installed and developed to help
  • So many top(1)s, but where is the interconnect-top?
  • Full USE Method checklist may, practically, only be used for

critical issues

Sunday, February 24, 13

slide-110
SLIDE 110

USE Method, cont.

  • Resource-based approach
  • Quick system health check, early in an investigation
  • Pros:
  • Complete: all resource bottlenecks and errors
  • Not limited in scope by your current toolset
  • No unknown unknowns – at least known unknowns
  • Efficient: picks three metrics for each resource –

from what may be dozens available

  • Cons:
  • Limited to a class of issues

Sunday, February 24, 13

slide-111
SLIDE 111

Other Methodologies

  • Include:
  • Blame-Someone-Else Anti-Method
  • Tools Method
  • Ad-Hoc Checklist Method
  • Problem Statement Method
  • Scientific Method
  • Latency Analysis
  • Stack Profile Method
  • http://dtrace.org/blogs/brendan/2012/12/13/usenix-lisa-2012-performance-analysis-methodology/

Sunday, February 24, 13

slide-112
SLIDE 112

Challenges

  • Performance counter analysis (eg, bus or interconnect port

analysis) is time consuming – would like tools for convenience

  • How about a “bustop” subcommand for perf?
  • DTrace for Linux ports still in progress – will be awesome

when complete

Sunday, February 24, 13

slide-113
SLIDE 113

Cloud Computing

  • Performance may be limited by cloud resource controls, rather

than physical limits

  • Hardware Virtualization complicates things – as a guest you

can’t analyze down to metal directly

  • Hopefully the cloud provider provides an API for accessing

physical statistics, or does the analysis on your behalf

  • We do analysis at Joyent (and our hypervisors have DTrace!)
  • Free trial for new customers: good for $125 of usage value (~
  • ne Small 1GB SmartMachine for 60 days). All prices subject

to change. Limited time only. Sign up at joyent.com

Sunday, February 24, 13

slide-114
SLIDE 114

References

  • Linux man pages, source, /Documentation
  • USE Method: http://queue.acm.org/detail.cfm?id=2413037
  • http://dtrace.org/blogs/brendan/2012/03/07/the-use-method-

linux-performance-checklist/

  • http://dtrace.org/blogs/brendan/2012/12/13/usenix-lisa-2012-

performance-analysis-methodology/

  • https://github.com/dtrace4linux, http://www.dtracebook.com,

http://illumos.org, http://smartos.org

  • Upcoming: “Systems Performance” (Prentice Hall)

Sunday, February 24, 13

slide-115
SLIDE 115

Thank you!

  • email: brendan@joyent.com
  • twitter: @brendangregg
  • blog: http://dtrace.org/blogs/brendan
  • blog resources:
  • http://dtrace.org/blogs/brendan/tag/linux-2/
  • http://dtrace.org/blogs/brendan/2012/02/29/the-use-method/
  • http://dtrace.org/blogs/brendan/2012/03/07/the-use-method-linux-performance-

checklist/

  • http://dtrace.org/blogs/brendan/2011/12/16/flame-graphs/
  • http://dtrace.org/blogs/brendan/2012/03/17/linux-kernel-performance-flame-

graphs/

  • http://dtrace.org/blogs/brendan/2011/10/15/using-systemtap/

Sunday, February 24, 13
