Applied Networking Research Workshop 2020 acm sigcomm Limiting the Power of RPKI Authorities Kris Shrishak Haya Shulman TU Darmstadt and Fraunhofer SIT Motivation - Resource Public Key Infrastructure (RPKI) secures the interdomain routing

slide-1
SLIDE 1

Applied Networking Research Workshop 2020

acm sigcomm

Limiting the Power of RPKI Authorities

Kris Shrishak Haya Shulman

TU Darmstadt and Fraunhofer SIT

slide-2
SLIDE 2

Motivation

  • Resource Public Key Infrastructure (RPKI) secures the interdomain routing

against prefix and subprefix hijacks

  • However, significant power lies with the Regional Internet Registries (RIRs)

This Work

  • Distributed RPKI system that relies on threshold signatures
  • Prevention rather than detection
  • Ensures that any change to the RPKI objects requires a joint action by a number
  • f RIRs, avoiding unilateral IP address takedowns
  • No changes required at Relying Parties

1 / 19

slide-3
SLIDE 3

Outline

RPKI MPC Our work

slide-4
SLIDE 4

Prefix hijacks

2 / 19

slide-5
SLIDE 5

RPKI

RPKI [RFC 6480] is a hierarchical PKI that includes: Routing Certificate (RC) Binds IP prefix to a public key Route Origin Authorization (ROA) Binds the prefix to AS

  • Signed by the public key associated with the RC

Route Origin Validation (ROV) Validates the origin of BGP route announcements RPKI is a prerequisite for BGPSec [RFC 8205] that provides path validation.

3 / 19

slide-6
SLIDE 6

Delegated and Hosted RPKI

Delegated RPKI

  • Members run their own CA
  • Member generates its own certificate, gets it signed by the parent CA

1https://ripe77.ripe.net/presentations/156-RPKI-deployment-at-scale-RIPE-1.pdf 4 / 19

slide-7
SLIDE 7

Delegated and Hosted RPKI

Delegated RPKI

  • Members run their own CA
  • Member generates its own certificate, gets it signed by the parent CA

Hosted RPKI

  • RIR runs the CA for the members and manages the keys and repo
  • Convenient option for members as they do need to run their own CAs
  • Even some large providers such as Cloudflare use hosted RPKI 1

1https://ripe77.ripe.net/presentations/156-RPKI-deployment-at-scale-RIPE-1.pdf 4 / 19

slide-8
SLIDE 8

Delegated and Hosted RPKI

Delegated RPKI

  • Members run their own CA
  • Member generates its own certificate, gets it signed by the parent CA

Hosted RPKI

  • RIR runs the CA for the members and manages the keys and repo
  • Convenient option for members as they do need to run their own CAs
  • Even some large providers such as Cloudflare use hosted RPKI 1

1https://ripe77.ripe.net/presentations/156-RPKI-deployment-at-scale-RIPE-1.pdf 4 / 19

slide-9
SLIDE 9

Power imbalance

  • RPKI authorities can revoke and allocations
  • RPKI authorities can unilaterally takedown IP prefixes
  • Law enforcement 2 3
  • ASes not necessarily in the same country as the RIR

(no recourse, loss of business)

  • RIRs do not usually collude with each other, and often disagree with each other

when it comes to their response to law enforcement agencies 4

2RIPE NCC Blocks Registration in RIPE Registry Following Order from Dutch Police (2011) 3ICANN Tells U.S. Court That ccTLDs Are Not “Property” — Files Motion to Quash in U.S. Legal Action

Aimed at Seizing Top-Level Domains (2014)

  • 4M. Mueller, M. van Eeten, and B. Kuerbis. In important case, RIPE-NCC seeks legal clarity on how it

responds to foreign court orders (2011)

5 / 19

slide-10
SLIDE 10

Prior Works

  • Adding transparency logs and .dead objects to signify consent 5
  • Relying parties take a part of the burden
  • Detection after the fact
  • Parent manages the signing in hosted RPKI and can sign the .dead objects itself
  • Blockchain to replace RPKI 6
  • Scalability
  • Deployment issues such as consensus algorithm and incentive for the nodes to run

the blockchain

  • If Proof-of-Stake is used, large providers will become powerful players; another form
  • f power imbalance

5Heilman, et. al. From the consent of the routed: Improving the transparency of the RPKI (SIGCOMM’14) 6Adiseshu Hari and T. V. Lakshman. The Internet blockchain: A distributed, tamper-resistant transaction

framework for the Internet (HotNets’16)

6 / 19

slide-11
SLIDE 11

Outline

RPKI MPC Our work

slide-12
SLIDE 12

Multiparty Computation (MPC)

x1 x2 x3 Trusted Third Party

7 / 19

slide-13
SLIDE 13

Multiparty Computation (MPC)

x1 x2 x3 Trusted Third Party x1 x2 x3 MPC

7 / 19

slide-14
SLIDE 14

MPC

Threshold Signatures

Traditional Signatures

sk Indistinguishable

Threshold Signatures {sk1, sk2, sk3} ← Share(sk)

sk1 sk2 sk3 MPC

8 / 19

slide-15
SLIDE 15

MPC

Threshold Signatures

Traditional Signatures

sk Indistinguishable

Threshold Signatures {sk1, sk2, sk3} ← Share(sk)

sk1 sk2 sk3 MPC

8 / 19

slide-16
SLIDE 16

Outline

RPKI MPC Our work

slide-17
SLIDE 17

Threat model

x1 x2 x3 x2 x3 MPC

Individual RIRs not entirely trusted

9 / 19

slide-18
SLIDE 18

Threat model

x1 x2 x3 x2 x3 MPC

Individual RIRs not entirely trusted Adversary power

  • Passive
  • Active

9 / 19

slide-19
SLIDE 19

Threat model

x1 x2 x3 x2 x3 MPC

Individual RIRs not entirely trusted Adversary power

  • Passive
  • Active

How many can be corrupt?

  • Minority

9 / 19

slide-20
SLIDE 20

Threat model

x1 x2 x3 x2 x3 MPC

Individual RIRs not entirely trusted Adversary power

  • Passive
  • Active

How many can be corrupt?

  • Minority
  • Majority

9 / 19

slide-21
SLIDE 21

System Setup

Trust Anchor Hosted CA Threshold Signature Module RPKI DB Hosted RPKI RIR CA Threshold Signature Module RPKI DB repos repos

10 / 19

slide-22
SLIDE 22

Distributed RPKI

CA Threshold Signature Module RIPE NCC ARIN LACNIC AFRINIC APNIC repos repos MPC

11 / 19

slide-23
SLIDE 23

Threshold signatures for RPKI

{sk1, sk2, sk3, sk4, sk5} ← Share(sk)

12 / 19

slide-24
SLIDE 24

Threshold signatures for RPKI

{sk1, sk2, sk3, sk4, sk5} ← Share(sk)

sk1 sk2 sk3 sk4 sk5 consent MPC repos repos

12 / 19

slide-25
SLIDE 25

Threshold signatures for RPKI

{sk1, sk2, sk3, sk4, sk5} ← Share(sk)

sk1 sk2 sk3 sk4 sk5 consent MPC repos repos

12 / 19

slide-26
SLIDE 26

Threshold signatures for RPKI

{sk1, sk2, sk3, sk4, sk5} ← Share(sk)

sk1 sk2 sk3 sk4 sk5 consent MPC repos repos

12 / 19

slide-27
SLIDE 27

Threshold signatures for RPKI

{sk1, sk2, sk3, sk4, sk5} ← Share(sk)

sk1 sk2 sk3 sk4 sk5 consent MPC repos repos

12 / 19

slide-28
SLIDE 28

Threshold signatures for RPKI

{sk1, sk2, sk3, sk4, sk5} ← Share(sk) Threshold signing should not be expensive

sk1 sk2 sk3 sk4 sk5 consent MPC repos repos

12 / 19

slide-29
SLIDE 29

Threshold Signature in 3 phases

MPC Preprocessing

  • Member independent

Preprocessing

  • Member independent
  • Message independent

Online phase

13 / 19

slide-30
SLIDE 30

Threshold Signature in 3 phases

MPC Preprocessing

  • Member independent

Preprocessing

  • Member independent
  • Message independent

Online phase

13 / 19

slide-31
SLIDE 31

Threshold Signature in 3 phases

sk1 sk2 sk3 sk4 sk5 MPC Preprocessing

  • Member independent

Preprocessing

  • Member independent
  • Message independent

Online phase

13 / 19

slide-32
SLIDE 32

Threshold Signature in 3 phases

sk1, M sk2, M sk3, M sk4, M sk5, M MPC Preprocessing

  • Member independent

Preprocessing

  • Member independent
  • Message independent

Online phase

13 / 19

slide-33
SLIDE 33

Deployment Scenarios

  • Two-layered
  • Is compatible with delegated RPKI
  • Upper layer generates a distributed TA to the five RIRs
  • Distributed key generation
  • All RIRs have the same subjectPublicKeyInfo in their TAL
  • Lower layer uses the threshold signing module for the Hosted CAs
  • Generates signed objects
  • Not entirely immune to state coercion
  • Flat
  • Combines RIR CA and hosted CA
  • Replaces the hierarchical RPKI with a flat architecture
  • Not compatible with delegated RPKI

14 / 19

slide-34
SLIDE 34

Evaluations

Frankfurt Sydney Sao Paolo Mumbai

  • N. Virginia

114.9|109 85.6|142 228.3|49 196.7|57 119.9|99 301.0|36 180.6|64 203.7|56 283.2|39 308.7|35

Figure: Latency in milliseconds|Bandwidth in Mbits/s between regions

15 / 19

slide-35
SLIDE 35

Evaluations

❤❤❤❤❤❤❤❤❤❤❤ ❤

Majority Adversary power Passive Active Honest Shamir

  • Mal. Shamir

Dishonest

  • Semi. OT

MASCOT

Table: Four MPC protocols

LAN WAN Preprocessing Online Preprocessing Online MASCOT 209 529 20 0.95 Semi OT 1042 662 111 2.05

  • Mal. Shamir

699 714 91 3.53 Shamir 1020 769 265 3.54

Table: Breakdown of throughput for preprocessing (tuples/sec) and online phases (signatures/sec)

16 / 19

slide-36
SLIDE 36

ROAs

2 1 5

  • 1

2 1 6

  • 1

2 1 7

  • 1

2 1 8

  • 1

2 1 9

  • 1

2 2

  • 1

Dates

20000 40000 60000 80000 100000

ROAs added

AFRINIC APNIC ARIN LACNIC RIPENCC 2 1 5

  • 1

2 1 6

  • 1

2 1 7

  • 1

2 1 8

  • 1

2 1 9

  • 1

2 2

  • 1

Dates

20000 40000 60000 80000 100000

ROAs removed

AFRINIC APNIC ARIN LACNIC RIPENCC

Figure: Number of ROAs added and removed from March 2015 to February 2020

17 / 19

slide-37
SLIDE 37

Evaluations

In the WAN setting,

  • MASCOT: 0.95 signatures/sec or 82080 signatures/day
  • Shamir: 3.53 signatures/sec or 304992 signatures/day
  • Even our slowest protocol is able to satisfy the requirements on an average day.
  • Our other protocols are able to generate enough signatures even on peak days

18 / 19

slide-38
SLIDE 38

Summary of our work

  • Distributed RPKI with a stronger threat model
  • Using threshold signatures in preprocessing model
  • No changes at Relying Parties
  • Technical solution that requires legal and policy barriers to be addressed to make

the work truly practical

19 / 19

slide-39
SLIDE 39

kris.shrishak@sit.tu-darmstadt.de

CA Threshold Signature Module RIPE NCC ARIN LACNIC AFRINIC APNIC repos repos MPC
