LHC Run1 Experimental Results Dmytro Kovalskyi (UCSD) Introduction There are many interesting results produced by LHC experiments Its unrealistic to show them all Ill concentrate on a few topics that are interesting from my point of

slide-1
SLIDE 1

LHC Run1 Experimental Results

Dmytro Kovalskyi (UCSD)

slide-2
SLIDE 2

LHC Run1 Results - Dmytro Kovalskyi April 7, 2014

Introduction

There are many interesting results produced by LHC experiments It’s unrealistic to show them all I’ll concentrate on a few topics that are interesting from my point of view Latest Moriond experimental summary talks:

Pierluigi Campana (Frascatti)

http://moriond.in2p3.fr/QCD/2014/Saturday/Campana.pdf

Kevin Einsweiler (Lawrence Berkeley Lab)

https://indico.in2p3.fr/getFile.py/access?contribId=227&sessionId=1&resId=1&materialId=slides&confId=9116

2

slide-3
SLIDE 3

LHC Run1 Results - Dmytro Kovalskyi April 7, 2014

Overview

Run1 overview and Run2 projections Standard Model

Higgs boson is discovered - SM is complete

In depth: Higgs width measurement

SM Properties

Physics beyond the Standard Model

Direct searches for SUSY and Exotic models Indirect searches by exploring vector boson scattering

Vacuum stability and top mass

3

slide-4
SLIDE 4

LHC Run1 Results - Dmytro Kovalskyi April 7, 2014

LHC Run 1

4

Missing Energy Resolution

Z→μμ

slide-5
SLIDE 5

LHC Run1 Results - Dmytro Kovalskyi April 7, 2014

Run 2: 2015-2017

Target Integrated lumi: 100/fb Pileup is a real concern

Jet and MET resolution degrades Event reconstruction issues

Triggers for Higgs and lighter object is a challenge

5

slide-6
SLIDE 6

Higgs Discovery

slide-7
SLIDE 7

LHC Run1 Results - Dmytro Kovalskyi April 7, 2014

Discovery

7

slide-8
SLIDE 8

LHC Run1 Results - Dmytro Kovalskyi April 7, 2014

Signal is Solid

H→ZZ→4l - golden channel

8

ATLAS : µZZ(mH = 125.5) = 1.44+0.40

−0.35

CMS : µZZ(mH = 125.6) = 0.93+0.29

−0.25

ATLAS : 6.6σ(4.4σexpected) CMS : 6.8σ(6.7σexpected)

slide-9
SLIDE 9

LHC Run1 Results - Dmytro Kovalskyi April 7, 2014

Higgs to VV

Main decay channels: ZZ, WW, γγ Signal present in all of them - consistent with SM

9

slide-10
SLIDE 10

LHC Run1 Results - Dmytro Kovalskyi April 7, 2014

Fermionic decay channels

H→ττ more than 5σ significance if combine ATLAS and CMS First hints of H→bb - need more data

10

slide-11
SLIDE 11

LHC Run1 Results - Dmytro Kovalskyi April 7, 2014

CMS ttH

11

slide-12
SLIDE 12

LHC Run1 Results - Dmytro Kovalskyi April 7, 2014

ATLAS ttH

12

slide-13
SLIDE 13

Higgs Properties

slide-14
SLIDE 14

LHC Run1 Results - Dmytro Kovalskyi April 7, 2014

Higgs Widths

Direct limit on Higgs width:

3.4GeV @ 95%C.L

About 7.6% of total cross-section in the ZZ final state, but can be enhanced by experimental cuts

14

σon−peak ∝ g2

ggHg2 HZZ

ΓH σoff−peak ∝ g2

ggHg2 HZZ

  • N. Kauer and G. Passarino, JHEP 08 (2012) 116
slide-15
SLIDE 15

LHC Run1 Results - Dmytro Kovalskyi April 7, 2014

Analysis Strategy

On-peak cross-section - Standard Higgs analysis Off-peak component predicts a broad excess at larger mass

ZZ has best sensitivity in this region

Closer to the peak backgrounds are getting larger and more complex to measure a broad excess Dominant background is qq→ZZ

15

slide-16
SLIDE 16

LHC Run1 Results - Dmytro Kovalskyi April 7, 2014

Channels and Methods

H→ZZ→4ℓuses special discriminator:

MELA (matrix element with mZ1, mZ2 and 5 angles)

H→ZZ→2ℓ2ν

16 Signal Enhanced Background Enhanced

slide-17
SLIDE 17

LHC Run1 Results - Dmytro Kovalskyi April 7, 2014

Results

17

H→ZZ→4ℓ H→ZZ→2ℓ2ν Combined

slide-18
SLIDE 18

LHC Run1 Results - Dmytro Kovalskyi April 7, 2014

Higgs Mass

ATLAS measures somewhat different mass in H→ZZ→4ℓ vs H→γγ

The difference is not statistically significant

Both ATLAS and CMS combined results are fully consistent

18

slide-19
SLIDE 19

LHC Run1 Results - Dmytro Kovalskyi April 7, 2014

Relative Cross-section

19

slide-20
SLIDE 20

LHC Run1 Results - Dmytro Kovalskyi April 7, 2014

Couplings

20

slide-21
SLIDE 21

LHC Run1 Results - Dmytro Kovalskyi April 7, 2014

Spin

Results are consistent with CP even SM Higgs

21

slide-22
SLIDE 22
slide-23
SLIDE 23

SM Properties

slide-24
SLIDE 24

LHC Run1 Results - Dmytro Kovalskyi April 7, 2014

SM Cross Sections

24

[pb] σ Production Cross Section,

  • 1

10 1 10

2

10

3

10

4

10

5

10

CMS Preliminary

Feb 2014

W Z γ W γ Z WW WZ ZZ WW → γ γ qqll EW γ WV tt t-ch t tW s-ch t γ tt ttZ σ Δ in exp. H σ Δ Th. ggH qqH VBF VH ttH

CMS 95%CL limit )

  • 1

5.0 fb ≤ 7 TeV CMS measurement (L )

  • 1

19.6 fb ≤ 8 TeV CMS measurement (L 7 TeV Theory prediction 8 TeV Theory prediction

https://twiki.cern.ch/twiki/bin/view/CMSPublic/PhysicsResultsCombined

slide-25
SLIDE 25

LHC Run1 Results - Dmytro Kovalskyi April 7, 2014

Diboson Cross-section

25

slide-26
SLIDE 26

LHC Run1 Results - Dmytro Kovalskyi April 7, 2014

QCD (Z+jets)

26

slide-27
SLIDE 27

LHC Run1 Results - Dmytro Kovalskyi April 7, 2014

QCD (W+jets)

27

slide-28
SLIDE 28

Physics Beyond Standard Model (direct searches)

slide-29
SLIDE 29

LHC Run1 Results - Dmytro Kovalskyi April 7, 2014

ATLAS SUSY Limits

29

slide-30
SLIDE 30

LHC Run1 Results - Dmytro Kovalskyi April 7, 2014

CMS SUSY Limits

30

slide-31
SLIDE 31

LHC Run1 Results - Dmytro Kovalskyi April 7, 2014

SUSY

31

2/28/14 CMS Physics Week 4 gluino mass [GeV] 600 700 800 900 1000 1100 1200 1300 1400 1500 LSP mass [GeV] 100 200 300 400 500 600 700 800 900 Observed SUSY theory ! Observed -1 Expected m(gluino) - m(LSP) = 2 m(top) m(gluino) - m(LSP) = m(W) + m(top) Nov 2013 = 8 TeV s CMS Preliminary 1 " # t t $ g ~ production, g ~
  • g
~
  • 1
) 19.4 fb T +H T E SUS-12-024 0-lep (
  • 1
SUS-13-004 0+1-lep (razor) 19.3 fb
  • 1
6) 19.4 fb % jets SUS-13-007 1-lep (n
  • 1
SUS-13-016 2-lep (OS+b) 19.7 fb
  • 1
SUS-13-013 2-lep (SS+b) 19.5 fb
  • 1
SUS-13-008 3-lep (3l+b) 19.5 fb

Gluino mass ~ 1350GeV

stop mass [GeV] 100 200 300 400 500 600 700 800 LSP mass [GeV] 50 100 150 200 250 300 350 400 450 500 W =m 1 ! "
  • m
t ~ m t =m 1 ! "
  • m
t ~ m SUSY 2013 = 8 TeV s CMS Preliminary production t ~
  • t
~ ) 1 ! " t # t ~ (
  • 1
SUS-13-004 0-lep+1-lep (Razor) 19.3 fb ) 1 ! " t # t ~ (
  • 1
SUS-13-011 1-lep (leptonic stop)19.5 fb , x=0.25) 1 + ! " b # t ~ (
  • 1
SUS-13-011 1-lep (leptonic stop)19.5 fb Observed Expected W =m 1 ! "
  • m
1 ± ! " m

Stop mass ~ 750GeV

(GeV) q m 400 600 800 1000 1200 (GeV) LSP m 200 400 600 800
  • 2
10
  • 1
10 1 10 = 8 TeV s ,
  • 1
CMS Preliminary, 19.5 fb NLO+NLL exclusion 1 ! " q # q ~ , q ~ q ~ # pp ) c ~ , s ~ , d ~ , u ~ ( R q ~ + L q ~ q ~
  • ne light
theory $ 1 ± Observed experiment $ 1 ± Expected 95% C.L. upper limit on cross section (pb)

10x degenerate squarks ~ 950GeV

PAS

Sbottom mass ~ 750GeV

slide-32
SLIDE 32

LHC Run1 Results - Dmytro Kovalskyi April 7, 2014

Cross-section Scaling 8→13 TeV

32

Xsection Ratios 13/8 TeV ~1/fb of 13TeV data surpasses our best gluino limits. ~3/fb of 13TeV data surpasses our sbottom and stop limits. There will be no relevant SM measurements at 13TeV

D t

1350GeV gluino: x30 950GeV squark: x20 750GeV squark: x9 350GeV X+-X0: x3 top pairs: x4

slide-33
SLIDE 33

LHC Run1 Results - Dmytro Kovalskyi April 7, 2014

Dark Matter

33

slide-34
SLIDE 34

LHC Run1 Results - Dmytro Kovalskyi April 7, 2014

CMS Exotica Results

34

CMS Exotica Physics Group Summary – March, 2014 stopped gluino (cloud) stopped stop (cloud) HSCP gluino (cloud) HSCP stop (cloud) q=2/3e HSCP q=3e HSCP neutralino, ctau=25cm, ECAL time 1 2 3 4 RS1(γγ), k=0.1 RS1(ee,uu), k=0.1 RS1(jj), k=0.1 RS1(WW→4j), k=0.1 RS1(ZZ→4j), k=0.1 bulk RS(ZZ→lljj), k=0.5 1 2 3 4 coloron(jj) x2 coloron(4j) x2 gluino(3j) x2 gluino(jjb) x2 1 2 3 4

RS Gravitons Multijet Resonances Long-Lived Particles

SSM Z'(ττ) SSM Z'(jj) SSM Z'(bb) SSM Z'(ee)+Z'(µµ) SSM W'(jj) SSM W'(lv) SSM W'(WZ→lvll) SSM W'(WZ→4j) 1 2 3 4

Heavy Gauge Bosons

CMS Preliminary

j+MET, SI DM=100 GeV, Λ j+MET, SD DM=100 GeV, Λ γ+MET, SI DM=100 GeV, Λ γ+MET, SD DM=100 GeV, Λ l+MET, ξ=+1, SI DM=100 GeV, Λ l+MET, ξ=+1, SD DM=100 GeV, Λ l+MET, ξ=-1, SI DM=100 GeV, Λ l+MET, ξ=-1, SD DM=100 GeV, Λ 1 2 3 4

Dark Matter

LQ1(ej) x2 LQ1(ej)+LQ1(νj) LQ2(μj) x2 LQ2(μj)+LQ2(νj) LQ3(νb) x2 LQ3(τb) x2 LQ3(τt) x2 1 2 3 4

Leptoquarks

e* (M=Λ) μ* (M=Λ) q* (qg) q* (qγ) b* 1 2 3 4

Excited Fermions

dijets, Λ+ LL/RR dijets, Λ- LL/RR dimuons, Λ+ LLIM dimuons, Λ- LLIM single e, Λ HnCM single μ, Λ HnCM inclusive jets, Λ+ inclusive jets, Λ- 3 6 9 12 15 ADD (γγ), nED=4, MS ADD (ee,μμ), nED=4, MS ADD (j+MET), nED=4, MD ADD (γ+MET), nED=4, MD QBH, nED=4, MD=4 TeV NR BH, nED=4, MD=4 TeV Jet Extinction Scale String Scale (jj) 3 6 9 12 15

Large Extra Dimensions Compositeness

https://twiki.cern.ch/twiki/bin/view/CMSPublic/PhysicsResultsEXO

slide-35
SLIDE 35

LHC Run1 Results - Dmytro Kovalskyi April 7, 2014

Boosted Top

35

CMS Searches for New Physics Beyond Two Generations (B2G) 95% CL Exclusions (TeV)

0.5 1 1.5 2 2.5 3 3.5 4 4.5 5 t+MET,scalar(had) t+MET,vectorial(had) tW(semilep) → B' bH(semilep) → B' bZ(semilep) → B' bZ(dilep) → B' tW(multilep) → B' bH(multilep) → B' bZ(multilep) → B' bW(combined) → T' tH(combined) → T' tZ(combined) → T' T'(5/3)(dilep,ss)

Dark matter Vector-like B' Vector-like T'

0.5 1 1.5 2 2.5 3 3.5 4 4.5 5 t*(semilep) t*(dilep) W'(lep) Z'(1.2%)(all-had) (all-had) KK g Z'(1.2%)(semilep) (semilep) KK g Z'(1.2%)(combined) (combined) KK g

Excited tops tb Resonances Resonances t t

slide-36
SLIDE 36

LHC Run1 Results - Dmytro Kovalskyi April 7, 2014

Beyond SM with Higgs

36

slide-37
SLIDE 37

Vector Boson Scattering (indirect searches)

slide-38
SLIDE 38

LHC Run1 Results - Dmytro Kovalskyi April 7, 2014

EWK W/Z production

EWK: t-channel vector boson exchange Observed 5σ effect

38

arXiv:1401.7610 ¡

Signal

Background

slide-39
SLIDE 39

LHC Run1 Results - Dmytro Kovalskyi April 7, 2014

Anomalous Triple Gauge Couplings

Approaching LEP limits New methods: merged fat jet Results are coming slowly

Trying to fix it for next RUN

39

slide-40
SLIDE 40

LHC Run1 Results - Dmytro Kovalskyi April 7, 2014

Anomalous Quoter Gauge Couplings

Exclusive γγ→WW exceptional sensitivity

Very hard (impossible?) in high pileup

Tools and Methods are in development

EFT with FeynmanRules in Madgraph becomes default

40

slide-41
SLIDE 41

Top Mass

slide-42
SLIDE 42

LHC Run1 Results - Dmytro Kovalskyi April 7, 2014

Stability of the SM vacuum

42 arXiv:1307.3536 Buttazzo et al

SM Higgs discovered, no BSM. Pushing SM to Plank scale the measured Mh and Mtop place the SM vacuum in a meta-stable state due to negative Higgs coupling

slide-43
SLIDE 43

LHC Run1 Results - Dmytro Kovalskyi April 7, 2014

Top Mass Combination

43

slide-44
SLIDE 44

LHC Run1 Results - Dmytro Kovalskyi April 7, 2014

Top Mass combination

LHC vs Tevatron - remarkably consistent results

44

slide-45
SLIDE 45

LHC Run1 Results - Dmytro Kovalskyi April 7, 2014

Top Mass - Latest from CMS

Lepton+MET+jets Simultaneous fit for top mass and energy scale using W-mass constraint Significant change in the central value

45

W mass before fit W mass for good fits Top mass for good fits Top mass before fit

σ = 172.04 ± 0.19 ± 0.75GeV

slide-46
SLIDE 46

LHC Run1 Results - Dmytro Kovalskyi April 7, 2014

Systematics

46

slide-47
SLIDE 47

LHC Run1 Results - Dmytro Kovalskyi April 7, 2014

Summary

Higgs discovered

Standard Model is complete

Higgs boson looks exactly as SM predicts Searches for BSM show nothing new

Naturalness is looking decidedly less natural

Run2 will increase energy to 13TeV

Last time in a while that we may have a quick discovery

47
