LED LIGHTING IN DUBAI GENERAL PROJECTS DEPARTMENT DUBAI MUNICIPALITY EMIRATE OF DUBAI: OBJECTIVE AND VISION: LIGHTING PEOPLE DUBAI - Maintaining People Safety - Creating - Providing Advanced Lighting An Excellent And Smart City &
SLIDE 2
SLIDE 3
OBJECTIVE AND VISION:
- Creating
An Excellent And Smart City
- Providing Comfortable And
Sustainable Living
- Maintaining People Safety
& Security
- Improving Performance
- Reducing
Carbon Foot Print
- Providing Advanced Lighting
Solutions
- Increasing Sustainability
- Saving Resources
DUBAI PEOPLE LIGHTING
SLIDE 4
OUTDOOR LIGHTING APPLICATION:
- Street lighting
- Roadway lighting
- Parks and Community
Facilities
- Parking lots
- City Landscaping
- Residential and
Commercial Buildings
- Pedestrian and
Bicycling Pathways
SLIDE 5
PURPOSE OF OUTDOOR LIGHTING:
- Provide a safe and secure
environment at night.
- Extend the use of parks and
walkways into the night.
- To enhance historic/notable
features
- To enhance travel on the roads
and at intersections.
SLIDE 6
DUBAI GREEN BUILDING REGULATION – OUTDOOR LIGHTING POWER DENSITY:
Building Area Maximum Watts per square meter or linear meter
Uncovered parking lots and drives 1.6 W/m² Walkways less than 3 meters wide 3.3 W/linear meter Walkways 3 meters wide or greater 2.2 W/m² Outdoor Stairways 10.8 W/m² Main entries 98 W/linear meter of door width Other doors 66 W/linear meter of door width Open sales areas (including vehicle sales lots) 5.4 W/m² Building Facades
- 2.2 W/m² for each illuminated wall or surface
(or)
- 16.4 W/linear meter for each illuminated wall or surface
length
Entrances and gatehouse inspection stations at guarded facilities 13.5 W/m² Drive-up windows at fast food restaurants 400 W per drive-through
Lighting Power Densities for exterior areas not listed in Table 502.05 (1) should be no greater than those values given in ASHRAE 90.1-2007 Table 9.4.5or equivalent as approved by DEWA.
SLIDE 7
Light Source Comparison
Light Type Data Sheet lm/W Usable* lm/W Lifetime (hrs)
Incandescent 17 10-17 3k Halogen 20 12-20 10k T12 fluorescent 60 45-50 20k Metal halide 70 <40 8k-12k T8 fluorescent 74 55-60 20k Best-in-Class Power LED 120 55-75 35k-60k High-pressure sodium 91 <50 20-24k T5 fluorescent 107 96 20k Low-pressure sodium 120 65-70 18k
SLIDE 8
Guidelines for Specifying LED Lighting Solution for Projects :
- A LED luminaire consists of the following:
- LED modules, ballast or driver where applicable,
- Heat-sink for thermal management,
- Fixture and optics assembly
- LED lighting type should be identified in the projects.
- Self-ballasted type. (direct connection to supply mains)
- Non-self-ballasted (required separate driver for supply mains connection)
- LED
modules replacement/upgrading possibility within the luminaire without replacing the whole luminaire/fixture.
- Adequate ingress protection (IP) rating of the LED luminaire should be prescribed
for the intended application under specific environmental conditions. (IEC 60529)
- Optics (lens, diffuser or reflector) considering that Well-designed optics will reduce
- ptical losses and help improve the luminaire efficacy.
- Type of driver to power and control LED lighting (IEC 62384)
SLIDE 9
- LED lighting should have well-designed thermal management provisions to ensure
LED junction temperature be maintained within design limit.
- Maximum allowable ambient temperature for the LED lighting should be considered,
so that it can operate without affecting its life or colour stability. (30-45 deg C)
- Life and lumen maintenance, change in light output of a light source over
- perational life, relative to initially measured light output
- L70 = time to 70% of original light output at XX% of operational hours
- L50 = time to 50% of original light output at XX% of operational hours
SLIDE 10
IMPLEMENTED PROJECTS
SLIDE 11
LED & HID COMPARISON
Site
# of LED lamps (bulbs) LED
Consumption
(Watt) Wattage Category of Baseline (Watt) Delta in
Consumption
per hour (Wh/h) Running hours
Consumption
p.a. (KWh) Amount (AED) Savings p.a. (KWh) Savings Amount (AED)
PORT SAEED PLAZA
49 55 70 15 6 5,902 2,597 1,610 21% 708
HATTA C.F.
10 60 125 65 6 1,314 578 1,424 52% 626
LEHBAB C.F.
20 60 125 65 6 2,628 1,156 2,847 52% 1,253
NAZWA C.F.
26 60 125 65 6 3,416 1,503 3,701 52% 1,628
AL-WARQA 3RD
187 55 70 15 6 22,524 9,911 6,143 21% 2,703
NAD AL-HAMMAR
97 40 70 30 6 8,497 3,739 6,373 43% 2,804
AL-WARQA 2ND
34 40 70 30 6 2,978 1,310 2,234 43% 983
AL-MIZHAR 1ST
85 40 70 30 6 7,446 3,276 5,585 43% 2,457
AL-Awir Park
48 55 125 70 6 5,782 2,544 7,358 56% 3,238
AL-LISILY PARK
30 30 70 40 6 1,971 867 2,628 57% 1,156
Al-Khazzan Park
34 30 70 40 6 2,234 983 2,978 57% 1,310
AL-MUSHRIF PARK
250 40 70 30 6 21,900 9,636 16,425 43% 7,227
Al-Quran Park
665 60 125 65 6 87,381 38,448 94,663 52% 41,652
Jumeirah J. Track
75 30 70 40 6 4,928 2,168 6,570 57% 2,891
Total
1610 173,974 78,716 153,968 47% 70,637
LED Proposed Life Span (Hrs)
30,000 13-14 Years
HID Proposed Life Span (Hrs)
8,000 3-4 Years
SLIDE 12
LED Light ghts in Public blic Park rks (DUBAI AI MUNICIPALI PALITY) Y) TOTAL AL LED LIGH GHTS = 1,610 610 Nos. (Out (Out Of 13,868 68 Fittings ings) SAVINGS GS %= 47 47% ∼ (15 154 4 MWh/ h/Year Year) CO CO₂ Foot
- t Print
nt = 69 69 Ton n CO₂ /Yea ear PERCNTAGE AGE OF LED LIGH GHTS S = 11. 1.6 6 %
SLIDE 13
AL -MUS USHRIF HRIF PARK
SLIDE 14
NAD AL-HAMM HAMMAR AR PARK
SLIDE 15
AL AL-WARQ WARQAA AA 2nd
nd NEIBOU
BOURHOO RHOOD D PARK
SLIDE 16
PORT RT SAEE EED D PLA LAZA ZA
SLIDE 17
AL AL-WARQ WARQAA AA 3rd
rd COMMU
MMUNITY ITY FACILITY CILITY:
SLIDE 18
- Risks associated with the use of high power LED (Environment & Human)
- LED luminaires/fixtures associated cost (High Initial Cost/Investment)
- LED efficiency and life span drop at higher temperatures
LED ISSUES/CONCERNS :
