Lecture ¡6: ¡MIMO ¡Channel ¡and ¡ Spatial ¡Multiplexing

I-Hsiang Wang ihwang@ntu.edu.tw 5/1, 2014

slide-2
SLIDE 2

Mutliple ¡Antennas

  • Multi-Antennas so far:
  • Provide diversity gain and increase reliability
  • Provide power gain via beamforming (Rx, Tx, opportunistic)
  • But no degrees of freedom (DoF) gain
  • because at high SNR the capacity curves have the same slope
  • DoF gain is more significant in the high SNR regime
  • MIMO channels have a potential to provide DoF gain by

spatially multiplexing multiple data streams

  • Key questions:
  • How the spatial multiplexing capability depends on the physical

environment?

  • How to establish statistical models that capture the properties

succinctly?

2

slide-3
SLIDE 3

Plot

  • First study the spatial multiplexing capability of MIMO:
  • Convert a MIMO channel to parallel channel via SVD
  • Identify key factors for DoF gain: rank and condition number
  • Then explore physical modeling of MIMO with examples:
  • Angular resolvability
  • Multipath provides DoF gain
  • Finally study statistical modeling of MIMO channels:
  • Spatial domain vs. angular domain
  • Analogy with time-frequency channel modeling (Lecture 1)

3

slide-4
SLIDE 4

Outline

  • Spatial multiplexing capability of MIMO systems
  • Physical modeling of MIMO channels
  • Statistical modeling of MIMO channels

4

slide-5
SLIDE 5

5

Spatial ¡Multiplexing ¡in ¡ MIMO ¡Systems

slide-6
SLIDE 6

MIMO ¡AWGN ¡Channel

  • MIMO AWGN channel (no fading):
  • nt := # of Tx antennas; nr := # of Rx antennas
  • Tx power constraint P
  • Singular value decomposition (SVD) of matrix H:
  • Unitary
  • Rectangular
  • with zero off-diagonal elements and

diagonal elements

  • These λ’s are the singular values of matrix H

6

y[m] = Hx[m] + w[m]

y[m] ∈ Cnr, x[m] ∈ Cnt, H ∈ Cnr×nt, w ∼ CN (0, Inr)

H = UΛV∗

U ∈ Cnr×nr, V ∈ Cnt×nt (UU∗ = U∗U = I) Λ ∈ Cnr×nt λ1 ≥ λ2 ≥ · · · ≥ λmin(nt,nr) ≥ 0

slide-7
SLIDE 7

MIMO ¡Capacity ¡via ¡SVD

  • Change of coordinate:
  • Let
  • , get an equivalent channel
  • Power of x and w are preserved since U and V are unitary
  • Parallel channel: since the off-diagonal entries of Λ are

all zero, the above vector channel consists of nmin := min{nt,nr} parallel channels:

  • Capacity can be found via water-filling

7

e y := U∗y, e x := V∗x, e w := U∗w y = Hx + w = UΛV∗x + w ⇐ ⇒ U∗y = ΛV∗x + U∗w

e y = Λe x + e w e yi = λie xi + e wi, i = 1, 2, . . . , nmin

slide-8
SLIDE 8

Spatially ¡Parallel ¡Channels

8

V* ...

λ1 λnmin e wnmin e w1

U x y V U* e y e x x y H w H = UΛV∗

slide-9
SLIDE 9

Multiplexing ¡over ¡Parallel ¡Channels

9 + AWGN coder AWGN coder {x1[m]} ~ {y1 [m]} ~ {xnmin[m]} ~ {ynmin[m]} ~ . . . . . . . . . n min information streams {0} {0} {w[m]} U* H V Decoder Decoder

P ∗

i =

✓ ν − σ2 λ2

i

◆+ , ν satisfies

nmin

X

i=1

P ∗

i = P

CMIMO =

nmin

X

i=1

log ✓ 1 + λ2

i P ∗ i

σ2 ◆

slide-10
SLIDE 10

Rank ¡= ¡# ¡of ¡Multiplexing ¡Channels

10

V* ...

λ1 λnmin e wnmin e w1

U x y V U* e y e x

  • If λi = 0 ⟹ the i-th channel contributes 0 to the capacity
  • Rank of H = # of non-zero singular values

CMIMO =

k

X

i=1

log ✓ 1 + λ2

i P ∗ i

σ2 ◆ , , k := rank (H)

slide-11
SLIDE 11

Rank ¡= ¡# ¡of ¡Multiplexing ¡Channels

  • DoF gain is more significant at high SNR
  • At high SNR, uniform power allocation is near-optimal:
  • Rank of H determines how many data streams can be

multiplexed over the channel ⟹ k := multiplexing gain

  • Full rank matrix is the best (∵k ≤ nmin)

11

CMIMO ≈

k

X

i=1

log ✓ 1 + λ2

i P

kσ2 ◆ ≈

k

X

i=1

log ✓λ2

i P

kσ2 ◆ = k log SNR +

k

X

i=1

log ✓λ2

i

k ◆

slide-12
SLIDE 12

Condition ¡Number

  • Full rank is not enough:
  • If the some λi < 1, then log(λi2/k) will be negative
  • How to maximize the second term?
  • By Jensen’s inequality:
  • For a family of full-rank channel matrices with fixed
  • ,

since

  • , maximum is attained

when all λ’s are equal ⟺ λmax = λmin

  • Well-conditioned (smaller condition number λmax/λmin)

attain higher capacity

12

CMIMO ≈ k log SNR +

k

X

i=1

log ✓λ2

i

k ◆ 1 k

k

X

i=1

log ✓λ2

i

k ◆ ≤ k log Pk

i=1 λ2 i

k ! P

i,j |hi,j|2

P

i,j |hi,j|2 = Tr (HH∗) = Pk i=1 λ2 i

slide-13
SLIDE 13

Key ¡Channel ¡Parameters ¡for ¡MIMO

  • Rank of channel matrix H
  • Rank of H determines how many data streams can be

multiplexed over the channel

  • Condition number of channel matrix H
  • An ill-conditioned full-rank channel can have smaller capacity

than that of a well-conditioned rank-deficient channel

13

slide-14
SLIDE 14

14

Physical ¡Modeling ¡of ¡ MIMO ¡Channels

slide-15
SLIDE 15

15

Line-­‑of-­‑Sight ¡SIMO ¡Channel

...

φ d ∆rλc carrier wavelength: λc antenna spacing: ∆rλc

  • If distance d ≫ antenna distance spread, then
  • Phase difference between consecutive antennas is
  • Channel vector h lies along the direction er(Ω), where

Rx antenna i

...

di 2π∆r cos φ hi = ae−j2π fcdi

c

= ae−j2π di

λc

channel to i-th antenna: di = d + (i − 1)∆rλc cos φ, ∀ i = 1, 2, . . . , nr h = ae−j2π d

λc ⇥

1 e−j2π∆r cos φ · · · e−j2π(nr−1)∆r cos φ⇤T Ω := cos φ, er (Ω) := 1 √nr ⇥ 1 e−j2π∆rΩ · · · e−j2π(nr−1)∆rΩ⇤T directional cosine

y = hx + w

slide-16
SLIDE 16
  • If distance d ≫ antenna distance spread, then
  • Phase difference between consecutive antennas is
  • Channel vector h lies along the direction et(Ω), where

di = d − (i − 1)∆tλc cos φ, ∀ i = 1, 2, . . . , nt

16

Line-­‑of-­‑Sight ¡MISO ¡Channel

φ d Tx antenna i

... ...

di directional cosine ∆tλc

y = h∗x + w

−2π∆t cos φ h = aej2π d

λc ⇥

1 e−j2π∆t cos φ · · · e−j2π(nt−1)∆t cos φ⇤T Ω := cos φ, et (Ω) := 1 √nt ⇥ 1 e−j2π∆tΩ · · · e−j2π(nt−1)∆tΩ⇤T

slide-17
SLIDE 17

Line-­‑of-­‑Sight ¡SIMO ¡and ¡MISO

  • Line-of-sight SIMO:
  • y = hx+w, h is along the receive spatial signature er(Ω), where
  • nr -fold power gain, no DoF gain
  • Line-of-sight SIMO:
  • y = hx+w, h is along the transmit spatial signature et(Ω), where
  • nt -fold power gain, no DoF gain

17

er (Ω) := 1 √nr ⇥ 1 e−j2π∆rΩ · · · e−j2π(nr−1)∆rΩ⇤T et (Ω) := 1 √nt ⇥ 1 e−j2π∆tΩ · · · e−j2π(nt−1)∆tΩ⇤T

slide-18
SLIDE 18

...

18

Line-­‑of-­‑Sight ¡MIMO ¡Channel

d

... y = Hx + w

Tx k Rx i

di,k

= ⇒ hi,k = ae−j2π d

λc e−j2π(i−1)∆rΩrej2π(k−1)∆tΩt

di,k = d + (i − 1)∆rλc cos φr − (k − 1)∆tλc cos φt = ⇒ H = ae−j2π d

λc √ntnrer (Ωr) et (Ωr)∗

  • Rank of H = 1 ⟹ no spatial multiplexing gain!
  • In line-of-sight MIMO, still power gain only
