Lecture 6: Introduction to Detection Jonathan Krause Fei-Fei Li, - - PowerPoint PPT Presentation

Lecture 6 - Fei-Fei Li, Jonathan Krause 1

Lecture 6: Introduction to Detection

Jonathan Krause

Lecture 6 - Fei-Fei Li, Jonathan Krause

• Locate objects in images

Goal

2

Lecture 6 - Fei-Fei Li, Jonathan Krause

Variants: Pedestrian Detection

3 Leibe et al., 2005

Lecture 6 - Fei-Fei Li, Jonathan Krause

Variants: Face Detection

4

Lecture 6 - Fei-Fei Li, Jonathan Krause

Variants: Instance Detection

5 Lowe 2004

Lecture 6 - Fei-Fei Li, Jonathan Krause

Variants: Multi-Class Detection

6

Lecture 6 - Fei-Fei Li, Jonathan Krause

Application: Tagging People

7

Putin Obama

Lecture 6 - Fei-Fei Li, Jonathan Krause

Application: Autonomous Driving

8 Huval et al., 2015

Lecture 6 - Fei-Fei Li, Jonathan Krause

Application: Robotics

9 Lai et al., 2012

Lecture 6 - Fei-Fei Li, Jonathan Krause

Application: Tracking

10 Berclaz et al., 2011

Lecture 6 - Fei-Fei Li, Jonathan Krause

Application: Segmentation

11 Hariharan et al., 2014

Lecture 6 - Fei-Fei Li, Jonathan Krause

• 1. Sliding Window Methods
• 2. Region-based Methods
• 3. Extra Topics

Outline

12

Lecture 6 - Fei-Fei Li, Jonathan Krause

• 1. Sliding Window Methods
• 1. Overview
• 2. Viola-Jones Face Detection
• 3. HOG
• 4. Exemplar SVM
• 5. DPM
• 2. Region-based Methods
• 3. Extra Topics

Outline

13

Lecture 6 - Fei-Fei Li, Jonathan Krause

Getting Started: Kitten Detection

14

Goal: Detect all kittens

Lecture 6 - Fei-Fei Li, Jonathan Krause

Checking Windows for Kittens

15

No

Lecture 6 - Fei-Fei Li, Jonathan Krause

Checking Windows for Kittens

16

No

Lecture 6 - Fei-Fei Li, Jonathan Krause

Checking Windows for Kittens

17

No

Lecture 6 - Fei-Fei Li, Jonathan Krause

Checking Windows for Kittens

18

No

Lecture 6 - Fei-Fei Li, Jonathan Krause

Sliding Windows

19

Evaluate every bounding box position

Lecture 6 - Fei-Fei Li, Jonathan Krause

• Even if we search all 2d positions, still don’t

know aspect ratio or scale.

Aspect Ratio and Scale

20

• Solution: Multiple aspect ratios and multi-scale

Lecture 6 - Fei-Fei Li, Jonathan Krause

• Extremely fast
• Very accurate (at the time)

Viola Jones Face Detector

21 Viola, Jones. 2001

Lecture 6 - Fei-Fei Li, Jonathan Krause

Viola Jones

22 Viola, Jones. 2001

Key Idea: Boosting on weak classifiers

Lecture 6 - Fei-Fei Li, Jonathan Krause

Haar Filters

23 Viola, Jones. 2001

Simple patterns of lightness and darkness

Lecture 6 - Fei-Fei Li, Jonathan Krause

Haar Filters w/Integral Images

24

Filter: Image:

Decomposition: smaller filters

Lecture 6 - Fei-Fei Li, Jonathan Krause

Haar Filters w/Integral Images

25

Response at a single location: =

• +

Only need to compute sum of top-left responses (DP)!

Lecture 6 - Fei-Fei Li, Jonathan Krause

Viola Jones: Weak Classifiers

26 Viola, Jones. 2001

Each Haar filter is a weak classifier

Top classifier Second best

Lecture 6 - Fei-Fei Li, Jonathan Krause

Combining Weak Classifiers

27 Viola, Jones. 2001

AdaBoost:

: binary classifier on Haar filter t : learned weight on classifier t AdaBoost classifier: minimizes loss:

Lecture 6 - Fei-Fei Li, Jonathan Krause

Cascade

28 Viola, Jones. 2001

Reject negatives quickly

Lecture 6 - Fei-Fei Li, Jonathan Krause

• Fast at runtime
• Takes a long time to train
• Very accurate (at the time)
• Inspired other detection methods

Viola Jones Summary

29

Lecture 6 - Fei-Fei Li, Jonathan Krause

• Histograms of Oriented Gradients
• Designed for Pedestrian Detection
• Really just good feature engineering

HOG

30 Dalal, Triggs. 2005

Lecture 6 - Fei-Fei Li, Jonathan Krause

• Lots of feature engineering…

HOG

31 Dalal, Triggs. 2005

Lecture 6 - Fei-Fei Li, Jonathan Krause

More feature engineering

32 Dalal, Triggs. 2005

Lecture 6 - Fei-Fei Li, Jonathan Krause

But it works

33 Dalal, Triggs. 2005

avg. gradient max pos. SVM weight min neg. SVM weight HOG pos SVM weights neg SVM weights

Lecture 6 - Fei-Fei Li, Jonathan Krause

• Key idea: Train a separate SVM for each positive

training example (on HOG features!).

Exemplar SVM

34 Malisiewicz et al. 2011

Lecture 6 - Fei-Fei Li, Jonathan Krause

• Q: But wait, isn’t that going to be horribly slow?
• A: Yep! Much slower than a single SVM. No one I

know of actually uses this. However….

• Can transfer metadata (segmentations!)

Exemplar SVM

35 Malisiewicz et al. 2011

Lecture 6 - Fei-Fei Li, Jonathan Krause

Exemplar SVM Examples

36 Malisiewicz et al. 2011

Lecture 6 - Fei-Fei Li, Jonathan Krause

Exemplar SVM Examples

37 Malisiewicz et al. 2011

Lecture 6 - Fei-Fei Li, Jonathan Krause

• (sneak preview of student presentation)
• Similar to SVM on HOG, but also with parts

(latent SVM)

• State of the art for several years

Deformable Part Models

38

Lecture 6 - Fei-Fei Li, Jonathan Krause

• Evaluate classifier at many positions
• Dominant detection paradigm until ~2 years ago
• Boosting, SVM, and DPM

Sliding Window Summary

39

Lecture 6 - Fei-Fei Li, Jonathan Krause

• 1. Sliding Window Methods
• 2. Region-based Methods

1. Motivation 2. Region Proposals 3. R-CNN

• 3. Extra Topics

Outline

40

Lecture 6 - Fei-Fei Li, Jonathan Krause

Sliding Window Problem: Efficiency

41

Q: How many bounding boxes in this 482 x 348 image? A: 6,999,078,138 (7 trillion)

Lecture 6 - Fei-Fei Li, Jonathan Krause 42

Can’t classify 7 trillion windows, even millions is slow. Can we massively cut down this number (e.g. 1000s)?

Sliding Window Problem: Efficiency

Lecture 6 - Fei-Fei Li, Jonathan Krause

Detection on Regions

43

• Generate detection proposals (typically ~2000)
• Classify each region with a much stronger classifier
• More or less taken over modern detection

van de Sande et al., 2011

Lecture 6 - Fei-Fei Li, Jonathan Krause

Region Proposals

44

• Sliding window or grouping pixels
• May or may not output score
• Varying amount of control over number of regions

“What makes for effective detection proposals?”. Hosang, Benenson, Dollar, Schiele. 2015

Lecture 6 - Fei-Fei Li, Jonathan Krause

• Sliding window
• Score based on a bunch of heuristic features

Objectness

45 Alexe, Deselares, Ferrari. 2010

Lecture 6 - Fei-Fei Li, Jonathan Krause

• Felzenszwalb superpixels
• Merge based on color features
• Most common method in use

Selective Search

46 van de Sande et al., 2011

Lecture 6 - Fei-Fei Li, Jonathan Krause

• Structured decision forest for object boundaries
• Coarse sliding windows with location refinement
• Seems fast and accurate, but time will tell

Edge Boxes

47 Zitnick, Dollar. 2014

Lecture 6 - Fei-Fei Li, Jonathan Krause

• What fraction of ground truth bounding boxes

do they recover?

• How many proposals does it take?
• At what IoU overlap threshold?

Evaluating Region Proposals

48 “What makes for effective detection proposals?”. Hosang, Benenson, Dollar, Schiele. 2015

Lecture 6 - Fei-Fei Li, Jonathan Krause

• Recall at IoU threshold=0.7 predicts detection

performance well

• Most people use ~2000 regions produced with

Selective Search (a few seconds/image)

• Edge Boxes looks promising

In Practice

49

Lecture 6 - Fei-Fei Li, Jonathan Krause

• Most detectors, region proposal methods in

particular, reduce detection to repeated classification

• Let’s take a look at a few key ideas in

classification

Aside: Classification

50

Lecture 6 - Fei-Fei Li, Jonathan Krause

Descriptors

Classification: Bag of Words

51

Codebook

Offline: Cluster descriptors in training images

Histogram SVM

frequency

Note: No spatial information

Lecture 6 - Fei-Fei Li, Jonathan Krause

Classification: Spatial Pyramid

52

big SVM

Lazebnik et al. 2006

Lecture 6 - Fei-Fei Li, Jonathan Krause

Classification

53

• Sparse Coding (LLC: Locality constrained Linear

Coding)

• Represent descriptor with more than one codeword
• Fisher Vectors
• Represent difference between descriptor and

codewords (very roughly)

• A little better, still used sometimes

Wang et al. 2010 Perronnin et al. 2010

Lecture 6 - Fei-Fei Li, Jonathan Krause

2012

54

• In 2012 neural networks started working

[Krizhevsky et al. 2012]

Russakovsky et al. 2015

Lecture 6 - Fei-Fei Li, Jonathan Krause

Neural Nets

55

• Learn the whole pipeline (pixels to classes)

from scratch.

• Many layers of (learned) intermediate features
• Will see more in student presentation

Krizhevsky et al. 2012

Lecture 6 - Fei-Fei Li, Jonathan Krause

• R-CNN = Selective Search + CNN
• That’s it.

R-CNN

56 Girshick et al. 2014

Lecture 6 - Fei-Fei Li, Jonathan Krause

• Need region to fit input size of CNN
• Region warping method:

R-CNN Details

57 Girshick et al. 2014

add context region pad with zero warp works the best

Lecture 6 - Fei-Fei Li, Jonathan Krause

• Context around region
• 0 or 16 pixels (in CNN reference frame)

R-CNN Details

58 Girshick et al. 2014

region works the best 16

Lecture 6 - Fei-Fei Li, Jonathan Krause

• CNN Layer is important
• fc6 best?

R-CNN Details

59 Girshick et al. 2014

Lecture 6 - Fei-Fei Li, Jonathan Krause

• fine-tuning on PASCAL (CNN trained on ILSVRC)
• It helps, and may make another layer better

R-CNN Details

60 Girshick et al. 2014

Lecture 6 - Fei-Fei Li, Jonathan Krause

• Bounding box regression
• Regress from CNN features to bounding box
• Helps quite a bit

R-CNN Details

61 Girshick et al. 2014

Lecture 6 - Fei-Fei Li, Jonathan Krause

• Train SVM on top of CNN features
• Be careful about which are positives and which

are negatives (use the IoU overlap!)

• Hard negative mining for efficiency.

R-CNN Details

62 Girshick et al. 2014

Lecture 6 - Fei-Fei Li, Jonathan Krause

• 1. Sliding Window Methods
• 2. Region-based Methods
• 3. Extra Topics

Outline

63

Lecture 6 - Fei-Fei Li, Jonathan Krause

• Typically done with Average Precision (AP)
• When considering multiple classes, use mean

(across classes) Average Precision (mAP)

Evaluation

64

Lecture 6 - Fei-Fei Li, Jonathan Krause

• Surroundings can provide information
• Many methods use a weak version of this

Context

65

What object is this?

Lecture 6 - Fei-Fei Li, Jonathan Krause

• Turn multiple detections into one
• Common approach: merge bounding boxes with

>= 0.5 (or some threshold) IoU, keep the higher scoring box.

Non-maximal Suppression

66

Lecture 6 - Fei-Fei Li, Jonathan Krause

• Efficient sliding windows with CNNs

OverFeat

67 Sermanet et al. 2013

Lecture 6 - Fei-Fei Li, Jonathan Krause

• Very new, reuses most CNN computation across

regions

Fast R-CNN

68

• Girshick. 2015

Lecture 6 - Fei-Fei Li, Jonathan Krause

• Try to learn the region proposals

Multibox

69 Erhan et al. 2014

Lecture 6 - Fei-Fei Li, Jonathan Krause

• 20 Object Categories, thousands of images
• 2007-2012
• Was the dataset for a long time.

Detection Challenges: PASCAL

70

Lecture 6 - Fei-Fei Li, Jonathan Krause

• 200 Object Categories, 100,000s of images
• 2013-current
• Not all images fully annotated.

Detection Challenges: ILSVRC

71
