Lecture 3: Bayesian Decision Theory

• Dr. Chengjiang Long

Computer Vision Researcher at Kitware Inc. Adjunct Professor at RPI. Email: longc3@rpi.edu

• C. Long

Lecture 3 January 28, 2018 2

Recap Previous Lecture

• C. Long

Lecture 3 January 28, 2018 3

Outline

• What's Beyesian Decision Theory?
• A More General Theory
• Discriminant Function and Decision Boundary
• Multivariate Gaussian Density

• C. Long

Lecture 3 January 28, 2018 4

Outline

• What's Beyesian Decision Theory?
• A More General Theory
• Discriminant Function and Decision Boundary
• Multivariate Gaussian Density

• C. Long

Lecture 3 January 28, 2018 5

Bayesian Decision Theory

• Design classifiers to make decisions subject to

minimizing an expected "risk".

• The simplest risk is the classification error (i.e.,

assuming that misclassification costs are equal).

• When misclassification costs are not equal, the risk

can include the cost associated with different misclassifications.

• C. Long

Lecture 3 January 28, 2018 6

Terminology

• State of nature ω (class label):
• e.g., ω1 for sea bass, ω2 for salmon
• Probabilities P(ω1) and P(ω2) (priors):
• e.g., prior knowledge of how likely is to get a sea

bass or a salmon

• Probability density function p(x) (evidence):
• e.g., how frequently we will measure a pattern with

feature value x (e.g., x corresponds to lightness)

• C. Long

Lecture 3 January 28, 2018 7

Terminology

• Conditional probability density p(x/ωj) (likelihood) :
• e.g., how frequently we will measure a pattern with

feature value x given that the pattern belongs to class ωj

• C. Long

Lecture 3 January 28, 2018 8

Terminology

• Conditional probability P(ωj /x) (posterior) :
• e.g., the probability that the fish belongs to

class ωj given feature x.

• Ultimately, we are interested in computing P(ωj /x)

for each class ωj.

• C. Long

Lecture 3 January 28, 2018 9

Decision Rule

• r
• Favours the most likely class.
• This rule will be making the same decision all times.
• i.e., optimum if no other information is available

• C. Long

Lecture 3 January 28, 2018 10

Decision Rule

• Using Bayes’ rule:

where

( / ) ( ) ( / ) ( )

j j j

p x P likelihood prior P x p x evidence w w w ´ = =

2 1

( ) ( / ) ( )

j j j

p x p x P w w

=

= å

Decideω1 if P(ω1 /x) > P(ω2 /x); otherwise decide ω2

• r

Decideω1 if p(x/ω1)P(ω1)>p(x/ω2)P(ω2); otherwise decideω2

• r

Decideω1 if p(x/ω1)/p(x/ω2) >P(ω2)/P(ω1) ; otherwise decide ω2

• C. Long

Lecture 3 January 28, 2018 11

Decision Rule

1 2

2 1 ( ) ( ) 3 3 P P w w = =

P(ωj /x) p(x/ωj)

• C. Long

Lecture 3 January 28, 2018 12

Probability of Error

• The probability of error is defined as:
• r
• What is the average probability error?
• The Bayes rule is optimum, that is, it minimizes

the average probability error!

• C. Long

Lecture 3 January 28, 2018 13

Where do Probabilities come from?

• There are two competitive answers:

 Relative frequency (objective) approach.

• Probabilities can only come from experiments.

 Bayesian (subjective) approach.

• Probabilities may reflect degree of belief and can be

based on opinion.

• C. Long

Lecture 3 January 28, 2018 14

Example: Objective approach

• Classify cars whether they are more or less than

$ 50K:

• Classes: C1 if price >50K, C2 if price <= 50K
• Features: x, the height of a car
• Use the Bayes’ rule to compute the posterior

probabilities:

• We need to estimate p(x/C1), p(x/C2), P(C1), P(C2)

( / ) ( ) ( / ) ( )

i i i

p x C P C P C x p x =

• C. Long

Lecture 3 January 28, 2018 15

Example: Objective approach

• Collect data
• Ask drivers how much their car was and measure height.
• Determine prior probabilities P(C1), P(C2)
• e.g., 1209 samples: #C1=221 #C2=988

1 2

221 ( ) 0.183 1209 988 ( ) 0.817 1209 P C P C = = = =

• C. Long

Lecture 3 January 28, 2018 16

Example: Objective approach

• Determine class conditional probabilities (likelihood)
• Discretize car height into bins and use normalized

histogram

 Calculate the posterior probability for each bin:

( / )

i

p x C

1 1 1 1 1 2 2

( 1.0/ ) ( ) ( / 1.0) ( 1.0/ ) ( ) ( 1.0/ ) ( ) 0.2081*0.183 0.438 0.2081*0.183 0.0597*0.817 p x C P C P C x p x C P C p x C P C = = = = = + = = = +

• C. Long

Lecture 3 January 28, 2018 17

Outline

• What's Beyesian Decision Theory?
• A More General Theory
• Discriminant Function and Decision Boundary
• Multivariate Gaussian Density

• C. Long

Lecture 3 January 28, 2018 18

A More General Theory

 Use more than one features.  Allow more than two categories.  Allow actions other than classifying the input to one of the possible

categories (e.g., rejection).

 Employ a more general error function (i.e., expected “risk”) by

associating a “cost” (based on a “loss” function) with different errors.

• C. Long

Lecture 3 January 28, 2018 19

Terminology

• Features form a vector
• A set of c categories ω1, ω2, …, ωc
• A finite set of l actions α1, α2, …, αl
• A loss function λ(αi / ωj)
• the cost associated with taking action αi when the

correct classification category is ωj

d

R Î x

• C. Long

Lecture 3 January 28, 2018 20

Conditional Risk (or Expected Loss)

• Suppose we observe x and take action αi
• The conditional risk (or expected loss) with taking

action αi is defined as:

1

( / ) ( / ) ( / )

c i i j j j

R a a P l w w

=

= å x x

From a medical image, we want to classify (determine) whether it contains cancer tissues or not.

• C. Long

Lecture 3 January 28, 2018 21

Overall Risk

• Suppose α(x) is a general decision rule that

determines which action α1, α2, …, αl to take for every x.

• The overall risk is defined as:
• The optimum decision rule is the Bayes rule

( ( ) / ) ( ) R R a p d = ò x x x x

• C. Long

Lecture 3 January 28, 2018 22

Overall Risk

• The Bayes rule minimizes R by:

(i) Computing R(αi /x) for every αi given an x (ii) Choosing the action αi with the minimum R(αi /x)

• The resulting minimum R* is called Bayes risk and

is the best (i.e., optimum) performance that can be achieved:

*

min R R =

• C. Long

Lecture 3 January 28, 2018 23

Example: Two-category classification

• Define
• α1: decide ω1
• α2: decide ω2
• λij = λ(αi /ωj)
• The conditional risks are:

1

( / ) ( / ) ( / )

c i i j j j

R a a P l w w

=

= å x x

• C. Long

Lecture 3 January 28, 2018 24

Example: Two-category classification

• Minimum risk decision rule:
• r (i.e., using likelihood ratio)
• r

likelihood ratio threshold

• C. Long

Lecture 3 January 28, 2018 25

Special Case: Zero-One Loss Function

• Assign the same loss to all errors:
• The conditional risk corresponding to this loss function:

• C. Long

Lecture 3 January 28, 2018 26

Special Case: Zero-One Loss Function

• The decision rule becomes:
• The overall risk turns out to be the average probability

error!

• r
• r

• C. Long

Lecture 3 January 28, 2018 27

Example

• Assuming general loss:
• Assuming zero-one loss:

Decide ω1 if p(x/ω1)/p(x/ω2)>P(ω2 )/P(ω1) otherwise decide ω2

2 1

( )/ ( )

a

P P q w w =

2 12 22 1 21 11

( )( ) ( )( )

b

P P w l l q w l l

• =
• 12

21

l l >

assume:

• C. Long

Lecture 3 January 28, 2018 28

Outline

• What's Beyesian Decision Theory?
• A More General Theory
• Discriminant Function and Decision Boundary
• Multivariate Gaussian Density
• Error Bound, ROC, Missing Features and Compound

Bayesian Decision Theory

• Summary

• C. Long

Lecture 3 January 28, 2018 29

Discriminant Functions

• A useful way to represent a classifier is through

discriminant functions gi(x), i = 1, . . . , c, where a feature vector x is assigned to class ωi if gi(x) > gj(x) for all j i

max

• C. Long

Lecture 3 January 28, 2018 30

Discriminants for Bayes Classifier

• Is the choice of gi unique?
• Replacing gi(x) with f(gi(x)), where f() is

monotonically increasing, does not change the classification results.

( / ) ( ) ( ) ( ) ( ) ( / ) ( ) ( ) ln ( / ) ln ( )

i i i i i i i i i

p P g p g p P g p P w w w w w w = = = + x x x x x x x

gi(x)=P(ωi/x)

we’ll use this discriminant extensively!

• C. Long

Lecture 3 January 28, 2018 31

Case of two categories

• More common to use a single discriminant function

(dichotomizer) instead of two: Examples:

1 2 1 1 2 2

( ) ( / ) ( / ) ( / ) ( ) ( ) ln ln ( / ) ( ) g P P p P g p P w w w w w w =

• =

+ x x x x x x

• C. Long

Lecture 3 January 28, 2018 32

Decision Regions and Boundaries

• Discriminants divide the feature space in decision regions

R1, R2, …, Rc, separated by decision boundaries.

Decision boundary is defined by: g1(x)=g2(x)

• C. Long

Lecture 3 January 28, 2018 33

Outline

• What's Beyesian Decision Theory?
• A More General Theory
• Discriminant Function and Decision Boundary
• Multivariate Gaussian Density

• C. Long

Lecture 3 January 28, 2018 34

Why are Gaussians so Useful?

• They represent many probability distributions in nature

quite accurately. In our case, when patterns can be represented as random variations of an ideal prototype (represented by the mean feature vector)

• Everyday examples: height, weight of a population

• C. Long

Lecture 3 January 28, 2018 35

Multivariate Gaussian Density

• A normal distribution over two or more variables (d

variables/dimensions)

• C. Long

Lecture 3 January 28, 2018 36

The Covariance Matrix

• For our purposes...
• Assume matrix is positive definite, so the determinant
• f the matrix is always positive
• Matrix Elements
• Main diagonal: variances for each individual variable
• Off-diagonal: covariances of each variable pairing i & j

(note: values are repeated, as matrix is symmetric)

• C. Long

Lecture 3 January 28, 2018 37

Discriminant Function for Multivariate Gaussian Density

• We will consider three special cases for:
• normally distributed features, and
• minimum error rate classification (0-1 loss)

 Recall:

• C. Long

Lecture 3 January 28, 2018 38

Minimum Error-Rate Discriminant Function for Multivariate Gaussian Feature Distributions

• ln (natural log) of

gives a general form for our discriminant functions:

• C. Long

Lecture 3 January 28, 2018 39

Special Cases for Binary Classification

• Purpose

Overview of commonly assumed cases for feature likelihood densities,

• Goal: eliminate common additive constants in discriminant
• functions. These do not affect the classification decision

(i.e. define providing “just the differences”)

• Also, look at resulting decision surfaces ( )
• Three Special Cases

①

Statistically independent features, identically distributed Gaussians for each class

②

Identical covariances for each class

③

Arbitrary covariances

• C. Long

Lecture 3 January 28, 2018 40

Case I:

• Satisfiy two conditions: (1) Features are statistically independent and

(2) Each feature has the same variance.

• Remove Items in red: same across classes (“unimportant additive

constants”)

• Inverse of covariance matrix:
• Only effect is to scale vector product by
• Discriminant function:

• C. Long

Lecture 3 January 28, 2018 41

Case I:

• Linear Discriminant Function
• Produced by factoring the previous form
• Threshold or Bias for Class i:
• Change in prior translates decision boundary

• C. Long

Lecture 3 January 28, 2018 42

Case I:

• Decision Boundary:
• Decision boundary goes through x0 along line between means,
• rthogonal to this line
• If priors equal, x0 between means (minimum distance classifier),
• therwise x0 shifted
• If variance small relative to distance between means, priors have

limited effect on boundary location

• C. Long

Lecture 3 January 28, 2018 43

Case 1: Statistically Independent Features with Identical Variances

• C. Long

Lecture 3 January 28, 2018 44

Example: Translation of Decision Boundaries Through Changing Priors

• C. Long

Lecture 3 January 28, 2018 45

Case II: Identical Covariances

• Remove terms in red as in Case I these can be ignored

(same across classes)

• Squared Mahalanobis Distance (yellow)
• Distance from x to mean for class i, taking covariance

into account; defines contours of fixed density

• C. Long

Lecture 3 January 28, 2018 46

Case II: Identical Covariances

• Expansion of squared Mahalanobis distance

the last step comes from symmetry of the covariance matrix and thus its inverse:

• Once again, term above in red is an additive constant independent of

class, and can be removed

• C. Long

Lecture 3 January 28, 2018 47

Multivariate Gaussian Density:

• Linear Discriminant Function
• Decision Boundary:

• C. Long

Lecture 3 January 28, 2018 48

Case II: Identical Covariances

• Notes on Decision Boundary
• As for Case I, passes through point x0 lying on the line between the two

class means. Again, x0 in the middle if priors identical

• Hyperplane defined by boundary generally not orthogonal to the line

between the two means

• C. Long

Lecture 3 January 28, 2018 49

Case III: arbitrary

 Can only remove the one term in red aboveSquared  Discriminant Function (quadratic)

• C. Long

Lecture 3 January 28, 2018 50

Case III: arbitrary

 Decision Boundaries

• Are hyperquadrics: can be hyperplanes,
• hyperplane pairs, hyperspheres,
• hyperellipsoids, hyperparabaloids,
• hyperhyperparabaloids

 Decision Regions

• Need not be simply connected, even in one dimension (next

slide)

• C. Long

Lecture 3 January 28, 2018 51

Case III: arbitrary

• C. Long

Lecture 3 January 28, 2018 52

Case III: arbitrary

Nonlinear decision boundaries

• C. Long

Lecture 3 January 28, 2018 53

Example: Case III

P(ω1)=P(ω2) decision boundary:

boundary does not pass through midpoint of μ1,μ2

• C. Long

Lecture 3 January 28, 2018 54
