Learning: Nearest Neighbor, Perceptrons & Neural Nets

Artificial Intelligence CSPP 56553 February 4, 2004

Nearest Neighbor Example II

• Credit Rating:

– Classifier: Good / Poor – Features:

• L = # late payments/yr;
• R = Income/Expenses

Name L R G/P A 0 1.2 G B 25 0.4 P C 5 0.7 G D 20 0.8 P E 30 0.85 P F 11 1.2 G G 7 1.15 G H 15 0.8 P

Nearest Neighbor Example II

Name L R G/P A 0 1.2 G B 25 0.4 P C 5 0.7 G D 20 0.8 P E 30 0.85 P F 11 1.2 G G 7 1.15 G H 15 0.8 P L R 30 20 10 1 A B C D E F G H

Nearest Neighbor Example II

L 30 20 10 1 A B C D E F G H R Name L R G/P I 6 1.15 J 22 0.45 K 15 1.2 G I P J ?? K Distance Measure: Sqrt ((L1-L2)^2 + [sqrt(10)*(R1-R2)]^2))

• Scaled distance

Nearest Neighbor: Issues

• Prediction can be expensive if many

features

• Affected by classification, feature noise

– One entry can change prediction

• Definition of distance metric

– How to combine different features

• Different types, ranges of values
• Sensitive to feature selection

Efficient Implementations

• Classification cost:

– Find nearest neighbor: O(n)

• Compute distance between unknown and all

instances

• Compare distances

– Problematic for large data sets

• Alternative:

– Use binary search to reduce to O(log n)

Efficient Implementation: K-D Trees

• Divide instances into sets based on features

– Binary branching: E.g. > value – 2^d leaves with d split path = n

• d= O(log n)

– To split cases into sets,

• If there is one element in the set, stop
• Otherwise pick a feature to split on

– Find average position of two middle objects on that dimension » Split remaining objects based on average position » Recursively split subsets

K-D Trees: Classification

R > 0.825? L > 17.5? L > 9 ? No Yes R > 0.6? R > 0.75? R > 1.025 ? R > 1.175 ? No Yes No Yes No Poor Good Yes No Yes Good Poor No Yes Good Good No Poor Yes Good

Efficient Implementation: Parallel Hardware

• Classification cost:

– # distance computations

• Const time if O(n) processors

– Cost of finding closest

• Compute pairwise minimum, successively
• O(log n) time

Nearest Neighbor: Analysis

• Issue:

– What features should we use?

• E.g. Credit rating: Many possible features

– Tax bracket, debt burden, retirement savings, etc..

– Nearest neighbor uses ALL – Irrelevant feature(s) could mislead

• Fundamental problem with nearest neighbor

Nearest Neighbor: Advantages

• Fast training:

– Just record feature vector - output value set

• Can model wide variety of functions

– Complex decision boundaries – Weak inductive bias

• Very generally applicable

Summary: Nearest Neighbor

• Nearest neighbor:

– Training: record input vectors + output value – Prediction: closest training instance to new data

• Efficient implementations
• Pros: fast training, very general, little bias
• Cons: distance metric (scaling), sensitivity

to noise & extraneous features

Learning: Perceptrons

Artificial Intelligence CSPP 56553 February 4, 2004

Agenda

• Neural Networks:

– Biological analogy

• Perceptrons: Single layer networks
• Perceptron training
• Perceptron convergence theorem
• Perceptron limitations
• Conclusions

Neurons: The Concept

Axon Cell Body Nucleus Dendrites Neurons: Receive inputs from other neurons (via synapses) When input exceeds threshold, “fires” Sends output along axon to other neurons Brain: 10^11 neurons, 10^16 synapses

Artificial Neural Nets

• Simulated Neuron:

– Node connected to other nodes via links

• Links = axon+synapse+link
• Links associated with weight (like synapse)

– Multiplied by output of node

– Node combines input via activation function

• E.g. sum of weighted inputs passed thru threshold
• Simpler than real neuronal processes

Artificial Neural Net

x x x w w w Sum Threshold +

Perceptrons

• Single neuron-like element

– Binary inputs – Binary outputs

• Weighted sum of inputs > threshold

Perceptron Structure

x0=1 x1 x3 x2 xn w1 w0 . . . w2 w3 wn

y

     > =

∑

=

• therwise

if 1

i n i ix

w y

x0 w0 compensates for threshold

Perceptron Example

• Logical-OR: Linearly separable

– 00: 0; 01: 1; 10: 1; 11: 1

x2 x1

+ + +

• r

x2 x1

+ + +

• r

Perceptron Convergence Procedure

• Straight-forward training procedure

– Learns linearly separable functions

• Until perceptron yields correct output for

all

– If the perceptron is correct, do nothing – If the percepton is wrong,

• If it incorrectly says “yes”,

– Subtract input vector from weight vector

• Otherwise, add input vector to weight vector

Perceptron Convergence Example

• LOGICAL-OR:
• Sample

x0 x1 x2 Desired Output

• 1 1 0 0 0
• 2 1 0 1 1
• 3 1 1 0 1
• 4 1 1 1 1
• Initial: w=(000);After S2, w=w+s2=(101)
• Pass2: S1:w=w-s1=(001);S3:w=w+s3=(111)
• Pass3: S1:w=w-s1=(011)

Perceptron Convergence Theorem

• If there exists a vector W s.t.
• Perceptron training will find it
• Assume

for all +ive examples x

• ||w||^2 increases by at most ||x||^2, in

each iteration

• ||w+x||^2 <= ||w||^2+||x||^2 <=k ||x||^2
• v.w/||w|| > <= 1

Converges in k <= O steps

δ k w v x x x w

k

> ⋅ + + + = r r r r r r , ...

2 1

     > =

∑

=

• therwise

if 1

i n i ix

w y

δ > ⋅ x v r r

k x k / δ

( )

2

/ 1 δ

Perceptron Learning

• Perceptrons learn linear decision

boundaries

• E.g.

+ + + + + +

x1 x2 But not x2 x1

+ + xor

X1 X2

• 1 -1 w1x1 + w2x2 < 0

1 -1 w1x1 + w2x2 > 0 => implies w1 > 0 1 1 w1x1 + w2x2 >0 => but should be false

• 1 1 w1x1 + w2x2 > 0 => implies w2 > 0

Perceptron Example

• Digit recognition

– Assume display= 8 lightable bars – Inputs – on/off + threshold – 65 steps to recognize “8”

Perceptron Summary

• Motivated by neuron activation
• Simple training procedure
• Guaranteed to converge

– IF linearly separable

Neural Nets

• Multi-layer perceptrons

– Inputs: real-valued – Intermediate “hidden” nodes – Output(s): one (or more) discrete-valued

X1 X2 X3 X4 Inputs Hidden Hidden Outputs Y1 Y2

Neural Nets

• Pro: More general than perceptrons

– Not restricted to linear discriminants – Multiple outputs: one classification each

• Con: No simple, guaranteed training

procedure

– Use greedy, hill-climbing procedure to train – “Gradient descent”, “Backpropagation”

Solving the XOR Problem

x1 w13 w11 w21

• 2
• 1

w12 y w03 w22

• 1

x2 w23 w02

• 1

w01

• 1

Network Topology: 2 hidden nodes 1 output Desired behavior: x1 x2 o1 o2 y 0 0 0 0 0 1 0 0 1 1 0 1 0 1 1 1 1 1 1 0 Weights: w11= w12=1 w21=w22 = 1 w01=3/2; w02=1/2; w03=1/2 w13=-1; w23=1

Neural Net Applications

• Speech recognition
• Handwriting recognition
• NETtalk: Letter-to-sound rules
• ALVINN: Autonomous driving

ALVINN

• Driving as a neural network
• Inputs:

– Image pixel intensities

• I.e. lane lines
• 5 Hidden nodes
• Outputs:

– Steering actions

• E.g. turn left/right; how far
• Training:

– Observe human behavior: sample images, steering

Backpropagation

• Greedy, Hill-climbing procedure

– Weights are parameters to change – Original hill-climb changes one parameter/step

• Slow

– If smooth function, change all parameters/step

• Gradient descent

– Backpropagation: Computes current output, works backward to correct error

Producing a Smooth Function

• Key problem:

– Pure step threshold is discontinuous

• Not differentiable
• Solution:

– Sigmoid (squashed ‘s’ function): Logistic fn

∑

−

+ = =

n i z i i

e z s x w z 1 1 ) (

Neural Net Training

• Goal:

– Determine how to change weights to get correct output

• Large change in weight to produce large reduction

in error

• Approach:
• Compute actual output: o
• Compare to desired output: d
• Determine effect of each weight w on error = d-o
• Adjust weights

Neural Net Example

y3 w03 w23 z3 z2 w02 w22 w21 w12 w1

1

w01 z1

• 1
• 1
• 1

x1 x2 w13 y1 y2

∑

− =

i i i

w x F y E

2 *

)) , ( ( 2 1 v v

xi : ith sample input vector w : weight vector yi*: desired output for ith sample Sum of squares error over training samples ) ) ( ) ( ( ) , (

03 02 2 22 1 12 23 01 2 21 1 11 13 3

w w x w x w s w w x w x w s w s w x F y − − + + − + = = v v

z3 z1 z2

Full expression of output in terms of input and weights

• From 6.034 notes lozano-perez

Gradient Descent

• Error: Sum of squares error of inputs with

current weights

• Compute rate of change of error wrt each

weight

– Which weights have greatest effect on error? – Effectively, partial derivatives of error wrt weights

• In turn, depend on other weights => chain rule

Gradient Descent

• E = G(w)

– Error as function of weights

• Find rate of change of

error

– Follow steepest rate of change – Change weights s.t. error is minimized E w G(w) dG dw Local minima w0w1

MIT AI lecture notes, Lozano- Perez 2000

Gradient of Error

) ) ( ) ( ( ) , (

03 02 2 22 1 12 23 01 2 21 1 11 13 3

w w x w x w s w w x w x w s w s w x F y − − + + − + = = v v

z3 z1 z2

j i j

w y y y w E ∂ ∂ − − = ∂ ∂

3 3 *

) (

1 3 3 1 3 3 13 3 3 3 13 3

) ( ) ( ) ( ) ( y z z s z s z z s w z z z s w y ∂ ∂ = ∂ ∂ = ∂ ∂ ∂ ∂ = ∂ ∂

1 1 1 13 3 3 11 1 1 1 13 3 3 11 3 3 3 11 3

) ( ) ( ) ( ) ( ) ( x z z s w z z s w z z z s w z z s w z z z s w y ∂ ∂ ∂ ∂ = ∂ ∂ ∂ ∂ ∂ ∂ = ∂ ∂ ∂ ∂ = ∂ ∂

∑

− =

i i i

w x F y E

2 *

)) , ( ( 2 1 v v

y3 w03 w23 z3 z2 w02 w22 w21 w12 w1

1

w01 z1

• 1
• 1
• 1

x1 x2 w13 y1 y2

Note: Derivative of sigmoid: ds(z1) = s(z1)(1-s(z1)) dz1

• From 6.034 notes lozano-perez

From Effect to Update

• Gradient computation:

– How each weight contributes to performance

• To train:

– Need to determine how to CHANGE weight based on contribution to performance – Need to determine how MUCH change to make per iteration

• Rate parameter ‘r’

– Large enough to learn quickly – Small enough reach but not overshoot target values

Backpropagation Procedure

• Pick rate parameter ‘r’
• Until performance is good enough,

– Do forward computation to calculate output – Compute Beta in output node with – Compute Beta in all other nodes with – Compute change for all weights with

z z z

• d −

= β

∑

− =

→ k k k k k j j

• w

β β ) 1 (

j j j i j i

• ro

w β ) 1 ( − = ∆

→

i j k

j i

w →

k j

w →

i

• j
• )

1 (

j j

• −

) 1 (

k k

• −

Backprop Example

y3 w03 w23 z3 z2 w02 w22 w21 w12 w11 w01 z1

• 1
• 1
• 1

x1 x2 w13 y1 y2

) (

3 * 3 3

y y − = β

23 3 3 3 2

) 1 ( w y y β β − =

13 3 3 3 1

) 1 ( w y y β β − =

Forward prop: Compute zi and yi given xk, wl

) 1 ( ) 1 (

3 3 3 03 03

− − + = β y ry w w ) 1 ( ) 1 (

2 2 2 02 02

− − + = β y ry w w ) 1 ( ) 1 (

1 1 1 01 01

− − + = β y ry w w

3 3 3 1 13 13

) 1 ( β y y ry w w − + =

2 2 2 1 12 12

) 1 ( β y y rx w w − + =

1 1 1 1 11 11

) 1 ( β y y rx w w − + =

3 3 3 2 23 23

) 1 ( β y y ry w w − + =

2 2 2 2 22 22

) 1 ( β y y rx w w − + =

1 1 1 2 21 21

) 1 ( β y y rx w w − + =

Backpropagation Observations

• Procedure is (relatively) efficient

– All computations are local

• Use inputs and outputs of current node
• What is “good enough”?

– Rarely reach target (0 or 1) outputs

• Typically, train until within 0.1 of target

Neural Net Summary

• Training:

– Backpropagation procedure

• Gradient descent strategy (usual problems)
• Prediction:

– Compute outputs based on input vector & weights

• Pros: Very general, Fast prediction
• Cons: Training can be VERY slow (1000’s
• f epochs), Overfitting

Training Strategies

• Online training:

– Update weights after each sample

• Offline (batch training):

– Compute error over all samples

• Then update weights
• Online training “noisy”

– Sensitive to individual instances – However, may escape local minima

Training Strategy

• To avoid overfitting:

– Split data into: training, validation, & test

• Also, avoid excess weights (less than # samples)
• Initialize with small random weights

– Small changes have noticeable effect

• Use offline training

– Until validation set minimum

• Evaluate on test set

– No more weight changes

Classification

• Neural networks best for classification

task

– Single output -> Binary classifier – Multiple outputs -> Multiway classification

• Applied successfully to learning pronunciation

– Sigmoid pushes to binary classification

• Not good for regression

Neural Net Example

• NETtalk: Letter-to-sound by net
• Inputs:

– Need context to pronounce

• 7-letter window: predict sound of middle letter
• 29 possible characters – alphabet+space+,+.

– 7*29=203 inputs

• 80 Hidden nodes
• Output: Generate 60 phones

– Nodes map to 26 units: 21 articulatory, 5 stress/sil

• Vector quantization of acoustic space

Neural Net Example: NETtalk

• Learning to talk:

– 5 iterations/1024 training words: bound/stress – 10 iterations: intelligible – 400 new test words: 80% correct

• Not as good as DecTalk, but automatic

Neural Net Conclusions

• Simulation based on neurons in brain
• Perceptrons (single neuron)

– Guaranteed to find linear discriminant

• IF one exists -> problem XOR
• Neural nets (Multi-layer perceptrons)

– Very general – Backpropagation training procedure

• Gradient descent - local min, overfitting issues
