Laser-Plasma Acceleration: Status from Italy

Danilo Giulietti Physics Department of the University and INFN, Pisa, Italy PLASMONX National Representative

The beginning of the Italian activity in LPA

In the 2000 the Pisa group performed the first experiments in LPA at LOA. After that INFN manifested interest in our activity and Sergio Bertolucci, at that time Director of the LNF invited me for a seminar. The LNF colleagues were very shocked when I was speaking of acceleration gradients of several 100GV/m !

The birth of PLASMONX

Later on NTA Commission (whose chairman was Sergio Bertolucci), after considering a CDR of a project devoted to the development NTA based

• n LPA and innovative X-gamma sources based
• n TS, launched in the 2005 the Strategic Project
• PLASMONX. The project takes advantages from

the complementary expertises of INFN and CNR in the fields of HEP and LASER-PLASMA Interactions respectively.

QuickTime™ and a decompressor are needed to see this picture.

The birth of….

Conceptual Design Report PLASMA ACCELERA TION AND MONOCH ROMATIC X-RAY PRODUCTION Acronym: PLASMONX

• D. G

iulietti Unive rsit฀ di Pisa e INFN-Pisa

• A. Barbini, W. Baldeschi, M. Galimberti, A. Gamucci, A. Giulietti, L.A. Gizzi,
• P. Koester, L.

Labate, A. Rossi, P. Tomassini ILIL Tea m @ CNR/I PCF - Pisa

• D. Alesini, S. Bertolucci, M.E. Biagini, C. Biscari, R. Boni, M. Boscolo, M. Castellano, A.

Clozza, G. Di Pirro, A. Drago, A. Esposito, M. Ferrario, V. Fusco, A. Gallo, A. Ghigo, S. Guiducci, M. Incurvati, C. Ligi, F. Marce llini, M. Migliorati, C. Milardi, A. Mostacci, L. Palumbo, L. Pellegrino, M. Prege r, P. Raimondi, R. Ricci, C. Sanelli, M. Serio,

• F. Sgamma, B.Spataro, A. Stecchi, A. Stella, F. Tazzioli, C. Vaccarezza,
• M. Vescovi,
• C. V

icario, M. Zobov SPARC- Project Tea m @ INFN-LNF

• F. Alessandria, A. Bacc

i, I. Boscolo, F. Broggi, S.Cialdi, C. DeMar tinis, D. Giove,

• C. Mar
• li, V. Pe

trillo, M. Rom¸, L. Serafini SPARC Project Tea m @ INFN-Milan

• e Università

di Milano

• R. B
• nifacio, N. Piovella, R. Pozzoli

Unive rsit฀ di Milano e INFN-Milano

The proposal was discussed and prepared by the Pisa, Milan and LNF groups …….soon joined by the Bologna, Naples and LNS groups PLASMONX: The Conceptual Design Report

PLASMONX UNITS

Milano Bologna Pisa Roma, LNF Napoli LNS

The site for the new INFN facility was chosen in LNF….

@ LNF-INFN

The 300TW LASER laboratory The 300TW LASER laboratory

…. the new lab replaced a small hill

The final amplifier of the PLASMONX 300TW LASER

Pulse duration 20 fs Pulse energy 6J

• Rep. Rate 10Hz

Peak power up to 300 TW ASE contrast ≈10 Pre Pulse duration 20 fs Pulse energy 6J

• Rep. Rate 10Hz

Peak power up to 300 TW ASE contrast ≈10-10 Pre-pulse contrast < 10-8

and a very powerful LASER was assembled …..

LPA Target Area LPA Target Area

Compressor vacuum chamber Interaction vacuum chamber Main beam (>250 TW) Vacuum transport line Beam transport to sparc bunker Radiation protection walls

……with an underground LPA target area

LPA Target Area LPA Target Area

Compressor vacuum chamber Interaction vacuum chamber Main beam (>250 TW) Vacuum transport line Beam transport to SPARC bunker Radiation protection walls

completely shielded and connected to the bunker of a 200MeV LINAC

• VERT. AND HORIZ. SHIELDING
• VERT. AND HORIZ. SHIELDING

LINAC UNDULATOR synchronisation laser pulse vacuum compressor acceleration chamber detectors area control & data

SPARC: the 200MeV LINAC and the UNDULATORS

Self-injection

Wed 4/5 11:15, SITE by L.Gizzi

The first experiments of SI-LPA offer also the possibility to test the LASER main parameters

LASER PLASMA ACCELERATION

QuickTime™ and a YUV420 codec decompressor are needed to see this picture.

PIC simulation for the first SI-LPA experiments @ LNF

Ne=1019cm-3 L=1mm T=20fs W=9µm I=1.5 1020W/cm2 Uel≈400MeV

LPA LPA-Self Injection:first results Self Injection:first results

20 mrad

First results focusing less than 1/10 of the maximum LASER power in a supersonic gas-jet at about 10Atm of N2

External injection

Wed 4/5 11:00, LPA/EI by L.Serafini We intend also to inject monochromatic e-bunches into LPW excited by the powerful LASER to reduce the energy spread of the accelerated electrons. The experiment is challenging due to the required synchronization between LASER and LINAC (10fs) and the shortness of the e-bunches (few µm) with respect to the plasma wavelength.

COherent Multi e-Bunches for electron acceleration in plasmas

QuickTime™ and a decompressor are needed to see this picture.

Wed 4/5 11:30, COMB by M. Ferrario

Due to the high control on the LINAC photo- injector we intend to accelerate electrons in a plasma wave resonantly excited by a train of e-bunches

Table-top source of femtosecond X-rays

X-rays e- beam He jet Gas-jet system 2J pulse

In the Project X-gamma ray sources will be developed based on the TS; using only the LASER …….

Tuneable X-ray radiation source based on Thomson Scattering

from the LINAC

BEATS-experiment

……and LASER and LINAC

LPA of ions

LILIA-experiment

The LASER parameters are suitable also for ion LPA

• nce the LASER is focused on solid thin targets

Spectral distributions

E2 = 11.8 MeV n°prot.MeV-1 sr-1 2.2x1011 E1 = 10.3 MeV E3 = 13.2 MeV E4 = 14.7 MeV E5 = 17.3 MeV E6 = 19.5 MeV E7 = 21.1 MeV E8 = 23 MeV

Angular divergence decreases as proton energy increases. Typical anular structures

Human Resources and expertises

*Complementary expertises from HEP and LASER-Plasma community *Major Italian Universities involved *International collaborations

Goals and planned activity

• Control of LPA mechanism
• Development of new targets
• Multi stages
• External Injection
• Coherent multi e-bunches
• X-gamma secondary sources
• LPA of ions

ELI would be the first infrastructure dedicated to the fundamental study of laser-matter interaction in a new and unsurpassed regime

• f laser intensity: the ultra-relativistic regime (IL>1023 W/cm2).

The infrastructure would serve to investigate a new generation of compact accelerators delivering energetic particle and radiation beams

• f femtosecond (10-15s) to attosecond (10-18s) duration.

ELI would afford wide benefits to society ranging from improvement

• f oncology treatment, medical imaging, fast electronics and our

understanding of aging nuclear reactor materials to development of new methods of nuclear waste processing.

FROM TO

The PLASMONX activity naturally fits the

• ne of the European Project ELI

Project manager

J.P. Chambaret + System Engineer

Laser system

• P. Georges
• S. Karsch

Attosecond Science

• G. Tsakiris, D Charalambidis
• P. Audebert

Laser plasma accelerator

• D. Giulietti
• V. Malka

Ultrafast X-ray radiation beams

• A. Rousse
• B. Rus

High field Science

• D. Habs
• D. Bernard

Steering committee Project leader

• G. Mourou

OPCPA TiSa:ampli Diode pumping Coherent beam combining Adaptative optic Attosecond to zeptosecond Physics Ultra relativisitc optics Beam lines Coherent (X,)-rays (FEL, HHG & plasma) Incoherent (X,)-ray beams (synchrotron- like, atomic) Beam lines NLQED Fundamendal physics Exotic physics Nuclear Physics Proposed Applications Probe ultrafast dynamics (atom, molecule and plasma) Ultra Non Linear X-UV phenomena Electron dynamics Gamma imaging Radiotherapy Test and Calibration Probing plasmas Polarised beam High energy physics … Probe ultrafast dynamics, high resolution image & create new states of matter

BUILDING SAFETY

Safety Manager Ultra relativistic plasma Electron beam Proton beam Ions beam Muons beam Beam lines Transmutation induced by laser

CONCLUSIONS

• @ LNF will offer unique opportunities for:
• New Acceleration Techniques
• High brightness sources of electrons, protons, ions,

positrons, neutrons, X & -rays, …

• Applications in HEP, medicine, material science,

astrophysics, ultrafast science, …
