Labeling particles with heavy atom clusters Brian Gibbons Kornberg Lab Stanford Localization / identification Tissue / cells Tomograms Cryo-EM Negative stain Alignment - HEAVEM Proposal Proc. Natl. Acad. Sci. USA Vol. 95,

slide-1
SLIDE 1

Labeling particles with heavy atom clusters

Brian Gibbons Kornberg Lab Stanford

slide-2
SLIDE 2

Localization / identification

 Tissue / cells  Tomograms  Cryo-EM  Negative stain

slide-3
SLIDE 3
  • Proc. Natl. Acad. Sci. USA Vol. 95, pp. 9262–9267, August

1998 Biophysics

Single-particle selection and alignment with heavy atom cluster-antibody conjugates

GRANT J. JENSEN AND ROGER D. KORNBERG*

Alignment - HEAVEM Proposal

slide-4
SLIDE 4

 (i) Synthesis of appropriate organothiolate

monolayer-protected gold clusters (MPCs)

 (ii) selection, generation and labeling of adaptor

molecules

 linkers between MPCs and targeted particles  (iii) labeling of particles, removal of excess label  (iv) data collection and processing.

slide-5
SLIDE 5

Monolayer Protected Cluster (MPC) synthesis

Parameters: Ligand type Ligand to gold ratio Amount of BH4

  • Au(III) + 3RSH (-Au(I)/SR-)n + RS-SR

(-Au(I)/SR-)n + BH4

  • Aux(SR)y

Au SR SR SR RS

Maia Azubel

slide-6
SLIDE 6

Organothiolate monolayer-protected gold culsters (MPCs)

  • Stable
  • Water soluble
  • Reactive (on - off)

3MBA/Au 3

Maia Azubel

slide-7
SLIDE 7

Uniformity of MPCs as synthesized

Chris Ackerson

slide-8
SLIDE 8

Au102(p-MBA)44 at 1.1 Å

P .D. Jadzinski, G. Calero, C.J. Ackerson, D.A. Bushnell and R.D. Kornberg, Science 318, 430 (2007).

slide-9
SLIDE 9

Adaptor molecule

scFv

Cys

Cys

Au SR SR SR

Cys

Au SR SR SR RS

+

SR’

1) Labeling 2) Passivation Cys

Au SR’ SR’ SR’

Fv Fab Fc Antigen-binding site Antigen-binding site

Murray place exchange

slide-10
SLIDE 10

Adaptor molecule

Maia Azubel

slide-11
SLIDE 11

Complex formation and purification

Pol II Cys

Au SR’ SR’ SR’

Cys

Au SR’ SR’ SR’

Cys

Au SR’ SR’ SR’

Gel filtration

Pol II Cys

Au SR’ SR’ SR’

Cys

Au SR’ SR’ SR’

Maia Azubel

slide-12
SLIDE 12

Cryo EM

Pol II + Au_dsDNA Pol II +Au_scFv aRpb3 & aRpb4

Maia Azubel

slide-13
SLIDE 13

Fv Fab Fc Antigen-binding site Antigen-binding site

slide-14
SLIDE 14

Fc

trypsin

slide-15
SLIDE 15

Fc

TCEP

HS-

slide-16
SLIDE 16

Fc

Fc-Au

Au SR SR SR RS

slide-17
SLIDE 17

CBP affinity purification

Prot

  • tein

n A Prot

  • tein

n A

CBP y.f. Protein calmodulin + Calcium sepharose

slide-18
SLIDE 18

CBP affinity purification

Prot

  • tein

n A Prot

  • tein

n A

CBP y.f. Protein + EDTA

slide-19
SLIDE 19

TAP AP t tag - Fc in c interact ctio ion

Prot

  • tein

n A Prot

  • tein

n A Fc Fc

Au SR SR SR RS Au SR SR SR RS

CBP y.f. Protein

slide-20
SLIDE 20

Cryo-EM of TAP- RNA polymerase II - Fc - gold

Chris Ackerson

slide-21
SLIDE 21

Prot

  • tein

n A Prot

  • tein

n A

CBP y.f. Protein

TEV EV

sepharose IgG IgG IgG IgG IgG IgG IgG IgG

IgG affinity purification

slide-22
SLIDE 22

CBP

y.f. Protein

calmodulin

Au SR SR SR RS

calmodulin

Au SR SR SR RS

calmodulin

Au SR SR SR RS

calmodulin

Au SR SR SR RS

calmodulin

Au SR SR SR RS

Label with calmodulin-Au

slide-23
SLIDE 23

CBP

y.f. Protein

calmodulin

Au SR SR SR RS

SEC or density gradient

slide-24
SLIDE 24

TFIIH is essential for transcription and DNA repair

slide-25
SLIDE 25

RNA Polymerase II pre-initiation complexes

Bushnell et al. 2004

slide-26
SLIDE 26

TFIIH holoenzyme – 10 subunits

slide-27
SLIDE 27

core core + Ssl2 holo TFIIH

slide-28
SLIDE 28

Localization of Tfb3 with calm-Au

  • C-CBP

Tfb3

calmodulin

Au SR SR SR RS

slide-29
SLIDE 29

Acknowledgments

Roger Kornberg Maia Azubel Phil Robinson Kenji Murakami Xin Liu Dave Bushnell Barbara Davis Ralph Davis Craig Kaplan Yael Kalisman Francisco Asturias Ed Brignole Neil Voss John McCaferty Consuelo Garcia Grant Jensen Chris Ackerson Pablo Jadzinski

slide-30
SLIDE 30

Chris Ackerson

slide-31
SLIDE 31

Adaptor molecule

scFv

Cys

Cys

Au SR SR SR

Cys

Au SR SR SR RS

+

SR’

1) Labeling 2) Passivation Cys

Au SR’ SR’ SR’

Fv Fab Fc Antigen-binding site Antigen-binding site

Murray place exchange

Maia Azubel

slide-32
SLIDE 32
slide-33
SLIDE 33

HEAVEM Proposal

slide-34
SLIDE 34

 Relies on derivatization of biological

sample with heavy atom clusters

scatter electron strongly

 Requires discrete particles

specific attachment rigid attachment

slide-35
SLIDE 35
  • Imaging under conditions required for high resolution
  • low dose
  • close to focus
  • Overcome technical limitations
  • detection of drift, astigmatism & magnification

variation (microscope aberrations)

  • CTF determination
  • Resolve particle heterogeneity
  • Allows faster & automated data collection and particle

picking

slide-36
SLIDE 36
slide-37
SLIDE 37

scFv-gold for heavy atom electron microscopy

slide-38
SLIDE 38

3-D crystals of 2 nm 4-mercaptobenzoic acid MPCs

slide-39
SLIDE 39

Sample preparation

H.R. Saibil 2000

slide-40
SLIDE 40

Cryo-EM of neuraminadase-scFv-gold

slide-41
SLIDE 41

Cryo-EM of neuraminadase-scFv-gold

slide-42
SLIDE 42

Summary

 Synthesis of defined Gold MPC  Selection and generation of adaptor molecule-

cojugates that provide Specificity & Rigidity

 Feasibility, Stability and visualization of

complexes

Stage is set for empirical test of the HEAVEM Proposal.

slide-43
SLIDE 43

Acknowledgments

Roger Kornberg Kornberg Lab Phil Robinson Xin Liu Barbara Davis Ralph Davis Andy Erhensberger Craig Kaplan John McCaferty Consuelo Garcia Grant Jensen Chris Ackerson Pablo Jadzinski
