Knowledge Representation Part VII Protégé / RDFS / OWL / ++

Jan Pettersen Nytun, UiA Much of the content of this presentation has been copied from: A Practical Guide To Building OWL Ontologies Using Protégé 4 and CO-ODE Tools Edition 1.3, Matthew Horridge

slide-2
SLIDE 2

S O

P

Outline

  • Property Characteristics
  • OWL Restrictions

Jan Pettersen Nytun, UiA, Ontologies, page 2

slide-3
SLIDE 3

S O

P

OWL Property types

  • There are two main

types of properties:

– Object properties. – Datatype properties.

  • Additionally:

Annotation properties can be used to add metadata (data about data).

Knowledge Representation Part II, JPN, UiA

3

slide-4
SLIDE 4

S O

P

Property Characteristics

OWL allows the meaning of properties to be enriched through the use of property characteristics.

Knowledge Representation Part III, JPN, UiA

4

slide-5
SLIDE 5

S O

P

Inverse Property

  • If some property links individual A to individual

B then its inverse property will link individual B

to individual A.

  • If Matthew hasParent Jean, then because of the

inverse property we can infer that Jean hasChild Matthew.

Knowledge Representation Part III, JPN, UiA

5

slide-6
SLIDE 6

S O

P

Functional Properties

  • A functional property connects only one object or

literal to a subject.

Knowledge Representation Part III, JPN, UiA

6

E.g., it is only possible to have one birth mother

slide-7
SLIDE 7

S O

P

Functional Properties Continues …

Mapping functional property to UML: It is possible to define an association as functional by specifying the upper multiplicity of the navigable end as being 0..1

Knowledge Representation Part III, JPN, UiA

7

Person Female

hasBirthMother isBirthMotherTo 0..1 *

slide-8
SLIDE 8

S O

P

Inverse Functional Properties

  • If a property is inverse functional then it means

that the inverse property is functional.

Knowledge Representation Part III, JPN, UiA

8

slide-9
SLIDE 9

S O

P

Functional / Inverse Functional Properties

JPN, UiA

9

Person Female

hasBirthMother isBirthMotherTo 0..1 *

Inverse Functional Property Functional Property

Inverse functional properties are similar, but in the reverse direction.

slide-10
SLIDE 10

S O

P

Functional / Inverse Functional Properties continues …

  • Both object properties and datatype properties can be

declared as "functional“ but only object properties

can be decleared to be “functional inverse”.

  • RDF does not allow literal values as the subjects of triples.

10

slide-11
SLIDE 11

S O

P

More Property Characteristics

If a property is transitive, and the property relates individual a to individual b, and also individual b to individual c, then we can infer that individual a is related to individual c via property P. E.g., subRegionOf

JPN, UiA

11

slide-12
SLIDE 12

S O

P

More Property Characteristics

If a property P is symmetric, and the property relates individual a to individual b then individual b is also related to individual a via property P. E.g., hasSibling

JPN, UiA

12

slide-13
SLIDE 13

S O

P

More Property Characteristics

If a property P is asymmetric, and the property relates individual a to individual b then individual b cannot be related to individual a via property P. E.g., isMotherTo

JPN, UiA

13

slide-14
SLIDE 14

S O

P

More Property Characteristics

A property P is said to be reflexive when the property must relate individual to itself. E.g., hasRelative (everybody has himself as a relative).

This does not necessarily mean that every two individuals which are related by a reflexive property are identical.

JPN, UiA

14

slide-15
SLIDE 15

S O

P

More Property Characteristics

Irreflexive, meaning that no individual can be related to itself by such a role. E.g., hasParent

Knowledge Representation Part III, JPN, UiA

15

parentOf

slide-16
SLIDE 16

S O

P

Outline

  • Property Characteristics
  • OWL Restrictions

Jan Pettersen Nytun, UiA, Ontologies, page 16

slide-17
SLIDE 17

S O

P

[4]: In OWL classes are built up of descriptions that specify the conditions that must be satisfied by an individual for it to be a member of the class.

Jan Pettersen Nytun, UiA, page 17

slide-18
SLIDE 18

S O

P

OWL Restrictions

  • Three main categories:

– Quantifier Restrictions

  • existential restrictions
  • universal restrictions

– Cardinality Restrictions – hasValue Restrictions

Jan Pettersen Nytun, UiA, Ontologies, page 18

slide-19
SLIDE 19

S O

P

  • A restriction describes a class of individuals

based on the relationships that members of the class participate in.

  • A restriction describes an anonymous class.

Jan Pettersen Nytun, UiA, Ontologies, page 19

slide-20
SLIDE 20

S O

P

Quantifier Restrictions

– Existential restrictions – some Describe classes of individuals that participate in at least one relationship along a specified property to individuals that are members of a specified class. – Universal restrictions – only Describe classes of individuals that for a given property only have relationships along this property to individuals that are members of a specified class.

Jan Pettersen Nytun, UiA, Ontologies, page 20

slide-21
SLIDE 21

S O

P

New version of Protégé calls it “Subclass of”

slide-22
SLIDE 22

S O

P

Existential Restrictions

Jan Pettersen Nytun, UiA, Ontologies, page 22

A restriction containing an

  • wl:someValuesFrom constraint

describes a class of all individuals for which at least one value of the property concerned is an instance of the class description or a data value in the data range.

slide-23
SLIDE 23

S O

P

Jan Pettersen Nytun, UiA, Ontologies, page 23

Cardinality in dialog window should be ignored (it is 1..*)

slide-24
SLIDE 24

S O

P

In Turtle Representation

pizza:Pizza rdf:type owl:Class ; rdfs:label "Pizza"@en ; rdfs:subClassOf [ rdf:type owl:Restriction ;

  • wl:onProperty pizza:hasBase ;
  • wl:someValuesFrom pizza:PizzaBase

] ; …

Jan Pettersen Nytun, UiA, page 24

At least one pizza base!

slide-25
SLIDE 25

S O

P

Jan Pettersen Nytun, UiA, Ontologies, page 25

slide-26
SLIDE 26

S O

Ppizza:Margherita rdf:type owl:Class ;

rdfs:label "Margherita"@pt ; rdfs:subClassOf pizza:NamedPizza , [ rdf:type owl:Restriction ;

  • wl:onProperty pizza:hasTopping ;
  • wl:allValuesFrom [ rdf:type owl:Class ;
  • wl:unionOf ( pizza:MozzarellaTopping

pizza:TomatoTopping ) ] ] , … Only = owl:allValuesFrom

slide-27
SLIDE 27

S O

P

Jan Pettersen Nytun, UiA, Ontologies, page 27

slide-28
SLIDE 28

S O

P

Jan Pettersen Nytun, UiA, Ontologies, page 28

There is no “+” for adding; conditions comes from superclass!

slide-29
SLIDE 29

S O

P

Multiple Inheritance from Anonymous Classes

Jan Pettersen Nytun, UiA, Ontologies, page 29

:Pizza rdf:type owl:Class ; rdfs:subClassOf [ rdf:type owl:Restriction ;

  • wl:onProperty :hasTopping ;
  • wl:someValuesFrom :PizzaTopping

] , [ rdf:type owl:Restriction ;

  • wl:onProperty :hasBase ;
  • wl:someValuesFrom :PizzaBase

] .

slide-30
SLIDE 30

S O

P

References

Jan Pettersen Nytun, UiA, Propositional Calculus, page 30

[1] Book: David Poole and Alan Mackworth, Artificial Intelligence: Foundations of Computational Agents, Cambridge University Press, 2010, http://artint.info/ [2] http://www.w3.org/TR/swbp-n-aryRelations/ [3] RDF 1.1 Primer, W3C Working Group Note, 24 June 2014 [4] A Practical Guide To Building OWL Ontologies Using Protégé 4 and CO-ODE Tools Edition 1.3, Matthew Horridge [5] http://www.w3.org/TR/2009/REC-owl2-syntax-20091027/
