KNEST MANUFACTURERS LLP PUNE, MAHARASHTRA - 411018 ALUMINIUM FORMWORK This system is a set of formwork panels precisely manufactured from aluminium alloy and connected together to form a mold into which concrete is poured. Panels are

slide-1
SLIDE 1

KNEST MANUFACTURERS LLP

PUNE, MAHARASHTRA - 411018

slide-2
SLIDE 2

ALUMINIUM FORMWORK

  • This system is a set of formwork panel’s precisely

manufactured from aluminium alloy and connected together to form a mold into which concrete is poured.

  • Panels are light weight avg 25kgs/sqm but very strong

to withstand pressure up to 80 kN/m2.

slide-3
SLIDE 3

When it is Suitable ..?

  • Mass Housing
  • No. of Repetitions Are More
  • Typical Floors
  • Fast Construction Required
  • High Quality
  • Column Less Structure
  • Highly Suitable To Load Bearing Structure (Shear wall)
slide-4
SLIDE 4

Formwork assembly

On leaving the factory all panels are clearly labeled to ensure that they are easily identifiable on site and can be smoothly fitted together using the formwork modulation drawings. All formwork begins at a corner and proceeds as per following sequence – 1. Wall panel erection 2. Wall top/beam panel erection 3. Soffit length panels 4. Deck panels 5. Kicker panels

slide-5
SLIDE 5

Formwork assembly

  • SIMPLICITY – PIN AND WEDGE SYSTEM

The panels are held in position by a simple pin and wedge system that passes through holes in the outside rib of each panel. The panels fit precisely, simply and securely and require no bracing.

  • Pin
  • Stub
slide-6
SLIDE 6

Components of Aluminium Formwork

slide-7
SLIDE 7

Beam components

Prop Head Beam Side Panel Beam Soffit Panel Beam Soffit Bulkhead

slide-8
SLIDE 8

Deck components

Deck Panel Deck Prop Deck Mid –Beam Soffit Length Deck End –Beam

slide-9
SLIDE 9

Other components

Internal Soffit Corner External Soffit Corner External Corner Internal Corner

slide-10
SLIDE 10

Wall components

Wall Panel Rocker Kicker

slide-11
SLIDE 11

Work cycle of aluminum formwork

slide-12
SLIDE 12

Day 1 – Reinforcement fixing

  • f one side
slide-13
SLIDE 13

Day 2 - Formwork Fixing of first side & reinforcement Fixing of second side

slide-14
SLIDE 14

Day 3 - Deck formwork of first side & vertical formwork of second side

slide-15
SLIDE 15

Day 4- Slab reinforcement of Part 1, Deck formwork of part 2

slide-16
SLIDE 16

Day 5 – Concrete of Part 1 , slab reinforcement part 2

slide-17
SLIDE 17

Day 6 concrete of part 2

slide-18
SLIDE 18

Comparison between aluminum formwork & Conventional formwork system

slide-19
SLIDE 19

Sr No Characteristic Aluminium formwork system Conventional Formwork system 1 Speed of construction 6 days cycle per floor 10-15 days cycle per floor 2 Quality of surface finish Excellent - plastering is not required Bad 3 Pre-planning of form work system Required Not Required 4 Type of construction Cast in situ cellular construction Simple RCC framed construction 5 Wastage of form work material Very less In great amount 6 Accuracy in construction Accurate construction Less than Aluform 7 Coordination between different agencies Essential Not necessrily required 8 Resistance to earthquake Good resistance Less than Aluform 9 Reusage value 250-300 15-20

slide-20
SLIDE 20

Advantages of Aluminium Formwork

Aluminium formwork is specifically designed to allow rapid construction of all types of architectural layouts. 1) Total system forms the complete concrete structure. 2) Custom designed to suit project requirements. 3) Unsurpassed construction speed. 4) High quality finish. 5) Cost effective. 6) Panels can be reused up to 250 times. 7) Erected using unskilled labor.

slide-21
SLIDE 21

Advantages of Aluminium Formwork

▪ Easy to handle. ▪ Aluminum does not rust like steel; therefore, the Aluminium formwork can

be reused hundreds of times.

▪ Formwork is made with an aluminium alloy, which has high tensile strength

and is also very hard.

▪ Saving on overhead expenses due to speedy construction. ▪ Doesn’t require timber or plywood for construction activities so, it saves the

environment.

▪ Casting of walls and slabs possible simultaneously. ▪ Doesn’t require skilled labour. ▪ Less debris generation. ▪ Higher scrap value. ▪ Carpet area will increase. ▪ Collect the best premium from the customer, because of 100% RCC

buildings.

slide-22
SLIDE 22

Why Knest Aluform?

slide-23
SLIDE 23

Knest Advantage

  • At KnestAluminium Formwork we use state of the art modern design & manufacturing technology.
  • Our panels are designed to bear up to 80kN/m2 load which is highest amongst industry.
  • We use state of the art automated robotic welding – so our panels can last for very long time achieving

very high repetitions.

  • W

e use state of art plasma cutting technology allowing us to maintain very tight tolerances resulting in exact dimensions of concrete structures.

  • We use special imported tooling for punching holes in panels – resulting in absolutely no gap in our

formwork panels – giving superior finish.

  • Our specialized 3D design software allows us to guide you from the very beginning and help in better

formwork planning to save costs.

  • Our 3D execution drawings are very easy to understand for unskilled labors – resulting in faster cycle

times.

  • We use state of the art tracking system to track every single part and child part in our factory resulting in

faster production time and very high quality control.

  • Our manufacturing facility is amongst the largest in country, spread on 3 acres in industrially developed

city of Pune.

slide-24
SLIDE 24

Knest Advantage

Process flow

4.

  • Modulation drawings are prepare

by Knest 5.

  • Manufacturing is started

6.

  • Mock-up is done at factory

1.

  • Receipt of structural & architectural

drawings from client 2.

  • Shell plan is prepared by Knest

3.

  • Shell plan is approved by client
slide-25
SLIDE 25

Knest Advantage

  • Alloy Grade – aluminum 6061 T6
  • Load bearing capacity–

– 80kN/m2

  • Unit wt. of formwork – 25 kg/sq.m
  • Welding – Automated - robotic
  • Repetition- more than 250 times
  • Side Rail – 65mm
  • Supporting System-- Adjustable propping MS
  • Panel Inter connection- Pin &Wedge
  • Slab cycle time – 6-7 days
  • Standard Panels – 600W 2250, 450W 2250, 600 D 1200, 450 D 1200
  • Striking Time – Vertical shutter 16 hrs , slab and soffit 72 hrs
  • Lifting of formwork- Manual lifting, Crane or other mechanical equipment not

required

slide-26
SLIDE 26

Knest Advantage

Load bearing :- Our panels are designed to bear loads upto 80 kN/m2 which is amongst highest in industry – allows for very little deflection & much higher repetitions

slide-27
SLIDE 27

Knest Advantage

Factory setup :- Automated robotic welding for consistent high quality welding – which leads to increased life cycle of

  • ur panels – achieving very high repetitions.
slide-28
SLIDE 28

Knest Advantage

Factory setup :- High quality plasma cutting allows us to achieve very tight tolerances – which leads to perfect dimensions of concrete structures.

slide-29
SLIDE 29

Knest Advantage

Factory setup :- Special imported dies for punching – allows us to obtain accurate holing on panels – ensure zero gap between panels

slide-30
SLIDE 30

Knest Advantage

Factory setup :- State of the art tracking system to track every main part & child part – allowing us to maintain strict quality control.

slide-31
SLIDE 31

Knest Advantage

Factory setup :- We always do mock-up of material at our factory and take approval from client before dispatch of material

slide-32
SLIDE 32

Knest Advantage

Factory setup :- Our plant spread across 3 acres in one of the largest in India – allowing us to deliver material quickly.

slide-33
SLIDE 33

Knest Advantage

Raw material:- We use only 6061 –T6 grade aluminium

  • alloy. All our raw material is sourced from top suppliers

across the world & checked for strength & composition

slide-34
SLIDE 34

Knest Advantage

Factory pictures – Special palletized packaging to ensure no transport damage to panels.

slide-35
SLIDE 35

Knest Advantage

3D design - Our specialized 3D design software allows us to guide you from the very beginning and help in better formwork planning to save costs.

slide-36
SLIDE 36

Knest Advantage

3D design – Our 3d drawings allows us to visualize & present any particular problems beforehand – avoiding possibility of project delays later on.

slide-37
SLIDE 37

Knest Advantage

3D design – Our 3d drawings allows us to visualize & design critical regions like staircase easily – avoiding delays later on.

slide-38
SLIDE 38

Knest Advantage

3D design – Our 3d drawings are very easy even for unskilled labor – leading to faster cycle times.

slide-39
SLIDE 39

Knest Advantage

Our projects

slide-40
SLIDE 40

Knest Advantage

Tata Centre Gurgaon - Mutliplex

slide-41
SLIDE 41

Knest Advantage

Tinsel Town Hinjewadi

slide-42
SLIDE 42

Knest Advantage

Prudentia Towers Wakad

slide-43
SLIDE 43

Knest Advantage

List of clients

  • 1. Brookfield – Tata projects.
  • 2. Kohinoor Group.
  • 3. Vilas Javdekar
  • 4. Shapoorji Paloonji
  • 5. Rama group – Momoi contructions
slide-44
SLIDE 44

Knest Advantage

Site pictures

slide-45
SLIDE 45

Knest Advantage

Site pictures

slide-46
SLIDE 46

Knest Advantage

Site pictures

slide-47
SLIDE 47

Knest Advantage

Site pictures

slide-48
SLIDE 48

Knest Advantage

Site pictures

slide-49
SLIDE 49

Knest Advantage

Site pictures

slide-50
SLIDE 50

Knest Advantage

Site pictures

slide-51
SLIDE 51

Knest Advantage

Site pictures

slide-52
SLIDE 52

ALUMINIUM FORMWORK – INDUSTRY TRIGGERS

Key triggers for aluminum formwork industry in India – expected to lead to dramatic increase in usage - 1. Low cost mass housing scheme – Pradhan mantri Awas Yojna.

  • 2. Implementation of RERA.
  • 3. Bigger

builders already shifting to aluminium formwork to ensure quality Aluminium formwork sales was estimated at 8 lakh sq.m for AY-2015-16

slide-53
SLIDE 53

LOW COST HOUSING

  • Under the Pradhan Mantri Awas Yojna- Govt of India

has set a target of building 2 crore houses in low cost/mass housing segment by 2022.

  • These projects

are usually consisting

  • f several

buildings of simple design & high no. of repetitions – creating need for durable formwork.

  • The deadline for these projects is very strict - making

cycle time very important – and hence use of monolithic formwork is necessary.

  • Aluminum formwork fulfills all the needs of these

projects.

slide-54
SLIDE 54

LOW COST HOUSING

slide-55
SLIDE 55

LOW COST HOUSING

slide-56
SLIDE 56

LOW COST HOUSING

slide-57
SLIDE 57

LOW COST HOUSING

slide-58
SLIDE 58

LOW COST HOUSING

slide-59
SLIDE 59

LOW COST HOUSING

slide-60
SLIDE 60

RERA Act

Salient points of RERA act implement on 1st May 2017

  • 1. Possession date will be sacrosanct – Builder will face

strict action for missing deadline – monolithic formwork will get preference to complete projects on time.

  • 2. Developers will be liable for repairing any defects for

5 years – this clause will lead to greater emphasis on factory made quality formwork rather than depend

  • n labor skill.
  • 3. Real estate developer will not be able to make

changes in project after start – will lead to pre- planning – suiting factory made formwork.

slide-61
SLIDE 61

Bigger builders are shifting to aluform for better quality & speed

slide-62
SLIDE 62

Bigger builders are shifting to aluform for better quality & speed

slide-63
SLIDE 63

Bigger builders are shifting to aluform for better quality & speed

slide-64
SLIDE 64

Thank You
