Jiangsu Yoke Technology PhireGuard ELF-800 / 808 Marketing Presentation 30 December 2016 1 PhireGuard ELF-800 Characterictics Oligomeric Chlorinated Diphosphate Esters low Fogging and VOCs Compatible with Polyether and

SLIDE 1

Jiangsu Yoke Technology

PhireGuard ELF-800 / 808

Marketing Presentation

1 30 December 2016

SLIDE 2

PhireGuard ELF-800 Characterictics

 Oligomeric Chlorinated Diphosphate Esters  low Fogging and VOC’s  Compatible with Polyether and Polyester-based

Urethane technologies

 Miscible in polyol blends  Enhanced fire properties over wide range of

foam density

 Offer durable Fire Protection (no Migration)

2 30 December 2016

SLIDE 3

PhireGuard ELF-800 Key Properties

 Appearance: Clear Liquid  Viscosity: # 4000 mPa.s  Phosphorus Content = 9.7 wt%  Chlorine Content > 33.3 wt%  Acidity: < 0.1 mgKOH/g  Water Content: < 0.1 wt%  Colour APHA: < 400  OH value (Water and Acid excluded): 0 mgKOH/g  Non Reactive

3 30 December 2016

SLIDE 4

PhireGuard ELF-808 Key Properties

 Appearance: Clear Liquid  Viscosity: # 2000 mPa.s  Phosphorus Content = 9.5 wt%  Chlorine Content = 31 wt%  Acidity: < 0.1 mgKOH/g  Water Content: < 0.1 wt%  Colour APHA: < 400  OH value (Water and Acid excluded): 0 mgKOH/g  Non Reactive

4 30 December 2016

Low Viscosity version of ELF-800

SLIDE 5

PhireGuard ELF-800 Value Proposition

5 30 December 2016

 New FR Technology  By Product TCPP, i.e. < 1%  Enhanced Emission (VOC’s, Fogging) performance  Compatible with most Fire Safety Standards:  BS 5852 Crib 5  Cal TB 117  UL-94  FMVSS  High molecular weight, non “fugitive” FR, meaning that ELF-

800 provide the flexible PU foam with durable fire protection

SLIDE 6

Typical formulations based on PhireGuard ELF-808

6 30 December 2016

Foam density

25 kg/m3 30 kg/m3 35 kg/m3 FMVSS 302, SE rating 8-9 php 5-6 php 4-5 php Cal TB 117 A 14 php 10-11 php 8-9 php BS 5852 Crib 5 15 php + 30 php Mel 12 php + 24 php Mel 9 php + 18 php Mel

SLIDE 7

PhireGuard ELF’s are non fugitive

7 30 December 2016

20 40 60 80 100 120 Unaged 2 Weeks 2 Months 6 Months TCPP TDCP ELF-800 % Phosphorous retention at 70 deg C, measured by P -NMR.

SLIDE 8

PhireGuard ELF-800 Fogging Performance

8 30 December 2016

10 20 30 40 50 60 70 80 90 100 TCPP Standard TDCP EL-22 / NC- 28 ELF-601 ELF-800 mg / 10 g

DIN B-75201, 120 deg C, 24 hours

SLIDE 9

PhireGuard ELF-800 vs Ageing

9 30 December 2016

 35 kg/m3: Polyether foam, 4 php  Comparison with competitive Hal-free  FMVSS 302: SE  Heat ageing: ELF-800 > Comp FR  Humid Aging: ELF-800 > Comp FR  35 kg/m3: Polyester foam, 5 php  Comparison with competitive Hal-free (different from

above)

 FMVSS 302: SE  Heat ageing: ELF-800 > Comp FR  VW Humid Aging : ELF-800 > Comp FR

SLIDE 10

PhireGuard 800 Summary

10 30 December 2016

Chlorinated DiPhosphate Ester Processability, for both Polyether and Polyester foams Superior FR Performance Best Emission (VOC’s, Fogging Performance). The “TDCP”Replacement?

SLIDE 11

One more thing…

11 30 December 2016

 PhireGuard ELF-800 belongs to the new class of Flame

Retardants that the Jiangsu Yoke Technology Corporation is launching on the market.

 Reach-Registered The PhireGuard tradename is associated with Innovation,
