Understanding Dyadic Human Spoken Interactions Using Speech Processing Techniques:

Case studies in Autism Spectrum Disorder (ASD) and behavioral Couple Therapy

Jeremy 李祈均

*Materials in this presentation partially comes from Daniel Bone, Dr. Matt Black, Prof. Panos Georgiou, Prof. Shri Narayanan

2

Picture credit to the USC SAIL lab: http://sail.usc.edu

3

Employ and advance signal processing and machine learning to sense human behaviors

• Aid in, and transform the traditional observational methods
• Focus on mental health research and practice

Many benefits: speedup, parallel observation capabilities, large scale trends etc.

• Significance: USA--‐10mil people receive psychotherapy every year, increasing!
• State of the art hasn’t changed for decades

What is BSP?

4

Mental health: traditional observational study

*Picture credit to

• S. Narayanan and P. G. Georgiou, "Behavioral Signal Processing: Deriving Human Behavioral Informatics From Speech and

Language: Computational techniques are presented to analyze and model expressed and perceived human behavior-variedly characterized as typical, atypical, distressed, and disordered-from speech and language cues and their applications in health, commerce, education, and beyond," Proc IEEE Inst Electr Electron Eng, vol. 101, pp. 1203-1233, Feb 7 2013.

5

Mental health: putting BSP in the loop

*Picture credit to

• S. Narayanan and P. G. Georgiou, "Behavioral Signal Processing: Deriving Human Behavioral Informatics From Speech and

Language: Computational techniques are presented to analyze and model expressed and perceived human behavior-variedly characterized as typical, atypical, distressed, and disordered-from speech and language cues and their applications in health, commerce, education, and beyond," Proc IEEE Inst Electr Electron Eng, vol. 101, pp. 1203-1233, Feb 7 2013.

6

7

Case Study I

Domain: behavioral couple therapy Specifics: problem solving interactions as part of IBCT Engineering Task: interaction modeling (vocal synchrony quantification)

Chi-Chun Lee, Athanasios Katsamanis, Matthew Black, Brian Baucom, Andrew Christensen, Panayiotis G. Georgiou, and Shrikanth S. Narayanan, "Compute Vocal Entrainment: A Signal-Derived PCA-based quantification Scheme with Application for Affect Analysis in Married Couple Interactions ", in: Journal of Computer Speech and Language, 28(2): 518-539 doi:10.1016/j.csl.2012.06.006

8

Couple therapy: Integrated Behavior Couple Therapy

9

• Collaborative work between UCLA and UW
• 134 seriously and chronically distressed REAL couples
• 10 minutes long problem-solving spoken interactions
• Audio-video recording (far-field microphone, varying noise conditions)
• 33 global ratings of behavioral codes for each spouse (SSIRS, CIRS)
• 372 Sessions  90 hours of data
• Manual transcripts available

Couple therapy database

Studying this large amount of data in a spontaneous fashion

Application Domain 2: Couples Therapy Research 10 / 55

Automatic pre-processing: automatic speaker segmentation

• Segment the sessions into meaningful regions

– Recursive automatic speech-text alignment technique [Moreno 1998] – Session split into regions: wife/husband/unknown – Segmented >60% of sessions’ words into wife/husband regions for 293/574 sessions

“… that she’s known for five months and didn’t tell me …” Example: Aligned Text

AM = Acoustic Model LM = Language Model Dict = Dictionary MFCC = Mel-Frequency Cepstral Coefficients ASR = Automatic Speech Recognition HYP = ASR Hypothesized Transcript *slide content credit to Dr. Matthew P. Black

Application Domain 2: Couples Therapy Research 11 / 55

Automatic acoustic feature extraction: LLDs computation

• Acoustic features shown to be relevant (e.g., [Gottman 1977, Yildirim et al. 2010])
• 11 low-level descriptors (LLDs) extracted every 10ms with 25ms window

– Voice Activity Detector (VAD), speaking rate, pitch, energy, harmonics-to-noise ratio, voice quality, 13 MFCCs, 26 MFBs, magnitude of spectral centroid, spectral flux

• Each session split into 3 “domains”: wife, husband, speaker-independent
• 13 statistics (mean, std. dev. …) across each domain for each LLD

– 2000 features capture the global acoustic properties for each spouse

*slide content credit to Dr. Matthew P. Black

12

• Definition:
• Naturally-spontaneous behavioral matching between dyadic social

interactions

• Purpose in human interactions
• Achieving communication efficiency* – unintentional effort
• Communicating interest and engagement* – conscious effort
• Psychological significance in theory and practice
• Learning and memory in child-parent interactions
• Regulating emotion processes*
• Precursor to empathy
• Mirroring neurons

What is vocal synchrony?

No quantification method is present! Can we do it even when it’s not possible for human perception – no ground truth

13

Unsupervised signal-derived method

14

Verification

15

Study of behavioral codes and vocal synchrony

16

Utilization as features for affect recognition application

04/11/2013 17

Utilization as quantitative metrics for clinical analysis via MLM Analysis

husband-to-wife entrainment wife demander/husband withdrawer polarization p<0.001, within-partner p<0.001 between-partner not significant p<0.01 between-partner

Wife-demander/Husband-withdrawer

wife-to-husband entrainment wife demander/husband withdrawer polarization husband-to-wife entrainment wife demander/husband withdrawer polarization wife-to-husband entrainment wife demander/husband withdrawer polarization

Clinical Implications Behavioral Informatics

18

Case Study II

Domain: Autism spectrum disorder Specifics: ADOS III Interview session Engineering Task: interaction modeling (atypical prosody quantification)

*slide content credit to Daniel Bone

Daniel Bone, Chi-Chun Lee, Matthew Black, Marian Williams, Sungbok Lee, Pat Levitt, and Shrikanth S. Narayanan, “The Psychologist as an Interlocutor in ASD Assessment: Insights from a Study of Spontaneous Prosody”, in: Journal of Speech, Language, and Hearing Research 2014 Feb 11. doi: 10.1044/2014_JSLHR-S-13-0062

19

Autism Spectrum Disorder: ADOS session

20

ADOS – Module 3: behavioral codes

21

• ADOS semi-structured assessment framework
• Used to help psychologists diagnose autism (one popular tool)
• Subject interacts with a psychologist for ~30-45 minutes
• Constrained developmentally-appropriate tasks
• 4 modules, depending on expressive language level and age
• Module 1 (less than phrase speech): Free play, response to joint attention
• Module 2 (some phrase speech): Joint interactive play, bubble play
• Module 3 (verbally fluent): Make-believe play, telling a story from a book
• Module 4 (verbally fluent adolescents/adults): More interview style
• Psychologist rate the child’s socio-communicative skills
• e.g., speech abnormalities (intonation/volume/rhythm/rate)
• e.g., reciprocal social interaction (unusual eye contact)
• Scores on sub-assessments added, and total score is used to diagnose ASD
• Psychologists trained to administer ADOS using stringent training protocol

22

Atypical Prosody

• Prosody refers to the way in which something is said (rhythm)
• Intonation, Volume, Rate, and Voice Quality
• Critical role in expressivity and social-affective reciprocity
• Variety of abnormalities
• Monotonous
• Atypical lexical stress and pragmatic prosody
• Speaking Rate
• “Bizarre” quality to speech
• Qualitative descriptions are general and contrasting, “bizarre”

"slow, rapid, jerky and irregular in rhythm, odd intonation or inappropriate pitch and stress, markedly flat and toneless, or consistently abnormal volume” -[Lord et al. 2003]

23

USC CARE Corpus

• Child-psychologist ADOS interactions
• ADOS- Autism Diagnostic Observation Schedule. [Lord et al., 2000]
• Multimodal: 2 HD video and 2 far-field microphones (ecological validity)

Experimental Setup: Subject Sample

24

• Analysis focused on subjects administered the ADOS Module 3
• Verbally fluent children and young adults
• 30 sessions total, 28 appropriate for analysis
• Manual transcription and segmentation
• Transcription: spoken words, non-verbal communication, and

vocalizations

• Segmentation: single speaker utterances, temporal markings
• Psychologists
• Three trained clinical psychologists conducted the ADOS sessions
• Each psychologist administered ~9 sessions

25

• Coding
• 60 minute session/14 subtasks
• 28 codes scored by psychologist that is interacting with child
• Not all codes used
• Code of Interest–Speech Abnormalities Associated with Autism
• Scored on an integer scale from ‘0’ (appropriate) to ‘2’ (clearly abnormal)
• Code of Interest-ADOS Totals
• ADOS totals relate to ‘Severity’ of autism spectrum disorder
• Three total codes: Communication, Social Interaction, and C.+S.I.
• Higher resolution, (min. 0, max. 8-22)
• Spearman’s ρ=0.74 (p<10e-6) for Speech Abnormality and C.+S.I. Total

Experimental Setup: Labels

26

• ASD literature: intonation, volume, rate, and voice quality
• 25 acoustic-prosodic features per speaker
• Intonation and volume (12 functionals)
• Mean (μ) and Stdv (σ) of 2nd-order coefficients
• Speaking rate and rhythm (9 functionals)
• Mean (μ) and 90% quantile (q90) of both turn-end and non-turn-end

syllabic-speaking rate

• Mean (μ) and Stdv (σ) of vowel and consonant durations
• Proportion of vowel speech to total speech
• Voice quality (4 functionals)
• Median and inter-quartile ratio (IQR) of jitter and shimmer
• Jitter and shimmer are extracted on extended vowels (at

least 3T0)

Experimental Setup: Acoustic features

27

• Word-level features:
• Phrase boundary prosody is most perceptually salient, so we extract

word-level features on turn-end words.

• We utilize lexical transcriptions and turn-level alignments.
• HTK alignment, Colorado Corpus children’s models, WSJ adult models

(also used for phonetic features)

• Intonation (pitch) and volume (intensity) contours:
• Extracted using Praat. Both in log-domain.
• Normalized per speaker by subtracting mean.
• Contour are bounded in range [-1,1], then fit by a 2nd-order polynomial

Experimental Setup: Acoustic features

28

29

Speech processing technology in behavioral science

Engineering pros:

Large scale, consistency, parallel observation (third-party) – interaction modeling

Scientific pros:

Quantitative insights, data-driven discovery, objective method

Challenges:

Large amount heterogeneity in behavioral production, perception, and effects coupling during interaction (while interaction is essential!)

Human-centered Behavioral Signal Processing

Behavioral Interface

Behavioral Informatics

Behavioral Signal Processing

Psychiatry Psychology Behavioral Couple therapy

• Automating manual observational coding

Autism Spectrum Disorder (ASD)

• ADOS diagnosis: Prosody modeling
• RapidABC: speech engagement modeling
• Virtual game: Physiology signal processing

Rapid Automatized Naming

• Quantification of eye-voice coordination

Affective Computing

• Multimodal emotion recognition
• Multimedia theater acting analysis
• Cross-corpora recognition

Interaction Synchrony

• Quantification of vocal behavior

synchronization

Automatic performance scoring

• Impromptu speech scoring

Human-Machine Interface Education

31

Thank You
