Jefferson County Vision Zero Safety Bowl Mike Vaughn Kentuckys 2019 Safety Bowl National Champion Mini Safety Bowl How Many Highway Fatalities did KY Experience in 2018? A. 724 B. 782 C. 834 Mini Safety Bowl How Many

slide-1
SLIDE 1

Jefferson County Vision Zero

slide-2
SLIDE 2

Safety Bowl

▰ Mike Vaughn ▰ Kentucky’s 2019 Safety Bowl National Champion

slide-3
SLIDE 3

Mini Safety Bowl

▰ How Many Highway Fatalities did KY Experience in 2018?

  • A. 724
  • B. 782
  • C. 834
slide-4
SLIDE 4

Mini Safety Bowl

▰ How Many Highway Fatalities did KY Experience in 2018?

  • A. 724
  • B. 782
  • C. 834
slide-5
SLIDE 5

Mini Safety Bowl

▰ How Many Highway Fatalities did Jefferson County Experience in 2018?

  • A. 63
  • B. 77
  • C. 94
slide-6
SLIDE 6

Mini Safety Bowl

▰ How Many Highway Fatalities did Jefferson County Experience in 2018?

  • A. 63
  • B. 77
  • C. 94
slide-7
SLIDE 7

Mini Safety Bowl

▰ How Many More Crashes Occur in Louisville in the PM Peak Than The AM Peak? ▰ 57% ▰ 144% ▰ 261%

slide-8
SLIDE 8

Mini Safety Bowl

▰ How Many More Crashes Occur in Louisville in the PM Peak Than The AM Peak? ▰ 57% ▰ 144% ▰ 261%

slide-9
SLIDE 9

Fatality Trends

slide-10
SLIDE 10

Pedestrian Master Plan 2010

▰ Vision: For Louisville to become the safest and most

appealing community for pedestrians!

▰ Mission: Create a community wide culture that

supports pedestrians through physical improvements, policies and pedestrian programs by increasing the pedestrian system network while simultaneously reducing the rate of pedestrian crashes.

slide-11
SLIDE 11

Understanding Pedestrian Crashes

▰ 23% of fatalities occurring on Metro

roadways were pedestrian fatalities.

▰ Louisville conducted a 5-year pedestrian

crash analysis to identify:

▰ Trends ▰ High risk populations ▰ High crash locations

slide-12
SLIDE 12

Road to Zero 2017

▰ Interdisciplinary, Intradepartmental Team ▰ Advocates ▰ Educators ▰ Engineers ▰ Health ▰ Planners ▰ Transit

slide-13
SLIDE 13

Vision Zero

▰ aka: Safe Systems Approach ▰ Principles: ▰ People make mistakes ▰ Crashes are going to happen ▰ The human body can only tolerate a certain amount of crash force

slide-14
SLIDE 14

Vision Zero

▰ Why? ▰ Average Crash Costs in KY: ▰ Fatal Crash = $9,281,571 ▰ Serious Injury = $537,913 ▰ Societal Costs: ▰ US: $433.7 Billion (Source: National Safety Council) ▰ KY: $8.9 Billion

slide-15
SLIDE 15

Vision Zero

▰ Paradigm Shift: ▰ Let’s not focus on eliminating crashes ▰ Let’s focus on eliminating fatalities and serious injuries

slide-16
SLIDE 16

Vision Zero

▰ How? ▰ Other elements of the Safety Systems approach: ▰ We can’t continue to blame the driver ▰ Shared responsibility ▰ Proven solutions ▰ Proactive approach (treat the risk factors)

slide-17
SLIDE 17

Shared Responsibility?

▰ The Swiss Cheese Model: ▰Layered security measures are

represented as slices of swiss cheese with the holes being weaknesses in the parts of the system

▰A “failure” only results when a hole

in each slice momentarily aligns, permitting a hazard to pass through all of the slices

The Swiss Cheese Model was originally put forward by Dante Orlandella and James T. Reason of the University of Manchester

slide-18
SLIDE 18

Vision Zero

▰ “Safe Systems” Goal: ▰ ensure redundancy in the system so that

when a crash does happen, the crash forces released are within the boundaries of human tolerance and that no fatalities should occur and serious injuries are reduced

Source: Roads and Traffic Authority of New South Wales

slide-19
SLIDE 19

Vision Zero

▰ Treat the risk factors? ▰ Improve the roadway features with high

correlation to fatal & serious injury crashes

▰ How are risk factors determined? ▰ In-depth Safety Diagnosis

(aka Analysis of Crash & Roadway data)

▰ Engineering Judgement

slide-20
SLIDE 20

Vision Zero

▰ Kentucky Strategic Highway Safety Plan ▰ The Four E’s

Engineering Enforcement Education Emergency Services

20

slide-21
SLIDE 21

Vision Zero

▰ Kentucky Strategic Highway Safety Plan ▰ Emphasis Areas ▰ Roadway Departures ▰ Intersections ▰ Framework for HSIP Initiatives

21

slide-22
SLIDE 22

Jefferson County Vision Zero

▰ Why a Separate Louisville Safety Plan? ▰ Louisville is Different than Kentucky ▰ Crash Types ▰ More Peds and Bicycles ▰ More Intersections ▰ Less Roadway Departures

slide-23
SLIDE 23

Jefferson County Vision Zero

STUDY CRASH DATABASE

HIS Roadway Data KSP Crash Data HIS Traffic Data KTC GIS Intersection Data KIPDA GIS Data Metro/KIPDA Traffic Data Metro Bicycle Facilities Transit and School Facilities Metro Signalized Intersections Speed Data

slide-24
SLIDE 24

Jefferson County Vision Zero

▰ KABCP Definitions ▰ K = Fatal crash (Killed) ▰ A = Suspected Serious Injury crash (Ambulance) ▰ B = Suspected Minor Injury crash (Bruised/Bloody) ▰ C = Possible Injury (Complaining) ▰ P = Property Damage Only crash

slide-25
SLIDE 25

Jefferson County Vision Zero

▰ KY Comprehensive Crash Costs (2017) ▰ K = $9,281,571 ▰ A = $537,913 ▰ B = $162,885 ▰ C = $102,957 ▰ P = $9,689

slide-26
SLIDE 26

Jefferson County Vision Zero

▰ Crash Study Database ▰ Crash Period: 2013-2017 ▰ Jefferson County: 157,160 ▰ Crashes On Interstates: 26,475 ▰ Spatial Deficiency Crashes: 3,511 (2%) ▰ Study Crash Database:

127,174 Crashes

K 357 <1% A 2,144 2% B 7,741 6% C 11,696 9% P 105,236 83% Total Crashes - Severity 127,174

slide-27
SLIDE 27

Jefferson County Vision Zero

▰ Crash Study Database ▰ Crash Period: 2013-2017 ▰ Jefferson County: 157,160 ▰ Crashes On Interstates: 26,475 ▰ Spatial Deficiency Crashes: 3,511 (2%) ▰ Study Crash Database:

127,174 Crashes

K 357 <1% A 2,144 2% B 7,741 6% C 11,696 9% P 105,236 83% Total Crashes - Severity 127,174

$ 7.95 Billion

slide-28
SLIDE 28

Jefferson County Vision Zero

▰ Limitations of Available Data ▰ Spatial Deficiencies ▰ ADT/VMT (Local Streets) ▰ Number of Lanes (13% Unknown) ▰ Lane Widths ▰ Lighting Conditions ▰ Driver Detail

slide-29
SLIDE 29

Jefferson County Vision Zero

▰ K and A Crashes with No Roadway Data

slide-30
SLIDE 30

Jefferson County Vision Zero

▰ K and A Crashes

slide-31
SLIDE 31

Jefferson County Vision Zero

▰ All Crashes

slide-32
SLIDE 32

Jefferson County Vision Zero

▰ K and A Over Time

68 62 69 75 83 425 454 435 427 403

  • 50

100 150 200 250 300 350 400 450 500

2013 2014 2015 2016 2017

All Crashes – Fatal (K) & Serious Injury (A)

Fatal Crash (K) Serious Injury Crash (A)

slide-33
SLIDE 33

Jefferson County Vision Zero

▰ K and A Time of Day

36 45 33 29 41 44 66 63 115 139 173 251 396 465 343 262 50 100 150 200 250 300 350 400 450 500

Crashes Time of Day

Fatal Crashes (K) Serious Injury Crashes (A)

slide-34
SLIDE 34

Jefferson County Vision Zero

45% 76% 87% 90% 95% 94% 0% 10% 20% 30% 40% 50% 60% 70% 80% 90% 100%

Killed Incapacitating Injury Non-Incapacitating Injury Possible Injury Not Injury Unknown

Restraint Used in Crashes

% Restraint Used

slide-35
SLIDE 35

Jefferson County Vision Zero

▰ Impaired Crashes ▰ 19% of Fatals ▰ 46% of Impaired KA

Crashes between 10:00 PM and 5:00 AM

12 15 14 11 15 44 59 52 39 28 10 20 30 40 50 60 70 2013 2014 2015 2016 2017

Impaired Crashes

Fatal Crash (K) Serious Injury Crash (A)

slide-36
SLIDE 36

Jefferson County Vision Zero

▰ Intersections ▰ 5 or More KA

Crashes

slide-37
SLIDE 37

Jefferson County Vision Zero

▰ Motorcycles ▰ 65 Fatals ▰ 215 Serious Injuries

slide-38
SLIDE 38

Jefferson County Vision Zero

▰ Non-Motorized ▰ 102 Fatals ▰ 29% of Fatals ▰ 10% Statewide

slide-39
SLIDE 39

Jefferson County Vision Zero

12 17 17 22 25 38 52 53 58 59 365 375 372 394 371 50 100 150 200 250 300 350 400 450

2013 2014 2015 2016 2017

Pedestrian Crashes by Year

Fatal Crash (K) Serious Injury Crash (A) All Severity Crashes

slide-40
SLIDE 40

Jefferson County Vision Zero

1 1 2 2 3 16 17 11 8 12 190 179 133 124 134 20 40 60 80 100 120 140 160 180 200 2013 2014 2015 2016 2017

Bicycle Crashes by Year

Fatal Crash (K) Serious Injury Crash (A) All

slide-41
SLIDE 41

Jefferson County Vision Zero

▰ Crash Trees ▰ Help Identify Risk Factors

slide-42
SLIDE 42

Jefferson County Vision Zero

EJ

Crashes

Crash Rate per Population (x1000)

Non EJ

Crashes

Crash Rate per Population (x1000)

K

151 0.71 206 0.27

A

1,004 4.71 1,140 1.51

B

3,670 17.22 4,071 5.39

C

5,573 26.16 6,123 8.10

P

42,206 198.09 63,030 83.39

ALL

52,604 246.89 74,570 98.66

K & A Crash Rate per Person is 3x Higher

slide-43
SLIDE 43

Jefferson County Vision Zero

▰ 53% (1,320) of KA crashes

  • ccur on 16 routes

▰ US 31W - 229 (9%) KA ▰ US 31E - 117 (5%) KA ▰ KY 1934 - 107 (4%) KA

slide-44
SLIDE 44

Jefferson County Vision Zero

▰ Identifies Emphasis Areas

Number % of Total Number % of Serious Crashes Number % of Fatal Total Jefferson County Total 127,174 2,144 357 Aggressive Driving 35,208 28% 778 36% 103 29% 32% Distracted Driving 59,535 47% 700 33% 66 18% 25% Impaired Driving 4,092 3% 222 10% 67 19% 21% Intersections 80,157 63% 1,394 65% 195 55% 18% Roadway Departures 4,670 4% 168 8% 48 13% 67% System Management Commercial Motor Vehicle 2,989 2% 49 2% 26 7% 10% High-Risk Drivers 38,056 30% 595 28% 94 26% 33% Motorcycles 1,275 1% 215 10% 65 18% 12% Non-Motorized Users 2,633 2% 324 15% 102 29% 10% Environmental Justice Areas 52,604 41% 1,004 47% 151 42%

  • PM Peak Period

34,573 27% 465 22% 44 12%

  • Dark (No Lighting)

7,968 6% 225 10% 102 29%

  • Specific Corridors / Areas
  • Other

Potential Emphasis Areas Fatal KY SHSP (2014) % of Fatal Behavior Modifications Design and Operations Vulnerable Roadway Users Crashes Serious Injury (A)

slide-45
SLIDE 45

Potential Countermeasures

▰ Gateway Crosswalks

slide-46
SLIDE 46

Potential Countermeasures

▰ Mini- Roundabouts

slide-47
SLIDE 47

Potential Countermeasures

▰ R-Cut Intersections

slide-48
SLIDE 48

Systemic Approach to Safety

▰ Systemic Approach ▰ Focus on Risk Factors ▰ Predicts Likely Locations ▰ Effective for Vulnerable Users (Bicycles, Motorcycles, Pedestrians)

slide-49
SLIDE 49

Systemic Approach to Safety

▰ Element 1 – Select Locations

and Countermeasures

▰ Element 2 – Achieve Balance

between Traditional and Systemic Approaches

▰ Element 3 – Evaluate

Effectiveness of Systemic Approach

slide-50
SLIDE 50

Intersection Elements

▰ Traffic Control (signal, stop, none, etc.) ▰ Speed ▰ Divided ▰ Bus Stops ▰ Retail Area

slide-51
SLIDE 51

Intersection Elements

▰ Traffic Volume ▰ Skew ▰ Number of Lanes ▰ Lane Widths ▰ Turn Lanes

slide-52
SLIDE 52

Potential Countermeasures

▰ Systemic ▰ Retroreflective Backplates ▰ Lighting ▰ Signing ▰ Striping ▰ Signal Revisions

slide-53
SLIDE 53

Funding Initiatives

▰ Funding Area Goals ▰ Intersections ($18M) ▰ Non-Motorized ($6M) ▰ Roadway Departures ($4.5M) ▰ Other ($1.5M)

slide-54
SLIDE 54

Jefferson County Vision Zero

Number % of Total Number % of Serious Crashes Number % of Fatal Total Jefferson County Total 127,174 2,144 357 Aggressive Driving 35,208 28% 778 36% 103 29% 32% Distracted Driving 59,535 47% 700 33% 66 18% 25% Impaired Driving 4,092 3% 222 10% 67 19% 21% Intersections 80,157 63% 1,394 65% 195 55% 18% Roadway Departures 4,670 4% 168 8% 48 13% 67% System Management Commercial Motor Vehicle 2,989 2% 49 2% 26 7% 10% High-Risk Drivers 38,056 30% 595 28% 94 26% 33% Motorcycles 1,275 1% 215 10% 65 18% 12% Non-Motorized Users 2,633 2% 324 15% 102 29% 10% Environmental Justice Areas 52,604 41% 1,004 47% 151 42%

  • PM Peak Period

34,573 27% 465 22% 44 12%

  • Dark (No Lighting)

7,968 6% 225 10% 102 29%

  • Specific Corridors / Areas
  • Other

Potential Emphasis Areas Fatal KY SHSP (2014) % of Fatal Behavior Modifications Design and Operations Vulnerable Roadway Users Crashes Serious Injury (A)

slide-55
SLIDE 55

Funding Initiatives

▰ Funding Area Goals ▰ Intersections ($18M)

64% K+A 60% Funding

▰ Non-Motorized ($ 6M)

17% K+A 20% Funding

▰ Roadway Departures ($4.5M)

13% K+A 15% Funding

▰ Other ($1.5M)

6% K+A 5% Funding

slide-56
SLIDE 56

Funding Initiatives

▰ Intersections ▰ R-Cuts $2M ▰ Previously Unwarranted Signals

(ex. Mini-Roundabouts) $4M

▰ Offset or Add Turn Lanes $2M ▰ Systemic Corridors $6M ▰ Lighting $4M ▰ Reactive Corridors and

Locations $6M

slide-57
SLIDE 57

Funding Initiatives

▰ Non-Motorized ▰ Road Diets $1.5M ▰ Bike Lane Striping/Green

Conflict Points $0.5M

▰ Reactive Hot Spots $1M ▰ Curb Bulb-Outs $1.5M ▰ Sidewalks $1.5M ▰ Lighting ▰ Leading Pedestrian Indicators

slide-58
SLIDE 58

Funding Initiatives

▰ Roadway Departures ▰ Reactive Corridors $3.5M ▰ High Friction Surface $0.5M ▰ Other ▰ Converting One-Way to Two-

Way

▰ Installing Cameras for Red

Light Running Data Collection

▰ Lists of EJ Emphasis Areas

slide-59
SLIDE 59

Questions?
