ITS Georgia

Kyle Mote GDOT Office of Planning June 27, 2013

Agenda

• 2009 Managed Lane System Plan overview
• Current activities: Managed Lane Implementation

Plan

• Lessons learned and emerging findings
• Next steps

2009 Atlanta Regional Managed Lane System Plan (MLSP) - Overview

• First regional managed lanes

plan in the country

• In 2009, there were no Priced

Managed Lanes in the Atlanta region (only HOV lanes)

• Identified $16 Billion in MLs
• Assumed $9 Billion could be

delivered via PPP

• $5.9 Billion programmed in

current Atlanta MPO Plan

2009 Managed Lane System Plan Goals

• Protect mobility with all new capacity
• Maximize person/vehicle throughput
• Minimize environmental impacts
• Provide a financially feasible system
• Design and maintain a flexible infrastructure

network, for varying lane management

Managed Lane Corridors Currently in Operation or in Development (Priced & HOV)

• Open to traffic:

– I-85 North Express Lanes (16 miles)

• HOV2+ to HOT3+ conversion in 2011
• 250,000 transponders issued
• Under Development:

– Northwest Corridor (I-75/I-575 North) Express Lanes

• ROD issued May 2013

– I-75 South Express Lanes

• Expect FONSI, summer 2013

– I-85 North Extension

• Construction currently planned for FY 15
• In the Alternative Evaluation Process:

– I-285 Top End (revive285)

• EIS under development

– SR 400 North of I-285

• Feasibility study underway

Existing & Planned Priced Managed Lanes

• All limited access highway new capacity in Metro

Atlanta will likely be tolled

• Remove HOV2+ to HOT3+ conversions from MPO

TIP

• Eliminate assumptions of long-term concession

agreements

• Evaluate lower-cost managed lane treatments

New Planning Assumptions Moving Forward

Managed Lane Implementation Plan (MLIP) Overview

• Updating MLSP as part of Managed Lanes Implementation Plan

(MLIP) to:

– Build upon previous MLSP goals – Reflect current funding constraints – Identify feasible locations for managed lane projects – Redefine and reprioritize projects from the previous plan based on current and future needs – Prioritize list of managed lane projects and accompanying financing strategies (P3 and traditional funding sources)

• Incorporate recommendations into RTP and TIP update, as

appropriate during 2013-2014

Innovations and Emerging Findings-MLIP

• Considering non-traditional Managed Lane solutions

– Reversible lanes

• Moveable barrier (new option)
• Fixed barrier (existing option)

– Shoulder lanes

• Consider managing inside lane in peak periods and off-setting the

removed general purpose capacity with travel on shoulder

– Option: use reversible barrier and shoulder lanes in conjunction with each other

• Intent is to not “reduce” current travel options for

motorists

Shoulder Lanes

Shoulder Lanes – Typical Section BEFORE

Source: Atlanta Regional Managed Lanes Implementation Plan, GDOT.

Shoulder Lanes – Typical Section AFTER

Source: Atlanta Regional Managed Lanes Implementation Plan, GDOT.

Shoulder Lanes – Case Studies

• Washington State - US 2

– 1.5 miles during PM only

• Minneapolis

– 3.0 miles during AM & PM – Use left shoulder – Region wide bus shoulders

• UK M42 Highway

– 10 miles – Shoulders used in conjunction with variable speed limits

• Netherlands

– Use left and right shoulder

Shoulder Sign in Washington State

Shoulder Lanes – Considerations

• Shoulder pavement depth
• Shoulder width
• Bridge spans and pillar

locations

• Entrance/exit ramp

locations and volumes

• Additional signage
• Refuge sites (incidents and

emergency access)

• Segment length

SR 400 Shoulder Lane (Atlanta, GA)

Source: www.itsinternational.com

Shoulder Lanes-Lessons Learned

• Manage expectations, not all shoulders lend

themselves to travel

• Capital costs vary dramatically based on existing

infrastructure

• Develop active traffic management system concept

Shoulder Lanes-Lessons Learned

• Pre-determine enforcement roles/processes,

incident response, training, public outreach and education

• Strategic placement of video cameras to monitor

traffic

• Strategic placement of emergency refuge areas,

with proper signing

Moveable Barriers

Moveable Barriers – Typical Section BEFORE

Source: Atlanta Regional Managed Lanes Implementation Plan, GDOT.

Moveable Barriers – Typical Section AFTER

Source: Atlanta Regional Managed Lanes Implementation Plan, GDOT.

Moveable Barriers – Case Studies

• I-30/Thornton Freeway: Dallas, TX
• 5.2 mile managed lane during AM & PM
• Increased speeds from 22 to 41 mph
• 1,200 – 1,400 vehicles per hour (vph)
• I-93: Boston, MA
• 6.0 mile managed lane during AM & PM
• Flows at posted speed (55 mph)
• 1,500 - 1,800 vph
• No increase in accidents
• I-70: West of Denver, CO
• 13.5 mile EB Sundays
• Significant decrease in EB travel times (79 to 41

min.) and increase in WB travel times (34 to 69 min.)

• 2% annual increase in crashes (snow conditions)

Source: Barrier Systems, Inc.

I-93 Rever versib ible le Lanes es in Boston ton

Moveable Barriers – Considerations

• Directional split of traffic and number of lanes
• Estimated benefit (travel time savings)
• Capital and Operating & Maintenance costs
• Bridge spans and pillar locations
• Median and/or shoulder widths
• Borrow inside lane or shoulder for reverse direction and/or widen

to the median

• Logistics of rev. lanes
• Additional signage
• Segment length

Source: Barrier Systems, Inc.

Moveable Barriers-Lessons Learned

• Plan ahead (traffic impacts, physical limitations,

storage, etc)

• Develop standard operating procedures
• Enforcement (if operated as managed lane)
• Public education
• Dependable contractor (if operation is privatized)

Moveable Barriers-Lessons Learned

• Spare parts inventory
• Aggressive preventative maintenance
• Adequate staffing for enforcement, traffic incident

management and maintenance

• Consider multiple access points

Priced Managed Lanes

Georgia Priced Managed Lane Overview

• High Occupancy Toll (HOT)

– Mixture of occupancy and tolling components – 17 currently in operation across US, including 1 in Georgia (I-85 North) – Relatively easy to convert HOV lanes to HOT (need public support) – Requires additional enforcement/back office operations – Transit buses have free access

• Express Toll Lanes (ETL)

– All users pay (except transit buses) – 1 currently in operation in US (SR 91, CA), 2 planned in Georgia (I-75 South & I-75/I-575 North) – Easier to enforce/back office operations, when compared to HOT – Higher revenue than HOT

Priced Managed Lanes – Case Studies

• High Occupancy Toll (HOT) Lanes

– I-95: Miami, FL – SR 167: Seattle, WA – I-15: Salt Lake City, UT – I-394: Minneapolis, MN – I-10 Katy Freeway: Houston, TX

• Express Toll Lanes (ETL)

– SR 91: Orange County, CA

SR 91 Express ess Toll

• ll Lanes

es

Priced Managed Lanes

Priced Managed Lanes-Lessons Learned

• Tolling existing capacity (HOV and GP) can be

challenging

• Likely not self-supporting, requiring funding

source, particularly in early years for O&M

• Recognize ramp-up period for tolling, adjustment

time for motorists

• Interface between differing managed lane types

(HOV to HOT) has been less of an issue than anticipated in MLSP

Priced Managed Lanes-Lessons Learned

• Ideally provide users with travel time estimates

and speed limits in using dynamic signs

• Complete camera coverage aids in operations and

enforcement

• Occupancy detection, declaration and

enforcement impact revenues

Priced Managed Lanes-Lessons Learned

• Access points may need modification after open to

traffic

• Design and operation should be flexible enough to

accommodate fluctuating traffic patterns

• Adequate signage is necessary to identify access

points

• Evaluate potential funding resources early

Priced Managed Lanes-Lessons Learned

• Effective outreach is essential and must continue

throughout project planning, implementation, and

• peration:

– Reliable/faster trips – Transit access – Increased network capacity – Limited ability to build additional general purpose lane capacity – HOV can be an ineffective way to regulate demand

Priced Managed Lanes – Emerging Trends

• Multi-lane facilities
• Dual purpose investments (auto and transit)
• Regional network
• Develop performance measures (speeds,

throughput-both car and transit)

• Moving from HOT based facilities to ETL facilities,

with new construction

Managed Lane Implementation Plan Next Steps

Corridors Selected for Managed Lanes Evaluation

Corridors Selected for Moveable Barrier Evaluation

Directional Split Directional Split, MARTA Rail Grass Median Limited Shoulders Grass Median Arterial, Grass Median Limited Shoulders

Corridors Selected for Shoulder Lane Evaluation

Limited Shoulders Limited Shoulders Limited Shoulders Limited Shoulders

• Evaluate potential improvements in each corridor

– Planning level traffic and toll revenue analysis – Detailed traffic assessment

• Financial feasibility assessment

– Preliminary capital and O&M cost estimates – High level project financing plan

• Develop and apply project prioritization framework
• Final recommendations and documentation

Next Steps

www.dot.ga.gov\MLIP Kyle Mote GDOT Office of Planning

(404) 631-1811 kmote@dot.ga.gov
