Iron Overload and Iron Chelation: The Inside Story

Jerry L. Spivak, MD Professor of Medicine and Oncology Johns Hopkins University School of Medicine Baltimore, Maryland jlspivak@jhmi.edu

Iron as a Prosthetic Group

• Oxygen transport -

Hemoglobin, myoglobin

• Cell proliferation -

Ribonucleotide reductase

• Electron transport -

Flavoproteins

• Respiratory enzymes -

Cytochromes

• Oxidases -

Catalase

• Reductases -

Cytochromes

Body Iron Stores (♂)

Hemoglobin 2.5 gm Myoglobin/heme and nonheme 0.4 gm enzymes Ferritin/hemosiderin 1.0 gm(2/1ratio) Transferrin 0.005 gm

There is no normal mechanism for iron excretion above physiologic losses

“Tales From the Crypt” Iron Absorption and the Mucosal Iron Block

Duodenum

Sugars, amino acids and Vitamin C

Fe++ Plasma transferrin Enterocyte precursor (Macrophage) Noniron-loaded FPN Enterocyte precursor (Macrophage) Iron-loaded

Mature enterocyte

DMT1 Hephaestin FPN (Hepcidin)

Hepcidin Ferritin/Fe++

Ferritin Fe++ Fe+++

Heme-Fe

Dctyd (ferri-reductase)

Other cells

Stomach Fe +++

Heme-Fe

pH pH

HCP-1 Mitochondria Other processes (Ceruloplasmin)

Fe+++ Fe++

Iron Balance in Adults

Gastrointestinal Absorption 1-2 mg/day Physiologic daily iron loss 1-2 mg/day Plasma transferrin 4 mg Storage Iron

Liver cells and Macrophages

1000 mg Functional iron

Bone marrow Red cell hemoglobin Myoglobin Cytochromes 2500 mg 18 mg

Spinach ,whole grains such as buckwheat and amaranth, other vegetables such as chard and rhubarb, as well as beans and nuts, all contain significant levels of oxalic acid, which binds with iron, inhibiting its absorption. Soy beans contain phytic acid, which also bind iron. Tea and coffee contain tannins, which block iron absorption. Clay and heavy metals also inhibit iron absorption. Iron Absorption Enhancers

• Meat/fish/poultry
• Vitamin C-rich fruits: oranges, cantaloupe, strawberries,

grapefruit

• Vegetables: broccoli, brussel sprouts, tomato, tomato juice,

potato, green & red peppers

• White wine

Natural Modifiers of Iron Absorption

Iron Absorption Inhibitors

Iron Turnover in the Anemia of Chronic Disease

Gastrointestinal Absorption <1 mg/day Physiologic daily iron loss 1 mg/day Plasma transferrin 2 mg Storage Iron

Liver cells and RES

1500 mg Functional iron

Bone marrow Red cell hemoglobin Myoglobin Cytochromes 2000 mg Hepcidin Hepcidin

Semin Liver Dis 31:280, 2011

Hepcidin Regulation*

*IL-6 and LPS also activate hepcidin expression

Preservation of the MCHC at the Expense of the MCV

Blood 20: 173, 1962

Iron Regulatory Proteins

• HFE
• Tfr-2
• Hemojuvelin

(HJV)

• Hepcidin
• DMT1
• Ferroportin (FPN)
• Tfr-1
• Hephaestin and

ceruloplasmin

• Senses cellular iron uptake
• Senses cellular iron uptake
• Upregulates Hepcidin (with Tfr-2

and HFE)

• Downregulates Ferroportin
• Imports GI iron
• Exports intracellular iron to Tf
• Receptor for Tf-bound iron
• Iron oxidases (cellular and

circulating)

Iron overload No anemia Iron overload anemia

Essential Factors in Erythropoiesis and the Effect of Cancer, Inflammation or Infection

• Intensity of the stimulus
• Functional capacity of the

bone marrow

• Available nutrients
• Red cell survival
• Erythropoietin production is

suppressed by cytokines and iron overload

• Erythroid progenitor cell

proliferation is suppressed by cytokines and erythropoietin lack

• Iron is sequestered and its

absorption is inhibited by hepcidin

• Red cell survival is reduced

and blood loss is increased due to diagnostic testing

Role of Iron Sequestration in the Anemia of Chronic Disease

• There is no impairment of utilization of absorbed iron
• There is no impairment of plasma transferrin iron uptake by erythroid cells
• Reduced transferrin receptor expression and decreased iron utilization are

primarily consequences of EPO deficiency

• Iron therapy cannot correct the anemia of chronic disease in the absence
• f tissue iron deficiency
• Pharmacologic concentrations of EPO can correct the anemia of chronic

disease but not iron deficiency anemia

• Correction of the anemia of chronic disease with EPO can occur without a

change in the serum iron abnormalities

• Correction of the anemia of chronic disease with EPO is associated with

mobilization of iron stores and sometimes iron deficiency

Hypoxic Regulation of Erythropoietin Production

N Engl J Med 348:1282, 2003

Serum Epo (mU/ml) Time (days) –2 2 4 6 8 10 12 1600 1400 1200 800 600 400 200 1000 Hgb, g/dL 10 9 7 6 5 8 sEpo, mU/mL Hb, g/dL Blood 91:2139, 1998

Effect of Iron Administration on the Serum Erythropoietin Level

Fe Rx

Br J Haematol 94:288, 1996

J Clin Invest 110:1042, 2002

Hepcidin Expression is Subordinate to Tissue Hypoxia

Increased storage iron

Serum Immunoreactive Erythropoietin in Iron Deficiency Anemia

sEPO (mU/ml) Hgb (g/dL) 9.5–9.9 10.0–10.4 10.5–10.9 11.0–11.4 P <.005 100 80 60 40 20

Time (months) Hemoglobin gm %

B J Haematol 94:288, 1996

Transfusion According to the Hemoglobin Level in MDS

Blood Transfusion – Bypassing a Natural Barrier

Body Iron Homeostasis

• After intake, iron is normally sequestered in complexes:

– Serum transferrin

• Iron transport protein in blood/extracellular fluid
• Capacity can be exceeded resulting in Nontransferrin-Bound Iron

(NTBI) – NTBI is the most toxic form of iron – Ferritin

• Binds intracellular iron
• High levels in the serum reflect iron overload but can be affected by

NASH, inflammation (Still’s disease and cancer) infection (hematophagocytosis, hepatitis)

• A transferrin saturation < 45 % with a high serum ferritin (>400

ng/mL) is characteristic of inflammation or liver disease, not iron

• verload, where the transferrin saturation is always > 50 % and often

> 95 %

Iron excess as a Toxin

Increased transferrin saturation (>50 %) leads to deposition of iron in nonerythroid tissues such as the heart, liver and pancreas leading to: Congestive heart failure Hepatic fibrosis Diabetes mellitus and other endocrinopathies Increased susceptibility to infection Increased transferrin saturation leads to the accumulation of nontransferrin-bound iron (NBTI), labile or bound to other proteins, and free radical formation. The generation of free hydroxyl radicals causes tissue damage through oxidative reactions with proteins, lipids and nuclei acids.

(Fenton reaction)

Int J Hematol 76:219, 2002

Potential Mechanisms for Iron-induced Cellular Injury

Measures of Body Iron Content

• Serum iron
• Serum transferrin
• Serum ferritin
• Liver biopsy
• Liver iron by MRI
• Cardiac MRI (T2*)
• Bone marrow aspirate
• Diurnal variation, affected by diet

inflammation and infection

• Affected by nutrition, liver disease,

inflammation, infection and FPN and ceruloplasmin mutations

• An acute phase reactant, specific only

if low. Correlation with LIC = 0.63

• Defines iron storage site and liver
• histology. May not correlate with

cardiac iron burden

• May not correlate with cardiac iron

status

• Correlates with cardiac function
• Considered the “gold standard” but

is invasive and not always technically adequate

Serum Ferritin: Disadvantages

LIC Predicts Total Body Iron

Liver MRI Correlation With Biopsy

Correlation between Plasma Ferritin (Pl Fer) and Hepatic Iron Concentration

Am J Hematol 42:81, 1993

R = 0.63

Months of chelation therapy Pl Fer LIC

Brit J Haematol 89:880, 1995

World J Gastroenterol 12:5866, 2006

Causes of Extreme Hyperferritinemia (>1500 µg/L)

BBA 1763:700, 2006

Hereditary (HFE) Hemochromatosis

• An autosomal recessive disorder due to a C282Y mutation and rarely an H63D

mutation in Northern Europeans (0.3-1.2 % prevalence) with variable penetrance

• Serum ferritin is elevated in 84 % of men and 65 % of female C282Y homozygotes
• Serum ferritin is > 1000 µg in 37 % of men and 3% of female C282Y homozygotes
• If baseline ferritin is < 1000 µg , < 50 % of men and 20 % of females exceeded 1000

µg after 12 years

• If baseline ferritin is < 1000 µg at age 55, < 15 % progressed to > 1000 µg in 12

years

• Iron overload was present in 28 % of men and 1 % of women at age 65.
• Iron overload with C282Y/H63D is rare without other risk factors such as liver

disease

• C282Y homozygosity doubles the colon cancer risk in everyone and the breast

cancer risk in women’

• H63D homozygosity triples the hereditary nonpolyposis colon cancer risk
• Environmental cofactors are alcohol, hepatic steatosis and viral hepatitis
• Non-citrus fruits are protective
• An elevated transferrin saturation (> 45 %) is the earliest clue
• Phlebotomy should start if the ferritin is if there is evidence of iron overload to

achieve a ferritin of 50 µg

• Liver biopsy is indicated for a ferritin >1000 µg and abnormal liver function

Major Complications of Iron Overload

• Cirrhosis
• Hepatic fibrosis (reversible with phlebotomy)
• Hepatocellular cancer
• Diabetes mellitus
• Arthritis
• Cardiomyopathy
• Hypogonadism
• Hypothyroidism
• Pituitary-adrenal axis impairment
• Increased susceptibility to infection (MDS)
• Increased risk of leukemic transformation (MDS)
• Impaired survival post BMT

Circulation 30: 698,1964

Terminal Heart Failure due to Cardiac Iron Overload

Lancet 334:27, 1989 Cardiac Disease is the Major Cause of Death in β-Thalassemia

Am J Hematol 84:29, 2009

Correlation Between NTBI and Transferrin Saturation

Survival in MDS According to Diagnosis (WHO criteria)

J Clin Onc 23:7594, 2005

Overall survival (HR = 1.91; p < 0.001) Leukaemia-free survival (HR = 1.84; p = 0.001)

Survival of MDS patients by transfusion dependence (N = 467)

180 Cumulative proportion surviving

Transfusion independent Transfusion dependent

0.0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0 20 40 60 80 100 120 140 160 Cumulative proportion surviving 0.0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0 20 40 60 80 100 120 140 160 180 Survival time (months) Survival time (months)

Transfusion independent Transfusion dependent

Malcovati L, et al. J Clin Oncol. 2005;23:7594-603. HR = hazard ratio.

Survival of MDS patients by severity of transfusion requirement

Survival time (months) 0.2 0.4 0.6 0.8 1.0 Survival time (months) 0.0 0.2 0.4 0.6 0.8 1.0 20 40 60 80 100 120 140 160 180 Cumulative survival 0 U pRBC/4 weeks 1 U pRBC/4 weeks 2 U pRBC/4 weeks 3 U pRBC/4 weeks 4 U pRBC/4 weeks

Malcovati L, et al. Haematologica. 2006;91:1588-90.

0 U pRBC/4 weeks 1 U pRBC/4 weeks 2 U pRBC/4 weeks 3 U pRBC/4 weeks 4 U pRBC/4 weeks Cumulative survival

pRBC = packed red blood cells.

Overall survival (HR = 1.36; p < 0.001) Leukaemia-free survival (HR = 1.40; p < 0.001)

180 20 40 60 80 100 120 140 160 0.0

RA/RARS/5q− (HR = 1.42; p < 0.001) RCMD/RCMD-RS (HR = 1.33; p = 0.07)

Malcovati L, et al. Haematologica. 2006;91:1588-90.

Overall survival of transfusion-dependent patients by serum ferritin level

180 Cumulative proportion surviving 0.0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0 20 40 60 80 100 120 140 160 Cumulative proportion surviving 0.0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0 20 40 60 80 100 120 140 160 180 Survival time (months) Survival time (months)

Serum ferritin 1,000 µg/L 1,500 µg/L 2,000 µg/L 2,500 µg/L Serum ferritin 1,000 µg/L 1,500 µg/L 2,000 µg/L 2,500 µg/L

RA = refractory anaemia; RARS = RA with ringed sideroblasts; RCMD = refractory cytopenia with multilineage dysplasia; RCMD-RS = RCMD with ringed sideroblasts..

Blood 109:4586, 2007

Impact of Pretransplant Serum Ferritin on Outcome in MDS Patients

Prevalence of comorbidities in transfusion- dependent MDS

Transfused MDS patients have a higher prevalence of cardiac events, diabetes mellitus, dyspnoea, and hepatic and infectious diseases than non-transfused MDS patients

Goldberg SL, et al. J Clin Oncol. 2010;28:2847-52.

82.4 44.4 62.9 1.0 81.0 14.6 67.1 37.1 40.4 0.7 55.7 6.2

50 100 Cardiac events 2003–2005 Diabetes 2003–2005 Dyspnoea 2003–2005 Hepatic events 2003–2005 Infectious complications 2003–2005 Fungal infection 2003–2005

Patients (%)

With transfusion (n = 205) Without transfusion (n = 307)

Probability of non-leukemic death in transfusion dependent MDS patients

51 31 8 8 2 25 50 75 100 Cardiac failure Infection Haemorrhage Hepatic cirrhosis Other Percentage

N = 467

p = 0.01

Malcovati L, et al. J Clin Oncol. 2005;23:7594-603

Current Guidelines for Iron Chelation in MDS Patients Organization Transfusion Status (units of blood) Serum Ferritin (ng/mL) Life Expectancy/ MDS Risk Score Italian Hematology Society > 50 units – > 6 months UK Hematology Society ≥ 25 units – Low/ Int-1 NCCN > 20-30 units > 2500 Low/Int-1 SCT MDS Foundation ≥ 24 units > 1000 > 1year Austrian Hematology Society Transfusion- dependent > 2000 or organ damage

• 2years/SCT/

Chemotherapy Canadian Hematology Society Transfusion- dependent > 1000 or organ damage Low/Int-1/SCT Int-2 if > 1year life expectancy Japanese Hematology Society > 40 units * > 1000 > 1 year

Blood 34:441, 1969

Iron Promotes the Growth of Candida

PLoS One 6:e23109, 2011

Correlation Between Hepcidin and Ferritin in MDS Subtypes

What about higher risk MDS and AML progression?

• Iron is mutagenic in hematopoietic cells and can promote

progression to AML in mice1

• NTBI  LPI  ROS*

– ROS damage

• membranes
• proteins
• nucleic acids

X

Mutagenesis

Apoptosis

ROS = reactive oxygen species, NTBI = non-transferrin bound iron

Genomic instability

AML?

• Chelation induced apoptosis, differentiation & repressed signalling in

AML cells & cell lines in vitro & in vivo2-5

• 1. Chan LSA, et al. Blood 2010;116:[abstract 122]
• 2. Eberhard Y, et al. Blood. 2009;114:3064-73.
• 3. Jiang Y, et al. Leukemia. 2005;19:1239-47.
• 4. Ohyashiki JH, et al. Cancer Sci. 2009;100:970-7.
• 5. Callens C, et al. J Exp Med. 2010;207:731-50.

Currently Available Iron Chelation Agents

Deferoxamine Deferiprone Deferasirox

Usual dose (mg/kg/day) 25−60 75 20−30 Route of administration Subcutaneous or intravenous, Oral, three times daily Oral, once daily 8−12 hours, 5 days/week Half-life 20−30 minutes 3−4 hours 8−16 hours Route of excretion Urinary and fecal Urinary Fecal Main adverse effects Local reactions, ocular and Gastrointestinal disturbances, Gastrointestinal disturbances, auditory abnormalities, growth agranulocytosis/neutropenia rash, mild non-progressive retardation, allergic reaction arthralgia, elevated liver enzymes creatinine increase, elevated liver enzymes

Leuk Res 31(S3):S16, 2007

,

J Cardio Mag Res 13: 45, 2011

CHF Risk Reduction with Chelation According to EF Improvement

B J Haematol 136:501, 2007

Effect of Deferasirox on LIC in Sickle Cell Anemia

Leuk Res 34:1560, 2011

Deferasirox Normalizes LPI in MDS Patients

Pre-administration Post-administration 0.2 0.4 0.6 0.8 1.0 1.2

Mean LPI  SD (μmol/L)

Baseline 12 28 52

Time (weeks)

Normal threshold

• 1. List AF, et al. Blood. 2008;112:[abstract 634].
• 2. Gattermann N, et al. Leuk Res. 2010;34:1143-50.

Patients, n 55 38 39 37 34 Patients with baseline LPI ≥ 0.5 μmol/L = 41% Threshold of normal LPI (≤ 0.5 µmol/L)

Mean LPI (µmol/L)

0.2 0.4 0.6 0.8 1.0 1.2 BL 3 6 9 12

Months from baseline

p  0.00001*

*Comparison of baseline LPI vs each treatment time point

US03 study1 EPIC study – MDS cohort2

Br J Haematol 94:288, 1996

Successful Iron Chelation Improves Erythropoiesis in MDS

ERYTHROID RESPONSE DURING IRON CHELATION

Transfusion 50:1568, 2010

EPIC: reduction in serum ferritin is associated with improvement in ALT in MDS

• At 12 months, there were significant reductions in

– median serum ferritin (−253 µg/L; p = 0.002) – mean ALT (−27.7 ± 37.4 U/L; p < 0.0001)

500 1,000 1,500 2,000 2,500 3,000 3 6 9 12 Baseline 3 6 9 12 Time (months) Median serum ferritin (µg/L) Mean ALT (U/L) ALT Serum ferritin ALT Mean actual deferasirox dose: 19.2 ± 5.4 mg/kg/day 10 20 30 40 50 60 70

ALT = alanine transaminase; EPIC = European Prospective Investigation into Cancer and Nutrition. Gattermann N, et al. Leuk Res. [Epub ahead of print 2010 May 5].

Survival in chelated versus non-chelated MDS patients with (a) transfusion requirements <3 PRBC/month and (b) transfusion requirements >3 PRBC/month.

Leukemia Res 34:864, 2010

Survival is improved in MDS with Chelation

IPSS = Low

Median: not reached vs 69 months (p < 0.002)

Survival distribution function 0.00 0.25 0.50 0.75 1.00 Time from diagnosis to death (months) 50 100 150 200 250

Iron chelation (n = 30) No chelation (n = 15)

Survival distribution function 0.00 0.25 0.50 0.75 1.00 Time from diagnosis to death (months) 20 40 60 80 100 120 140

No chelation (n = 29)

IPSS = Int-1

Median: 115 vs 50 months (p < 0.003)

Results were the same regardless of sex and age.

Rose C, et al. Leuk Res. [Epub ahead of print 2010 Feb 1].

Iron chelation (n = 23)

GFM: effect of iron chelation therapy on survival in lower-risk MDS patients

GFM = Groupe Francophone des Myélodysplasies.

NTBI elevation during allogeneic SCT

C

Sahlstedt L, et al. Br J Haematol. 2001;113:836-8.

20 40 60 80 100 120 140 −14 −7 7 14 21 Transferrin saturation (%) Time from SCT (days)

0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 1.1 20 40 60 80 100 120 140 160

NTBI (μmol/L)

C = onset of conditioning regimen.

20 40 60 80 100 120 140 −14 −7 7 14 21 Transferrin saturation (%)

Lee JW, et al. Bone Marrow

• Transplant. 2009;44:793-7.

SF > 1,000 SF < 1,000 IC p = 0.001 0.2 0.4 0.6 0.8 1.0 12 24 36 48 60 SF > 1,000 SF < 1,000 IC p = 0.000 12 24 36 48 60 0.2 0.4 0.6 0.8 1.0 SF > 1,000 SF < 1,000 IC p = 0.003 12 24 36 48 60 0.2 0.4 0.6 0.8 1.0

Overall survival rate Event-free survival Treatment-related mortality rate Months from transplantation Months from transplantation Months from transplantation

SF > 1,000 = patients with serum ferritin ≥ 1,000 µg/L at the time of SCT; SF < 1,000 = patients with serum ferritin < 1,000 µg/L at the time of SCT, without ICT; IC = patients with serum ferritin decreased to < 1,000 µg/L with ICT before SCT.

Iron Chelation Before SCT Improves Survival (n = 101)

Adverse event* Number (%) Diarrhoea 111 (32.6) Nausea 45 (13.2) Vomiting 26 (7.6) Abdominal pain 26 (7.6) Upper abdominal pain 25 (7.3) Rash 23 (6.7) Constipation 21 (6.2) Total number 341

*Drug-related as assessed by the investigator.

EPIC Study: Adverse Events with Deferasirox

Gattermann N, et al. Leuk Res. 2010;34:1143-50.

Side effect n % Gastrointestinal symptoms (abdominal discomfort, pain, nausea, vomiting, diarrhea) 18 37.5 Granulocytopenia (neutrophils = 0.5–1.0 × 109 /L) 5 13.0 Agranulocytosis (neutrophils < 0.5 × 109 /L) 2 4.0 Elevation of liver enzymes (>3 × upper normal limits) 9 18.8 Weight gain, fluid retention 2 4.0 Most Frequent Side Effects of Deferiprone Therapy in Myelodysplastic Syndrome Patients

Hemoglobin 35: 217, 2011

Correlation of Anemia and Survival in the Elderly

JAGS 45:825, 1997

Men Women Haematologica 2011

Probability of Death in MDS According to the Hemoglobin Level

Haematologica 2011 Probability of Cardiac Death in MDS According to the Hemoglobin Level

Men Women

EPO/G-CSF Control

Improved Overall Survival in MDS with EPO/G-CSF Therapy

J Clin Oncol 26:3607, 2008

Summary

• Iron overload is associated with impaired survival and an increased risk of

leukemic transformation in MDS patients with Low or Int-1 disease

• Risk assessment based on iron stores is imperfect because of poor correlation

between the transfusion burden and body iron store measurements

• Iron chelation therapy can reduce total body iron stores and NTBI
• Iron chelation is associated with improved survival as well as an improved response

to bone marrow transplantation in MDS patients

• Oral chelation may be more effective than parenteral chelation in reducing

intracellular cardiac iron and combining oral and parenteral chelation may be the most effective strategy

• Anemia per se contributes to iron overload and is also an important cofactor for

disease morbidity in iron-overloaded MDS patients

• Current transfusion practice needs to be altered to maintain the hematocrit

commensurate with continuous relief of tissue hypoxia on a gender-specific basis

• The threshold for initiating iron chelation should be based on organ dysfunction

Gold is for the mistress, silver for the maid, copper for the craftsman cunning at his trade but iron said the Baron sitting in his hall, iron, cold iron is the master of them all.

Rudyard Kipling

Which of these Individuals is Tebowing?

A B C

Answer:
