SLIDE 1
iRODS in the Cloud: SciDAS and NIH Helium Commons
Claris Castillo RENCI, UNC Chapel Hill
- Commons
iRODS in the Cloud: SciDAS and NIH Helium Commons Commons Claris - - PowerPoint PPT Presentation
iRODS in the Cloud: SciDAS and NIH Helium Commons Commons Claris - - PowerPoint PPT Presentation
iRODS in the Cloud: SciDAS and NIH Helium Commons Commons Claris Castillo RENCI, UNC Chapel Hill Not Scaling up Data Analysis is Not an Option 20 th Century 21st Century Normal veteran (giga-/terascale) and newbie
SLIDE 2
SLIDE 3
Not Scaling up Data Analysis is Not an Option
www.smartpractice.com Wisegeek.org
DatAPocaLypse Prediction (Genomics): In 20 years, every CVS, subway, hospital, research lab, public health facility, police station, etc will have a DNA sequencer generating Exabytes of data in aggregate each week. 20th Century 21st Century Normal veteran (giga-/terascale) and newbie (megascale) users MUST ADVANCE to the peta/exa-scale in this generation. Issues:
- Limited computational skills (What is a C library?)
- Poor use of advanced networks (We need more HDs to mail!)
- Limited access to computational resources (awareness, $$$)
- Unpredictable time to compute result (queue times, queue times,
queue times, broken nodes, segfaults, OOM, data geography)
- Missing skillsets (I only know Perl)
- Data must be organized and good stuff deleted (Data policies)
- How many bioinformaticists are on the CVS payroll?
- How many faculty recruitments failed because campus X research computing
resources are stuck in 2015?
- How many adverse drug reactions were not predicted because of limited/broken
cyberinfrastructure?
Alex Feltus
SLIDE 4
Heterogeneous and Complex CI Ecosystems
+100 sites +1500 users
Community data sharing platforms
…
Compute infrastructure Advance networks Storage infrastructure
SLIDE 5
Commoditization of Cloud computing and the convergence of compute, storage, data and network technologies enables the ‘illusion’ of a single large computer consisting of widely distributed systems.
SLIDE 6
Breakdown: One Layer at A Time -- Data
+100 sites +1500 users
… iRODS team connected iRODS to a MariaDB Galera Cluster to provide a multi-master, distributed iRODS catalog over the WAN.
“Distributing the iRODS Catalog: a way forward”, M. Stealey, et. al. iRODS User Group Meeting (UGM), Netherlands, 2017.
SciDAS Zone MariaDB Gallera cluster
SLIDE 7
+100 sites +1500 users
… Apache Mesos: A layer of abstraction, to utilize an entire data center as a single large server
Breakdown: One Layer at A Time -- Compute
SLIDE 8
+100 sites +1500 users
…
Scientific applications will be available in the form of SciApps “virtual appliances” (NSF CC-ADAMANT, [works15])
[works15] Enabling Workflow Repeatability with Virtualization Support, Fan Jiang et.al. Workshop on Workflows of Large-Scale Science, Supercomputing Conference (SC15), Austin, Texas,2015.
Breakdown: One Layer at A Time – Scientific Tools
SLIDE 9
SciDAS: Bringing it All Together Into One System
+100 sites +1500 users
…
[works15] Enabling Workflow Repeatability with Virtualization Support, Fan Jiang et.al. Workshop on Workflows of Large-Scale Science, Supercomputing Conference (SC15), Austin, Texas,2015.
SciDAS Middleware
Cost-Aware Optimize iRODS Shim (aaS) API PerfSONAR Shim (aaS) API PerfS ONA R map ping Requester Orchestrator
- Network aware placement
- Optimize for data locality
- Capability aware resource aware
placement
- GPU able nodes
- Authentication and authorization
infrastructure
- CiLogon
SLIDE 10
Improving scientific productivity by the numbers
SLIDE 11
- Commons
Cloud-Agnostic Platform
Global Unique ID Search & Indexing Workspace
Security & Compliance
FAIR
Data Commons APIs Scientific Communities
Interoperability Component APIs
Data / Tools Enrollment Data / Tools Discovery Scalable, Secure and Collaborative Workflow Execution
Data Commons
SLIDE 12
`
TopMED MOD GTEX …
Marathon
Chronos
Jupyter apps
Appliances JSON Descriptors {:}
JSON
{:}
JSON
{:}
JSON
{:}
JSON
data: /aws/TopMed cloud-preference: GC Encryption: true Docker-imge:foo Ram:16G CPU:Stge: 5TB
PIVOT API/Core Service
High-level descriptor of applications Intelligent decision (cloud aware) Provision & deploy Access/write data anywhere
Input
Make results discoverable
CWL apps
CommonsShare (KC5:portal)
Bring-Your-Own-Data `
TopMED MOD GTEX …
Metadata to encode rich information Rule engine programmed with rules to enact policies Data Federation Virtualization system
- Commons
Bring-Your-Own- Data-Service
SLIDE 13
`
TopMED MOD GTEX …
Marathon
Chronos
Jupyter apps
Appliances JSON Descriptors {:}
JSON
{:}
JSON
{:}
JSON
{:}
JSON
data: /aws/TopMed cloud-preference: GC Encryption: true Docker-imge:foo Ram:16G CPU:Stge: 5TB
PIVOT API/Core Service
High-level descriptor of applications Intelligent decision (cloud aware) Provision & deploy Access/write data anywhere
Input
Make results discoverable
CWL apps
CommonsShare (KC5:portal)
Bring-Your-Own-Data ` Bring-Your-Own- Data-Service
TopMED MOD GTEX …
- Commons
BYOD: Cloud storage can be added as storage resources Extended data collaboration (BYODS): Seamless integration with data hosted on external data services Data Federation (default): continuous virtual system while retaining control of each endpoint
iRODS enables powerful data sharing models in the Commons
SLIDE 14
