BIOL 6505 Invasive Fetal Therapy Stephen R. Carr Francois I. Luks Fetal Therapy Definitions: Fetal intervention Non-invasive (time, mode of delivery) Minimally invasive therapy Invasive therapy Fetal surgery EXIT

slide-1
SLIDE 1

BIOL 6505 Invasive Fetal Therapy

Stephen R. Carr Francois I. Luks

slide-2
SLIDE 2

Fetal Therapy

Definitions:

  • Fetal intervention
  • Non-invasive (time, mode of delivery)
  • Minimally invasive therapy
  • Invasive therapy
  • Fetal surgery
  • EXIT procedure
slide-3
SLIDE 3

Fetal Surgery

Problems and research:

  • Major maternal surgery (laparotomy)
  • Hysterotomy
  • Bleeding ++
  • Membrane integrity/rupture/separation
  • Intraoperative contractions
slide-4
SLIDE 4

Fetal Surgery

Problems and research:

  • Fragile fetus
  • Dehydration
  • Hypothermia (1°C per 5 min of surgery)
  • Direct fetal trauma
  • Cord manipulation
  • Complex operations!
  • Postoperative tocolysis and labor!
slide-5
SLIDE 5

Fetal Surgery

Solutions and research:

  • Back-biting hysterotomy clamps
  • Staplers
  • Absorbable staples
  • Anesthesia
  • Tocolysis
  • Halogenated gases
  • Postoperative: ideal agent?
slide-6
SLIDE 6

Fetal Surgery

Animal models:

  • Fetal rabbit
  • Basic physiologic principles
  • Fetal lamb
  • Quiescent uterus
  • Tolerant fetus
  • Long gestation (145 d)
slide-7
SLIDE 7

Fetal Surgery

Animal models:

  • Non-human primate
  • More realistic
  • Sensitive uterus
  • Last step before clinical application
  • Rhesus monkey
  • Baboon
slide-8
SLIDE 8

Fetal Surgery

Types of operations:

  • Lower urinary tract obstruction (LUTO)
  • Pulmonary hypoplasia prevention
  • Congenital diaphragmatic hernia (CDH)
  • Pulmonary hypoplasia prevention
  • Large CCAM
  • Pulmonary hypoplasia prevention
  • Avoid/reverse fetal hydrops
  • Sacrococcygeal teratoma
  • Avoid fetal hydrops and maternal ecclampsia
slide-9
SLIDE 9

Fetal Surgery

Results:

  • 100% preterm labor
  • High fetal mortality (condition-specific)
  • CDH: 14% survival
  • SCT: 0% survival
  • Vesicostomy: 75% renal failure
  • CCAM: 60% survival
slide-10
SLIDE 10

Fetal Surgery

Results:

  • Maternal complications
  • Blood transfusion

12%

  • Pulmonary edema

12-16%

  • Tocolysis

(average duration) 90.0 hours

  • ICU stay (average stay)

9.6 d

  • Mandatory subsequent C/S
slide-11
SLIDE 11

Open fetal surgery

Maternal complications:

Harrison MR, SPO 1995

Preterm labor Transfusion Amniotic fluid leak Mirror syndrome Pulmonary edema Pseudomembranous colitis Wound infection

N %

42 100 5 12 2 5 2 5 5 12 1 2 1 2

slide-12
SLIDE 12

Open fetal surgery

Results updated (MMC): N=17

Wilson RD et al, 2003

Chorioamniotic separation Delivery at 36-37 wk

N %

17 34 18 43

slide-13
SLIDE 13

Open fetal surgery

Most recent results (MMC): N=78

Adzick NS et al, 2011

Chorioamniotic separation Delivery > 36-37 wk Pulmonary edema Placental abruption Intact hysterotomy wound

N %

20 26 16 21 5 6 5 6 49 64

slide-14
SLIDE 14

Eurofoetus Registry- Endoscopy

Maternal complications: 7.3% (123 cases)

  • Chorioamnionitis

2

  • Abruptio

1

  • Pulmonary edema

2

Maternal deaths:

  • 1 (in registry): of amniotic fluid embolus, after C/S, 1

week after unsuccessful FLOC

  • 1 (not in registry): Intraoperative abruption

(as of 9/20/00)

slide-15
SLIDE 15

Fetal Surgery

Conditions that have to be met:

  • Correct prenatal diagnosis
  • Correct differential diagnosis
  • Known natural history
  • Condition lethal if left untreated
  • No available postnatal treatment
  • Fetal operation feasible
slide-16
SLIDE 16

Fetal Surgery

So… What’s left?

  • Spina bifida
  • MOMS trial and beyond
  • Diaphragmatic hernia
  • Open repair: results worse than postnatal R/
  • Endoscopic repair: tracheal occlusion trial
  • CCAM, SCT
  • Only extreme, exceptional cases
  • Urinary tract obstruction
  • Only percutaneous, sometimes
  • TTTS, Acardiac twin
slide-17
SLIDE 17

Acardiac twin: TRAP sequence Acardiac is parasite:

  • No heart, no brain
  • Reverse flow in umbilical artery
  • “Pump” twin exsanguinates in acardiac
slide-18
SLIDE 18

Acardiac twin: TRAP sequence Goal:

  • Block acardiac’s umbilical cord
  • 2-instrument ligation of the cord
  • Laser ablation of the cord vessels
  • Radiofrequency ablation
slide-19
SLIDE 19

Acardiac twin: TRAP sequence Goal:

  • Block acardiac’s umbilical cord
  • 2-instrument ligation of the cord
  • Laser ablation of the cord vessels
  • Radiofrequency ablation
slide-20
SLIDE 20

Acardiac twin: TRAP sequence

slide-21
SLIDE 21

Acardiac twin: TRAP sequence

slide-22
SLIDE 22

Acardiac twin: TRAP sequence

slide-23
SLIDE 23
  • Minimally invasive surgery
  • Percutaneous vs. open endoscopy vs. laparotomy
  • Local vs. regional vs. general anesthesia
  • Access and exit techniques
  • Risks:
  • Chorioamnionitis
  • Preterm labor
  • Membrane rupture/PPROM
  • Amniotic leak
  • Bleeding

Technique:

Laser Ablation for TTTS

slide-24
SLIDE 24

A V A V A V A V

slide-25
SLIDE 25

Instrument: 1 port, Mini-Endoscope

1.9 mm diameter Sheath 3 mm diameter 400 laser Low-flow irrigation

Laser Ablation for TTTS

slide-26
SLIDE 26

The operating room

Laser Ablation for TTTS

slide-27
SLIDE 27

Twin-to-twin Transfusion - Laser

Car SR et al SMFM annual meeting 2006

Do the patients survive?

slide-28
SLIDE 28

Twin-to-twin Transfusion - Laser

Car SR et al SMFM annual meeting 2006

Do the patients survive?

slide-29
SLIDE 29

Congenital Diaphragmatic Hernia

One-Slide Background

  • Herniated viscera compress the lungs
  • Hypoplastic lungs function poorly
  • Decades ago: 80% mortality at birth
  • Prenatal repair of the hernia too invasive
  • 14% survival
  • Fetal tracheal occlusion makes the lungs grow
  • Works great in animal models
slide-30
SLIDE 30

Type II cell

PGE2 secretion Fluid excretion Cl - Cl -

Late Lung Maturation

slide-31
SLIDE 31

Type II cell

STRETCH PGE2 secretion Fluid excretion Cl - Cl -

Late Lung Maturation

slide-32
SLIDE 32

Type II cell Fibroblast

STRETCH PGE2 secretion Fluid excretion Cl - Cl -

Late Lung Maturation

slide-33
SLIDE 33

Type II cell Fibroblast

STRETCH PGE2 secretion Fluid excretion Cl - Cl - TG uptake and release cAMP PTHrP

Late Lung Maturation

slide-34
SLIDE 34

Type II cell Fibroblast

STRETCH PGE2 secretion Fluid excretion Cl - Cl - TG uptake and release

IGF, HGF, KGF, EGF, TGF-

cAMP PTHrP

Late Lung Maturation

slide-35
SLIDE 35

Type II cell Fibroblast

STRETCH IL-6,11 PGE2 secretion Fluid excretion Cl - Cl - TG uptake and release TG incorporation

IGF, HGF, KGF, EGF, TGF-

DNA synthesis PL synthesis SP synthesis MAP kinase cAMP PGE2 PTHrP

Late Lung Maturation

slide-36
SLIDE 36

Type II cell Fibroblast

STRETCH IL-6,11 PGE2 secretion Fluid excretion Cl - Cl - TG uptake and release TG incorporation

IGF, HGF, KGF, EGF, TGF-

DNA synthesis PL synthesis SP synthesis MAP kinase cAMP PGE2 PTHrP

SPACE- OCCUPYING MASS

Late Lung Maturation

slide-37
SLIDE 37

Type II cell Fibroblast

↑STRETCH

IL-6,11 PGE2 secretion Fluid excretion Cl - Cl - TG uptake and release TG incorporation

IGF, HGF, KGF, EGF, TGF-

DNA synthesis PL synthesis SP synthesis MAP kinase cAMP PGE2 PTHrP

TRACHEAL OCCLUSION

Late Lung Maturation

slide-38
SLIDE 38

Fetal Surgery

Diaphragmatic hernia

  • Tracheoscopy and detachable balloon
  • Prenatal surgery ‘no better’ than postnatal treatment
  • Moratorium in U.S.
  • European experience encouraging
slide-39
SLIDE 39

Tracheal balloon L lung R lung 8/3/07 9/18/07

slide-40
SLIDE 40

Fetal Tracheal Occlusion

Now what?

  • Late, temporary occlusion works
  • Rapid lung growth and proliferation
  • Investigational Device Exemption (FDA)
  • Two centers in the US:
  • Brown
  • UCSF
slide-41
SLIDE 41

Spina Bifida

Outcome of fetal surgery

First report: Adzick NS et al? Bruner JP et al?

slide-42
SLIDE 42

Spina Bifida

Adzick NS et al, 2011

slide-43
SLIDE 43

Spina Bifida

Adzick NS et al, 2011

slide-44
SLIDE 44

Spina Bifida

Now that the MOMS trial is over

Standard of care? What about maternal safety? What about the trial effect?

  • Future results may not match the MOMS results
slide-45
SLIDE 45

Spina Bifida

Now that the MOMS trial is over

Minimally invasive approach? (Didn’t work in 2002, but how about now?)

slide-46
SLIDE 46

Fetal Surgery Spin-off: The EXIT Procedure

BIOL 6505

slide-47
SLIDE 47

Ex-Utero Intra-Partum t

Previously termed “Operation On Placental Support”

Procedure

slide-48
SLIDE 48
slide-49
SLIDE 49
slide-50
SLIDE 50
slide-51
SLIDE 51
slide-52
SLIDE 52
slide-53
SLIDE 53
slide-54
SLIDE 54

EXIT Procedure

Multidisciplinary team:

  • Obstetrical Anesthesia
  • Maternal-Fetal Medicine
  • OB OR Nurses
  • Pediatric Anesthesia
  • Pediatric Surgery
  • Pediatric ENT
  • Pediatric Radiology
  • Pediatric OR Nurses
  • Neonatologists
  • Respiratory Therapists
  • Neonatology Nurses
slide-55
SLIDE 55
slide-56
SLIDE 56
slide-57
SLIDE 57
slide-58
SLIDE 58

Tracheostomy

slide-59
SLIDE 59
slide-60
SLIDE 60
slide-61
SLIDE 61

No. Gestational Age Indications mean Range Reversal of tracheal occlusion 13 31.8 29-37 Giant fetal neck mass 13 36.0 32-40 EXIT

  • to-ECMO

1 36 Resection of CCAM 1 38 Unilateral pulmonary agenesis 1 39 Bridge to separation for conjoined twins 1 34 CHAOS 1 31 Overall 31 34.2 29-40

The EXIT Procedure: Experience and Outcome in 31 Cases

By Sarah Bouchard, Mark P. Johnson, Alan W. Flake, Lori J. Howell, Laura B. Myers, N. Scott Adzick, and Timothy M. Crombleholme

Philadelphia, Pennsylvania

Journal of Pediatric Surgery, Vol 37, No 3 (March), 2002: pp 418-426

slide-62
SLIDE 62

The EXIT Procedure: Experience and Outcome in 31 Cases

By Sarah Bouchard, Mark P. Johnson, Alan W. Flake, Lori J. Howell, Laura B. Myers, N. Scott Adzick, and Timothy M. Crombleholme

Philadelphia, Pennsylvania

Journal of Pediatric Surgery, Vol 37, No 3 (March), 2002: pp 418-426

Table 2. Duration of Uteroplacental Gas Exchange Minutes on Uteroplacental Indications Support (range) Reversal of tracheal occlusion 26.7 ± 6.3 (18-38) Giant fetal neck mass 29.2 ± 16.4 (8-54) EXIT-to-ECMO 58 Resection of CCAM 66 Unilateral pulmonary agenesis 14 Bridge to separation conjoined twins 43 CHAOS 25 Overall 30.3 ± 14.7 (8-66)

slide-63
SLIDE 63

The Ex Utero Intrapartum Treatment Procedure: Looking Back at the EXIT

By Shinjiro Hirose, Diana L. Farmer, Hanmin Lee, Kerilyn K. Nobuhara, and Michael R. Harrison

San Francisco, California

Journal of Pediatric Surgery, Vol 39, No 3 (March), 2004: pp 375-380 Table 1. Indications and Outcome Data for EXIT Procedure Indication for EXIT CDH 45 Neck mass 5 CHAOS 2 Outcome data for EXIT procedures Survivors 27 (52%) Female:male 1:2 Gestational age at birth (wk) 31.95 ± 2.55 Birth weight (g) 1895 ± 853 Maternal blood loss (mL) 970 ± 510 Time on placental support (min) 45 ± 25 T racheostomy-dependent (n of patients) 6
