Introduction Who We Are We offer a diverse scope of professional - - PowerPoint PPT Presentation

Introduction – Who We Are

• Broward County
• Palm Beach County
• Pompano Beach
• Marathon
• Islamorada
• Key West
• Oakland Park
• West Palm Beach
• Pembroke Pines
• Dania Beach
• Hollywood
• Miami Gardens
• Tamarac
• West Park
• Weston
• North Lauderdale
• Lauderhill
• Sunny Isles
• Surfside
• Riviera Beach
• Lake Worth
• Lantana
• Parkland
• Weston
• Florida Department of

Transportation

• District 1, 4 , 6 & 7
• Florida Department of

Environmental Protection

• Seminole Tribe of Florida

Municipal Experience (not limited to)

• We offer a diverse scope of professional services that often enables us to serve as

a reliable one-source partner, efficiently tackling time-sensitive projects with customized solutions.

• Since 1937, the company has grown from a small, two-person surveying firm to
• ver 380 employees, providing over 34+ Municipal Services.
• The Construction Engineering & Inspection Division (CEI) was launched by Calvin,

Giordano & Associates in 2002.

I. Staffing Experience & Qualifications

• II. Project Scope
• III. Approach to Critical Issues
• IV. Past Record & Experience on Similar

Projects

• V. Why CGA ?

Project Scope

I. Staffing Experience & Qualifications (150 Years of Combined Experience)

Project Manager / Senior Project Engineer: Bryan Williams, P.E. (18 years experience) (Former Broward County Employee)

• Overall Management
• Technical Assistance
• Financial Project Management
• Palm Beach County Liaison & Main Point
• f Contact

Quality Assurance / Quality Control: Moe Mabrouk, P.E. (11 years experience) Diana Rivas, P.E. (12 years experience)

• Quality Assurance Quarterly Inspection.
• Development of a project specific QA/QC Plan
• Technical Support

Project Administrator : Felix Garcia, P.E. (12 years experience) (Former FDOT District 4 Employee)

• Review & Monitor
• All construction documentation
• Ensure compliance with Contract
• Project Coordination
• Processing payments
• Contract records
• Change orders
• Time Control
• Budget Control

Contract Support Specialist Alfredo Rauseo, PE (22 years experience)

• Monthly Payments
• Final Estimates

Inspection Team: Julio Antonio (33 years experience) Nataniel Mohandes (3 years experience)- F&J Engineering, Inc. (CBE/DBE) Survey & Mapping: Steve Watts, PSM (28 years experience) RCS/Clerk/Landscape Specialist: Erin Sudman (11 years experience) Geotechnical Testing & Services: Federal Engineering & Testing (CBE/DBE/SBE)

Responsible Office (Broward County): 1800 Eller Drive Suite 600 Fort Lauderdale, FL

I. Staffing Experience & Qualifications (150 Years of Combined Experience)

Responsible Office (Broward County): 1800 Eller Drive Suite 600 Fort Lauderdale, FL

• Project Scope: The Improvements under this contract includes:
• Roadway widening ( 12” type B stabilization and OBG 9) to accommodate three

11’ lanes with a 4’ to 5’ green background bike lanes on each side

• Milling and resurfacing (milling the existing roadway 1” and resurfacing with 1” of

SP Structural Course (Traffic C) and 1” FC-9.5)

• Extensive drainage and stormwater improvements including 70 curb inlets, ditch

bottom inlets and manholes with over 1,600 LF of pipe and 1,750 LF of French Drain

• Signalization improvements at Riverside Drive and Woodside Drive
• Mast arms
• Pedestrian detectors
• Video detection system
• New cabinets
• Landscape improvements including installation and repair of irrigation and

installation of new landscape

• Lighting system on the North side of the roadway.

II. Project Scope

III. Approach to Critical Issues

Critical Issue- PIO & Stakeholders Coordination Challenges & Approach:

• Coordination with Broward County and the City of Coral Springs
• Coordination with adjacent business to ensure continuous driveway access during construction.
• Especially for plazas on the south side with one way traffic through the parking lot
• Coordination with adjacent schools/Parks
• Extra attention to protecting Whispering Woods Park right-of-way
• Approach Highlights: construction flyer distributer, weekly progress update & 2 week advance notice prior

to work. Critical Issue- Utility Coordination Challenges & Approach:

• Coordination with utility owners (TECO, ATT, FPL, CITY, Etc.)
• Soft digs are critical for mast arm locations
• Multiple Utility relocations not addressed in the Draft Plans.
• Proximity to overhead utilities and OSHA Requirements (De-energizing; using low profile equipment; Etc.)
• Our approach includes:
• Create a matrix with all the anticipated utility work
• Pre-construction utility meeting
• Early Utility relocation coordination

Critical Issue- Communication with County Project Manager Challenges & Approach:

• Our SPE will ensure that the PM is informed of project related issues and construction progress using the

following methods:

• Weekly progress meetings
• Weekly progress reports
• Monthly logs (PIO, WO, RFI, Etc.), dailies and emails

III. Approach to Critical Issues

Critical Issue: Earthwork & Asphalt Challenges & Approach:

• Monitoring Earthwork Quantities
• Performing VT and QC testing
• Monitoring the paving operation to ensure smooth ridability is critical at intersections.
• Pre paving meeting with the contractor.
• Review the asphalt QC plan prior to paving and will provide comments to the contractor.
• Ensure temperature testing is performed.
• Asphalt tickets are collected for review.
• Milling depth is checked.
• Cleanness of the milled surface prior to tack application, track asphalt application rates, track tack

application rates.

• Tracking overbuild and verifying final elevations using OUR survey crew.

Critical Issue- Drainage Challenges & Approach:

• Pre-activity meeting.
• Timely submittal & review of shop drawings. Only Stamped Structures are used.
• Ensure that all filter fabric, bricks, mortar & coarse aggregate are:
• Certified & Sampled and accepted to AVOID any rework.

Critical Issue- Signalization & Pavement Markings Challenges & Approach:

• Locations of the mast arm foundation.
• Foundation elevation.
• Foundation bolt alignment.
• Thorough review of Drill Shaft Installation Plan.
• Pavement marking layout prior to paint and thermoplastic application.
• Allow proper curing time prior to placing thermo.

III. Approach to Critical Issues

Critical Issue- MOT & Safety Challenges and Proactive Approach:

• MOT will be a main focus to our team, working on one side of the roadway at a time, ensuring:
• Pedestrian access specifically for:
• Coral Springs High School, Center Academy Coral Springs, American High School, Forest

Glen Middle School; Coordination will include school & crossing guard staff for construction during school hours. Coordination with surrounding residents and businesses.

• Driveway Access
• Implementing lane closures as per the FDOT standard index 600, protection of drop offs, providing

business access Other Critical Issues:

• Tree removal / trimming in proposed sidewalk areas
• Obtaining permits prior to start of tree removal or clearing and grubbing
• Comparing the work performed by construction project east of the project limits to our proposed work

in order to avoid conflicts, redundancy and rework

• Coordination with FDOT
• CIGP Contract Requirements
• Reimbursements
• WO’s, CO’s, Time Extensions
• Constant Communication

Final Materials Certification and Final Estimates: Using only materials approved by the County and FDOT, using APL signalization items, & coordination for material testing between the QC/VT Lab. Monthly & Final Estimates will be prepared by Felix and reviewed by Bryan to ensure the accuracy of payments to the contractor Contract Administration: RFI’s, Schedule Review, QC plans review, meetings, As-builts, monthly letters, sampling and testing, claim documentation and technical support

City of Pompano Beach MLK Blvd. – Drainage, Signalization, Lighting & Roadway improvements (from Powerline Rd. to Florida Turnpike) Contact: Horacio Danovich Title: Project Manager Address: 100 West Atlantic Blvd. Pompano Beach, FL 33060 Telephone: 954.786.7834 Email: horacio.danovich@copbfl.com Scope

• f

Work: Project FM # 432861-1-58-01 (LAP Funded $2,855,802.00); Improvements include the construction of a new intersection on NW 27th Ave, The installation of 34 light poles, extensive utility coordination, roadway widening, extensive storm and waste water pipe relocation, drainage improvements, milling and resurfacing, sidewalk and median installation, curb and gutter installation, signage, landscaping, irrigation and pavement markings.

• Original Cost: $2,870,777.00
• Actual Cost: On-Going
• Original Completion: On-going
• Completion: Anticipated March 2017

IV. Past Record & Experience on Similar Projects

City of Oakland Park Bid Pack 9; Drainage, Utility and roadway Infrastructure Improvements Contact: Akin Ozaydin,P.E. Title: Project Manager Telephone: 954.630.4343 Email: dincero@oaklandparkfl.gov Scope of Work: The project encompasses approximately 570 acres, the project boundaries are east of Dixie Highway, west of Federal Highway, north of NE 38th Street and south of NE 50th Court. This project includes drainage improvement, water main replacement, sewer force main replacement, rehabilitation of Lift Station B-2, Lift Station #3, Lift Station #4, sidewalk installation, roadway improvements and resurfacing. The proposed drainage improvements include construction of roadside swales and closed drainage system, construction of new stormwater conveyance system piping networks, modification of the existing conveyance systems and replacement of outfall structures that discharge into the existing interconnected lakes and canals. Construction of roadway improvements on NE 45th Street will include the addition of paved shoulders and eastbound lane widening at the intersection of NE 18th Ave. Original Cost: $9,640,779.41 Actual Cost: On-Going Original Completion: On-going Completion: Anticipated March 2017

IV. Past Record & Experience on Similar Projects

City of Oakland Park Park Lane East drainage and Roadway Improvements Contact: Ron Desbrunes, PE, Project Manager Telephone: 954.430.4482 Email: ronaldd@oaklandpark.gov Scope of Work: LAP Project FM # 427767-1-58/68-01(LAP Funded); The project encompassed NE 11TH Avenue to Andrews Avenue. Improvements included the installation

• f storm drain piping and structures, sanitary sewer main relocation, landscaping, irrigation,

decorative lighting with coordination for utilities on NE 38 Street between Andrews Avenue and NE 11th Avenue. Original Cost: $3,415,898.00 Actual Cost: $3,415,898.00 Original Completion: 12/2014 Actual Completion: 12/2014

IV. Past Record & Experience on Similar Projects

City of West Palm Beach Clematis Street Improvements Contact: Brian Collins, PE Title: City Traffic Engineer Telephone: 561.494.1076 Email: bcollins@wpb.org Scope of Work: Project FM # 427652-1-58-01; LAP Funded; Improvements included pedestrian and landscape enhancements such as construction of a landscaped median and installation of additional landscaping, tree grates, benches, bike racks, trash receptacles, sidewalk, milling and resurfacing, striping, signing and irrigation system from Sapodilla Avenue to Tamarind Avenue. Original Cost: $744,534.17 Actual Cost: $797,236.17 Original Completion: 07/2014 Actual Completion: 07/2014

Past Record & Experience on Similar Projects

IV. Past Record & Experience on Similar Projects

V. Why CGA?

 Team’s Experience and Qualifications: We have the A-Team!  Familiarity with the Broward County and FDOT Team: Our team has completed multiple projects for the County and FDOT and understand their requirements. Mr. Bryan Williams and Mr. Felix Garcia were Broward county and FDOT employees.  Familiarity with Signalization in Broward County: Our team includes veterans who have completed multiple signalization projects that were transferred to Broward County.  Ability to provide support: With over 380 professionals, we can provide any services needed by the County on this contract including support by our Traffic and Survey Departments to the CEI team.  Ability to Meet your CEI Budget: controlling overhead costs the use of crossed trained staff are factors that will help control the CEI budget.  Availability to Work Immediately: We are available now!  Commitment to Meet your Project Goals: We have met our Time, Money, Materials Certification and Final Estimates goals on all of our projects in the past 5 years. We are committed to meeting those same goals on this project.
