SLIDE 1
Introduction to Seismic Essentials in Groningen
3.1
Seismic Design Concepts
Capacity Design Philosophy
Timurhan Timur MSc PhD - Arup
Introduction to Seismic Essentials in Groningen Seismic Design - - PowerPoint PPT Presentation
Introduction to Seismic Essentials in Groningen Seismic Design - - PowerPoint PPT Presentation
Introduction to Seismic Essentials in Groningen Seismic Design Concepts 3.1 Capacity Design Philosophy Timurhan Timur MSc PhD - Arup Design Philosophy A term used for the fundamental basis of design Selection or identification of design loads
SLIDE 2
SLIDE 3
Design Philosophy
A term used for the fundamental basis of design Selection or identification of design loads Analytical techniques Design procedures Structural configuration Extent of economic optimization
SLIDE 4
Strength-based Design Philosophy
Gravity Load Wind Load
SLIDE 5
Strength-based Design Philosophy
Displacement within elastic region
Displacement Force
SLIDE 6
Force Displacement Yielding structure Elastic structure
Strength-based vs. Reality
Strength-based design philosophy not viable under earthquake conditions Structures are subjected to cyclic loads
SLIDE 7
Ductility
Base Shear Lateral displacement Force Lateral displacement Elastic range Inelastic range
SLIDE 8
Brittle behaviour Ductile behaviour Adequate warning (by deformations and cracks No warning (by sudden collapse) Shear failure Bending failure
SLIDE 9
Ductility
Base Shear Lateral displacement Force Lateral displacement Elastic range Inelastic range
SLIDE 10
Capacity Design Philosophy
Structural response often exceeds elastic range Damage is therefore expected Control damage by selecting proper lateral load resisting systems and proper detailing of individual members
Ductile link
SLIDE 11
Ductility
Base Shear Lateral Displacement Yield point Failure Structure A Failure Structure B Large inelastic deformation Elastic range Inelastic range
SLIDE 12
Thank you for your attention!
SLIDE 13
3.1
References and further reading
Elnashai, A.S. and Di Sarno, L. (2008). Fundamentals of Earthquake
- Engineering. Published by John Wiley & Sons.
Paulay, T. and Priestley, M.J (1992). Seismic Design of Reinforced Concrete and Masonry Buildings. Published by John Wiley & Sons. EN 1998 - Eurocode 8 (2004-2005). Design of structures for earthquake resistance - Part 1: General rules, seismic Actions and rules for buildings - Part 3: Assessment and retrofit of buildings and Part 5: Foundations, retaining structures and geotechnical aspects. Published by CEN/CENELEC, Brussels.
