Introduction to Adaptive Designs

Minh Huynh, Ph.D. Aaron Heuser, Ph.D. Chunxiao Zhou, Ph.D.

FUNDAMENTAL DESIGN PRINCIPLES, CASE STUDIES, AND HANDS-ON PRACTICE

Course Objectives

1.

Gain familiarity with the basic principles of adaptive designs

2.

See of examples of adaptive designs in practice

3.

Understand the strengths and weaknesses of adaptive methods, and when to use and when not to use them

4.

See the latest application of adaptive designs

5.

Obtain a starter toolkit to start using adaptive designs in your work

What is Adaptive Design?

1.

A research protocol in which some features are adaptive



At pre-determined points in the study, data are analyzed



Some design aspects of the protocol may change depending on the latest findings from the data



These aspects include sample size, treatment group randomization and assignment, dose, treatment arms

2.

A research protocol in which pre-planned design changes are aimed at improving power, increasing efficiency, reducing cost, reducing time, or addressing ethical issues.

What is Adaptive Design?

Possible adaptive features include:

• study eligibility criteria
• randomization procedure
• treatment regimens of the different study groups (e.g., dose level, schedule,

duration)

• total sample size of the study (including early termination)
• concomitant treatments used
• planned schedule of patient evaluations for data collection
• primary endpoint
• selection and/or order of secondary endpoints
• analytic methods to evaluate the endpoints

Key Operational Principles

1.

Data collected during study are not only for studying

• utcomes or impacts, and are not only for hypothesis testing

2.

These data are very useful for the conduct of the study itself

3.

They are typically available sooner than study outcomes

4.

Flexible designs based on population response will result in more efficient and more powerful studies than fixed designs

What is NOT Adaptive Design

1.

Ad-hoc changes in design

2.

Changes in design not based on accumulated data

3.

Changes in design based accumulated data, but not part

• f pre-determined interim analysis

4.

Stopping rules, sample size changes, or dose escalations based on other factors not related to pre-established design.

Adaptive Versus Conventional Design

Design Data Collection Data Analysis

Conventional

Initial Design Revise Protocol Data Collection Interim Analysis Data Analysis

Adaptive

Yes No

Adaptive Versus Conventional Design

Advantages of Adaptive Designs:

1.

Reduce number of subjects

2.

Reduce subject exposure time

3.

Shorten overall length of study

4.

Lower Cost

Adaptive Versus Conventional Design

Disadvantages of Adaptive Designs:

1.

Requires statistical expertise, some Bayesian concepts

2.

May require longer protocol planning time/regulatory approval

3.

Requires near real-time data entry

4.

Requires high level of coordination for multi-arm study

5.

May yield bias estimates if not done properly

Notes on Applicability

Study Type Key Objectives Key Design Consideration(s) Applicable Clinical Science Phase I Clinical Trial Optimal Dosing, Minimum Toxicity, Minimum Risks Maximum Tolerable Dose identified

Yes

Phase II Clinical Trial Establish Proof of Principle, measure treatment effect, make treatment comparison Ineffective treatments identified with the minimum sample size

Yes

Phase III Clinical Trial Large Scale study of therapeutic effects of treatment, with follow-up Identified impact using double-blind, randomized, placebo-controlled subjects

Yes

Phase IV Clinical Trial Post-introduction monitoring for adverse events Detection of rare adverse events not previously identified NO

Notes on Applicability

Study Type Key Objectives Key Design Consideration Applicable Social Science Randomized Controlled Impact Evaluation Determine whether a social intervention works; Measure Treatment effects Determine treatment effect with minimum bias Yes Quasi-experimental Impact Evaluation Determine whether a social intervention works; Measure Treatment effects Finding useful comparison groups to use in place of the controls; Determine treatment effect with minimum bias Yes Survey methodology Real-time Dynamic Survey management Design, Implement, and manage survey with minimal resources Obtain intended coverage using minimum resources Yes Network Sampling Design, Implement, and manage survey to reach rare or hard-to-reach population Obtain intended coverage using fewer resources than conventional sampling designs Yes

Some Basic Uses of Adaptive Designs

1.

Sample Size Re-estimation

a) Early Stopping b) Interim sample size adjustments

2.

Treatment group Randomization

a) Pick-the-winner b) Arm dropping or switching

3.

Treatment Intensity Escalation

a) Continual Reassessment b) Adaptive dose-finding algorithm Ensures the most number of subjects get the most effective treatment Ensures the study is completed with minimum number of subjects Ensures the maximum benefits with the minimum cost or harm

Case Study #1

Simple Adaptive Stopping Rule Suppose you conduct a study with binary outcomes You observe 13 successes among 65 subjects Based on a binomial distribution, 𝑞 =.2 , and 𝑇𝐹 = 𝑞(1 − 𝑞) 𝑜  .05 The confidence interval is thus [ 𝑞 - 1.96x 𝑇𝐹, 𝑞 + 1.96x 𝑇𝐹 ]  [.1, .3] (1)

Case Study #1

Simple Adaptive Stopping Rule Suppose your policy advisors tell you that a success rate of 35% or more is a policy relevant outcome. At any time, you can use (1) to monitor your study as shown below

.35 𝑞 𝑞𝑉 𝑞𝑀

You can thus stop the trial for futility when [ 𝑞𝑀 , 𝑞𝑉 ] is below .35

Case Study #1

Simple Adaptive Stopping Rule What is wrong with this ?  You don’t know the optimal time to stop  stopping too early may bias estimate of [ 𝑞𝑀 , 𝑞𝑉]  stopping too late is costly as n increases This simple method is easy to use, and you can thus stop the trial at any time for futility when [ 𝑞𝑀 , 𝑞𝑉 ] is below some target P

Case Study #1

Hands-on Practice Suppose you conduct a study to evaluate where a new job search strategy will help unemployed individuals. Your study have the budget to enroll 700 people. You decide to take a look after 100 people have been enrolled and received the intervention, and see that 25 of the were placed. Your policy advisors tell you that the treatment needs to be at least 35% effective to be worth pursuing. What should you do ?

Case Study #2

Optimal Adaptive Sample Size

Rapid Enrollment Design Fleming’s 2-Stage Ivanova’s 2-Stage Gehan’s 2-stage Simon’s 2-Stage

Case Study #2

Gehan’s 2-Stage Design

 One of the earliest design for phase II clinical trials with binary

response by Gehan(1961)

 At the end of first round, study may be stopped for futility  This method minimizes sample size under H0 for a given target

effectiveness and a given -level

Stage 1

Rejecting Rule Met ?

Stage 2

Rejecting Rule Met ?

Yes Yes

Reject Treatment

Case Study #2

Gehan’s 2-Stage Design

 Suppose you have a new treatment that either works, or

does not work at all

 This treatment is administered to everyone (uncontrolled)  treatment is worth pursuing only if it can hit the 20% mark

(Probability of success=.2)

 Since you do not know if this will work, you would like the

minimal sample size required to see this new treatment is worth pursuing.

Case Study #2

1.

Gehan’s 2-Stage Design Let p = .2 =target success rate Let X = 1 if treatment is successful, 0 otherwise Let Y1= y1 number of successes among first n1 subjects, Y = 𝑗=1

𝑜1 𝑌𝑗 Bin(n1,p)

Then the probability of getting 0 success after first n1 subjects is Pr 𝑍 = 0 𝑞 = (1 − 𝑞)𝑜1

Case Study #2

1.

Gehan’s 2-Stage Design Let  = small number, such as .05 Then the probability of getting 0 success after first n1 subjects, given p=.2 is Pr 𝑍 = 0 𝑞 = .2 = (1 − .2)𝑜1= 0.8𝑜1 =.05 It follows that n1  14 In general, when p = any minimally accepted target, then the number of subjects required for stage 1 is

𝑜1 = log(0.05)

log(1−𝑞)

Case Study #2

1.

Gehan’s 2-Stage Design

  This can allow the study to end early

NOTE p can be set arbitrarily high to end any study early!!

Step 1 Set target success rate p Step 2 If there is 0 response among the first 𝑜1 = log(0.05)

log(1−𝑞) then

Step 3 Else continue to end of study

Case Study #2

Hands-on Practice Suppose you conduct a study to evaluate where a new job search strategy will help unemployed individuals. Your study have the budget to enroll 700 people.

Case Study #2

Hands-on Practice Suppose you conduct a study to evaluate where a new job search strategy will help unemployed individuals. Your study have the budget to enroll 700 people. Your policy advisors tell you that the treatment needs to be at least 35% effective to be worth pursuing. Use Gehan’s 2-stage design to come up with a stopping strategy.

Case Study #3

Optimal Adaptive Sample Size

Rapid Enrollment Design Fleming’s 2-Stage Ivanova’s 2-Stage Gehan’s 2-stage Simon’s 2-Stage

Case Study #3

Simon’s 2-Stage Design

 Originally designed for phase II clinical trials with binary

response

 Suitable for a one-arm (uncontrolled) study testing H0 : p  p0  At the end of first round, study may be stopped for futility  This method minimizes sample size under H0 for a given -level

Stage 1

Rejecting Rule Met ?

Stage 2

Rejecting Rule Met ?

Yes Yes

Reject Treatment

Case Study #3

Simon’s 2-Stage Design

 Suppose you have a new treatment that either works, or

does not work at all

 This treatment is administered to everyone (uncontrolled)  You currently have a treatment that works 20% of the time

(p0=.2)

 Your policy advisors tell you that is your new treatment is

worth pursuing only if it can hit the 40% mark (p1=.4)

 Since you do not know if this will work, you would like the

minimal sample size required to test this new treatment

Case Study #3

Simon’s 2-Stage Design

 Simon’s method allows you to enroll some subjects,

administer treatment, stop and take a look, and decide whether to proceed.

 Can we do better than the traditional design?

Case Study #3

1.

Simon’s 2-Stage Design Let n1 = number of subjects in 1st stage and n2 = number of subjects in 2nd stage Y1= y1 number of successes among n1 Y1  Bin(n1,p) Y2= y2 number of successes among n2 Y2  Bin(n2,p) r1 = number of successes below which we terminate the study r= number of successes below which we reject the treatment

Case Study #3

1.

Simon’s 2-Stage Design Type 1 and type 2 Error Constraints The treatment is defined to be non-promising if y1  r1 or ( y1 > r1 ) ( y1 + y2  r ) ; or promising if ( y1 > r1 )  ( y1 + y2 > r ); or promising if ( y1 > r )

Case Study #3

1.

Simon’s 2-Stage Design Type 1 and type 2 Error Constraints Thus we need Prob( promising | p  p0 ) <  Prob( promising | p  p1 ) >  At the boundaries, we need Prob(( y1 > r1 )  ( y1 + y2 > r ) | p = p0 ) =  ; Prob(( y1 > r1 )  ( y1 + y2 > r ) | p = p1 ) =  (2)

Case Study #3

1.

Simon’s 2-Stage Design Assuming independence between Y1 and Y2 Prob{( y1 > r1 )  ( y1 + y2 > r ) | p } = =

𝑧1>𝑠1 𝑧2>𝑠−𝑧1

𝑄(𝑧1|𝑞) 𝑄(𝑧2|𝑞)

𝑧1>𝑠1 𝑧2>𝑠−𝑧1

𝑜1 𝑧1 𝑞𝑧1 (1 − 𝑞)𝑜1−𝑧1 𝑜2 𝑧2 𝑞𝑧2 (1 − 𝑞)𝑜2−𝑧2

Case Study #3

1.

Simon’s 2-Stage Design Simon’s method chooses the set of (n1 , n2 , r1 , r ) to minimize sample size, subject to Type 1 and Type 2 errors probability constraints in (2)

Case Study #3

1.

Simon’s 2-Stage Design (n1 , n2 , r1 , r ) can be chosen to meet one of two optimality criteria (1) Minimizes Expected Sample size under the null, E(N|H0 ) where E(N|H0 ) = n1 + n2 Prob(Proceed to Stage 2|H0 ) = n1 + n2 Prob(r1 +1  y1  r | p = p0 ) Optimal OR (2) Minimizes maximum size in the trial, n= n1 + n2 Minimax

Case Study #3

1.

Simon’s 2-Stage Design Simon’s method chooses the set of (n1 , n2 , r1 , r ) to minimize sample size, subject to Type 1 and Type 2 errors probability constraints in (2)

Step 1 Specify p0 , p1,  and  Step 2 For each value of total sample size n, and each value of n1 in the range (1, n – 1), determine the integer values of r1 and r which satisfy the error constraints and minimize EN when p = p0

• a. For each value of r1 in (0,n1), find the maximum value of r that satisfy the Type 2 constraint
• b. Determine whether the identified set of parameters (n,n1,r1,r) satisfy the Type 1 constraint
• c. If yes, compute EN and compare to previously identified feasible design and continue to search over r1
• d. Keeping n fixed, search over the range of n1 to find the optimal two-stage design.

Alpha Power Current Treatment success rate New Treatment success rate Click

http://cancer.unc.edu/biostatistics/program/ivanova/SimonsTwoStageDesign.aspx

Total Sample Size = 54 Total Stage 1 Sample Size = 19 End Study and Reject Treatment after Stage 1 if success  4/19 Reject Treatment after Stage 2 if success  15/54 Expected Sample Size Under H0 is 30.4 Probability of Stopping Early Under H0 is .6733

Case Study #3

Simon’s 2-Stage Design From these calculations, the resulting adaptive design is

Step 1 Observe 19 subjects Step 2 If fewer than 4 subjects receive successful treatments  Step 3 If 4 or more subjects receive successful treatments, go to Stage 2 Step 4 Observe 35 more subjects and count total successes Step 5 If fewer than 15 subjects total receive successful treatments, fail to reject Ho,  reject new treatment Step 6 If 15 or more subjects total receive successful treatments, reject Ho,  suggest new treatment is better than the existing treatment

Case Study #3

Simon’s 2-Stage Design If these steps and stopping rules are followed,

Expected Sample Size is only 30.4 subjects Probability of Stopping early is .6733  This is very good efficiency gain !

NOTE: This design stops early for futility, and not for efficacy

Case Study #3

Hands-on Practice

Suppose you conduct a Phase II clinical trial to test whether a new drug is effective in treating the ZIKA virus. You would like to have =0.05 and your trial to have power = 90%. Your Section Chief informs you that the previous candidate drug had a 20% response rate, and for the new drug to have move to Phase III you need a response rate of at least 40%. You have a research budget that can enroll no more than 100 subjects. (a) Design a Simon 2-stage trial using both optimal and minimax criteria (b) How far below the 100 subjects mark will you expect to be ? (c) What is the probability that this will happen (i.e., that you will have an early stop?)

Questions ?

Case Study #4

Bayesian Phase II Design with Posterior Probability

 Use successive predictive probabilities of success as stopping

rules

 Data accrual are monitored continuously to make adaptive

decisions

 Can be stopped for both efficacy or futility  Suited for situations where a new treatment is being considered

for further study, but you do not have a large number of subjects (or you do not want to)

 Simple to implement for studies with binary outcomes

Case Study #4

Bayesian Phase II Design with Posterior Probability Let p1= response rate for new, experimental treatment, p1 Beta(1,1) Let p0= response rate for currently existing treatment, p0 Beta(0,0) At any stage of the study, let Y = number of successes among n subjects treated, Y Bin(n,p1) Because of conjugate property between the binomial distribution and the beta distribution, the posterior distribution of p1 given Y = y is a beta distribution p1 |Y = y  Beta(1 +y, 1 +N-y)

Case Study #4

Bayesian Phase II Design with Posterior Probability Let f(p; 1,) = p.d.f. of p Beta(1,) and let F(p; 1,) =

𝑞 𝑔 𝑦; 1, its

correspondent c.d.f; then we can compute Pr 𝑞1 > 𝑞0 + 𝜀 𝑧 =

1−𝜀

1 − 𝐺 𝑞 + 𝜀; 𝛽1 + 𝑧, 𝛾1 + 𝑜 − 𝑧 𝑔 𝑞; 𝛽0,, 𝛾0 𝑒𝑞; where 0<  <1 is the minimally acceptable change in the new treatment’s response rate compared to the standard treatment.

Case Study #4

Bayesian Phase II Design with Posterior Probability Now we are almost ready to specify the design: Let U= upper probability cut-off, U[.95,.99] L= lower probability cut-off, U[.01,.05] Un=smallest integer of y such that Pr(p1>p0|y) U Ln=largest integer of y such that Pr(p1>p0+|y) L

Case Study #4

Bayesian Phase II Design with Posterior Probability Step 0 Let N = the max number of subjects you can enroll Step 1 Enroll n subjects, and observe the first y the number of successes Step 2 If y  Un= end Phase II for efficacy, treatment is promising If y  Ln= terminate the study for futility, treatment is not promising Step 3 If Ln < y < Un= and n < N , continue enroll the next subject Step 4 If n reaches N before y crosses any stopping boundary, then the study is inconclusive

Case Study #4a

Bayesian Phase II Design with Posterior Probability Example 3a Suppose the most we can enroll in a study is N=40 And suppose the prior beta distribution for the current treatment is p0 Beta(0,0)=Beta(15,35) and prior beta distribution for the new treatment is p1 Beta(1,1)=Beta(.6,1.4)

Case Study #4a

Bayesian Phase II Design with Posterior Probability Using L= .05 and  =0 for futility stopping, we enroll our subjects and monitor each of them. Our stopping rules are given by Each pair (Ln , n) is a stopping rule = stop the study if the number of successes after enrolling n subjects is less than or equal to Ln For example, (2,18) means that after enrolling 18 subjects, if there are 2

• r fewer successes, then the study should be terminated for futility

Ln 1 2 3 4 5 6 n 6 13 18 24 29 35 40

Questions ?

Case Study #5

Bayesian Predictive Monitoring with Posterior Probability One particular feature of the Bayesian paradigm is that one can obtain predictions based on the posterior predictive distribution. Frequentist predictive methods use conditional probability based on a particular value of a model parameter. Bayesian predictive methods average these probabilities over the parameter space given the

• bserved data.

Lee and Liu (2008) used this concept to derive a method, Predictive Probability Monitoring

Case Study #5

Bayesian Predictive Monitoring with Posterior Probability Let n = current number of subjects, 1 < n < Nmax, where Nmax is the maximum sample size planned Let X = the number of successes among n treated patients, X ~ Bin(n,p1). Assume that the prior distribution of the success rate  (p1) follows ~ Beta(a0,b0). The posterior distribution for p1 thus follows p1|X=x ~ Beta(a0+ x, b0+ n - x)

Case Study #5

Bayesian Predictive Monitoring with Posterior Probability Let Y denote the number of successful subjects out of m=N-n future recruits , Y< m The probability of Y = y given the current data x follows a beta-binomial distribution, Y|x ~ Beta-Bin(N – n, a0 + x, b0 + n – x), with probability mass function Pr 𝑧 𝑦 =

1 𝑂 − 𝑜

𝑧 𝑞𝑧(1 − 𝑞)𝑂−𝑜−𝑧 𝑞𝑏0+𝑦−1(1 − 𝑞)𝑐0+𝑜−𝑦−1 𝐶(𝑏0 + 𝑦; 𝑐0 + 𝑜 − 𝑦) 𝑒𝑞; = 𝑂 − 𝑜 𝑧

𝐶(𝑏0+𝑦+𝑧,𝑐0+𝑜−𝑦−𝑧) 𝐶(𝑏0+𝑦,𝑐0+𝑜−𝑦)

Case Study #5

Bayesian Predictive Monitoring with Posterior Probability Thus the posterior distribution of the success rate, given y and x, is p1|Y=y,X=x~ Beta(a0+y+x,b0+N-y-x) The criterion for declaring the treatment is promising is Prob(p1>p0|y,x)  T with p0 the previous success rate and T is some threshold.

Case Study #5

Bayesian Predictive Monitoring with Posterior Probability Lee and Liu next defined the Predictive Probability (PP) as 𝑄𝑄 ≡

𝑗=1 𝑛

𝑄 𝑍 = 𝑗 𝑌 = 𝑦 × 𝑱[𝑄 𝑞1 > 𝑞0 𝑍 = 𝑗, 𝑌 = 𝑦 > 𝜄𝑈] where I I [] is an indicator function, and Prob(Y=i|X=x) is the probability of observing i responses in m patients given current data X=x

Case Study #5

Bayesian Predictive Monitoring with Posterior Probability

 PP is the predictive probability of obtaining a positive result by the end

• f the trial based on the current cumulative information

 A high PP means that the treatment is likely to be efficacious by the

end of the study, given the.

 A low PP suggests that the treatment may not have sufficient activity.  Therefore, PP can be used to determine whether the trial should be

stopped early due to efficacy/futility based on the current data . We are almost there…

Case Study #5

Bayesian Predictive Monitoring with Posterior Probability

 Next, choose two cut-offs L (small number) , U (large number)  (0,1) 1.

If PP > U , stop the study  the new treatment is promising.

1.

If PP < L , stop the study  the new treatment is not promising

2.

Otherwise, continue the study until Nmax is reached. To illustrate, we use a hands-on example, and this software from the MD Anderson Cancer Center Software Repository

Case Study #5

Hands-On, Part A Suppose you have a Phase II trial, where you have observed the first 10 subjects. Your trial has a prior distribution of success rates of beta(.6,.4), and you have a budget for a maximum of 50 subjects. Suppose you set the threshold T at 0.9, and would like the Type I error to be 0.05, and Power to be 0.9. You also would not stop unless U =1.0. Use the Lee and Liu (2008) Predictive Probability Method to design your trial.

the number of patients in the first cohort being evaluated for response when PP interim decision starts to be implemented

How many incoming subjects any given time

Maximum sample size

Choose one of these

Set your thresholds here; Note the flexible starting point, ending point, and step size

Success rate of current treatment

Target success rate for your trial

Set desired alpha and power levels

Information from previous trial(s) What if you do not have any information?

Case Study #5

What if your trial is the first, and do not have any prior information?

 Recall our assumption that the prior distribution of the response rate,

(p), follows a beta distribution, namely beta(a0, b0)

 The quantity a0/(a0+b0) reflects the prior mean  while size of a0+b0 indicates how informative the prior is, with a0=the

number of successes and b0= the number of failures

 Thus, a0+b0 can be considered as a measure of the amount of

information contained in the prior.

 You can always run the trial and record the first a0 , b0

Click to run Click to see output

suitable ranges of L and T under an Nmax that satisfies the constrained Type I and Type II error rates

Subject number

First (Negative) Rejection Region: This shows the maximum number of patients with positive response to terminate a trial. If the number of responses is less than or equal to this boundary, stop the trial and reject the alternative hypothesis

Second (Positive) Rejection Region: This shows minimum number of patients with positive response to terminal a trial and claim to reject the null hypothesis. If the number of responses is greater than this boundary, stop the trial and reject the null hypothesis. If this number is greater than what you have in the sample, keep going. You cannot reject the null

Probability of making the negative decision under the null hypothesis

Probability of making the positive decision under the null hypothesis

Probability of continuing the trial under the null hypothesis Same information is also computed under the alternative

PET=probability of early termination for futility (PP<L), probability of

early termination for efficacy (PP>U), and total probability of early termination

Expected number of subjects under the null

Highest Type I and Type II error rates within suitable range of L and T

Case Study #6

What are some major weakness with the methods we discussed?

Erratic Accrual Rate Suppose a few subjects have been treated at a leisurely pace and then the long line of patients appears. The

• utcomes of a small number of patients would affect the computed

probabilities for everyone, and additional information do not get to play a role. Accrual Rate Mismatch If subjects are accruing faster than information is accruing, adaptive learning is compromised, or if subjects are treated at a faster rate than outcomes can be recorded, there can be no adaptation to the data,

Case Study #6

What are some major weakness with the nethods we discussed?

Single-Arm Biases Many promising drugs eventually fail in Phase III trials, even though they showed efficacy in Phase II trials. The reason  Single-arm trials can introduce bias, because there can be significant but unobserved differences in patient populations, in study criteria, and in medical facilities between the current and previous studies. For a better assessment, Predictive Monitoring in Randomized Phase II trials should be used

Case Study #6

Predictive Monitoring in Randomized Phase II trials

Main idea: the posterior predictive probability can be use to monitor a study by predicting the outcome of the study at t = after all the subjects are enrolled. If there is a high predictive probability that a definitive conclusion would be reached by the end of the study (e.g., superiority or futility), then the study could be stopped earlier.

Case Study #6

Predictive Monitoring in Randomized Phase II trials

Suppose you have a two-arm trial, and let pk = the success rate for treatment k, pk ~ Beta(ak,ßk), k=1,2 Nk = the maximum sample size planned for arm k, and Yk = the number of successes among k treated subjects, 1 < nk < Nk, then Yk ~ Bin(nk,Pk) Thus, as before, the posterior distribution of pk is

pk|Y=yk ~ Beta(ak+ yk, bk+ nk - yk) k=1,2

Case Study #6

Predictive Monitoring in Randomized Phase II trials Let Xk = the number of future successes among the remaining Nk  n subjects in arm k. Then, as before, the posterior predictive distribution of Xk given Yk = yk is Beta-Binomial: Pr 𝑦𝑙 𝑧𝑙 = 𝑂𝑙 − 𝑦𝑙 𝑦𝑙

𝐶(𝛽1+𝑦𝑙+𝑧𝑙, 𝛾1+𝑂𝑙−𝑦𝑙−𝑧𝑙) 𝐶(𝛽1+𝑧𝑙, 𝛾1+𝑜𝑙−𝑧𝑙)

Case Study #6

Predictive Monitoring in Randomized Phase II trials Next, let H0 : p1= p2 H1: p1  p2

For each pair of future data (X1=x1, X2=x2), we can draw a conclusion on whether this hypothesis test would give a significant difference by the time the study concludes.

Case Study #6

Predictive Monitoring in Randomized Phase II trials

The predictive probability of rejecting H0 is found by summing over all possible future outcomes of this pair (x1,x2), and is given by (6) where I[ I[] ] is an indicator function indicating whether a binomial test of two proportions for H0 : p1=p2 is significant.

Pr 𝑡𝑗𝑕𝑜𝑗𝑔𝑗𝑑𝑏𝑜𝑢 𝑒𝑗𝑔𝑔𝑓𝑠𝑓𝑜𝑑𝑓 𝑏𝑢 𝑓𝑜𝑒 𝑝𝑔 𝑡𝑢𝑣𝑒𝑧 𝑒𝑏𝑢𝑏 =

𝑦1=0 𝑂1−𝑜1 𝑦2=0 𝑂2−𝑜2

𝑄 𝑦1 𝑧1 𝑄 𝑦2 𝑧2 𝑱[𝑆𝑓𝑘𝑓𝑑𝑢𝑗𝑜𝑕 𝐼0]

Case Study #6

Predictive Monitoring in Randomized Phase II trials

We would reject H0 if |𝑎| ≥ 𝑨

𝛽 2 where

and and 𝑨

𝛽 2 is the 100(1-/2)th percentile of the standard normal distribution.

This is a hybrid Frequentist/Bayesian approach. See Yin (2012) 𝑎 = 𝑞1 − 𝑞2 𝑞(1 − 𝑞)( 1 𝑂1 + 1 𝑂2)

𝑞𝑙 = 𝑧𝑙 + 𝑦𝑙 𝑂𝑙

Case Study #6

Predictive Monitoring in Randomized Phase II trials

We can also employ a fully Bayesian interim monitoring procedure using predictive probability. Given current data (y1,y2) and future data (x1,x2), we compute the posterior probability

Pr 𝑞1 > 𝑞2 𝑦1, 𝑦2, 𝑧1, 𝑧2 =

1 𝑞2 1

𝑔 𝑞2 𝑦2, 𝑧2 𝑔 𝑞1 𝑦1, 𝑧1 𝑒𝑞1𝑒𝑞2 ≥ 𝜄𝑈

Where 𝑔 𝑞𝑙 𝑦𝑙, 𝑧𝑙 is the probability density function of 𝑞𝑙 with the distribution 𝑞𝑙~Beta 𝛽𝑙 + 𝑧𝑙 + 𝑦𝑙, 𝛾𝑙 + 𝑂𝑙 − 𝑧𝑙 − 𝑦𝑙 , 𝑙 = 1,2

Case Study #6

Predictive Monitoring in Randomized Phase II trials Treatment 1 is superior if Pr 𝑞1 > 𝑞2 𝑦1, 𝑦2, 𝑧1, 𝑧2 ≥ 𝜄𝑈 where is 𝜄𝑙 the

usual threshold. But since future data (x1,x2) have not yet been observed, we use

𝑦1=0 𝑂1−𝑜1 𝑦2=0 𝑂2−𝑜2

𝑄 𝑦1 𝑧1 𝑄 𝑦2 𝑧2 𝑱[Pr 𝑞1 > 𝑞2 𝑦1, 𝑦2, 𝑧1, 𝑧2 ≥ 𝜄𝑈]

Case Study #6

Predictive Monitoring in Randomized Phase II trials Yin (2012) Illustration: For the frequentist hypothesis testing, use a two- sided binomial test at  = 0.05. For the Bayesian method, use prior distributions for p1 and p2 as Beta(0.2,0.8) . = 0.95 in (5.5), and 𝜄𝑈 = .095

Arm 1 Arm 2 Pr(favoring Arm 1) Pr(favoring Arm 2) N y1/n1 y2/n2 Frequentist Bayesian Frequentist Bayesian 40 5/10 2/10 0.5062 0.6702 <0.0001 <0.0001 60 5/10 2/10 0.6266 0.7225 0.0005 0.0013 80 5/10 2/10 0.6915 0.7567 0.002 0.0037 100 5/10 2/10 0.7291 0.7815 0.004 0.0065 100 10/20 4/20 0.8415 0.8999 <0.0001 <0.0001 100 15/30 6/30 0.9306 0.9735 <0.0001 <0.0001 100 20/40 8/40 0.991 0.9993 <0.0001 <0.0001

Case Study #6

Arm 1 Arm 2 Pr(favoring Arm 1) Pr(favoring Arm 2) N y1/n1 y2/n2 Frequentist Bayesian Frequentist Bayesian 40 5/10 2/10 0.5062 0.6702 <0.0001 <0.0001 60 5/10 2/10 0.6266 0.7225 0.0005 0.0013 80 5/10 2/10 0.6915 0.7567 0.002 0.0037 100 5/10 2/10 0.7291 0.7815 0.004 0.0065 100 10/20 4/20 0.8415 0.8999 <0.0001 <0.0001 100 15/30 6/30 0.9306 0.9735 <0.0001 <0.0001 100 20/40 8/40 0.991 0.9993 <0.0001 <0.0001

N=40: Enroll 20 subjects in each arm to compare the two treatments. Suppose after 10 patients were treated in each arm, 5 patients responded in Arm 1 and 2 patients responded in Arm 2.

Predictive Probability of picking Arm 1 is 51% for frequentist, 67% for Bayesian Predictive Probability of picking Arm 2 is close to zero

Case Study #6

Arm 1 Arm 2 Pr(favoring Arm 1) Pr(favoring Arm 2) N y1/n1 y2/n2 Frequentist Bayesian Frequentist Bayesian 40 5/10 2/10 0.5062 0.6702 <0.0001 <0.0001 60 5/10 2/10 0.6266 0.7225 0.0005 0.0013 80 5/10 2/10 0.6915 0.7567 0.002 0.0037 100 5/10 2/10 0.7291 0.7815 0.004 0.0065 100 10/20 4/20 0.8415 0.8999 <0.0001 <0.0001 100 15/30 6/30 0.9306 0.9735 <0.0001 <0.0001 100 20/40 8/40 0.991 0.9993 <0.0001 <0.0001

N=60-100: As Nmax increases, the predictive probability of choosing Arm 1 increases, but reaches a plateau. These calculations show that there is value to adding additional data, but the conclusion is unchanged beyond certain level of success.

Case Study #6

Adaptive Randomization

 For a more objective comparison of different treatments, subjects

should be randomized the two (or more) arms.

 Randomization can use a fixed probability, or an outcome-based

adaptive probability—this is called adaptive randomization (AR)

 AR is more beneficial, as each new subject has a higher probability

• f receiving the favored treatment.

 Yin, Chen and Lee (2012) proposed a method to combine PP and

AR for trial monitoring.

Case Study #6

Adaptive Randomization Yin, Chen and Lee (2012) proposed the use of a tuning parameter  Each new subject is randomized into Arm 1 with probability 𝜌(, )=  +(1−) where  = Pr(p1 > p2|y1,y2), and  is a tuning parameter This method is implement in the AR software by the M.D. Anderson Canter Center, Department of Biostatistics.

What we covered thus far

Adaptive Randomization Predictive Monitoring in Randomized Phase II trials Bayesian Predictive Monitoring with Posterior Probability Simon’s 2-Stage Design Gehan’s 2-Stage Design Basic Concepts in Adaptive Design Simple Adaptive Stopping Rule Key Design Principles

Next

Dose-escalation Designs Adaptive Sampling Methods Hands-on Practice Starter Kit General Concerns with Adaptive Design

Adaptive Survey Design

Key Concepts in Adaptive Survey Design

• In the adaptive survey methodology literature, adaptive surveys

mean two different things

• One is the use of innovative adaptive sampling methods to

improve survey quality metrics, such as response rate, sample balance, non-response error, stability/quality of estimates, sampling errors, etc…

• This is referred to as adaptive survey designs

Adaptive Survey Design

Key Concepts for Dynamic Adaptive Survey Management

• The other meaning is the use of accumulated data to improve the

conduct of the survey. At pre-determined points in the survey implementation, these data are examined to guide the rest of the implementation

• Based on information in collected data, adjustments are made to

improve cost, efficiency, and precision This is sometimes referred to as dynamic survey management.

• We will be introducing you to both concepts today, but neither in

depth.

Dynamic Survey Management

Key Concepts Data collected and examined are of four groups

• Response data: estimates of key variables
• Frame Data: type of structure, block group demographic

statistics, alternative modes, previous response data

• Paradata: data accrual rate, contact history, effort and response

propensity, interviewer observations, time and travel, survey progress rate, Web survey metrics

• Quality metrics: R-indicators, sample balance, response rate,

stability/quality of estimates

Dynamic Survey Management

Key Concepts After the data are examined, the following survey design features can be changed

• Case priorities
• Mode priorities
• Oversampling
• Timing of Data collection stop
• Incentives
• Speed of data collection
• Processing flow and priorities
• Timing of Benchmarking

Dynamic Survey Management

R-indicators and their use An important tool to use for dynamic survey management is the R-indicator First introduced by Schouten and Cobben (2007), it is a measure used to show the extent to which survey response deviates from the representative measure. Schouten and Cobben introduced three measures, and there have been my variants introduced since. R-indicators are used to track how a survey is preforming over time, and corrections or adjustments can be made

Dynamic Survey Management

R-indicators and their use The basic R-indicator has the form 𝑆 𝑦 = 1 − 2𝑦 where x is the individual response propensity given the auxiliary variable X An important variant is the Partial R-indicator First introduced by Schouten et al (2010), it allows the representativeness of subgroups to be measured over time.

Dynamic Survey Management

Example from Miller et al (2013) National Survey of College Graduates

intervention

Adaptive Web Sampling

Sampling Hard to reach population Example: Homeless, Sex Worker, HIV/AIDS, Drug user… Hidden, Invisible, Vulnerable Social Network Traditional Sampling methods may not be efficient Adaptive Web Sampling (Steven Thompson)

Adaptive Web Sampling

Colorado Springs HIV/AIDS Study (Potterat 1993)

injection drug user yi=1 non-Injection drug user yi=0 drug using relationship Wij= 1 if there is a link between i and j Wij= 0 otherwise

Adaptive Web Sampling

Steven Thompson 2006 Main idea: follow link + random jump



Design based: probability only enters through design, no probability model for the population



Selecting of units depends on observed values of interest Variable of interest: node variable + link variable



Flexible : balancing depth and width two previous methods: Random walk: depth Snowball: width

Adaptive Web Sampling

Sampling in networks

 Population: units 1,2, …, N  Variable of interest:

node variables: y1, y2, …, yN link variable (weights): wij, i,j = 1,2, …, N

 Sample : (S, ys)

S = (units, pairs of units)

Example: network Population

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 21 20 22 23 24 25 26 27 28 29 30 Population: units 1,2, …, 30

yi=1, i = 1, 2, … , 30 yi=0, i = 1, 2, … , 30 relationship Wij= 1 if there is a link between i and j Wij= 0 otherwise

Example: random walk

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 21 20 22 23 24 25 26 27 28 29 30

Example: random walk

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 21 20 22 23 24 25 26 27 28 29 30

Initial sample sample size =1 Select a node randomly S0 = {7}

Example: random walk

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 21 20 22 23 24 25 26 27 28 29 30

First wave sample sample size =2 Select a node randomly among all nodes connect to the node selected in the previous step S1 = {7, 10}

Example: random walk

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 21 20 22 23 24 25 26 27 28 29 30

Second wave sample sample size =3 Select a node randomly among all nodes connect to the node selected in the previous step S2 = {7, 10, 15}

Example: random walk

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 21 20 22 23 24 25 26 27 28 29 30

Third wave sample sample size =4 Select a node randomly among all nodes connect to the node selected in the previous step S3 = {7, 10, 1, 18}

Example: random walk

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 21 20 22 23 24 25 26 27 28 29 30

Fourth wave sample sample size =5 Select a node randomly among all nodes connect to the node selected in the previous step S4 = {7, 10, 1, 18, 19}

Example: random walk

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 21 20 22 23 24 25 26 27 28 29 30

Fifth wave sample sample size =6 Select a node randomly among all nodes connect to the node selected in the previous step S5 = {7, 10, 1, 18, 19, 17}

Example: snowball

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 21 20 22 23 24 25 26 27 28 29 30

Example: snowball

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 21 20 22 23 24 25 26 27 28 29 30

Initial sample sample size =5 S0 = {7, 11, 18, 20, 24}

Example: snowball

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 21 20 22 23 24 25 26 27 28 29 30

First wave sample sample size =20 S1 = {7, 11, 18, 20, 24, 4, 6, 8, 10, 12, 13, 14 15, 16, 17, 19, 22, 23, 26, 27}

Example: snowball

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 21 20 22 23 24 25 26 27 28 29 30

Second wave sample sample size =25 S2 = {7, 11, 18, 20, 24, 4, 6, 8, 10, 12, 13, 14 15, 16, 17, 19, 22, 23, 26, 27, 2, 3, 9, 21, 30}

Example: adaptive web sampling

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 21 20 22 23 24 25 26 27 28 29 30

The next unit or set of units is selected by follow a link or a random jump with some probability

Example: adaptive web sampling

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 21 20 22 23 24 25 26 27 28 29 30

Example: adaptive web sampling

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 21 20 22 23 24 25 26 27 28 29 30

random jump

Example: adaptive web sampling

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 21 20 22 23 24 25 26 27 28 29 30

follow a link

Example: adaptive web sampling

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 21 20 22 23 24 25 26 27 28 29 30

follow a link

Example: adaptive web sampling

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 21 20 22 23 24 25 26 27 28 29 30

random jump

Example: adaptive web sampling

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 21 20 22 23 24 25 26 27 28 29 30

follow a link

Example: adaptive web sampling

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 21 20 22 23 24 25 26 27 28 29 30

follow a link

Adaptive Web Sampling

Design-based estimation



Main idea Start with some preliminary estimator improve the estimator by Rao-Blackwellization



Sufficient statistic A statistics T(X) is sufficient for parameter Θ iff P(X|T, Θ) = P(X|T) A statistic T(X) is minimal sufficient iff i) T(X) is sufficient ii) for any

• ther sufficient statistic S(X), there exists a function f such that T(X) = f(S(X))

In network sampling, minimal sufficient statistics: dr ={ (i, yi, wi+, wij); i,j are sampled units}, i.e., distinct units and associated values of interest, wi+ is out-degree

Adaptive Web Sampling

Rao-Blackwellization



Rao-Blackwell Theorem conditional expectation of original estimator given sufficient statistic is always as good as or better û = E(û0 |dr)=Σpaths û0(S)P(S|dr) , E((û – μ)2)≤ E((û0 – μ)2) Note sample S includes order information



Complete ensures that the distributions corresponding to different values of the parameters are distinct If the conditioning statistic is both complete and sufficient, and the original estimator is unbiased, then the Rao–Blackwell estimator is the unique best unbiased estimator In network sampling, the minimal sufficient statistic dr is not complete No unique best estimator

Adaptive Web Sampling

Four Rao-Blackwellization Estimators (no unique best estimator) To estimate the proposition of injection drug users



Estimator based on initial sample mean û01 = Σi∈s0 yi/n0 or û01 = 1/NΣi∈s0 yi/πi



Improved estimator by Rao-Blackwellization û1 = E(û01 |dr)=Σpaths û01(S)P(S|dr) , paths are all permutations of sample unit S Similarly, the other three estimators and improved Rao-Blackwellization estimators are based on conditional probabilities, composite conditional generalized ratio, and composite conditional mean of ratios.

Adaptive Web Sampling

Rao-Blackwellization



Computational issue Going through all possible sample paths (all permutations n!) is prohibitively expensive!



Solution MCMC Target: generate a Markov chain of permutations X0, X1, X2… having Stationary distribution p(x|dr) Metropolis–Hastings algorithm: 1) generate a tentative permutation tk 2) xk=tk with probability α, else xk=xk-1 , where α=min {p(tk)/p(xk-1)*pt(xk-1|dr)/pt (tk|dr),1}

Adaptive Web Sampling

Thompson 2006

Adaptive Web Sampling

Thompson 2006

Left column: four original estimators; Right column: improved estimators By Rao-Blackwellization

Questions ?

Adaptive Design for Clinical Science

Maximum Tolerated Dose

• A promising compound will launch a phase I clinical trial.
• Aims:
• Determine the maximum tolerated (MTD) dose for phase II.
• Assess safety and tolerability.
• Investigate pharmacokinetics and pharmacodynamics.

Adaptive Design for Clinical Science

Maximum Tolerated Dose

• Assumption: toxicity and efficacy increase with the dose.
• MTD: most toxic dose tolerated by patients.
• Maximizes effect of drug while keeping patients safe.
• MTD determines the dose used in phases II and III.
• Too low an MTD may cause an effective drug to be

ignored.

• Too high an MTD can seriously injure patients.

Adaptive Design for Clinical Science

Dose Finding

• Search methods to determine MTD:
• Algorithm-Based – do not assume dose-toxicity curve.
• 3 + 3 design
• Biased Coin dose-finding design
• Model-Based – assume a parametric dose-toxicity curve.
• Continual Reassessment Method (CRM)

Adaptive Design for Clinical Science

Dose Finding – 3 + 3 Design

• Dose escalation should proceed with caution.
• Too much caution can result in too many patients receiving

an ineffective dose.

• MTD is the highest dose with toxicity probability < 0.33.
• Patients treated with cohort size of 3 after entering the trial.
• Toxicity outcomes observed before further enrollment.

Adaptive Design for Clinical Science

Dose Finding – 3 + 3 Design

1.

Current dose level = j (administered to 3 patients).

2.

N(j) = number experiencing dosage limiting toxicity (DLT).

a.

If N(j) = 0, then escalate dose to j+1 and go to step 1.

b.

Else if N(j) = 1, treat 3 more patients at dose level j.

i.

If N(j) = 1, escalate dose to j+1.

ii.

Else if N(j) = 2, trial is ended and MTD = j – 1.

iii.

Else, treat 3 more patients at dose j – 1.

Adaptive Design for Clinical Science

Dose Finding – 3 + 3 Design

DLT = 1/3 DLT > 2/6 DLT = 1/6 DLT = 2/6 DLT = 0/3 DLT > 1/3 3 patients – dose level j 3 patients Escalate to j+1 MTD = j-1 De-escalate to j-1

Questions ?

Adaptive Design for Clinical Science

Dose Finding – Continual Reassessment Model

• Model-based approach.
• Links the true dose toxicity to pre-specified probabilities.
• Information from accumulated toxicity data updates model.
• New cohorts are sequentially assigned to appropriate dose.
• MTD identified when total sample size is exhausted.

Adaptive Design for Clinical Science

Dose Finding – Continual Reassessment Model

• CRM Skeleton: 𝑞1 < ⋯ < 𝑞𝐾.
• Pre-specified toxicity probabilities for J doses.
• Often an educated guess.
• Can add significant subjectivity.
• Target toxicity probability - 𝜚𝑈.
• The pre-specified acceptable level of risk.
• Probability that any given individual will experience a DLT.

Adaptive Design for Clinical Science

Dose Finding – Continual Reassessment Model

• Model:
• 𝜌𝑘 𝛽 = 𝑄 𝑢𝑝𝑦𝑗𝑑𝑗𝑢𝑧 𝑏𝑢 𝑒𝑝𝑡𝑓 𝑚𝑓𝑤𝑓𝑚 𝑘 = 𝑞𝑘

exp(𝛽)

• 𝛽 – unknown parameter
• For some unknown 𝛽, at each dosage 𝑘, we find the probability
• f toxicity.
• The dose level that gives toxicity nearest 𝜚𝑈 is our best choice.

Adaptive Design for Clinical Science

Dose Finding – Continual Reassessment Model

Adaptive Design for Clinical Science

Dose Finding – Continual Reassessment Model

• Alternative models:
• Logistic - 𝜌𝑘 𝛽 =

exp(𝑦+𝛽𝑒𝑘) 1+ exp(𝑦+𝛽𝑒𝑘), for some fixed x.

• Hyperbolic Tangent - 𝜌𝑘 𝛽 =

tanh 𝑒𝑘 +1 2 𝛽

.

• 𝑒𝑘: Standardized dose at dose level j.

Adaptive Design for Clinical Science

Dose Finding – Continual Reassessment Model

• Likelihood and Posterior
• At dose level j, treat 𝑜𝑘 total patients.
• Suppose that 𝑙𝑘 ≤ 𝑜𝑘 is the count experiencing DLT.
• The likelihood function is thus given by:

𝑀𝛽 ∝

𝑘=1 𝐾

𝑞𝑘

exp 𝛽 𝑙𝑘 1 − 𝑞𝑘 exp 𝛽 𝑜𝑘−𝑙𝑘

Adaptive Design for Clinical Science

Dose Finding – Continual Reassessment Model

• Likelihood and Posterior
• Let the prior distribution of 𝛽 be given by 𝑔 𝛽 .
• From Bayes’ theorem, we have the posterior mean estimate:

𝜌𝑘 = 𝑒𝛽 𝑞𝑘

exp 𝛽

𝑀𝛽𝑔 𝛽 𝑒𝛽 𝑀𝛽𝑔(𝛽)

• After each cohort is treated, use the updated toxicity data to

recalculate the posterior means at all dose levels.

Adaptive Design for Clinical Science

Dose Finding – Continual Reassessment Model

• Recommended dose for next cohort determined by

𝑘 = argmini∈{1,…,𝐾} | 𝜌𝑗 − 𝜚𝑈|

• For safety, restrict dose skipping, so that escalation (or de-

escalation) never exceeds one dose level.

• Trial continues until the total sample size is exhausted.
• MTD is dose with toxicity probability closest to 𝜚𝑈.

Adaptive Design for Clinical Science

Dose Finding – Continual Reassessment Model

• Dose-Finding Algorithm

1.

Treat the first cohort at the lowest dose level.

2.

Denote the current dose level as 𝑘0, and based on observed data, obtain the posterior mean estimates

𝜌1, … ,

𝜌𝐾.

Adaptive Design for Clinical Science

Dose Finding – Continual Reassessment Model

• Dose-Finding Algorithm

3.

Find the dose level with toxicity probability closest to 𝜚𝑈: 𝑘∗ = argminj∈{1,…,𝐾} | 𝜌𝑘 − 𝜚𝑈|

a.

If 𝑘0 > 𝑘∗, de-escalate to dose 𝑘0 − 1;

b.

If 𝑘0 < 𝑘∗, escalate to dose 𝑘0 + 1;

c.

Otherwise, the dose remains the same.

4.

Once the maximum sample size has been reached, set the MTD as the dose with toxicity probability closest to 𝜚𝑈.

Adaptive Design for Clinical Science

Dose Finding – Continual Reassessment Model

• Dose-Finding Algorithm
• Note that the algorithm assumes that the lowest dose is not toxic.
• Fix a threshold value, 𝜐 ∈ 0, 1 .
• The trial will be terminate for safety in the event that

𝑄 𝜌1 > 𝜚𝑈 𝑃𝑐𝑡𝑓𝑠𝑤𝑓𝑒 =

−∞ log log 𝜚𝑈 log 𝑞1

𝑒𝛽 𝑔(𝛽|𝑃𝑐𝑡𝑓𝑠𝑤𝑓𝑒) > 𝜐

Questions ?

Adaptive Design for Clinical Science

Dose Finding – Bayesian Model Averaging CRM

• Though the CRM is superior in performance to 3+3 design,

note the following:

• The skeleton (𝑞1, … , 𝑞𝐾) must be pre-specified, adding

subjectivity to the design.

• Model misspecification can lead to an incorrect MTD.
• Since the true toxicity level is usually unknown, justification of a

pre-specified skeleton may be impossible.

Adaptive Design for Clinical Science

Dose Finding – Bayesian Model Averaging CRM

• To improve upon model performance, consider instead a

collection of CRMs.

• Each CRM has its own skeleton, which represents a guess as

to the toxicity level of a drug.

• Carry out multiple parallel CRMs and assign a weight

proportional to the model fit.

Adaptive Design for Clinical Science

Dose Finding – Bayesian Model Averaging CRM

• For 𝐿 > 0, assume a collection of 𝐿 CRMs, {𝑁1, … , 𝑁𝐿}.
• Denote by 𝑞𝑙1, … , 𝑞𝑙𝐾 the skeleton of Mk, 𝑙 ∈ {1, … , 𝐿}.
• Under 𝑁𝑙, the toxicity probability at dose level 𝑘 is

𝜌𝑙𝑘 𝛽𝑙 = 𝑞𝑙𝑘

exp(𝛽𝑙).

• Suppose at some point in the trial, 𝑛𝑘 patients have toxicity, then

the likelihood function is 𝑀𝛽𝑙

𝑙

∝ 𝑘=1

𝐾

𝑞𝑙𝑘

exp 𝛽𝑙 𝑜𝑘 1 − 𝑞𝑙𝑘 exp 𝛽𝑙 𝑜𝑘−𝑛𝑘.

Adaptive Design for Clinical Science

Dose Finding – Bayesian Model Averaging CRM

• For 𝐿 > 0, assume a collection of 𝐿 CRMs, {𝑁1, … , 𝑁𝐿}.
• Denote by 𝑞𝑙1, … , 𝑞𝑙𝐾 the skeleton of Mk, 𝑙 ∈ {1, … , 𝐿}.
• Under 𝑁𝑙, the toxicity probability at dose level 𝑘 is

𝜌𝑙𝑘 𝛽𝑙 = 𝑞𝑙𝑘

exp(𝛽𝑙).

• Suppose at some point in the trial, 𝑛𝑘 patients have toxicity, then

the likelihood function is 𝑀𝛽𝑙

𝑙

∝ 𝑘=1

𝐾

𝑞𝑙𝑘

exp 𝛽𝑙 𝑜𝑘 1 − 𝑞𝑙𝑘 exp 𝛽𝑙 𝑜𝑘−𝑛𝑘.

Adaptive Design for Clinical Science

Dose Finding – Bayesian Model Averaging CRM

• Let P(𝑁𝑙) be the prior probability that 𝑁𝑙 is the true model.
• Assume that 𝑄 𝑁𝑙 = 1

𝐿 (Uniform distribution) if no prior information.

• If 𝑔(𝛽𝑙|𝑁𝑙) is the prior distribution of 𝛽𝑙 given 𝑁𝑙, the marginal

likelihood of 𝑁𝑙 is 𝑀𝑙 = 𝑒𝛽𝑙 𝑀𝛽𝑙

𝑙 𝑔(𝛽𝑙|𝑁𝑙)

• The posterior model probability for 𝑁𝑙 is

𝑄 𝑁𝑙 𝑃𝑐𝑡𝑓𝑠𝑤𝑓𝑒 = 𝑀𝑙𝑄 𝑁𝑙 𝑗=1

𝐿

𝑀𝑗𝑄 𝑁𝑗

Adaptive Design for Clinical Science

Dose Finding – Bayesian Model Averaging CRM

• Let

𝜌𝑙1, … , 𝜌𝑙𝐾 be the posterior means of toxicity probability at all dose levels, where 𝜌𝑙𝑘 = 𝑒𝛽𝑙 𝑀𝛽𝑙

𝑙 𝑔 𝛽𝑙 𝑁𝑙

𝑒𝛽𝑙 𝑀𝛽𝑙

𝑙 𝑔(𝛽𝑙|𝑁𝑙)

• The BMA estimate of the toxicity at dose level 𝑘 is

𝜌𝑘 =

𝑙 𝐿

𝜌𝑙𝑘𝑄(𝑁𝑙|𝑃𝑐𝑡𝑓𝑠𝑤𝑓𝑒)

Adaptive Design for Clinical Science

Dose Finding – Bayesian Model Averaging CRM

• Note that in the definition of

𝜌𝑘 assigned to each 𝜌𝑙𝑘 is the weight 𝑄 𝑁𝑙|𝑃𝑐𝑡𝑓𝑠𝑤𝑓𝑒 .

• This ensures that the BMA estimator favors the model of best

fit.

• Recommendation of dose escalation (de-escalation) is

based on 𝜌𝑘.

Adaptive Design for Clinical Science

Dose Finding – Bayesian Model Averaging CRM

• The BMA-CRM algorithm.
• Let 𝜚𝑈 be the pre-specified target toxicity probability.
• Dose escalation (de-escalation) is restricted to one dose level

at a time.

1.

The first cohort is administered the lowest treatment level.

2.

Denote the current dose level as 𝑘0, and based on observed data, obtain the BMA estimates for toxicity probability at all dose levels:

𝜌1, … , 𝜌𝐾

Adaptive Design for Clinical Science

Dose Finding – Bayesian Model Averaging CRM

• The BMA-CRM algorithm.

3.

Find the dose level with toxicity probability closest to 𝜚𝑈: 𝑘∗ = argminj∈{1,…,𝐾} | 𝜌𝑘 − 𝜚𝑈|

a.

If 𝑘0 > 𝑘∗, de-escalate to dose 𝑘0 − 1;

b.

If 𝑘0 < 𝑘∗, escalate to dose 𝑘0 + 1;

c.

Otherwise, the dose remains the same.

4.

Once the maximum sample size has been reached, set the MTD as the dose with toxicity probability closest to 𝜚𝑈.

• As with the CRM, if the lowest dose it too toxic, terminate.

Questions ?

Adaptive Design for Clinical Science

Escalation With Overdose Control (EWOC)

• Model-based Bayesian dose-finding method.
• Controls the toxicity percentage in a trial to protect from
• verdose.
• Each dose selection is done according to a predetermined

threshold of overdose proportion.

Adaptive Design for Clinical Science

Escalation With Overdose Control (EWOC)

• Assume that patient 𝑗 is administered dose level ℓ𝑗.
• Define the indicator 𝑒𝑗 = 1 if DLT experienced, and 0
• therwise.
• For a pre-specified CDF 𝐺, and parameters 𝛾0, 𝛾1 > 0, model

the relationship between ℓ𝑗 and 𝑒𝑗 by 𝑄 𝑒𝑗 = 1 ℓ𝑗 = 𝐺(𝛾0 + 𝛾1ℓ𝑗)

Adaptive Design for Clinical Science

Escalation With Overdose Control (EWOC)

• If 𝑜 subjects are enrolled, the likelihood function is given by

𝑀 𝑒1, … , 𝑒𝑜 𝛾0, 𝛾1 =

𝑗=1 𝑜

𝐺 𝛾0 + 𝛾1ℓ𝑗 𝑒𝑗 1 − 𝐺 𝛾0 + 𝛾1ℓ𝑗

1−𝑒𝑗

• If 𝜚𝑈 is the target toxicity probability, ℓ∗ the MTD, and 𝜌0 the

toxicity probability of the lowest dose ℓ0: 𝜚𝑈 = 𝑄 𝑒 = 1 dose = ℓ∗ = 𝐺 𝛾0 + 𝛾1ℓ∗ 𝜌0 = 𝑄 𝑒 = 1 𝑒𝑝𝑡𝑓 = ℓ0 = 𝐺(𝛾0 + 𝛾1ℓ0)

Questions ?

Concerns with Adaptive Designs

FDA Draft Guidelines (2010) Cautions

• Currently not all adaptive designs are well understood in

terms of their performance and characteristics

• Concerns include issues with control of the study-wide Type I

error rate, minimization of the impact of adaptation- associated statistical or operational bias on the estimates of treatment effects, potential increase of Type II error rates, and the interpretability of study results

• These issues are more problematic with some designs than
• thers

Concerns with Adaptive Designs

Control of Study-Wide Type I Errors

• Type I errors can arise out of inadequate adjustments
• At each stage of interim analysis, multiple opportunities arise

for early rejection of various hypothesis, for changing the final hypothesis to be tested, or for increasing the sample size.

• These opportunities, which came from unblended data

analyses represent multiplicities that have the potential to inflate the Type I error rate,

Concerns with Adaptive Designs

Statistical Bias in Estimates of Treatment Effect Associated with Study Design Adaptations

• At each stage of interim analysis, estimates are made of

multiple study outcomes, cief among them the treatment effects

• Since interim analyses are based, by design, on small

samples, some bias may exist

• In addition, the final results may overstate the treatment

effect because studies usually adapt steer subjects to the highest observed impact. This is another source of bias

Concerns with Adaptive Designs

Potential for Increased Type II Error Rate

• Adaptive designs by their nature have multiple occasions to

fail to detect a treatment effect when one actually exists.

• This possibility arises every time a treatment arm is dropped,
• r a dose is reduced, or an intervention is modified in some

way due to an interim data analysis

• Since interim analyses are based on limited and early data,

some treatments with a delayed impact may be erroneously dropped due to futility.

Adaptive Design Planning

The Role of Simulations

• For study designs that have multiple factors to be

simultaneously considered in the adaptive process, it is difficult to assess design performance.

• In these cases, trial simulations performed before

conducting the study can help evaluate the various trial design options

• Trial simulations can help investigators anticipate the clinical

scenarios that might occur when the study is actually conducted, and proper adaptations can be designed

• Different designs can be compared via simulations

Adaptive Design Evaluations

Things to compare across designs

• Power
• Study-wide control of Type I and Type II error rates
• Expected sample size (E(N)), maximum sample size,
• Stability of E(N) across design changes (e.g. choice of T)
• Probability of early termination (PET) for futility/ efficacy

under different values of the chosen threshold

• Number of required interim analyses

Getting Started

Things you need to do to get started

• Reading List (Provided)
• Starter Kit of Tools (Provided)
• List of Web Resources (Provided)
• Simulation Tool (not provided)
• Your proposed design needs to demonstrate substantial

improvement over competing designs, and over traditional design

• Simulation can be done simply by repeated single step

analyses

What we covered thus far

What we Covered
