Introduction

to

Optimization

Amy Langville SAMSI Undergraduate Workshop N.C. State University

SAMSI 6/1/05

GOAL: minimize f(x1, x2, x3, x4, x5) = x2

1 − .5x2x3 + x4/x5

PRIZE: $1 million

• # of independent variables =
• z = f(x1, x2, x3, x4, x5) lives in ℜ?

GOAL: minimize f(x1, x2, x3, x4, x5) = x2

1 − .5x2x3 + x4/x5

PRIZE: $1 million

• # of independent variables =
• z = f(x1, x2, x3, x4, x5) lives in ℜ?

Suppose you know little to nothing about Calculus or Optimization, could you win the prize? How?

GOAL: minimize f(x1, x2, x3, x4, x5) = x2

1 − .5x2x3 + x4/x5

PRIZE: $1 million

• # of independent variables =
• z = f(x1, x2, x3, x4, x5) lives in ℜ?

Suppose you know little to nothing about Calculus or Optimization, could you win the prize? How? Trial and Error, repeated function evaluations

Calculus III Review

• local min vs. global min vs. saddle point
• CPs and horizontal T. planes
• Local Mins and 2nd Derivative Test
• Global Mins and CPs and BPs
• Gradient = Direction of ?

Constrained vs. Unconstrained Opt.

• Unconstrained

min f(x, y) = x2 + y2

• Constrained

— min f(x, y) = x2 + y2 s.t. x ≥ 0, y ≥ 0 — min f(x, y) = x2 + y2 s.t. x > 0, y > 0 — min f(x, y) = x2 + y2 s.t. 1 ≤ x ≤ 2, 0 ≤ y ≤ 3 — min f(x, y) = x2 + y2 s.t. y = x + 2

• EVT

Gradient Descent Methods

• Hillclimbers on Cloudy Day: max f(x, y) = − min f(x, y)
• Initializations
• 1st-order and 2nd-order info. from partials: Gradient + Hessian
• Matlab function: gd(α, x0)

Iterative Methods

Issues — Convergence Test: what is it for gd.m? — Convergence Proof: is gd.m guaranteed to converge to local min? For α > 0? For α < 0? — Rate of Convergence: how many iterations? How do starting points x0 affect number of iterations? Worst starting point for α = 4? Best?

Convergence of Optimization Methods

global vs. local vs. stationary point vs. none

• Most optimization algorithms cannot guarantee convergence to

global min, much less local min.

• However, some classes of optim. problems are particularly nice.

— Convex objective—EX: z = .5(α x2 + y2), α > 0 Every local min is global min!

• Even for particularly tough optim. problems, sometimes the most

popular, successful algorithms perform well on many problems, despite lack of convergence theory.

• Must qualify statements: I found best “global min” to date.

Your Least Squares Problem

• how many variables/unknowns n =?
• z = f(x1, x2, ..., xn) lives in ℜ?
• can we graph z?

Nonsmooth, Nondifferentiable Surfaces

• Can’t compute gradient ∇f ⇒ can’t use GD Methods
• Line Search Methods
• Method of Alternating Variables (Coordinate Descent): solve se-

ries of 1-D problems — what would these steps look like on contour map?

fminsearch and Nelder-Mead

• maintain basis of n + 1 points where n = # variables
• form simplex using these points; convex hull
• idea: move in direction away from worst of these points
• EX: n = 2, so maintain basis of 3 points living in xy-plane

⇒ simplex is triangle

• create new simplex by moving away from worst point: reflect, ex-

pand, contract, shrink steps

PROPERTIES OF NELDER–MEAD

117 ¯ x xr x3 ¯ x xr xe x3

• Fig. 1. Nelder–Mead simplices after a reflection and an expansion step. The original simplex is

shown with a dashed line.

¯ x xr xc x3 ¯ x xcc x3 x1

• Fig. 2. Nelder–Mead simplices after an outside contraction, an inside contraction, and a shrink.

The original simplex is shown with a dashed line.

then x(k+1)

1

= x(k)

1 . Beyond this, whatever rule is used to define the original ordering

may be applied after a shrink. We define the change index k∗ of iteration k as the smallest index of a vertex that differs between iterations k and k + 1: k∗ = min{ i | x(k)

i

= x(k+1)

i

}. (2.8) (Tie-breaking rules are needed to define a unique value of k∗.) When Algorithm NM terminates in step 2, 1 < k∗ ≤ n; with termination in step 3, k∗ = 1; with termination in step 4, 1 ≤ k∗ ≤ n + 1; and with termination in step 5, k∗ = 1 or 2. A statement that “xj changes” means that j is the change index at the relevant iteration. The rules and definitions given so far imply that, for a nonshrink iteration,

N-M Algorithm

N-M Algorithm

• ✂

• ✂

• ☎

• ☎

• ✁

20 40 60 80 100 120 140 160 180 10

10

10 SN1939A days luminosity 20 40 60 80 100 2 3 4 5 6 7 8 0.17 0.18 0.19 0.2 0.21 0.22 0.23 SN1939A, Residual norm as a function of λ1 and λ2 λ2 λ1 Residual norm

20 40 60 80 100 120 140 160 180 10

10

10 SN1939A days luminosity 20 40 60 80 100 2 3 4 5 6 7 8 0.17 0.18 0.19 0.2 0.21 0.22 0.23 SN1939A, Residual norm as a function of λ1 and λ2 λ2 λ1 Residual norm

• ✂

• ✂

• ☎

• ☎

20 40 60 80 100 120 140 160 180 10

10

10 SN1939A days luminosity 20 40 60 80 100 2 3 4 5 6 7 8 0.17 0.18 0.19 0.2 0.21 0.22 0.23 SN1939A, Residual norm as a function of λ1 and λ2 λ2 λ1 Residual norm

20 40 60 80 100 120 140 160 180 10

10

10 SN1939A days luminosity 20 40 60 80 100 2 3 4 5 6 7 8 0.17 0.18 0.19 0.2 0.21 0.22 0.23 SN1939A, Residual norm as a function of λ1 and λ2 λ2 λ1 Residual norm

• ✂

• ✂

• ☎

• ☎

20 40 60 80 100 120 140 160 180 10

10

10 SN1939A days luminosity 20 40 60 80 100 2 3 4 5 6 7 8 0.17 0.18 0.19 0.2 0.21 0.22 0.23 SN1939A, Residual norm as a function of λ1 and λ2 λ2 λ1 Residual norm

20 40 60 80 100 120 140 160 180 10

10

10 SN1939A days luminosity 20 40 60 80 100 2 3 4 5 6 7 8 0.17 0.18 0.19 0.2 0.21 0.22 0.23 SN1939A, Residual norm as a function of λ1 and λ2 λ2 λ1 Residual norm

• ✂

• ☎

20 40 60 80 100 120 140 160 180 10

10

10 SN1939A days luminosity 20 40 60 80 100 2 3 4 5 6 7 8 0.17 0.18 0.19 0.2 0.21 0.22 0.23

Starting guess λ0

SN1939A, Residual norm as a function of λ1 and λ2 λ2

Optimizer λ*

λ1 Residual norm

• ✏

• ✼

N-M Algorithm

• not proven to converge in general
• but, widely used

— easy to implement — inexpensive: usually only 1-2 function evaluations/iteration — no derivatives needed — makes good progress at beginning of iteration history Assignments: — Display N-M steps using

• ptions.Display=’iter’;

fminsearch(fun,[x0],options);

— Write nested ‘for’ loops in Matlab to generate grid of starting points (and later random starting points) for fminsearch to find best “global min”

Genetic/Evolutionary Algorithms

• at each iteration either mate or mutate possible solution vectors
• based on fitness of possible solution vectors as measured by ob-

jective function
