ITB_Indonesia International Genetically Engineered Machine 2013 Competition Indonesia and risk of aflatoxin Bad post harvesting and storage system can increase the growth of fungi such as Aspergillus sp % Commodity Contaminated by

SLIDE 1

ITB_Indonesia International Genetically Engineered Machine 2013 Competition

SLIDE 2

Indonesia and risk of aflatoxin

SLIDE 3

Bad post harvesting and storage system can increase the growth of fungi such as Aspergillus sp

Farombi, et. al. (2006) Aflatoxin contamination of foods in developing ountries: Implications for hepatocellular carcinoma and chemopreventive strategies

8% 48% 8% 6% 5% 11% 3% 11%

% Commodity Contaminated by aflatoxin

Egypt Others India Malaysia Nepal Nigeria Turkey Indonesia

SLIDE 4

Increasing susceptibility

f liver cancer*

*International Agency for Research of Cancer (IARC).

SLIDE 5

Build a whole cell biosensor for aflatoxin B1

detection in foods

SLIDE 6

In monitoring environment status (Polutans, toxic compounds, etc) we need : Accuracy Rapidity Conventional Sensor VS Biosensor

Biosensor
Biomolecule
Whole cell

SLIDE 7

aflatoxin GFP

SLIDE 8

CYP 3A4

Illegal Restriction Site

Remove the illegal restriction site

Signal peptide

Remove the signal peptide

Bba_K1064004

B0030

Add a strong RBS

Double terminator Bba_J23119

Bba_K1064000

Add a constitutive promotor

SLIDE 9

SDS PAGE analysis of CYP expression

SLIDE 10

Reporter Gene

Double terminator Promotor sensitive To DNA damage pUV

pUV + GFP (Bba_K1064003)

pSOS

pSOS + GFP (Bba_K1064002)

Part submitted Part submitted

SLIDE 11

pUV pSOS

Control (No UV) UV irradiation (10s) Bright Field Microscope Fluorescence Microscope Bright Field Microscope Fluorescence Microscope

SLIDE 12

44 46 48 50 52 54 56 58 60 62 Bba_K1064002 (pSOS+GFP) Bba_K1064003 (pUV+GFP) Fold GFP

pUV pSOS

SLIDE 13

Goal To find time for analyzing aflatoxin presence in food with sensitivity threshold about 20 ppb*

*) Based on Indonesia Food and Drug Regulation

Aflatoxin diffusion CYP synthesis Enzymatic reaction DNA damage and SOS response Reporter

Simulate all phenomena!

SLIDE 14

using Simbiology (computational biology toolbox from Mathworks Matlab) :

20 ppb 15 ppb 10 ppb 0 ppb 5 ppb 25 ppb 30 ppb 35 ppb 40 ppb 45 ppb

GFP (mole) (s)

minimum observable [GFP] minimum time needed for analysis

SLIDE 15

Submitting part Bba_K1064002 and Bba_K1064003 Our construct works successfully as expected Characterize part Bba_K1064002 and Bba_K1064003 Improvement on part BBa_J22106 and Bba_I765001

SLIDE 16

 Making prototype of our device  Adding another more visible chromopohore as reporter  Constructing the reactive sequence  amplifying the DNA damage signal  Adding buoyancy system  Make the device safer for user

SLIDE 17

 Indonesian Potential to Synthetic Biology

synbio.itb.ac.id facebook.com/synbio.itb @synbio_itb

SLIDE 18

 Project

Survey : Indonesian people awareness about aflatoxin and

the urgency of detector of it

32%

correspondent need a biosensor

SLIDE 19

ARI Biotechnology INDRA Microbiology NUKE Microbiology RIANDY Informatic Engineering LILI Bioengineering DIMAS Chemical Engineering

Dr. Sony
Dr. Maelita
Dr. Adi

SLIDE 20

Special Thanks To :

School of Life Sciences

and Technology

School of Electrical and

Informatics engineering

Faculty of Industrial

Technology
