ISSP soft matter 2010 Interfacial microrheology of phospholipid monolayers at the air/water Interface Siyoung Choi K. Kim, J. Zasadzinski, T. Squires University of California, Santa Barbara Motivation Science Engineering Cell membrane

slide-1
SLIDE 1

Interfacial microrheology

  • f phospholipid monolayers

at the air/water Interface

Siyoung Choi

  • K. Kim, J. Zasadzinski, T. Squires

University of California, Santa Barbara ISSP soft matter 2010

slide-2
SLIDE 2

Lung surfactants High Internal Phase Emulsion(PS-P2VP) Kramer group (2003) Zasadzinski group (2003)

Cell membrane Coating Process Shampoo, detergents, etc. Foams

Science Engineering

Motivation

slide-3
SLIDE 3

Interfacial viscoelasticity

A magnetic needle at the air/water Interface

slide-4
SLIDE 4

Interfacial viscoelasticity

A magnetic needle at the air/water Interface A few drops of water-insoluble surfactants

slide-5
SLIDE 5

Systems we are working on

DPPC (phospholipid) DPPC +Chol (60:40) Colloidal crystal at the oil/water interface

slide-6
SLIDE 6

Systems we are working on

DPPC (phospholipid) DPPC +Chol (60:40) Colloidal crystal at the oil/water interface

slide-7
SLIDE 7

Systems we are working on

DPPC (phospholipid) DPPC +Chol (60:40) Colloidal crystal at the oil/water interface

slide-8
SLIDE 8

Systems we are working on

DPPC (phospholipid) DPPC +Chol (60:40) Colloidal crystal at the oil/water interface

slide-9
SLIDE 9

Viscometry of 2D interfaces

s

  • a

s : surface viscosity : subphase viscosity a : disk radius P : Contact perimeter to 2D surface A : Contact Area to bulk phase

High perimeter/area ratio: higher sensitivity High aspect ratio (e.g. needles – Brooks, Fuller,

Vermant, Fischer, Zasadzinski …) Small probes (microrheology – Sickert & Rondelez, Fischer, Dai, Weeks, …)

“Boussinesq Number” High aspect ratio (e.g. needles - Brooks, Fuller, Vermant, Fischer, Zasadzinski, ...) Small probes (microrheology - Weeks, Sickert & Rondelez, Fischer, Dai, ...

slide-10
SLIDE 10

General Experimental Procedure

DATA acquisition board microscope Camera Image analysis Angular strain(t) (Red) Magnetic torque(t) (Green) electromagnets interface subphase

Applied Torque ~ Stress Rotational displacement ~ Strain

Imposed oscillatory magnetic field Can compute viscoelasticity(G’, G’’)

slide-11
SLIDE 11

General Experimental Procedure

DATA acquisition board microscope Camera Image analysis Angular strain(t) (Red) Magnetic torque(t) (Green) electromagnets interface subphase

Applied Torque ~ Stress Rotational displacement ~ Strain

Imposed oscillatory magnetic field Can compute viscoelasticity(G’, G’’) Imposed constant stress Can measure Creep compliance--J(t)

slide-12
SLIDE 12

Janus ferromagnetic microprobes

slide-13
SLIDE 13

Janus ferromagnetic microprobes

requirements

  • Small, yet visible
  • Ferromagnetic
  • Amphiphilic
slide-14
SLIDE 14

Janus ferromagnetic microprobes

Photolithography

requirements

  • Small, yet visible
  • Ferromagnetic
  • Amphiphilic
slide-15
SLIDE 15

Janus ferromagnetic microprobes

Photolithography

Photoresist (~ 1 um) Ni/Co (~100 nm) Au (~10 nm) Thiol monolayer

requirements

  • Small, yet visible
  • Ferromagnetic
  • Amphiphilic
slide-16
SLIDE 16

Janus ferromagnetic microprobes

Photolithography

20μm diameter 1μm tall

20µm

bright field image Amphiphilic - Janus

Photoresist (~ 1 um) Ni/Co (~100 nm) Au (~10 nm) Thiol monolayer

requirements

  • Small, yet visible
  • Ferromagnetic
  • Amphiphilic
slide-17
SLIDE 17

Janus ferromagnetic microprobes

Photolithography

20μm diameter 1μm tall

20µm

bright field image Amphiphilic - Janus Size, Shape, Magnetic and Surface properties

Control over

Photoresist (~ 1 um) Ni/Co (~100 nm) Au (~10 nm) Thiol monolayer

requirements

  • Small, yet visible
  • Ferromagnetic
  • Amphiphilic
slide-18
SLIDE 18

I + + k = m B

!" Oscillatory Magnetic Field Angular displacement m : magnetic moment B : magnetic field ! : angle for magnetic field " : angle for magnetic moment ! : drag coefficient k : spring constant

From field, orientation data

  • – measure (viscosity) and k (elasticity)

Rotational drag Rotational elastic constant Torque

= mBsin( ) mB

How the disk responds

From field vs. orientation: recover ς(~viscosity) and κ (~elasticity)

slide-19
SLIDE 19

Surface drag of the probe

h D Total drag Bulk drag Bo = η(bulk viscosity)a ηs(surface viscosity)

slide-20
SLIDE 20

Apparatus

Allows interfacial visualization during measurement

slide-21
SLIDE 21

50 40 30 20 10 Surface Pressure / mN/m 120 100 80 60 40 Area/molecule / Å

2

DPPC and its isotherm

  • Major component of Lung surfactants and cell membranes
  • One of the most common phospholipids

(Equilibrium properties are well known)

high conc. low conc.

slide-22
SLIDE 22

50 40 30 20 10 Surface Pressure / mN/m 120 100 80 60 40 Area/molecule / Å

2

DPPC and its isotherm

  • Major component of Lung surfactants and cell membranes
  • One of the most common phospholipids

(Equilibrium properties are well known) Liquid Expanded(LE)

texas red DHPE(0.1mol%)

Inspired by Mcconnell

high conc. low conc.

slide-23
SLIDE 23

50 40 30 20 10 Surface Pressure / mN/m 120 100 80 60 40 Area/molecule / Å

2

DPPC and its isotherm

  • Major component of Lung surfactants and cell membranes
  • One of the most common phospholipids

(Equilibrium properties are well known) LC+LE coexistence Liquid Expanded(LE)

texas red DHPE(0.1mol%)

Inspired by Mcconnell

high conc. low conc.

slide-24
SLIDE 24

50 40 30 20 10 Surface Pressure / mN/m 120 100 80 60 40 Area/molecule / Å

2

DPPC and its isotherm

  • Major component of Lung surfactants and cell membranes
  • One of the most common phospholipids

(Equilibrium properties are well known) Liquid condensed(LC) LC+LE coexistence Liquid Expanded(LE)

texas red DHPE(0.1mol%)

Inspired by Mcconnell

high conc. low conc.

slide-25
SLIDE 25

Elasticity - domain deformation Viscosity - Slipping domains

Linear viscoelasticity of LC phase

slide-26
SLIDE 26

Elasticity - domain deformation Viscosity - Slipping domains

Slow dynamics

  • does not flow for 10 sec

Elastic dominant Viscous dominant

8 9

0.1

2 3 4

Surface Dynamic Modulus / uN /m

8

0.1

2 4 6 8

1

2 4 6 8

10

2

Frequency / Hz

G’ G’’

Linear viscoelasticity of LC phase

slide-27
SLIDE 27

Elasticity - domain deformation Viscosity - Slipping domains

Incredibly long relaxation time for 2 nm thick film Slow dynamics

  • does not flow for 10 sec

Elastic dominant Viscous dominant

8 9

0.1

2 3 4

Surface Dynamic Modulus / uN /m

8

0.1

2 4 6 8

1

2 4 6 8

10

2

Frequency / Hz

G’ G’’

Linear viscoelasticity of LC phase

slide-28
SLIDE 28

Elasticity - domain deformation Viscosity - Slipping domains

Incredibly long relaxation time for 2 nm thick film Slow dynamics

  • does not flow for 10 sec

Elastic dominant Viscous dominant

8 9

0.1

2 3 4

Surface Dynamic Modulus / uN /m

8

0.1

2 4 6 8

1

2 4 6 8

10

2

Frequency / Hz

G’ G’’

Linear viscoelasticity of LC phase

slide-29
SLIDE 29

Elasticity - domain deformation Viscosity - Slipping domains

Incredibly long relaxation time for 2 nm thick film Slow dynamics

  • does not flow for 10 sec

Elastic dominant Viscous dominant

8 9

0.1

2 3 4

Surface Dynamic Modulus / uN /m

8

0.1

2 4 6 8

1

2 4 6 8

10

2

Frequency / Hz

G’ G’’

Linear viscoelasticity of LC phase

slide-30
SLIDE 30

Where does this G’ come from?

G' ~ γ a a2 ~ γ a

γ ~ G'a ~ 10−7(N / m) ×10−5(m) ~ 1pN

From emulsion theory

slide-31
SLIDE 31

Where does this G’ come from?

G' ~ γ a a2 ~ γ a

γ ~ G'a ~ 10−7(N / m) ×10−5(m) ~ 1pN

line tension ~ adhesive energy length kT 1 nm ~ 1 pN ~ Molecular argument From emulsion theory

slide-32
SLIDE 32

Where does this G’ come from?

G' ~ γ a a2 ~ γ a

γ ~ G'a ~ 10−7(N / m) ×10−5(m) ~ 1pN

surface tension ~ adhesive energy area ~ kT 1 nm2~ 1 mN/m line tension ~ adhesive energy length kT 1 nm ~ 1 pN ~ Molecular argument From emulsion theory

slide-33
SLIDE 33

Linear rheology after large shear

slide-34
SLIDE 34

Linear rheology after large shear

Viscous dominant over frequencies

slide-35
SLIDE 35

Linear rheology after large shear

Viscous dominant over frequencies

History dependent rheology

slide-36
SLIDE 36

Visualization for large shear

slide-37
SLIDE 37
  • Domain deformation
  • Interface fractures(plastic)
  • Slip-line forms

Visualization for large shear

slide-38
SLIDE 38
  • Domain deformation
  • Interface fractures(plastic)
  • Slip-line forms

Visualization for large shear

Does the interface heal?

slide-39
SLIDE 39

Complete healing of the deformed domains

Before deforming

0 sec 30 sec 60 sec 0 sec 60 sec 30 sec

slide-40
SLIDE 40

Complete healing of the deformed domains

Before deforming

0 sec 30 sec 60 sec 0 sec 60 sec 30 sec

slide-41
SLIDE 41

Complete healing of the deformed domains

Before deforming

0 sec 30 sec 60 sec

20 times smaller moduli after large stress

0 sec 60 sec 30 sec

slide-42
SLIDE 42

Complete healing of the deformed domains

Before deforming

0 sec 30 sec 60 sec

20 times smaller moduli after large stress Viscous - Elastic transition

0 sec 60 sec 30 sec

slide-43
SLIDE 43

A few clues of yield stress

Elastic dominant Viscous dominant

8 9

0.1

2 3 4

Surface Dynamic Modulus / uN /m

8

0.1

2 4 6 8

1

2 4 6 8

10

2

Frequency / Hz

G’ G’’

3 4 5 6 7 8 9

0.1 Surface Dynamic Modulus / uN /m

3 4 5 6 7 8 9

0.1

2 3 4 5 6 7 8 9

Amplitude / rad

Point that starts to yield Frequency sweep Amplitude sweep

2 nm molecular Mayonnaise??

slide-44
SLIDE 44

Steady rotation - yield stress

No yield stress

slide-45
SLIDE 45

Steady rotation - yield stress

No yield stress

slide-46
SLIDE 46

Steady rotation - yield stress

No yield stress

slide-47
SLIDE 47

Steady rotation - yield stress

No yield stress

slide-48
SLIDE 48

Steady rotation - yield stress

higher stress

τ  σ yr

c(2πr c)

applied stress~ yield stress

  • Evident yield stress

σ y ~ 10−8 N / m

No yield stress

slide-49
SLIDE 49

Steady rotation - yield stress

higher stress

τ  σ yr

c(2πr c)

applied stress~ yield stress

  • Evident yield stress

σ y ~ 10−8 N / m

No yield stress

slide-50
SLIDE 50

Steady rotation - yield stress

higher stress

τ  σ yr

c(2πr c)

applied stress~ yield stress

  • Evident yield stress

σ y ~ 10−8 N / m

No yield stress

slide-51
SLIDE 51

Steady rotation - yield stress

higher stress

τ  σ yr

c(2πr c)

applied stress~ yield stress

  • Evident yield stress

σ y ~ 10−8 N / m

No yield stress

slide-52
SLIDE 52

Yield stress

Theories and experiments by Daniel Bonn

Thixotropic behavior

(time dependent viscosity)

Aging (system) vs Rejuvenation (applied stress)

Can we do analogous experiments after yielding the interface?

slide-53
SLIDE 53

After ~ 5 minutes rotation We turn off the field

25x real time

Healing by unwinding

slide-54
SLIDE 54

After ~ 5 minutes rotation We turn off the field

25x real time

Healing by unwinding

slide-55
SLIDE 55

After ~ 5 minutes rotation We turn off the field

25x real time

Field off

Healing by unwinding

slide-56
SLIDE 56

After ~ 5 minutes rotation We turn off the field

25x real time

Field off

Healing by unwinding

slide-57
SLIDE 57

After ~ 5 minutes rotation We turn off the field

25x real time

Field off

Healing by unwinding

slide-58
SLIDE 58

After ~ 5 minutes rotation We turn off the field

25x real time

Strong memory Slow recovery

Field off

Healing by unwinding

slide-59
SLIDE 59

Domains don’t melt - they stretch!

Red - recoiling Blue - T1 transition Green - change its neighbor

Watching individual domains

slide-60
SLIDE 60

Rayleigh - Plateau instability

3D

high P low P low P

slide-61
SLIDE 61

Rayleigh - Plateau instability

3D

high P low P low P high P low P high P

2D Always stable without fluctuation or defects

slide-62
SLIDE 62

Rayleigh - Plateau instability

No Rayleigh-Plateau instability for 2D 3D

high P low P low P high P low P high P

2D Always stable without fluctuation or defects

slide-63
SLIDE 63

Asymmetric stress response

slide-64
SLIDE 64

Chirality of DPPC

20 um 20 um

slide-65
SLIDE 65
  • Direct visualization of individual DPPC domains under stress
  • Shear banding, yield stress, history dependence and aging
  • 2D Soft glassy materials - 2D high internal phase emulsions

Conclusion
