CASE STUDY INTELLIGENT TIRE SYSTEM Pierluigi Nuzzo, Safa Messaoud, Ben Zhang INTELLIGENT TIRE SYSTEM Distributed architecture for real-time data acquisition of road-surface and vehicular information from sensors located inside the tire of a car

slide-1
SLIDE 1

CASE STUDY

INTELLIGENT TIRE SYSTEM

Pierluigi Nuzzo, Safa Messaoud, Ben Zhang

slide-2
SLIDE 2

INTELLIGENT TIRE SYSTEM

Distributed architecture for real-time data acquisition of road-surface and vehicular information from sensors located inside the tire of a car

System Architecture

Personal Area Network (PAN)

Lowest level: sensor nodes

Upper level: PAN coordinator (communication with the sensor nodes, synchronization)

System Control Host (the highest level coordinator of the network)

UWB Communication System

UWB radio transmission

Preferable with respect to narrow-band transmission and spread spectrum techniques

slide-3
SLIDE 3

Signal Properties

slide-4
SLIDE 4

UWB RECEIVER FRONT-END DESIGN

  • A. Receiver Requirements
  • B. RF Front-End Exploration
  • C. Low Pass Filter Abstraction
  • D. Receiver Composition and Optimization
slide-5
SLIDE 5
  • A. Receiver Requirements
slide-6
SLIDE 6
  • B. RF Front-End Exploration

RF front-end: LNA + passive Mixer (M1 and M2)+low noise gain stage (M3-M8)

LNA

Mixer

1. AP components and contracts 2. RF Front-End Composition

slide-7
SLIDE 7
  • 1. AP components and contracts

 LNA component

  • Specify the related variables
  • Assumptions & Guarantees (ALN A, GLN A)

ALN A= {(RL ,CL ) : RL ∈ [85, 520] ,CL∈ [0.03, 0.25] pF}

 GLN A is the set of performance figures ζ LNA that satisfy

PLNA(ζLN A) = 1 and are obtained by evaluating the mapping φLNA on the input, configuration and interface variables in ALNA.

 Mixer component  CLNA and CMIX: horizontal contracts

slide-8
SLIDE 8
  • 2. RF Front-End Composition

 CRF = CLNA⊗CMIX  The intersection between the

set of configurations assumed by the LNA and the set of configurations offered by the Mixer is non-empty.

slide-9
SLIDE 9

Design Exploration Via Optimization

7186/20730 satisfied the contracts 21 minutes on a 3.16 GHz Intel Core2 Duo Workstation to obtain the optimum

slide-10
SLIDE 10

Optimization Results

Transistor-level simulation using the nearest neighbors

slide-11
SLIDE 11

Contract-based vs. No Contract

slide-12
SLIDE 12

Optimization Computation Cost

slide-13
SLIDE 13

Low Pass Filter

slide-14
SLIDE 14

Low Pass Filter Abstraction

Filter Behavioral Model

slide-15
SLIDE 15

Performance and Interface Parameters

Power consumption Cell quality-factor Resonant angular frequency Output noise power Gain Third-order harmonic distortion Input impedance Output impedance

slide-16
SLIDE 16

Benefit of contracts

slide-17
SLIDE 17

Receiver

slide-18
SLIDE 18

Receiver Composition

slide-19
SLIDE 19

Receiver Optimization

slide-20
SLIDE 20

Receiver Optimization Results
