Insight Power Smart Outlet Team 15 || Advisor : David Irwin Brendon Burke Mark Chisholm Garrett Olson Kriss Strikis 1 Problem statement Current State of the Market Problems with smart outlets Benefits of smart outlets Tedious to set up


slide-1
SLIDE 1

Insight Power Smart Outlet

Team 15 || Advisor : David Irwin Brendon Burke Mark Chisholm Garrett Olson Kriss Strikis

1

slide-2
SLIDE 2

Problem statement

Problems with smart outlets

  • Tedious to set up
  • Plugged-in devices are not

automatically managed

  • Setup friction increases hugely for

home-scale installation

2

Benefits of smart outlets

  • Allow monitoring of power usage for

plugged in devices

  • Devices plugged in can be turned
  • n/off remotely
  • Enable home automation policies

Current State of the Market

slide-3
SLIDE 3

Problem statement (Cont.)

Our Solution

3

Simple Setup

Classifies Devices in Use

Intuitive App Interface

Records Power Metrics

Insight Smart Power Outlet

slide-4
SLIDE 4

“Customers often find smart outlets difficult to use. The Insight Smart Power Outlet fixes this by providing customers with an easy and intuitive experience by classifying devices that are plugged into the product.”

4

slide-5
SLIDE 5

System Requirements

  • Plug easily into wall outlet, remains firmly in place once plugged in.
  • Connect wirelessly to app
  • Measures and graphs (via app) power usage in real-time
  • Turn device on and off via app
  • Continuous analysis of usage data
  • Classify devices based on data into different categories (lighting,

heating/cooling, etc)

  • User-Friendly companion app
  • 12cm x 3cm x 3cm (L x W x H)
  • Less than 1lb

5

slide-6
SLIDE 6

System Specifications

  • Measures power usage at least once per second within 5%
  • Companion app updates once per second
  • Communication between app and outlet takes at most 1 second
  • ≥80% accuracy, error biased towards resistive loads

6

slide-7
SLIDE 7

Block Diagram

7

slide-8
SLIDE 8

New PCB Layout

8

slide-9
SLIDE 9

Proposed FPR Deliverables

1. Working classification that is implemented on SVMs rather than a Decision Tree. 2. At least 3 working outlets, all able to classify and read power under required specifications. a. Measures power usage at least once per second within 5% b. Achieve classification accuracy of 80% with false positive <1% 3. Smaller design for all outlets. 4. Companion App and GUI refinement. a. Implement only resistive load toggling on the App.

9

slide-10
SLIDE 10

Achieved FPR Deliverables

1. Working classification that is implemented Dynamic Time Warping (DTW) 2. At least 3 working outlets, all able to classify and read power under required specifications. a. Measures power usage at least once per second within 5% b. Achieve overall classification accuracy of ≥80% i. We have achieved an average accuracy of 70% 1. Resistive: 92% 2. Inductive: 55% 3. Non-linear: 63% 3. Smaller design for all outlets. 4. Companion App and GUI refinement. a. Implement only resistive load toggling on the App

10

slide-11
SLIDE 11

What is Dynamic Time Warping?

  • Compares two waveforms and finds the distance between them.
  • As the distance calculated increases, the waveforms are more dissimilar.
  • For our classification we normalize the incoming power data between 0

and 1 and perform DTW against ideal waveforms for each class.

  • The class that has the calculates lowest distance is what is classified.
  • We are classifying based on startup data.

11

slide-12
SLIDE 12

12

Resistive loads: Ideal

Features to note:

1. Steady with slight decay or increase in active power. 2. Zero, or very little reactive power.

slide-13
SLIDE 13

13

Resistive loads: Tall Lamp Example

Features to note:

1. Steady with slight decay or increase in active power. 2. Zero, or very little reactive power.

slide-14
SLIDE 14

Inductive loads: Ideal

14

Features to note:

1. Big spike at the beginning which drops to a steady power usage. 2. Reactive power is non-zero.

slide-15
SLIDE 15

Inductive loads: Vacuum Example

15

Features to note:

1. Big spike at the beginning which drops to a steady power usage. 2. Reactive power is non-zero.

slide-16
SLIDE 16

Non-linear loads: Ideal

16

Features to note:

1. Both active and reactive power vary greatly over time. 2. We also see greater reactive power than active power at times.

slide-17
SLIDE 17

Non-linear loads: Printer Example

17

Features to note:

1. Both active and reactive power vary greatly over time. 2. We also see greater reactive power than active power at times.

slide-18
SLIDE 18

DEMO!!!
