InRouter300

Compact Industrial LTE Router

September 2020

2

Speakers

Louis Tao

Business Development Manager, Europe

Zilla Li

Technical Support

3

Contents

Q & A Introducing InRouter300 Applications Selection Guide About InHand Networks

• Pioneering IoT for 19 Years

Selected by GE Healthcare; Now a global supplier of GEHC 2005 Delivered industrial cellular modem for China State Grid 2007 2012 2017 2019 2001 Founded as M2M startup, Pioneer of IoT Schneider CAPP and Rockwell Product Partner Proven by world-class customers New factory construction completed 2020 Listed on SSE STAR Market Tech Board as of Feb.12, 2020

*STAR Market is a Nasdaq-style tech board – the Science and Technology Innovation Board at Shanghai Stock Exchange.

• Global Coverage

Employees 300+ R&D Team 100+ 2019 Total Sales $40 Million+ 390K+ IoT products shipped worldwide New factory plant in Jiaxing, China,

APAC Germany Office US Office

6

……………

IoT/M2M Products & Solutions

Industrial IoT/M2M products, Intelligent distribution network monitoring system, smart vending control system:

Application Layer “Cloud + Edge” IoT Solution

Distribution Network Monitoring System (IWOS) Smart Vending Control System Smart IoV System

Platform Layer Device Cloud PaaS Platform

InHand Device Networks Cloud Platform

Network Layer IIoT/M2M Products

Industrial Cellular Router Industrial Ethernet Switch Cellular Modem Edge Gateway

Sense & Control Layer Sensors, Controllers, Industrial Devices

Sensor Industrial Device

9

InRouter300 Features

• Compact Industrial Router IR300

LTE CAT 4/1, CAT M1 ETH, Wi-Fi Dual-SIM Failover Highly secure Versatile Easy to deploy and manage

InRouter302

• Network Access Anywhere

Dual ETH ports, ADSL Wi-Fi network access, standard 802.11b/g/n Cellular network access:

! High-speed network ! LTE Cat-4 (150 / 50Mbps down/uplink) ! Low and medium speed network ! LTE Cat-1 (10 / 5Mbps down/uplink) ! LTE Cat-M (588 / 1119Kbps down/uplink) ! Narrowband network ! NB-IoT (127 / 158.5Kbps down/uplink) ! Dual-SIM failover

InRouter302

• Reliable Network Connection

Data Center Internet Main link: Ethernet, Wi-Fi, 4G Backup link: Ethernet, Wi-Fi, 4G

Multiple Link Backups: mutual failover between wired ETH, wireless and Wi-Fi Dual SIM: failover between different

• perator networks

VRRP Hot Backup: build a redundant network link with multiple routers Multi-layer auto detection and recovery of link failures

• InRouter302

• Comprehensive Data Protection

! Full state packet inspection (SPI) ! Built-in DoS protection ! Filter multicast/Ping packets ! Access control list (ACL) ! Virtual IP mapping ! MAC-IP address binding ! IPsec VPN, L2TP , PPTP , GRE, OPENVPN ! Digital certificate CA, supports PEM, PKCS12, SCEP and X.509. ! User authorization management ! Local or remote HTTP , HTTPS, Telnet, SSH management, console login ! User management logs

Network Security Data Security Device Access Security

InRouter302

• Easy Deployment and Network Management

" APN self-adaptation, no user configuration needed

• n simple public network connection

" Multiple configuration methods: CLI, HTTP , HTTPS, SSH, etc. " SNMP V1/V2c/V3 simple network management protocol " Supports alarms " Supports data traffic management " Supports InHand Device Manager (DM), for efficient monitoring and management of large numbers of devices

• InRouter302

• Built for Industrial Use, Easy to Install and Deploy
• "

Small and compact, fit in narrow spaces more easily " Supports both panel and DIN-rail mounting, suitable for various IoT deployment sites " industrial design.

!"#$%&'()* InRouter302

!"

Various IoT Applications

• Device

Manager

iot.inhandnetworks.com InRouter300 InRouter300 InRouter300 InRouter300 InRouter300

Remotely manage distributed equipments for various industries.

InRouter302

Easy Connection, Instant Remote Maintenance

• !

InConnect is a simple service which builds secure remote networks for your IoT applications ! Gateway traffic monitoring ! Update of gateway configurations ! Upgrading of gateway firmware

InRouter302

ics.inhandnetworks.com

• Application Cases of InRouter300

Smart City ! Intelligent lighting ! Traffic Management ! Security surveillance ! Charging station ! Smart parking More Industries ! Smart metering ! HVAC ! Facilities ! Work-from-home connectivity Smart Retail ! Self-service terminal ! ATM/POS ! Coffee machine ! Digital signage ! Vending machine

• Offsite ATMs and Self-

service Terminals Networking Solution

Offsite ATM Self-service terminal Utility bill payment terminal Traffic fine payment terminal InHand SmartATM Platform 4G/3G InRouter302

VPN

! Accesses bank system through the operator VPDN ! Establishes VPN tunnel to the data center ! Uses AAA server for authentication, authorization and accounting ! Performs identity authentication effectively using CA certificate

• 4G/3G

InRouter302 Costa Data Center LAN

#$%&'()*+,'(%)-*.&&/-001112)3+&)45 ,67$6)+.,/28)09):;,,&0<&,()!"0<.,/+0"!=>!>"?0=@"A0B>!B0>!BA0@!C=0D>EE0AEFG0BCH"0A I?=0J,6)KA,'6&)(KL,/$)2M#NO .&&/-00$283$7PQ3$72%,2'40$0/$R0BE!?0!!0E?0!=0BIBH=@?GEEEEE?>G5HHE?!!E5$Q3O)535 !?K!==">HBG!BG"G2S/O

Coffee Machine Remote Networking Solution

Self-service Coffee Machine 4G/3G InRouter302

! Send transaction data to the operation center in real time ! Inventory alert ! Video monitoring

• EV Charging Pile

Networking Solution

4G/3G Charging Station Operation Data Center

• Elevator Networking

Solution

Elevator IoT InRouter302 Monitoring Center 4G/3G

Heat Exchange Station Networking Solution

Build a smarter real-time monitoring network of heat exchange stations, make your business more efficient, profitable and sustainable.

Heat Exchanger Controller HMI InRouter302 Data Center

• Roadside Parking

Networking Solution

• InRouter302

InRouter302 Parking Space Status Parking Space Status Parking Space Status Roadside Parking Management System Mobile APP/ Monitoring Center

• Mobile Bedside

Monitor Networking Solution

InRouter302 Medical Equipment Monitoring Center Monitor

• 4G/3G

Selection Guide

• LTE CAT 4/3

LTE CAT 1 LTE CAT M1 NB-IoT LTE CAT 6

InRouter600-S

Enhanced Industrial LTE Router ! Light industrial, Smart City, Retail/Kiosk Vehicle Gateway

InVehicle G710

IoT Edge Gateway

InGateway902 InRouter900

High-end Industrial LTE Router ! Industrial, Smart Grid, Oil & Gas, Smart City

InDTU300

Serial-to-Cellular Modem ! Energy, Industrial Automation

Comparison: Network Type

InRouter300

Compact Industrial LTE Router ! Light industrial, Smart City, Retail/Kiosk

• Selection Guide for Industrial LTE Routers
• InRouter611-S

Selection Guide for Industrial LTE Routers

InRouter615-S InRouter302

29

IR302 vs. IR611-S

2*LAN, WAN/LAN setting supported Dual-SIM failover No serial port Wi-Fi: 802.11 b/g/n 150Mbps Flexible installation: DIN-rail and panel mounting Compact size: 90x90x25(mm) 1*LAN Single SIM Serial port: RS232 Wi-Fi: 802.11 b/g/n 300Mbps Only panel mounting supported Dimensions: 100x98.5x23.5(mm)

30 30

Panel Mounting DIN-rail Mounting （Optional. Need to be placed in order)

IR300 Installation

31

Q&A

Q1: When will be eSIM supported? A: No plan to be supported. Q2: What is the power required to get it to work, can we connect it to a dc solar panel and batteries? A: It can be powered directly from up to DC36V and as low as DC9V, so it would be ideal where only solar power is available. Q3: Is there an easy way of first commissioning (special configuration)? A: It has a nice, easy-to-use web configuration because for some users this is something they will only use occasionally. But we also support command line access for technicians who want a shorthand way to configure the units. This can also be used to automatically configure the units via a scripting tool. Q4: Is it possible to add customized applications additionally in the router? A: Yes, if your order a large of quantity, we will offer customized development. Q5: Can we install the Device Manager in our servers? A: Yes, we do support deploying DM on premise, and you can consult our sales manager about the price.

32

Contacts Louis Tao Louis.tao@inhandnetworks.com Zilla Li liziy@inhand.com.cn

33

3900 Jermantown Road, Suite 150 Fairfax, VA 22030 +1 (703) 348 2988
