INFS 423 Preservation of Information Resources

Lecture 7 – Deterioration Caused by Insects

Lecturer: Prof. Harry Akussah & Mr. Michael Allotey, Contact Information: mallotey@ug.edu.gh, hakussah@ug.edu.gh

Lecture Overview

In the previous lecture, we learnt how fungi thrive and damage information resources and how we can contain them. In this lecture, I will be introducing you to the various types of insects that can cause damage to our materials. You will be taken through how to control their activities and how to prevent their infestation.

Slide 2

Lecture Outline

The key topics to be covered in this lecture are as follows:

• Topic One: Economic Importance of insects
• Topic Two: Categories of Insects
• Topic Three: Conducive Environment for Propagation
• Topic Four: Damages Caused by Insects
• Topic Five: Extermination of Insects

Slide 3

Reading List

• Akussah, H. (2011). Preservation of Documents. Department of

Information Studies, Legon, NAB Superior Services.

• Gorman, G. E., & Shep, S. J. (2006). Preservation management for libraries,

archives and museums. London: Facet Pub.

• Adcock, E.P. (2000). Principles for the care of handling of Library Materials.

Washington, D.C., IFAPAC.

• Swartburg, S. G. (1983). “Conservation Library.” A Handbook of use and

care of traditional materials. Connecticut: Greenwood Press, 1983.

• Feather, J. (2004). Managing preservation for libraries and archives:

current practice and future developments. Aldershot, Hants, England, Ashgate Publishing.

Slide 4

ECONOMIC IMPORTANCE OF INSECTS

Topic One

Slide 5

Economic Importance of Insects

• 1. Financial Implications
• Insects can cause partial damage to documents

– cost of repair

• Insects can cause total loss of documents –

cost of replacement

2.Health Hazards – Custodians visiting hospitals

– Hospital Bills – Loss of Man-Hours

3.Psychological Revulsion

– Loss of Clients/Patrons

Slide 6

Common Insects That Affect Documents:

• Silver Fish
• Book

worms/Beetles

• Book lice
• Cockroaches
• Termites
• Mud wasps

Slide 7

Silverfish

• Silverfishes feed on mold and starchy

materials that are found on paper documents.

• Silverfishes are small grey insects

(approximately 12mm in length). They have a scaly appearance and are generally found in dark, cool and moist environments such as basements.

• Evidence of silverfish damage is visible as an

abraded, rough surface on paper materials.

Slide 8

Book Lice

• This is generally found in heated buildings. It

feeds on mold spores that are found on paper and cardboard.

• Direct feeding by this insect does not cause

visible damage to paper; however, its squashed body can cause staining.

• Book louse prefers high humidity levels above

60% and they reproduce at warm temperatures above 25 degrees Celsius.

Slide 9

Book Worm/ Beetles

• This is actually the larva of any of 160 different species of

beetle.

• Eggs are laid on the edges of books and when the larvae

hatch they burrow into the books, eating their way through the leaves, leaving little tunnels.

• It feeds on anything that is cellulosic in content. When it

matures into a beetle, it stays on the cover of a book to feed since it can no longer penetrate books.

Slide 10

Termites

These are also known as white ants. They are the most dangerous of all the insects and very difficult to dislodge. There are two types of termites:

• wood dwelling termites and
• Earth dwelling termites.

Slide 11

Wood Dwelling Termites

• Wood dwelling termites are all over the place always

looking for organic materials. They feed rapidly and can cause great havoc within a week or less.

• They hate light even though they are not nocturnal. Most

times, it is difficult to detect because they hide under wood and any sign is hardly seen, therefore vigilance is required.

• To destroy them, their hiding place should be ruffled.

They should be exposed to light in order to kill them. Glue traps can also be used to trap them. The only permanent method however is termite-proofing.

Slide 12

Earth Dwelling Termites

• Earth dwelling termites normally live in nests called ant hill. They enter

the storage areas through cracks in the foundation, walls or ceiling.

• They travel long distances in search of food or organic matter to feed on.

Once they get a source of food, it becomes their source of attraction. They go in, take food and go back. They move along sewage lines and their presence can easily be detected by tunnels on walls or floors of the storage area.

• To destroy them, the nests from which they come must be identified,

destroyed and fumigants placed in them. DDT can be used to spray inside the nests. This is very effective because when some of the termites die,

• thers feed on them and they also die. Termites can also be

exterminated by digging round the building as deep as 2 feet and disinfesting the trench round. The trench is filled with insecticides.

Slide 13

CATEGORIZATION OF INSECTS

Topic Two

Slide 14

Categorization of Organisms

• Habitual/Permanent Visitors

– They live permanently in the storage area or on the premises. They are born on books, feed and die on books.

Example: silver fish, booklice, bookworm.

• Occasional/Casual Visitors

– only visit the storage area looking for food. Once accomplish their aim and go back.

Example: termites, cockroaches and mud wasps.

Slide 15

CONDUCIVE ENVIRONMENT FOR PROPAGATION

Topic Three

Slide 16

Conducive Environment for Propagation

• Insects are attracted to nutrients found in paper

documents, particularly cellulose, adhesive and starch.

• They also thrive under some favorable

conditions: damp, dark, warm and dirty locations.

• When the temperature is above 21 degrees

Celsius and relative humidity is above 65%, a conducive environment is created for insects.

• Long periods of darkness, undisturbed

environment and areas of minimal use and inspection encourage insect infestation.

Slide 17

How Insects Enter the Storage Environment

There are several ways through which insects enter the storage area. Among these are:

• Flying into the storage area through doors, windows, etc.
• Through new acquisitions or accessions and returned

borrowed documents.

• Through cracks and along sewage lines in the storage

area.

Slide 18

How Insects Enter the Storage Environment

• Through new and donated furniture.
• Through archival and pamphlet boxes.
• Through poor housekeeping practices.

Slide 19

Indications of their Presence

• Surface erosions of irregular shapes
• Pile of fine powder on shelves/book cover
• Small round holes on spine or cover of books
• Tiny black/brown droppings
• Scratches on spine of books
• Tiny bites/nibbles at edges of documents
• Occasionally, broken wings left behind
• Mud tunnels on walls, shelves, furniture, etc.
• Mud nests at corner of shelves, furniture and at times

books.

Slide 20

Activity 1

• Undertake another study tour of a public archives or
• library. Conduct an internal and external survey to

identify probable means by which insects can enter the center. Write down five (5) of them.

Slide 21

DAMAGES CAUSED BY INSECTS

Topic Four

Slide 22

Damages Caused by Insects

Insects are usually active at night when people are not present, and the damage they cause is irreversible:

• They can cause partial or total destruction. Example

is termites.

• They can cause permanent stains to documents.
• They can deface documents by scratching.
• Structural damage can result if a maze of holes or

perforations left in sheets of paper or through bindings.

Slide 23

PROTECTION AGAINST INSECTS

Topic Five

Slide 24

Prevention Insect Infestation

A number of measures can be taken:

• Food and drink should be prohibited in the storage

and reading areas. Temperature and relative humidity should be controlled.

• Building must be insect proof. Screens should be

placed on windows and exterior doors and, where possible, all cracks along floors and walls and holes around pipes plugged to limit the entrance of insects from outside.

Slide 25

Protection Against Insects

• All new materials should be inspected and fumigated

before they are brought into the building.

• All vegetation around the storage area should be

removed or kept trimmed . Ideally, there should be no live plants or flowers in the storage areas as plants can easily habour insects, which can propagate in the storage area and lead to infestations.

• Insect traps can be used to catch flying insects.
• It is essential that storage areas be cleaned on a regular

basis particularly behind shelves and in dark areas.

Slide 26

Activity 2

Go back to the information centre you visited during activity 1. Conduct a mini interview with the head of the centre to find out how they protect their documents against insect damage.

Slide 27

EXTERMINATION OF INSECTS

Topic Five

Slide 28

Extermination of Insects

• Effective eradication of insects is achieved through

fumigation.

• The whole storage area must be exposed to appropriate

fumigants – insecticides.

• It is important to practice double or triple stage

fumigation as most insecticides are unable to kill the eggs but just the larvae and the live insects.

• Examples of Insecticides are:
• Paradichlorobenzene
• Ethylene-Oxide +CO2
• Mythyl Bromride

Slide 29

Extermination of Insects

• Insecticides may be toxic causing severe irritation to;

skin, eye and respiratory system. Therefore modern methods are recommended. For example: Deep freezing.

Slide 30

Deep Freezing

• It kills the insects, larvae and the insect eggs.
• With this method, infested documents are bagged in

polythene bags under room temperature of 21 degrees Celsius and relative humidity of 50% and dropped in a freezing compartment.

• The temperature is brought to -20 degrees Celsius and

left for three days. After three days, the polythene containing the documents is removed but not opened immediately otherwise it will result in cracking of

• documents. It is allowed to return to normal room

temperature of 21 degrees Celsius before opening. The eggs and insects would have been dead.

Slide 31

Summary

You have successfully completed this Session. You have learned the following:

• Favorable condition under which insects flourish
• How insects enter storage areas
• Damages caused by insects
• Protection against insects, and
• Extermination of insects

Slide 32

References

• Akussah, H. (2011). Preservation of Documents. Department of

Information Studies, Legon, NAB Superior Services.

• Gorman, G. E., & Shep, S. J. (2006). Preservation management for libraries,

archives and museums. London: Facet Pub.

• Adcock, E.P. (2000). Principles for the care of handling of Library Materials.

Washington, D.C., IFAPAC.

• Swartburg, S. G. (1983). “Conservation Library.” A Handbook of use and

care of traditional materials. Connecticut: Greenwood Press, 1983.

• Feather, J. (2004). Managing preservation for libraries and archives:

current practice and future developments. Aldershot, Hants, England, Ashgate Publishing.
