Implementation of the RPE and the RPO from the EU BSS in The Netherlands Barbara Godthelp (ANVS) 15 June 2017 System of radiation protection expertise in the Netherlands EU directive BSS Radiation protection expert - RPE Radiation

slide-1
SLIDE 1

Implementation of the RPE and the RPO from the EU BSS in The Netherlands

Barbara Godthelp (ANVS)

15 June 2017

slide-2
SLIDE 2

System of radiation protection expertise in the Netherlands

EU directive BSS Radiation protection expert - RPE Radiation protection officer – RPO Radiation protection decree Bs (NL) (General) Coordinating Expert Supervisory Expert Basic safety standards radiation protection decree Bbs (NL) Radiation protection expert Stralingsbeschermingsdeskundige Supervisory officer radiation protection Toezichthoudend medewerker stralingsbescherming

15 June 2017 Authority for Nuclear Safety and Radiation Protection

slide-3
SLIDE 3

Radiation protection officer (RPO) in BSS

  • Article 4 (74) "radiation protection officer" means an individual

who is technically competent in radiation protection matters relevant for a given type of practice to supervise or perform the implementation of the radiation protection arrangements

3 15 June 2017 Authority for Nuclear Safety and Radiation Protection

I supervise specific applications with ionizing radiation

slide-4
SLIDE 4

Supervisory expert

  • Carries out a practise, or alternatively a practise is carried out under

supervision of the SE

  • Diploma attesting completion of RP training
  • Adequate continuing training and retraining
  • Registration is not required for SE in Dutch legislation

→ Dutch supervisory expert comparable to the radiation protection

  • fficer (RPO)

But the Dutch supervising expert is not (yet)

  • Practise-specific

4 15 June 2017 Authority for Nuclear Safety and Radiation Protection

slide-5
SLIDE 5

Application specific

5 15 juni 2017

Gradual approach – low to high risk

15 June 2017 Authority for Nuclear Safety and Radiation Protection

slide-6
SLIDE 6

Specialisations Dutch RPO

  • Sector Medical

– Medical applications -1 – Dentistry - 2 – Veterinary medicine - 3

  • Sector Nuclear

– Nuclear fuel cycles - 4

  • Sector Industry and Research

– Researchlabs/Open radioactive sources - 5 – NORM - 6 – Accelerators - 7 – Industrial radiography - 8 – Gauging techniques - 9

6 15 June 2017 Authority for Nuclear Safety and Radiation Protection

slide-7
SLIDE 7

Adaptation Dutch educational system RPO

Educational system radiation protection for RPO Basal part Application-specific part Modular or integrated education possible Levels education SE: EQF-levels

7 15 juni 2017 Authority for Nuclear Safety and Radiation Protection

slide-8
SLIDE 8

Model adapted Dutch educational system RPO

8 15 June 2017 Authority for Nuclear Safety and Radiation Protection

Sector Medical Nucl Industry & Research Type of specialisation EQF level Topics MA 5 De 4/5 Vet 4/5 NFC 6/7 Os 6 No 4/6 Acc 4 IR 5 GT 4

B

Technical

  • Radiation physics and interaction

with matter, dosimetry and detection, risks and effects B5 B5 B5 B7 B6 B6 B4 B5 B4 Supervisory

  • General role and duties RPO,

legislation, dose limits, O.P.A, safety assessment, ALARA, environment etc B5 B5 B5 B7 B6 B6 B4 B5 B4

S

Technical

  • Technical knowledge, operation

and maintenance, specific risks, shielding, measurement, storage, packing and transport, waste and discharges. MA De Vet NFC Os No Acc IR GT Supervisory

  • Specific tasks RPO, specific

legislation, licences/reports incidents, supervising MA De Vet NFC Os No Acc IR GT

slide-9
SLIDE 9

Conclusions RPO

  • Educational system for Dutch RPO needs to be redefined to become

application-specific: – New application-specific learning oucomes (2016/2017): 9 specialisations – Laid down in national legislation (July 2017) Issues to be solved Exchange with other European countries still possible Common understanding learning outcomes RPO (ENETRAP/HERCA) Is registration RPO required? For which practises the designation of a RPO is necessary?

9 15 June 2017 Authority for Nuclear Safety and Radiation Protection

I supervise specific applications with ionizing radiation

slide-10
SLIDE 10

Radiation protection expert (RPE) in BSS

  • Article 4 (73) "radiation protection expert" means an individual
  • r, if provided for in the national legislation, a group of individuals

having the knowledge, training and experience needed to give radiation protection advice in order to ensure the effective protection

  • f individuals, and whose competence in this respect is recognised by

the competent authority;

10 15 June 2017 Authority for Nuclear Safety and Radiation Protection

I am a recognized expert giving radiation protection advice

slide-11
SLIDE 11

Coordinating expert

  • Ensures that practises with ionising radiation are performed within

the legal framework (also for medical practises)

  • Radiation protection training (learning outcomes)
  • Registered in a special register

– Comply with registration requirements (Regulation Implementing Radiation

Protection Decree EZ)

  • Knowledge level EQF6

→ Comparable with the radiation protection expert (RPE)

11 15 June 2017 Authority for Nuclear Safety and Radiation Protection

slide-12
SLIDE 12

General coordinating expert

  • Ensures that practises with ionising radiation are performed within the legal

framework (also for medical practises)

  • Grants internal permission for practises (complex license)
  • Radiation protection training (fulfills learning outcomes laid down in

legislation)

  • Registered in a special register
  • Knowledge level EQF7

→ Comparable to the radiation protection expert (RPE)

12 15 June 2017 Authority for Nuclear Safety and Radiation Protection

slide-13
SLIDE 13

Conclusions RPE

→ Implementation of the RPE in the Dutch radiation protection system well advanced → Learning outcomes (ENETRAP based) → Registration requirements laid down in legislation Issues to be solved Not application-specific (broad) Tasks RPO performed by RPE: application and supervisory-specific knowledge (retraining)

13 15 June 2017 Authority for Nuclear Safety and Radiation Protection

I am a recognized expert giving radiation protection advice

slide-14
SLIDE 14

Questions?

14 15 June 2017 Authority for Nuclear Safety and Radiation Protection

slide-15
SLIDE 15

15 15 June 2017 Authority for Nuclear Safety and Radiation Protection

slide-16
SLIDE 16

Nuclear environment

16 June 15, 2017 Authority for Nuclear Safety and Radiation Protection (ANVS)

  • 18. October 2012

COVRA, Vlissingen URENCO (Almelo) Research centre Petten and the High Flux Reactor Higher Education Reactor, Delft Borssele nuclear power plant Dodewaard nuclear power plant

slide-17
SLIDE 17

Radiation environment

Radiation

  • 1,000

licensees (100 extra security)

  • 10,000

individuals subject to a reporting requirement (dentists, veterinarians, those not subject to a licence requirement)

  • 30

complex licences

  • 10,000

transports per year

17 June 15, 2017 Authority for Nuclear Safety and Radiation Protection (ANVS)
