Implement Physically Based Ray Tracing with OptiX and MDL Detlef - - PowerPoint PPT Presentation

April 4-7, 2016 | Silicon Valley

Detlef Röttger, 4/4/2016

Implement Physically Based Ray Tracing with OptiX and MDL

2

AGENDA

OptiX Material Definition Language MDL SDK Shader Code Generation Path Tracer Implementation

3

OptiX

4

NVIDIA OptiX SDK

GPU ray tracing „to the algorithm“

OptiX is a ray casting engine, not a renderer C-API to setup scene graph and data on host CUDA C++ to implement ray tracing algorithms on device OptiX does the heavy lifting!

Acceleration Structures, Recursions, GPU resource management Multi-GPU and NVIDIA VCA support

Get it here: https://developer.nvidia.com/designworks

4/3/2016

5

OptiX Scene Hierarchy

Use the OptiX C-API to create and connect scene data

4/3/2016

GeometryGroup GeometryInstance Geometry Material Acceleration

Instancing with Transforms Sharing Geometry and Acceleration Structures

Group Transform Transform Acceleration

6

OptiX Program Domains

Developer controls the algorithm via CUDA C++ programs

RayGeneration

4/3/2016

Intersection BoundingBox ClosestHit Miss AnyHit

7

Material Definition Language

8

Material Definition Language

A domain-specific language for abstract declarative material description Independent of a specific rendering system Procedural programming language to customize texture image lookups

• r procedural textures

MDL Handbook and Specifications: http://www.mdlhandbook.com More Information: https://developer.nvidia.com/designworks

4/3/2016

9

MDL Code Example

mdl 1.2; import df::*; export material my_diffuse( uniform float par_roughness = 0.0, uniform color par_color = color(0.5) ) = material( surface: material_surface( scattering: df::diffuse_reflection_bsdf( roughness: par_roughness, tint: par_color ) ) );

Name Parameters Definition Version and Imports

10

MDL Basic Building Blocks

Bidirectional Scattering Distribution Functions (BSDF)

diffuse reflection diffuse transmission specular(reflect) specular(transmit) specular(reflect_transmit) measured glossy backscattering glossy(reflect) glossy(transmit) glossy(reflect_transmit)

11

MDL Basic Building Blocks

Layers

weighted_layer fresnel_layer custom_curve_layer measured_curve_layer

12

MDL Basic Building Blocks

Modifiers

tint thin_film directional_factor measured_curve_factor

13

MDL Basic Building Blocks

Mixers

normalized_mix clamped_mix

0.25/0.25 0.5/0.5 0.75/0.75 1.0/1.0

14

MDL Basic Building Blocks

Emission Distribution Functions (EDF)

diffuse_edf spot_edf measured_edf (IES profiles) mixer on edf_component[]

15

MDL Basic Building Blocks

Volume Distribution Functions (VDF)

anisotropic_vdf

0.0 1.0 0.75 0.5

• 1.0
• 0.75
• 0.5

Henyey-Greenstein phase function vdf()

16

Material Definition Language SDK

17

MDL SDK

Compiler and API

Compile materials into internal data structures (Directed Acyclic Graph, DAG) Different compilation methods

instance compilation, class compilation

Optimizations

Inlining, dead code elimination, complete evaluation of uniform sub-graphs

Easy to inspect view on the material definition, full traversal of the DAG Code generation backends for use on GPU or CPU (LLVM, PTX, GLSL) More information: https://developer.nvidia.com/designworks

4/3/2016

18

Shader Code Generation

19

Shader Code Generation

4/3/2016

<name>.mdl MDL SDK Compiled Material Builder Class DAG Nodes Texture References Parameter Interface Parameter Macros Header Traverser Code Getter Classes Hierarchy Typedefs Material Constructor Description <name>.txt Traverser <hash>.cu

Using the MDL SDK

20

Parameter Macros and Getter Classes

4/3/2016

#define par_color_macro (make_float3(sys_Parameters[index].u.f4[0])) #define par_roughness_macro (sys_Parameters[index].u.f1[3]) class DiffuseReflectionGetter_1 // df::diffuse_reflection_bsdf { public: RT_FUNCTION float3 getTint(State const& state, const int index) const { return par_color_macro; } RT_FUNCTION float getRoughness(State const& state, const int index) const { return par_roughness_macro; } };

Connecting variable expressions with hardcoded building blocks

21

Material Hierarchy as Typedefs

typedef bsdf_diffuse_reflection< DiffuseReflectionGetter_1 > DiffuseReflection_6; typedef material_emission< edf, EmissionGetter_2 > Emission_7; typedef material_surface< DiffuseReflection_6, Emission_7 > Surface_8; typedef material_emission< edf, EmissionGetter_3 > Emission_9; typedef material_surface< bsdf, Emission_9 > Surface_10; typedef material_volume< vdf, VolumeGetter_4 > Volume_11; typedef material_geometry< GeometryGetter_5 > Geometry_12; typedef material< Surface_8, Surface_10, Volume_11, Geometry_12, MaterialGetter_0 > Material_13;

Match MDL material structure with C++ class implementation

22

Material Hierarchy Traversal Function

RT_CALLABLE_PROGRAM void traverser(State, Traversal, PerRayData, modifier, probability, normal) { const Material_13 theMaterial = Material_13( Surface_8( DiffuseReflection_6(), Emission_7( edf() ) ), Surface_10( bsdf(), Emission_9( edf() ) ), Volume_11( vdf() ), Geometry_12() ); theMaterial.traverse(state, traversal, prd, modifier, probability, normal); }

Single function to evaluate material hierarchy and parameters

23

Material Hierarchy Traversal

Traversal and Data Storage (layered example)

4/3/2016

weighted layer material glossy bsdf diffuse reflection bsdf material surface

base layer theMaterial.traverse()

Traversal.nodes[] data array

(Inner nodes‘ data stored at end, BSDF and EDF node data stored at begin)

...

dfIndex dataIndex

24

Forward Path Tracer Implementation

25

Ray Generation

4/3/2016

Per Launch-Index Initialization Lens Shader Integrator Accumulate Result

26

Closest Hit Program

4/3/2016

State Calculation, Traversal Setup Material Hierachy Traversal (for parameters, emission, estimation, calculation) BSDF Sampling Inlined Code Bound Callable Program (per material shader, called multiple times) Bindless Callable Programs (per BSDF) Bindless Callable Programs (per light type) Bindless Callable Programs (per diffuse BSDF) Light Sampling BSDF Evaluation Diffuse Reflection BSDF?

A single program for all materials!

27

Any Hit Program

4/3/2016

State Calculation, Traversal Setup Material Hierachy Traversal (for cutout opacity value only) Inlined Code Bound Callable Program (per material shader) Stochastic Transparency if (opacity < RNG) ignore intersection;

A single program only present for cutout opacity materials!

28 4/3/2016

29 4/3/2016

30

EDF examples

Blackbody Radiation

1900 K 3000 K 5000 K 7000 K

31 4/3/2016

32

Future Development

„Cameras? Lights? Shading!“

Add MDL 1.3 BSDFs Runtime compilation of generated code Use MDL SDK PTX backend for code generation measured_bsdf sampling measured_edf evaluation Different camera implementations

4/3/2016

33

Summary

Takeaways from this Presentation

Overview of the MDL material features and capabilities Example how to use the MDL SDK to convert MDL materials to a custom renderer Implementing an MDL-capable global illumination renderer with OptiX

Single ClosestHit and AnyHit programs configured by callable programs Easy to extend with more distribution functions

4/3/2016
