NRP EEE22 Implement Environmental Sensor under Internet of Things Huang Ruiyue, Amanda Koh BACKGROUND Over reliance on food imports (>90%) Increase self sufficiency Encourage growing edible plants within homes Smart Nation

slide-1
SLIDE 1

NRP EEE22

Implement Environmental Sensor under Internet of Things

Huang Ruiyue, Amanda Koh

slide-2
SLIDE 2

BACKGROUND

▪ Over reliance on food imports (>90%) ▪ Increase self sufficiency ▪ Encourage growing edible plants within homes ▪ Smart Nation

2

slide-3
SLIDE 3

ENGINEERING GOALS

To build an environment sensor:

  • 1. to be used in a mini farm in individual

households

  • 2. that monitors the microclimate and informs

users when conditions deviate from the ideal

  • 3. that runs on solar energy

3

slide-4
SLIDE 4

4

Stage 1: Microcontroller & IoT platforms Stage 3: Integration of Solar Panel Stage 2: Coding Optimisation Stage 4: Soldering

slide-5
SLIDE 5

MATERIALS

5

slide-6
SLIDE 6

6

more power efficient

>

PLATFORMS

slide-7
SLIDE 7

7

MKR1000 ESP8266

MICROCONTROLLERS

slide-8
SLIDE 8

8

DHT22

Temperature and Relative Humidity

LM393

Soil Moisture

LM393

Light

SENSORS

slide-9
SLIDE 9

9

IOT PLATFORMS

slide-10
SLIDE 10

10

TP4056 charging board Rechargeable LiPo battery Polycrystalline solar panels

POWER SYSTEM

slide-11
SLIDE 11

STAGE 1

Microcontrollers & IoT Platforms

11

slide-12
SLIDE 12
  • 1. Create 4 separate systems
  • 2. Code for the same functions:
  • 1. Measure power consumption

12

Read and upload data 60s sleep 20s buffer

slide-13
SLIDE 13

13

slide-14
SLIDE 14

14

MKR1000 ESP8266 Thinger.io Thing Speak Thinger.io Thing Speak Voltage / V 7.00 7.02 7.10 7.09 Sleep / mA 14.1 9.6 12.2 17.7 Awake / mA 101.9 103.5 83.5 88.5 Average / mA 39.1 39.6 35.5 39.8 Average power / W 0.274 0.278 0.252 0.282

slide-15
SLIDE 15

STAGE 2

Code Optimisation

15

slide-16
SLIDE 16
  • 1. Power input for sensors
  • 1. Power input for microcontroller
  • 1. Sleep time

16

slide-17
SLIDE 17

17

Relative humidity

Lower threshold: 60% Upper threshold: 90%

Temperature

Upper threshold: 30°C

Light

Analog Converted to lux

Soil moisture

Calibrated for digital use

slide-18
SLIDE 18

18

slide-19
SLIDE 19

19

Initial Optimised Voltage / V 7.10 3.46 Sleep current / mA 12.2 0.9 Awake current / mA 83.5 69.3 Average current / mA 35.5 3.4 Average power / W 0.252 0.012

slide-20
SLIDE 20

STAGE 3

Integration of Solar Panel

20

slide-21
SLIDE 21

▪ 2 solar panels with a combined surface area of 13000mm2 ▪ connected in parallel to charge the battery at a faster rate ▪ maximum output voltage of 5V

21

slide-22
SLIDE 22

STAGE 4

Soldering

22

slide-23
SLIDE 23

23

slide-24
SLIDE 24

24

slide-25
SLIDE 25

25

slide-26
SLIDE 26

CONCLUSION

26

slide-27
SLIDE 27

FUTURE WORK

27

slide-28
SLIDE 28

▪ Timer relay system to automatically charge battery ▪ Notification system for light readings ▪ Systems to automatically create ideal conditions

28

slide-29
SLIDE 29

THANK YOU

29

slide-30
SLIDE 30

QUESTIONS?

30
