IconIntent : Automatic Identification of Sensitive UI Widgets based on Icon Classification for Android Apps Xusheng Xiao 1 , XiaoyinWang 2 , Zhihao Cao 1 , HanlinWang 1 , and Peng Gao 3 1 Case Western Reserve University 2 The University of Texas at


slide-1
SLIDE 1

Xusheng Xiao1, XiaoyinWang2, Zhihao Cao1, HanlinWang1, and Peng Gao3

1Case Western Reserve University 2The University of Texas at San Antonio 3Princeton University

IconIntent: Automatic Identification of Sensitive UI Widgets based on Icon Classification for Android Apps

IconIntent - ICSE 2019

slide-2
SLIDE 2

Privacy Issues of Mobile App

  • Mobile apps have become an integral part of our life

– E.g., business, transportation, education

  • Many apps access sensitive data, raising privacy concerns

– E.g., location, contacts, microphone

1 IconIntent - ICSE 2019

slide-3
SLIDE 3

Sensitive UI Widgets

  • It is crucial to understand the apps’ intentions in using the sensitive

information

– E.g., Inspecting permissions and informing users about sensitive data

  • Apps express their intentions to use or collect users’ sensitive data via

sensitive UI widgets, i.e., justifying the uses of the data

  • App market needs an automatic approach to understand these intentions

IconIntent - ICSE 2019 2

slide-4
SLIDE 4

Challenges: Understanding Intentions of UI Widgets

  • UI widgets’ intentions are expressed via texts and images

– Prior works focus on analyzing framework APIs (e.g., device identifiers, and contacts) or descriptive texts (e.g., text labels), not images

IconIntent - ICSE 2019 3

  • Object icons: icons with specific

shapes, no co-located texts

– Different styles, scales, angles

  • Text icons: icons embedded with

texts

– Diversified colors and opacities

Automatic Identification of Sensitive UI Widgets with Icons

slide-5
SLIDE 5

Sensitive UI Widget Identification

  • Given an app, which UI widgets are associated

with icons?

  • Based on the icons, which sensitive data the UI

widgets will use?

IconIntent - ICSE 2019 4

slide-6
SLIDE 6

IconIntent

  • Synergistically combine program analysis and

icon classification

  • Associate icons with UI widgets via static

analysis

  • Classify the intentions of icons (both object

icons and text icons) into eight pre-defined sensitive user input categories

– Including Camera, Contacts, Email, Location, Phone, Photo, SMS, and Microphone

IconIntent - ICSE 2019 5

slide-7
SLIDE 7

Overview of IconIntent

  • Icon-Widget Association: static analysis on UI layout files and

code

  • Icon Mutation: image mutations on extracted icons
  • Icon Classification: classification of icons into sensitive categories

IconIntent - ICSE 2019 6 APK UI Layout Association Program Association Icon-Widget Association Icon Classification Object Icon Classification Training Icon Dataset Optical Character Recognition Text Icon Classification Icon Mutation Icon Resource Extraction Image Mutation

slide-8
SLIDE 8

Icon-Widget Association: UI Layout

  • Static Analysis: XML parsing and resource resolution
  • UI layouts: widgets and icons
  • Drawable objects

IconIntent - ICSE 2019 7

<LinearLayout android:orientation="horizontal"> <ImageView android:id="@+id/img” android:src="@drawable/loc" .../> <EditText android:id="@+id/TxtCity" ... /> <Button android:text="@string/search" .../> </LinearLayout>

UI Widgets Icon loc.png

<selector> <item android:state_checked="true" android:drawable="@drawable/btn_radio_to_on_mtrl_015" /> <item android:drawable="@drawable/btn_radio_to_on_mtrl_000" /> </selector>

slide-9
SLIDE 9

Icon-Widget Association: API Calls

  • Life cycle methods: load layout files, bind variables to

UI widgets, and associate icons to UI widgets

  • Static analysis: dataflow analysis with over-

approximations to associate UI widgets and icons

IconIntent - ICSE 2019 8 void onCreate(Bundle savedInstance) { 1 View g = this.findViewById(R.id.button_esc); // FindView ImageView 2 h = (ImageView) g; // cast to ImageView 3 h.setImageResource(R.drawable.icon2); // associate icon ... } h.setImageResource(R.drawable.icon2);

Widget ID set: Γ(h) = {R.id.button_esc} Icon ID set: Σ(h) = {R.drawable.icon2},

slide-10
SLIDE 10

App Icon Varieties

  • Icons have different combinations of colors and

transparencies in texts, backgrounds, and object shapes

  • Challenges for computer vision techniques

– Small: (a) and (b) – Low contrast: (c) and (d) – Bright color text and dark background: (e) – Opacity: (f) and (g)

IconIntent - ICSE 2019 9

slide-11
SLIDE 11

Icon Mutation

  • RGBA model <R,G,B,A> to represent an icon

– R,G,B for red, green, blue, A for opacity

  • Image mutations:

– Image Scaling: enlarge pixel values using nearby pixels – Grayscale Conversion: convert an image to represent only the amount of light – Color Inversion: invert the colors of each pixel – Contrast Adjustment: adjust the contrast of colors in the image – Opacity Conversion: convert the opacity differences to the color differences

IconIntent - ICSE 2019 10

slide-12
SLIDE 12

Icon Classification – Object Icon

  • Object recognition to classify object icons based on a training

icon set labeled with sensitive user-input categories

  • Scale-Invariant-Feature-Transform (SIFT)

– Identifying key locations that are invariant with respect to image translation, scaling, and rotation and matching key locations – Challenges:

  • Too few key locations

– Enlarging icons and FAST

  • Lower tolerance for changes

– Relative One-to-One Mapping IconIntent - ICSE 2019 11


Icon Dataset

slide-13
SLIDE 13

Icon Classification –Text Icon

  • Optical Character Recognition (OCR)

– Working well for dark text and bright background – Still not perfect even with image mutations

  • E.g., location -> lcation or llocation, email -> emai
  • Classification based on Keyword Similarity

– 95+% of 300 text icons extracted from top Google Play apps containing 1 to 3 words – Edit distance-based similarity (considering keyword length)

  • 𝑇𝑗𝑛%,' = 1 − +,-. /-0.1234

5426.7(')

IconIntent - ICSE 2019 12

slide-14
SLIDE 14

Evaluation Setup

  • Implementation:

– Static analysis: Gator and Soot – Icon classification: OpenCV and Asprise OCR

  • Subject:

– Training dataset: 1,576 icons

  • Google image search: 800
  • Top 10,000 apps: 776

– Test dataset: 150 apps with 5,791 icons

  • 539 sensitive object icons
  • 49 sensitive text icons
  • Total: 588 sensitive icons

IconIntent - ICSE 2019 13

Camera 31% Contacts 3% Email 11% Location 4% Microphone 16% Phone 4% Photo 7% SMS 24%

Test Dataset

slide-15
SLIDE 15

Identifying Sensitive UI Widgets

  • Detecting most sensitive icons (90.1%, 530 / 588) from most apps (135 out of

138 apps that contain sensitive icons)

  • Prevalent sensitive UI widgets: 248 UI widgets from 97 apps (prec: 82.4%)
  • Sensitive icons not always used in UI widgets

– 125 SMS icons -> 24 UI widgets, 20 Phone icons -> 38 UI widgets

IconIntent - ICSE 2019 14

Category #Detected SIs #Apps with SIs #Detected SWs #Apps with SWs Object Text All Camera 148 1 149 47 65 35 Contacts 14 1 15 6 10 6 Email 44 5 49 16 25 12 Location 19 11 30 9 12 9 Microphone 75 3 78 26 65 19 Phone 20 1 21 6 38 4 Photo 41 12 53 13 19 13 SMS 125 11 136 23 24 10 All 486 44 530 135 248 97

slide-16
SLIDE 16

Combining with SUPOR

  • SUPOR: text-based sensitive UI widget identification

– Expand to include buttons, radio buttons, check boxes, – Leverage dex2jar to support custom widgets

  • SUPOR: 242 SUI <-> SUPOR+IconIntent: 487 SUI
  • Only 3 UI widgets are identified by both SUPOR and IconIntent

IconIntent - ICSE 2019 15

slide-17
SLIDE 17

Icon Classification

  • IconIntent achieves an average F-score of 87.7% (with

distance threshold as 0.3)

  • IconIntent greatly improves F-score with image

mutation (from 36.6% to 89.8%)

IconIntent - ICSE 2019 16

Setting P (%) R(%) F (%) SIFT 43.0 54.5 48.1 Without Mutation 91.2 64.9 75.8 IconIntent 88.2 87.3 87.7 Setting P (%) R(%) F (%) Without Mutation 91.7 22.9 36.6 IconIntent 89.8 89.8 89.8

Object-Icon Classification Text-Icon Classification

slide-18
SLIDE 18

Conclusion

  • IconIntent

– Program analysis techniques to associate icons and UI widgets – Computer vision techniques to classify the associated icons into eight sensitive categories

  • Evaluation on 150 apps from Google Play

– Detect 248 sensitive UI widgets in 97 apps, achieving a precision of 82.4% – SUPOR +IconIntent can detect 487 sensitive UI widgets (101.2% improvement over SUPOR only) – Image mutations improves icon classification

IconIntent - ICSE 2019 17

slide-19
SLIDE 19

Thank You !

Questions ?

18 IconIntent - ICSE 2019
