I nnovative Materials and Methods for Long Lasting, Rapid Renewal of Aging I nfrastructure I nnovative Materials and Methods for Long Lasting, Rapid Renewal of Aging I nfrastructure

Director Kirk T. Steudle, P.E. Michigan Department of Transportation United States of America Director Kirk T. Steudle, P.E. Michigan Department of Transportation United States of America

Michigan

• U. S. A.

I nfrastructure Management

• Asset Management Approach
• Innovative Contracting

Methods

• Innovative Construction

Methods

• Use of Innovative materials

Asset Management

A systematic process to cost effectively maintain, upgrade and operate an organization’s infrastructure by inventorying assets (roads, bridges, utilities, equipment, facilities) and evaluating specific data (condition, value capacity) in

• rder to make critical

infrastructure decisions based

• n fact rather than assumption.

Expectations Decision-Making & Resource Allocation Goals and Objectives Analysis of Options and Tradeoffs

Preservation, Operations, Capacity Expansion

Implementation Monitoring and Performance Measures Feedback

Transportation Asset Management

Overview

Budgets Policies

Inventory and condition assessment

Transportation Asset Management

Preservation Capital Improvement Operations

RESOURCES

Safety Other

• Innovative construction

methods

• Innovative bridge

designs for rapid renewal

• Durable bridges

for service life beyond 100 years

Strategic Highway Research Program (SHRP 2)

Rapid Approaches Minimal Disruption

Successful Renewal

Long-Lasting Facilities

Renewal Program - Goals

“GET IN, GET OUT, STAY OUT” The search for renewal tools and techniques that reduce preparation and execution times, reduce disruptions to traffic, utilities, and neighborhoods, and extend the time between renewal activities

• R09. Risk Manual
• R09. Risk Manual
• R06. High-Speed NDT*
• R06. High-Speed NDT*
• R04. Innovative Bridge

Designs

• R04. Innovative Bridge

Designs

• R01. Locating Utilities*
• R01. Locating Utilities*
• R02. Geotech Solutions
• R02. Geotech Solutions
• R05. Modular Pavement
• R05. Modular Pavement
• R07. Performance Specs
• R07. Performance Specs
• R16. Railroad-DOT

Mitigation Strategies

• R16. Railroad-DOT

Mitigation Strategies

• R15. Integrating Utility

and Transportation Agency Priorities*

• R15. Integrating Utility

and Transportation Agency Priorities*

• R23. Using Existing

In-place Pavement & Achieving long Life

• R23. Using Existing

In-place Pavement & Achieving long Life

• R21. Composite

Systems

• R21. Composite

Systems

• R26. Preservation

Approaches

• R26. Preservation

Approaches

• R19. Bridges for

Service Life

• f 100 Years*
• R19. Bridges for

Service Life

• f 100 Years*

Rapid Approaches Long-Lived Facilities Minimize Disruption

SHRP 2 Renewal Landscape

• R11. Strategic

Approaches at Corridor/Network Level

• R11. Strategic

Approaches at Corridor/Network Level

• R10. Project

Management for Large Projects

• R10. Project

Management for Large Projects

• R03. Worker Fatigue
• R03. Worker Fatigue

Technology related Project Delivery related * Track Project

Innovative Contracting Methods

• Contracts with cost

and time components (A+B) versus exclusively low bid contract

• Performance

contracting with specific performance requirements

• Design-Build-Finance

alternatives being investigated

“ABC” Accelerated Bridge Construction

• Precast bridge

elements

• Building

bridges and moving them into place

• Scheduling to

reduce customer delays

An Illustration of ABC (Accelerated Bridge Construction)

Parkview Avenue over US-131

Demolition Took Place at Night with Maximum 5 Minute Freeway Closure

Beam removal was done at night allowing for a maximum of 5 minute lane closures

All Bridge Components were Precast Concrete

Abutment Placement

This abutment segment took 8 minutes to place

Placement of the Pier Caps

Prestressed I -Beams were Placed at Night

The Bridge Deck was Made of Precast Concrete Panels

48 deck panels were placed in four days

A Hot-Mix Asphalt Wearing Surface was Placed on the Deck

Waterproof membrane and 1 ½ inch lift

• f hot mix asphalt (HMA) placed on top
• f the concrete deck panels

Parkview over US 131

Before After

Self-Propelled Modular Transporters

• Used to move entire

bridge spans into place

• Reduces roadway

closure time

• Less impact to the

traveling public

Bridge Preservation

• Epoxy Overlays
• n bridge decks
• Zinc-based

primer paint systems for steel beams

• Acrylic coatings

for concrete elements

Durable Bridges for Service Life Beyond 100 Years

• Innovative

materials and designs

• Protecting

bridges with preventive maintenance

I nnovative Materials Designed for Maximum Durability

• Non-corrosive

materials

– Carbon fiber reinforced composites – New alloys of stainless steel

• Ultra-ductile,

high-performance concrete

Column Wrapping with Fiber Reinforced Polymer sheets

Using I nnovative Materials to Build, Strengthening, and Repair Bridge Beams

Prestressed concrete beam reinforced with CFRP prestressing strands and rebar

Load Testing a CFRP Reinforced Bridge

Thank you!
