i n t r o d u c i n g REFRESH AC AUTO increases Auto A/C efficiency - - PowerPoint PPT Presentation

i n t r o d u c i n g

2

• 1. Removal and permanent prevention of oil-fouling

This removal restores the 20-30% loss in heat transfer capability. PTFE (Teflon) is then permanently, mechanically bonded to the system interior to prevent future oil-fouling.

• 2. Refrigerant evaporates or “boils” more quickly

This, combined with the removal of oil-fouling results in a 73% improvement in heat transfer capability.

• 3. Increased lubricity boosts the compressor oil’s performance.

There is less wear and tear, extended equipment life, and reduced

• maintenance. And the tenacious bond actually keeps the friction reducing

properties even when the oil is not present.

REFRESH AC AUTO™ increases Auto A/C efficiency by optimizing the system in 3 distinct ways.

3

• Eliminates and Prevents Oil Fouling
• Increases Refrigerant Flow
• Increases Heat Transfer
• Improves Pool Boiling
• Cleans and coats friction bearing surfaces
• Colder Air and Increased Comfort
• Faster Cabin Cool Down
• Reduced Fuel Use
• Quieter Compressor Operation
• Extended Compressor Life
• Reduced Environmental Impact

REFRESH AC AUTO™ has numerous, significant improvements and benefits

System Improvements Benefits

REFRESH AC AUTO™ Unique Features

• Contains no corrosive or combustible ingredients such as chlorine, sulfur, chloro-wax, solids, or

formaldehyde etc. – ingredients that remove the fouling by harsh solvent action

• Removes oil-fouling in a completely benign manner without introducing any destructive ingredients into

treated systems

• Creates a permanent mechanical bond to prevent future oil-fouling for the life of the system
• Circulates nano-particles in the refrigerant that act as nuclei to accelerate pool boiling
• Has been developed over the past 8 years and there has never been one registered complaint from a

manufacturer or end-user customer 4

REFRESH AC AUTO™ is the ONLY next generation PROA

Before After

Aluminum

26 Months After Treatment

Aluminum

Prior to Treatment

Tests ¡of ¡the ¡REFRESH ¡AC AUTO™ ¡formula ¡were ¡conducted ¡in ¡Tucson, ¡AZ; ¡Austin, ¡TX; ¡and ¡Port ¡St. ¡Lucie, ¡FL ¡from ¡May, ¡2011 ¡to ¡March, ¡2012. ¡The ¡tests ¡ were ¡conducted ¡at ¡various ¡ambient ¡temperatures. ¡

10 20 30 40 50 60 70 2003 Ford Expedition 1998 Chevrolet Pickup 2005 Lexus 430 2008 Honda Civic 2003 Subaru Impreza 2003 Acura 3.2 CL 2003 Chevrolet Suburban

Before and After Installation

Before Install Vent-Temp (°F) After Install Vent-Temp (°F)

39 ¡°F 69 ¡°F ¡ 36 ¡°F 51 ¡°F 28 ¡°F 47 ¡°F 28 ¡°F 47 ¡°F 55 ¡°F 46 ¡°F 51 ¡°F 28 ¡°F 41 ¡°F 21 ¡°F

REFRESH AC AUTO™ can dramatically improve auto AC systems

• ­‑30 ¡°F ¡
• ­‑16 ¡°F ¡
• ­‑19 ¡°F ¡
• ­‑19 ¡°F ¡
• ­‑ 9 ¡°F ¡
• ­‑23 ¡°F ¡
• ­‑20 ¡°F ¡

“I have been absolutely amazed in the difference I’ve seen in my Jeep Cherokee since the application of the the REFRESH AC Auto formula. Using a temperature gun at the vent opening I saw a 19 degree drop in temperature and it has continued to remain 19 degrees colder than before the treatment.”

REFRESH AC AUTO™ Customer Quotes

“I was absolutely shocked with the performance of the AC in my car after the treatment. Typically when you hear of things that sound too good to be true; they are. That is not the case with this product. I saw a 11 degree cooler temperature change immediately.” “Your product is amazing. I can't believe how cold it

• blows. I definitely

recommend.”

• Jimmy H
• Joe C
• Shane W.

REFRESH AC AUTO™ is a permanent solution

“One of the main advantages of the RESTORE 1030 and the REFRESH AC AUTO™ technology is the ability to provide a longer lasting protection than any other product on the market.” “…since the particles are imbedded in the surface of the tubing, they will remain there for the life of the tubing.”

• Dr. Peter Jenkins, PhD, PE

Professor – Mechanical Engineering University of Colorado

PhD - Purdue University IEM - Harvard University MS - Southern Methodist U MBA - Pepperdine University BS - University of Kansas U.S. Naval Academy

Research Interests: Thermal/fluid sciences, Energy conversion, Engines, Turbomachinery

The samples of the REFRESH AC Auto formula comply with the following acceptance criteria:

1. The presence of the additive or flushing agent shall not cause an increase or decrease in hardness when compared to those tested in the neat oil via rank order analysis*. 2. The presence of the additive or flushing agent shall not cause an increase in particles, precipitates, or insolubles in the sealed tubes when compared to those tested in the neat oil via rank order analysis*.

3.

The presence of the additive or flushing agent shall not cause an increase or decrease in volume when compared to those tested in the neat oil via rank order analysis*.

Rank order analysis is defined as ordering both the three control groups’ and the three samples’ numeric results. A test failure is defined as a total separation of the numeric results of the sample and control groups where the sample’s results negatively affected the desirable properties of the flushing agent or process fluid. A pass test is defined as having overlapping sets of numeric results of the sample and control groups, or a total separation of the numeric results of the sample and the control groups where the samples’ results positively affected the desirable properties of the flushing agent or process fluid.

TESTING Done to ASHRAE Standards REPORT 3172187COL-00 March 18th, 2009 INTERTEK-ETL SEMKO Division

REFRESH AC AUTO™ is compatible with and does not harm AC Systems

RAISE Energy Solutions is an incubator, manufacturer, and integrator of intelligent LED lighting, innovative energy efficiency products, renewable power generation, and energy storage and distribution technologies. Our holistic approach to energy efficiency begins with energy conservation and includes generation, storage, and distribution. Visit www.RaiseEnergySolutions.com to learn more. 1059 Triad Court, Suite 1, Marietta, Georgia 30062 | USA 678.331.5548 | info@raiseenergysolutions.com
